windshield wipers FORD E SERIES 2002 4.G Owners Manual

WINDSHIELD WIPER/WASHER CONTROLS
Rotate the windshield wiper control
to the desired interval, low or high
speed position.
The bars of varying length are for
intermittent wipers. When in this
position rotate the control upward
for fast intervals and downward for
slow intervals.
Push the control on the end of the
stalk to activate washer. Push and
hold for a longer wash cycle. The
washer will automatically shut off
after ten seconds of continuous use.
Windshield wiper blades
Check the wiper blades at least twice a year or when they seem less
effective. Substances such as tree sap and some hot wax treatments used
by commercial car washes reduce the effectiveness of wiper blades.
Checking the wiper blades
If the wiper blades do not wipe properly, clean both the windshield and
wiper blades using undiluted windshield wiper solution or a mild
detergent. Rinse thoroughly with clean water. To avoid damaging the
blades, do not use fuel, kerosene, paint thinner or other solvents.
Driver controls
94

snow tires and chains ............252
tire grades ...............................249
treadwear ................................249
Towing .......................................163
recreational towing .................172
trailer towing ..........................163
wrecker ....................................196
Traction-lok rear axle ...............155
Transmission .............................156
fluid, checking and adding
(automatic) .............................245
fluid, refill capacities ..............254
lubricant specifications ..258, 260
Transmission control indicator
light ..............................................15
Trip odometer .............................19
Trunk .........................................106
Turn signal ............................15, 86V
Vehicle dimensions ...................261
Vehicle Identification Number
(VIN) ..........................................263
Vehicle loading ..........................160
Ventilating your vehicle ...........152
W
Warning chimes .....................15±16
Warning lights (see Lights) .......12
Washer fluid ..............................217
Water, Driving through .............160
Windows
power .........................................96
Windshield washer fluid and
wipers
checking and adding fluid .....217
checking and cleaning ..............94
operation ...................................94
replacing wiper blades .............95
Wrecker towing .........................196
Index
272
