Preparing to Change the Tire
*
[RE07650(ALL)02/92]
1. Make sure that your vehicle will not move
or roll. If you have an automatic transaxle,
put the gearshift in P (Park). If you have a
manual transaxle, put the gearshift in 1
(First). Set the parking brake and block the
wheel that is diagonally opposite the tire
that you are changing.
*
[RE08590(ALL)08/95]
When one of the front wheels is off the ground,
the transaxle alone will not prevent the vehicle
from moving or slipping off the jack, even if the
vehicle is in P (Automatic) or 1 (Manual). To
prevent the vehicle from moving when you
change one of the front tires, put a block behind
the wheel that is diagonally opposite the tire.
*
[RE08600(ALL)05/95]
RWARNING
If the vehicle slips off the jack, you or
someone else could be seriously injured.
*
[RE08800(ALL)03/95]
2. Get out the spare tire and jack.
[RE08850(ALL)08/93]
3. Remove any optional wheel covers or center
caps covering the lug nuts by gently prying
with the tapered end of the lug wrench.
[RE08870(ALL)09/89]
4. Loosen the wheel lug nuts one-half turn
each, but do not remove them until the tire
is raised off the ground. You should pull up
on the handle rather than push to develop
maximum force to loosen wheel lug nuts.
%*
[RE08875(ALL)05/95]
Removing and Replacing the Tire
[RE08880(ALL)03/95]
1. Place the scissors-type jack under the side of
the vehicle and adjust the jack height with
the jack handle. The jack should fit under
the side sill. There are small notches in the
seam to indicate the proper position for the
jack.
File:12ctree.ex
Update:Tue Sep 19 14:55:16 1995

252
*
[RE09800(ALL)05/95]
RWARNING
To lessen the risk of personal injury, do
not put any part of your body under the
vehicle while changing a tire. Do not start
the engine when your vehicle is on the
jack. The jack is only meant for changing
the tire.
[RE09825(ALL)08/95]
two third page art:0070180-D
The location for the jack (left rear trim panel shown)
[RE09850(ALL)03/95]
2. Insert the jack handle into the jack and turn
it clockwise until the tire just clears the
ground. Remove the wheel lug nuts.
File:12ctree.ex
Update:Tue Sep 19 14:55:16 1995

253
*
[RE10390(ALL)08/95]
Your vehicle has metric (12 mm) wheel studs
and lug nuts. During wheel removal and
replacement, make certain that you use the same
lug nuts to reinstall the wheel or replace them
with nuts of the same metric size and threading.
*
[RE10400(ALL)08/95]
RWARNING
Installation of an English thread nut on a
metric stud (or vice-versa) will not
properly secure the wheel to the hub.
Damaged studs may result in wheel
separation and possible injury.
[RE12100(ALL)03/95]
3. Replace the flat tire with the spare tire.
(TEMP. USE ONLYlabel facing outward.)
*
[RE12200(ALL)03/95]
4. Reinstall the lug nuts, tightening until the
wheel is snug against the hub. The beveled
edges on the lug nuts face inward. Do not
fully tighten the lug nuts until you lower the
vehicle. If you do, you could force the
vehicle off the jack.
*
[RE12300(ALL)01/95]
5. Lower the vehicle by turning the jack handle
counterclockwise.
File:12ctree.ex
Update:Tue Sep 19 14:55:16 1995

254
*
[RE12400(ALL)06/95]
6. Remove the jack and fully tighten the lug
nuts in the order shown in the following
illustration.
[RE12550(ALL)12/91]
one third page art:0070009-B
The lug nuts on the wheel
[RE12575(E )06/95]
7. Replace any wheel covers, ornaments, or hub
caps that your vehicle has. Line up the notch
in the cover with the air valve on the tire
and press on with the heel of your hand.
(Some wheel covers have markings on the
inside to point to the appropriate air valve
notch.) Make sure that they are snapped into
place.
File:12ctree.ex
Update:Tue Sep 19 14:55:16 1995

255 [RE12600(E )08/93]
half page art:0070204-A
Replacing optional wheel covers
*
[RE12700(ALL)03/95]
8. Put the tire, jack, and wrench away. Make
sure the jack is securely fastened so it does
not rattle when you drive.
*
[RE12750(ALL)06/95]
9. Unblock the wheels.
%*
[RE13000(ALL)03/95]
Anti-Theft Wheel Lug Nuts (If equipped)
[RE13100(ALL)08/93]
If your vehicle has ªlockingº lug nuts, one of the
lug nuts on each wheel must be unlocked with a
special key. The key and registration card are
located in the tool bag with the lug wrench. If
you lose the key, send the registration card to
the manufacturer (not to the dealer) to get a
replacement key.
*
[RE13150(ALL)09/95]
NOTE: DO NOT USE A POWER IMPACT
WRENCH ON THE LUG NUT KEY.
File:12ctree.ex
Update:Tue Sep 19 14:55:16 1995

256 [RE13200(ALL)06/93]
quarter page art:0070177-AAnti-theft lug nut and key
*
[RE13300(ALL)03/95]
Removing the anti-theft lug nut
*
[RE13500(ALL)03/95]
Insert the key over the locking lug nut. Make
sure that you hold the key square to the lug nut.
If you hold the key on an angle, you may
damage the key and the lug nut.
*
[RE13600(ALL)03/95]
Place the lug nut wrench over the lug nut key
and apply pressure on the key with the wrench.
Turn the wrench in a counterclockwise direction
to remove the lug nut.
*
[RE13650(ALL)09/95]
Reinstalling the anti-theft lug nut
*
[RE13700(ALL)03/95]
Insert the key over the locking lug nut. Place the
lug nut wrench over the lug nut key and, while
applying pressure on the key, install the lug nut.
*
[RE15100(ALL)12/91]
If the Engine Cranks but Does
Not Start or Starting After a
Collision
*
[RE15150(ALL)07/95]
The Fuel Pump Shut-off Switch
*
[RE15200(ALL)07/95]
If the engine cranks but does not start or if you
have had a collision, the fuel pump shut-off
switch may have been triggered. The shut-off
switch is a device that stops the fuel pump
when your vehicle has been involved in a
substantial jolt.
*
[RE15250(ALL)07/95]
For information on how to check and reset the
fuel pump shut-off switch, seeFuel pump shut-off
switchin the Index.
File:12ctree.ex
Update:Tue Sep 19 14:55:16 1995

257
%*
[RE16400(ALL)05/95]
Towing Your Vehicle
[RE16500(ALL)08/95]
DO NOT TOW WITH SLINGBELT
EQUIPMENT. Ford Motor Company has not
developed or approved a T-hook or slingbelt
towing procedure. It is recommended that your
vehicle be towed with wheel lift or flatbed
equipment.
[RE16550(ALL)12/89]
two third page art:0000927-A
Towing your vehicle
File:12ctree.ex
Update:Tue Sep 19 14:55:16 1995

258 [RE16650(ALL)12/89]
quarter page art:0000928-ATowing your vehicle on a flatbed truck
File:12ctree.ex
Update:Tue Sep 19 14:55:16 1995

259
Customer Assistance
%*
[HS00205(ALL)06/94]
Roadside Assistance
*
[HS00210(ALL)08/95]
Ford Motor Company has set up a 24-hour,
seven-day-a-week hotline with trained operators
who put you in touch with the help you need if
you experience a problem with your vehicle.
This complimentary service is provided to you
throughout your warranty period of 3 years or
36,000 miles (60,000 km), whichever comes first.
To purchase Roadside Assistance coverages
beyond this period (available through Ford Auto
Club in the United States or Ford and
Lincoln-Mercury dealers in Canada), contact
your Ford or Lincoln-Mercury dealer.
*
[HS00215(ALL)06/94]
Roadside Assistance will cover the following:
*
[HS00220(ALL)06/94]
q
Mount your spare if you have a flat tire.
*
[HS00225(ALL)06/94]
q
Jump-start your battery if it is dead.
*
[HS00230(ALL)06/94]
q
Unlock your vehicle if you are locked out.
*
[HS00235(ALL)06/94]
q
Bring you fuel if you run out.
*
[HS00240(ALL)06/94]
q
Tow your vehicle if you are stranded. Even
non-warranty related tows, like accidents or
getting stuck in mud or snow, are covered
(some exclusions apply, such as impound
towing and repossession).
File:13cthse.ex
Update:Tue Sep 19 14:56:21 1995

260
*
[HS00245(ALL)06/94]
How to use Roadside Assistance
*
[HS00250(ALL)06/94]
Your Roadside Assistance identification card can
be found in the Owner Guide portfolio in your
glove compartment. Complete the card and place
it in your wallet for quick reference.
*
[HS00255(ALL)04/95]
To receive roadside assistance in the United
States call 1-800-241-FORD (in Canada call
1-800-665-2006).
*
[HS00260(ALL)04/95]
Should you need to arrange for roadside
assistance yourself, Ford Motor Company will
reimburse the reasonable cost. To obtain
information about reimbursement call
1-800-241-FORD (in Canada call 1-800-665-2006).
*
[HS00300(ALL)01/95]
If You Have a Service Problem
*
[HS00400(ALL)01/95]
Ford Motor Company has authorized Ford and
Lincoln-Mercury dealerships that can service
your vehicle for you. This chapter tells you how
to get service or maintenance for your vehicle.
%*
[HS00505(ALL)02/95]
Service/Maintenance Concerns
(U.S. or Canada)
*
[HS00600(ALL)04/95]
Ford recommends taking your vehicle to your
selling dealer who wants to ensure your
continued satisfaction. You may, however, take
your vehicle to any authorized Ford or
Lincoln-Mercury dealer. In most cases, your
dealer will be able to resolve your concern.
*
[HS00700(ALL)04/95]
If you are not satisfied with the service you
received from your dealership's service
department, talk to the service manager at the
dealership, or if you still are not satisfied, talk to
the owner or general manager of the dealership.
In most cases, you will have your concern
resolved at this level.
