FORD E SERIES 1998 4.G Owners Manual

Fluid Ford Part
NameApplication Capacity
Transmission
3Motorcraft
MERCONtV
AT FAutomatic
(4R70W)13.1L
(13.9 quarts)
Motorcraft
MERCONt
AT FAutomatic
(E4OD)15.0L
(15.9 quarts)
Windshield
washer fluidUltra-Clear
Windshield
Washer
ConcentrateAll Fill to line on
reservoir
If your vehicle's rear axle is filled with a synthetic rear axle lubricant it is
considered lubricated for life. These lubricants do not need to be
checked or changed unless a leak is suspected, service is required or the
axle assembly has been submerged in water. The axle lubricant should
be changed any time the rear axle has been submerged in water.
1Fill 6 mm to 14 mm (1/4 inch to 9/16 inch) below bottom of fill hole.
Add 118 ml (4 oz.) of additive friction modifier C8AZ-19B546-A, Ford
specification EST-M2C118±A, for complete refill of 8.8 inch and 9.75 inch
Traction-Lok axles.
2Fill Dana rear axles to 6 mm to 19 mm (1/4 inch to 3/4 inch) below
bottom of fill hole.
3Always use dipstick to determine exact fluid requirement.
4Ford conventional and Traction-Lok axles, Dana 80 axle (E-Super
Duty) and Dana axles on E-350 vans/wagons with 4.10:1 ratio require
Motorcraft SAE 75W140 Synthetic Rear Axle Lubricant (part number
F1TZ-19580±B). Add 118 ml (4 oz.) of friction modifier C8AZ-19B546-A,
Ford specification EST-M2C118±A. Dana conventional and limited-slip
axles require Motorcraft SAE 80W90 Premium Rear Axle Lubricant. Add
177ml (6 oz.) of additive friction modifier C8AZ-19B546-A, Ford
specification EST-M2C118±A.
Capacities and specifications
131

LUBRICANT SPECIFICATIONS
Item Ford part name Ford part
numberFord
specification
Brake fluid High Performance
DOT 3 Motor Vehicle
Brake FluidC6AZ-
19542-ABESA-
M6C25-A and
DOT 3
Door
weatherstripsSilicone Lubricant C0AZ-19553-AA
and
D7AZ-19553-AAESR-M13P4-A
Engine
coolantFord Premium
Cooling System FluidEFZ-19549-AA ESE-M97B44-A
Engine oil
(gasoline)Motorcraft 5W-30
Super Premium
Motor OilXO-
5W30-QSPWSS-M2C153-G
with API
Certification
Mark
Engine oil
(diesel)Consult separate diesel engine owner's guide
supplement
Hinges,
latches,
Striker plates,
fuel filler door
hinge, and
seat tracksMulti-Purpose
GreaseD0AZ-
19584-AA or
F5AZ-
19G209-AAESB-
M1C93-B or
ESR-
M1C159-A
Lock cylinders Penetrating
LubricantE8AZ-
19501-Bnone
Power
steering fluidMotorcraft
MERCONtAT FXT-2-QDX MERCONt
Automatic
transmission
(E4OD)Motorcraft
MERCONtAT FXT-2-QDX MERCONt
Automatic
tranmission
(4R70W)Motorcraft
MERCONtVATFXT-5-QM MERCONtV
Disc brake
caliper railsSilicone Brake
Caliper and
Dielectric compoundD7AZ-19A331-A
WA-10ESE-M1C171-A
Capacities and specifications
132

Item Ford part name Ford part
numberFord
specification
Parking brake
assembly
(E-Super
Duty)Motorcraft
MERCONt
Automatic
Transmission FluidXT-2-QDX MERCONt
Ford
conventional
and
Traction-Lok
axles
1
Motorcraft SAE
75W140 High
Performance
Synthetic rear axle
lubricantF1TZ-19580-B WSL-M2C192-A
Dana
conventional
and
Traction-Lok
axles
2
Motorcraft SAE
80W90 Premium rear
axle lubricantXY-80W90-QL WSP-M2C197-A
Dana 80 Axle
(E-Super
Duty)Motorcraft SAE
75W140 High
Performance
Synthetic rear axle
lubricantF1TZ-19580-B WSL-M2C192-A
Dana Axle
(E-350
van/wagon
w/4.10 ratio)Motorcraft SAE
75W140 High
Performance
Synthetic rear axle
lubricantF1TZ-19580-B WSL-M2C192-A
Windshield
washer fluidUltra-Clear
Windshield Washer
ConcentrateC9AZ-19550-AB ESR-M17P5-A
1Add 118 ml (4 oz.) of EST-M2C118±A (friction modifier Part No.
C8AZ-19B546±A) for complete refill of Ford Traction-Lok rear axles.
2Add 237 ml (6 oz.) of EST-M2C118±A (friction modifier Part No.
C8AZ-19B546±A) for complete refill of Dana Traction-Lok rear axles.
Capacities and specifications
133

ENGINE DATA
Engine 4.2L V6 engine
Cubic inches 256
Horsepower 200 @ 4800 rpm
Torque 250 lbs.ft. @ 2800 rpm
Required fuel grade 87 octane
Firing order 1-4-2-5-3-6
Spark plug gap 1.3-1.4 mm (0.052-.056 inch
Ignition system EDIS
Compression ratio 9.0:1
Engine 4.6L V8 engine
Cubic inches 281
Horsepower 215 @ 4450 rpm
Torque 290 lbs.ft. @ 3250 rpm
Required fuel grade 87 octane
Firing order 1-3-7-2-6-5-4-8
Spark plug gap 1.3-1.4 mm (0.052-.056 inch
Ignition system EDIS
Compression ratio 9.0:1
Engine 5.4L V8 engine
Cubic inches 330
Horsepower 235 @ 4450 rpm
Torque 335 lbs.ft. @ 3000 rpm
Required fuel grade 87 octane
Firing order 1-3-7-2-6-5-4-8
Spark plug gap 1.3-1.4 mm (0.052-.056 inch
Ignition system EDIS
Compression ratio 9.0:1
Capacities and specifications
134

Engine 6.8L V10 engine
Cubic inches 415
Horsepower 265 @ 4250 rpm
Torque 405 lbs.ft. @ 2750 rpm
Required fuel grade 87 octane
Firing order 1-6-5-10-2-7-3-8-4-9
Spark plug gap 1.3-1.4 mm (0.052-.056 inch
Ignition system EDIS
Compression ratio 9.0:1
VEHICLE DIMENSIONS
Van/wagon models
E-150 E-250 E-350
(1) Overall height 2 054.8 mm (80.9
in)2 118.4 mm
(83.4)2 136.1
(84.1 in)
(2) Track front/rear 1 762.8 mm (69.4 in)/ 1 701.8 mm (67.0 in)
(3) Overall width
(excluding mirrors)2 014.2 mm (79.3 in)
(4) Wheelbase 3 505 mm (138 in)
(5) Overall length Regular van, 5 379.7 mm (211.8 in) Supervan, 5
892.8 mm (232.0 in)
Capacities and specifications
135

3
2
1
4
5
Capacities and specifications
136

Cutaway/commercial stripped chassis models
E-250 E-350 E-Super Duty
(1) Overall
heightRefer to Body Builder for specifications
(2) Track
front/rear1 762.8 mm
(69.4 in)
1 701.8 mm
(67.0 in)1 762.8 mm
(69.4 in.)/SRW 1
701.8 mm (67.0 in.),
DRW 1 859.3 mm
(73.2 in.)1 762.8 mm
(69.4 in.)/1
973.6 mm
(77.7 in.)
(3) Overall
width
(excluding
mirrors)Refer to Body Builder for specifications.
(4) Wheelbase 3 149.6 mm
(124 in)3 505 mm
(138 in.)
4 013 mm
(158 in.)
4 470 mm
(176 in.)4 013 mm
(158 in.)
4 470 mm
(176 in.)
(5) Overall
lengthRefer to Body Builder for specifications.
VEHICLE IDENTIFICATION NUMBER
Complete Ford built vehicles
The vehicle identification number is attached to your vehicle in the
following places:
²On the metal tag attached to the top of the instrument panel on the
driver's side.
Capacities and specifications
137

²On the safety compliance
certification label. This label is
required by the National Highway
Traffic Safety Administration and
is made of special material. If it is
tampered with, it will be
destroyed or a destruction
pattern will appear.
Incomplete vehicles
On completed derivations of incomplete vehicles, the safety compliance
certification label is affixed at a location determined by a subsequent
stage manufacturer of the completed vehicle. In these cases the
completed vehicle is manufactured in two or more stages by two or more
separate manufacturers.
Capacities and specifications
138

REPORTING SAFETY DEFECTS (U.S. ONLY)
If you believe that your vehicle has
a defect that could cause a crash, or
could cause injury or death, you
should immediately inform the
National Highway Traffic Safety
Administration (NHTSA) in addition
to notifying Ford Motor Company.
If NHTSA receives similar complaints, it may open an investigation, and
if it finds that a safety defect exists in a group of vehicles, it may order a
recall and remedy campaign. However, NHTSA cannot become involved
in individual problems between you, your dealer or Ford Motor Company.
To contact NHTSA, you may either call the Auto Safety Hotline toll-free
at 1±800±424±9393 (202±366±0123 in the Washington D.C. area) or write
to:
NHTSA
U.S. Department of Transportation
400 Seventh Street
Washington D.C. 20590
You can also obtain other information about motor vehicle safety from
the Hotline.
Reporting safety defects
139

Aiming headlamps ....................125
Air bag supplemental
restraint system ..........................46
and child safety seats ..............47
description ................................46
disposal ......................................49
indicator light ...........................48
passenger air bag .....................47
Air conditioning
manual heating and air
conditioning system .......16,17,18
Anti-lock brake system (ABS)
description ................................64
Battery .......................................108
voltage gauge ............................12
Brake fluid
checking and adding ..............100
Brakes ..........................................63
anti-lock .....................................63
anti-lock brake system (ABS)
warning light .............................63
fluid, checking and adding ....100
Brake-shift interlock ...................65
Break-in period .............................2
Bulbs, replacing ........................122
headlamps ...............................123
specifications ..........................125
Changing a tire ...........................85
Child safety seats ........................51
Chime
headlamps on ..............................9
Cleaning your vehicle ...............125
engine compartment ..............127
fabric ........................................128
instrument panel ....................128
plastic parts ............................127
safety belts ..............................128
tail lamps .................................128
washing ....................................126
waxing .....................................126
wheels ......................................126
windows ..................................128Controls .......................................20
Emission control system ..........121
Engine ........................................134
check engine temperature
warning, message center .........96
service points ............................96
Engine block heater ...................61
Engine coolant
checking and adding .......101,102
disposal ....................................103
refill capacities ........................103
Engine oil ...............................97,99
changing oil and oil filter .........99
checking and adding ...........97,99
Exhaust fumes ............................62
Fail safe cooling ........................103
Fuel
calculating fuel economy .......120
improving fuel economy ..........76
octane rating ...........................119
quality ......................................120
running out of fuel .................120
safety information relating
to automotive fuels ................118
Fuel gauge ...................................10
Fuel pump shut-off switch .........77
Fuse panels
instrument panel ......................79
power distribution box .............82
Fuses ............................................79
Gauges, Mechanical ....................10
engine coolant temperature
gauge .........................................11
Hazard flashers ...........................77
Headlamps ...................................13
daytime running lights .............13
flashing ......................................14
high beam .................................13
Heating ........................................14
High beams
indicator light .............................9
Index
140
