headlamp FORD E SERIES 1997 4.G Owners Manual

OVERDRIVE
ON
OFFRES
SET
ACCEL
COAST
Engine coolant
temperature gauge
(pg. 12)
Fuel Gauge
(pg. 12)Speedometer
(pg. 12)Engine oil
pressure gauge
(pg. 13)
Battery
voltage
gauge
(pg. 13)
Warning
lights
(pg. 8)
Speed controls
(pg. 28)
Headlamp switch
and dimmer
(pg. 15)Transmission
control switch
(pg. 24)
Wiper/washer
control
(pg. 27)
Instrumentation
6

flash or remains on, have the
system serviced immediately.
Turn signal
Illuminates when the left or right
turn signal or the hazard lights are
turned on.
High beams
Illuminates when the headlamp
high beams are on.
Door ajar (if equipped)
Illuminates when the ignition
switch is in the ON or START
position and any door is open.
Oil pressure/Engine coolant
This light will come on when the
key is in the ON position and the:
²engine coolant temperature is
very high
²engine oil pressure is low
The light serves as a notice that a
system needs your attention and to
check the engine coolant
temperature gauge and the engine
oil pressure gauge.
Refer to engine coolant
temperature gauge and engine oil
pressure gauge in this section for
more information.
DOOR
AJAR
com_turn_signal.01
com_high_beams.01
eco_door_ajar
eco_oil-press_eng-temp_light
eco_warning_chimes
Instrumentation
10

WARNING CHIMES
Safety belt warning chime
For information on the safety belt
warning chime, refer to the
Seating and safety restraints
chapter.
Supplemental restraint system
(SRS) warning chime
For information on the SRS
warning chime, refer to the
Seating and safety restraints
chapter.
Key-in-ignition warning
chime/buzzer
Sounds when the key is left in the
ignition and the driver's door is
opened.
Headlamps on warning chime (if
equipped)
Sounds when the headlamps are
on, the ignition is off and the
driver's door is opened.
GAUGES
0 1020304050
60
70
80
90
10 0
20 km/h
406080
10 0
12 0
14 0
H
L
16 0
MPH
000000
0000
NORMAL
18
8NORMALFH
C
E
NORMAL
com_safety_chime.01
com_srs_chime.01
eco_key_chime
eco_headlamps_chime
eco_gauges
com_speedometer.01
Instrumentation
11

INSTRUMENT PANEL
CONTROLS
Headlamp control
1. Pull the headlamp control
toward you to the first position.
Parking lamps, tail lamps, license
plate lamps and marker lamps are
now on.eco_panel_controls
eco_headlight_switch_operation
Controls and features
15

2. Pull the headlamp control
toward you to the outer position.
Headlamps are now on in addition
to above.
3. Rotate the control when it is in
the on position to brighten or dim
the instrument panel lamps. Rotate
fully counterclockwise to operate
courtesy and cargo lamps.
Daytime running light (DRL)
system (if equipped)
The DRL system turns on the high
beam headlamps, with a reduced
light output, when:
²the vehicle is running (ignition
switch is in the ON position)
²the vehicle has a fully released
parking brake
eco_headlight_daytime_running
Controls and features
16

²the headlamp system is in the
OFF or park lamp position
Audio System
For information on the audio
system, refer to theAudio Guide.
Power point electrical outlet
The power point is a power source
for the operation of electrical
accessories.
Do not use the cigarette lighter in
place of the power point.
CLIMATE CONTROLS
Your vehicle has one of the
following climate control systems:
²Manual heating system
²Manual heating and air
conditioning system
In addition your vehicle may also
be equipped with a auxiliary heater
and air conditioning system.
In some modes, the systems
function similarly; in modes where
the systems do not functioneco_audio_system
eco_power_point eco_climate_controls
Controls and features
17

To disengage speed control
²Depress the brake pedal.
Disengaging the speed control will
not erase the previously
programmed set speed.
To return to a set speed
²Press RES. For RES to operate,
the vehicle speed must be faster
than 48 km/h (30 mph).
OVERHEAD CONTROLS
Cargo and dome lamps
Rear cargo lamps equipped with an
ON/OFF/DOOR control will light
when:
²the doors are closed and the
switch is in the ON position
²either front door is open and
the switch is in the DOOR
position
²the headlamp control is rotated
fully counterclockwise
When the cargo lamp switch is in
the OFF position, it will not
illuminate when you open the
doors or turn the headlamp
control.
ON
OFFRES
SET
ACCEL
COAST
ONDOOROFF
com_resume_feature.01
eco_overhead_control
eco_cargo-dome_lamps
eco_courtesy-reading_lamps
Controls and features
30

Courtesy/reading lamps
The courtesy/reading lamps will
illuminate when:
²the lens is in the flat position
and any door is open
²the lens is in the flat position
and the headlamp control is
rotated fully counterclockwise
²the lens is in the rotated
position.
DOOR MOUNTED CONTROLS
Power outside mirrors (if
equipped)
To adjust the outside mirrors:
1. Select the mirror you want to
adjust:
Driver side mirror
Passenger side mirror
2. Move the mirror control in the
desired direction.
3. Lock the mirror by moving the
control to the center
position.
eco_door_controls
eco_power_mirror
eco_power_door_locks
Controls and features
31

theSeating and safety restraints
chapter.
2. Make sure the headlamps and
vehicle accessories are off.
Starting
75

Number Fuse amperage
ratingCircuits protected
1 20 amp 4WABS or RABS
module
2 15 amp 4WABS relay (coil),
RABS (diode/resistor),
instrument cluster,
warning chime
3 15 amp Headlamp switch,
radio sense, rear
radio control, Remote
keyless entry module
4 15 amp Power mirrors,
modified vehicle,
power locks w/RKE,
Headlamp switch
(dome), illuminated
entry, Courtesy lamp
switches, Radio
(KAP), Cluster (KAP),
warning chime
5 20 amp Remote keyless entry
module, power door
lock switches,
memory lock
6 10 amp Brake shift interlock,
speed control,
daytime running light
module
7 10 amp Multi-function switch
Roadside emergencies
105
