Using the mix mode
The MIX mode directs outside air
to flow through the floor vents and
windshield defroster vents. The air
conditioning will function to
dehumidify the windows provided
the outside temperature is above
10ÉC (50ÉF).
Select the MIX mode for air to flow
through these vents:
Using themode
In addition to defogging and
demisting, in defrost mode your
vehicle has the capability to demist
the front side windows. The air
conditioning will function to
dehumidify the windows provided
the outside temperature is above
10ÉC (50ÉF).
Select the
mode for air to flow
through these vents:
AUXILIARY HEATER AND AIR
CONDITIONER (IF EQUIPPED)
If your vehicle is equipped with a
factory installed auxiliary unit, the
front control panel will include
eco_climate_def_air
eco_climate_control_auxiliary
Controls and features
21

Power door locks (if equipped)
Push to lock or unlock the doors.
LAll doors locked
UAll doors unlocked
²Driver side
²Passenger side
UL
U L
eco_power_windows
Controls and features
32

Power Windows (if equipped)
Driver side controls
Press the appropriate window
switch to operate the power
windows.
²Driver window
²Front passenger windowUL
UL
UL
eco_power_windows_driver
eco_power_windows_passenger
Controls and features
33

Passenger side controls
Press the window switch to
operate the power window.
REMOTE ENTRY SYSTEM (IF
EQUIPPED)
The remote entry system allows
you to lock or unlock all vehicle
doors without a key.
Unlocking the doors
Press UNLOCK to unlock the
driver door. The interior lamps will
illuminate.
Press UNLOCK a second time
within five seconds to unlock all
doors.
Locking the doors
Press LOCK to lock all doors.
To confirm all doors are closed and
locked, press the LOCK button a
second time within five seconds.
The doors will lock again, the horn
will chirp and the lamps will flash.U L
LOCK
PANICUN
LOCK
PANICUN
LOCKLOCK
com_remote_entry.01
com_remote_unlocking.01
eco_remote_locking
com_remote_panic.01
Controls and features
34

²the sound of the exhaust system
changes
²the vehicle has been damaged in
a collision
Important ventilating
information
If the engine is idling while the
vehicle is stopped in a closed area
for long periods of time, open the
windows at least 2.5 cm (1 in).
Adjust the heating or air
conditioning (if equipped) to bring
in fresh air.
Improve vehicle ventilation by
keeping all air inlet vents clear of
snow, leaves and other debris.
MAX
A C/
VENT
NORM
A C
/
OFF
FLR
MIX
eco_ventilation_info
Starting
79

Number Fuse amperage
ratingCircuits protected
21 30 amp Power windows
22 - Not used
23 20 amp Cigar lighter, data link
connector
24 5 amp Illuminated entry
25 10 amp Left headlamp (low
beam)
26 - Not used
27 - Not used
28 25 amp Instrument panel
power point
29 - Not used
30 15 amp Headlamps (high
beam), Daytime
running lamps (DRL),
high beam indicator
31 10 amp Right headlamp (low
beam), Daytime
running lamps (DRL)
32 - Not used
33 - Not used
34 10 amp Digital transmission
range sensor (start
control)
35 - Not used
36 5 amp Panel illumination
37 - Not used
38 10 amp Air bag module
39 - Not used
40 30 amp Modified vehicle
41 30 amp Modified vehicle
42 - Not used
