FORD ESCORT 1996 7.G Workshop Manual

49 %
*
[SR12876(ALL)08/95]
Safety Belt Extension Assembly
[SR12878(ALL)08/95]
For some people, the safety belt may be too
short even when it is fully extended. You can
add about eight inches (20 cm) to the belt length
with a safety belt extension assembly. Safety belt
extensions are available from your dealer.
*
[SR12880(ALL)08/95]
Use only extensions manufactured by the same
supplier as the safety belt. Manufacturer
identification is located at the end of the
webbing on the label. Also, use the safety belt
extension only if the safety belt is too short for
you when fully extended. Do not use extension
to change the fit of the shoulder belt across the
torso.
*
[SR12882(ALL)08/95]
RWARNING
Failure to follow these instructions will
affect the performance of the safety belts
and increase the risk of personal injury.
%
*
[SR12884(ALL)08/95]
Safety Belt Maintenance
*
[SR12886(ALL)08/95]
Check the safety belt systems periodically to
make sure that they work properly and are not
damaged.
%*
[SR12888(ALL)08/95]
All safety belt assemblies, including retractors,
buckles, front seat belt buckle support assemblies
(slide bar) (if equipped), child safety seat tether
bracket assemblies (if equipped), and attaching
hardware, should be inspected after any
collision. Ford recommends that all safety belt
assemblies used in vehicles involved in a
collision be replaced. However, if the collision
was minor and a qualified technician finds that
the belts do not show damage and continue to
operate properly, they do not need to be
replaced. Safety belt assemblies not in use
during a collision should also be inspected and
replaced if either damage or improper operation
is noted.
File:03ctsre.ex
Update:Tue Sep 19 15:05:35 1995

50 %
*
[SR12889(ALL)06/95]
Cleaning the Safety Belts
*
[SR12901(ALL)06/95]
Clean the safety belts with any mild soap
solution that is recommended for cleaning
upholstery or carpets. Do not bleach or dye the
belt webbing because this may weaken it.
%
*
[SR12905(ALL)06/95]
Air Bag Supplemental Restraint
System (SRS)
[SR12910(ALL)02/94]
The driver and right front passenger air bag are
Supplemental Restraint Systems (SRS), provided
at these seating positions in addition to the
lap/shoulder belt and are designed to
supplement the protection provided to properly
belted occupants in moderate to severe frontal
collisions. The supplemental air bag system does
not provide restraint to the lower body.
%*
[SR12920(ALL)05/95]
The Importance of Wearing Safety Belts
*
[SR12925(ALL)06/95]
RWARNING
Safety belts must be worn by all vehicle
occupants to be properly restrained and
help reduce the risk of injury in a
collision.
*
[SR12927(ALL)05/95]
RWARNING
All occupants of the vehicle, including the
driver, should always wear their safety
belts, even when an air bag Supplemental
Restraint System is provided.
File:03ctsre.ex
Update:Tue Sep 19 15:05:35 1995

51
*
[SR12940(ALL)01/95]
There are four very important reasons to use
safety belts even with an air bag system. Use
your safety belts to:
*
[SR12950(ALL)01/95]
q
help keep you in the proper position (away
from the air bag) when it inflates
*
[SR12960(ALL)01/95]
q
reduce the risk of harm in rollover, side or
rear impact collisions, because an air bag is
not designed to inflate in such situations
*
[SR12970(ALL)01/95]
q
reduce the risk of harm in frontal collisions
that are not severe enough to activate the
supplemental air bag
*
[SR12980(ALL)01/95]
q
reduce the risk of being thrown from your
vehicle
%*
[SR12990(ALL)01/95]
The Importance of Being Properly Seated
*
[SR13000(ALL)05/95]
In a collision, the air bag must inflate extremely
fast to help provide additional protection for
you. In order to do this, the air bag must inflate
with considerable force. If you are not seated in
a normal riding position with your back against
the seatback, the air bag may not protect you
properly and could possibly hurt you as it
inflates.
*
[SR13002(ALL)08/95]
RWARNING
If a passenger is not properly seated and
restrained, an inflating air bag could cause
serious injury.
*
[SR13004(ALL)09/95]
RWARNING
Rear-facing infant seats should never be
placed in the front seat.
File:03ctsre.ex
Update:Tue Sep 19 15:05:35 1995

52
*
[SR13005(ALL)07/95]
In rear-facing infant seats, the infant's head is
closer to the air bag. The force of the rapidly
inflating air bag could push the top of the
rear-facing seat against the vehicle seatback or
center armrests (if so equipped), or center
console (if so equipped). REAR-FACING
INFANT CARRIERS MUST ALWAYS BE
SECURED IN THE REAR SEAT, and other child
safety seats and infant seats should be secured in
the rear seat whenever possible.
*
[SR13006(ALL)07/95]
Your vehicle is equipped with a right front
passenger air bag. Air bags deploy with great
force, faster than the blink of an eye. Front
passengers, especially children and small adults,
must never sit on the front edge of the seat,
stand near the glove compartment of the
instrument panel, or lean over near the air bag
cover when the vehicle is moving. All occupants
should sit with their backs against the seatback,
move the seat to the most rearward position if
possible and use the safety belts. Children
weighing less than 40 lbs. (18 kg) always should
use child or infant seats.
%*
[SR13007(ALL)07/95]
RWARNING
When using forward-facing child seats
move the passenger seat as far back from
the instrument panel as possible. NEVER
SECURE REAR-FACING INFANT SEATS
IN THE FRONT SEAT.
*
[SR13008(ALL)08/95]
The force of the rapidly inflating passenger air
bag could push the top of the rear-facing seat
against the vehicle seatback, armrests or console.
Rear-facing infant seats must always be secured
in the rear seat.
File:03ctsre.ex
Update:Tue Sep 19 15:05:35 1995

53
*
[SR13009(ALL)07/95]
RWARNING
Do not place objects or mount equipment
on or near the air bag cover on the
steering wheel or in front seat areas that
may come in contact with a deploying air
bag. Failure to follow this instruction may
increase the risk of personal injury in the
event of a collision.
%*
[SR13010(ALL)01/95]
How the Air Bag Supplemental Restraint
System Operates
*
[SR13020(ALL)09/95]
The Air Bag Supplemental Restraint System
consists of the Driver and Passenger air bags,
impact sensors, a system diagnostic module, a
readiness light and tone, and the electrical
wiring which connects the components. The
diagnostic module monitors its own internal
circuits and the supplemental air bag electrical
system readiness, including crash sensors, the
system wiring, the air bag readiness light, air
bag backup power, and the supplemental air bag
ignitors.
*
[SR13030(ALL)08/95]
The driver air bag is in the center of the steering
wheel. The front passenger seat air bag is
located in the center section of the instrument
panel ledge above the glove compartment. Both
air bags are designed to stay out of sight until
they are activated.
File:03ctsre.ex
Update:Tue Sep 19 15:05:35 1995

54 [SR13035(ALL)06/94]
half page art:0070212-BThe location of the air bag and warning labels
*
[SR13037(ALL)07/95]
If a collision occurs, the sensors sense the
severity of the impact and activate the air bags if
necessary. The air bag system is designed to
deploy in frontal and front-angled collisions
more severe than hitting a parked vehicle (of
similar size and weight) head-on at about
28 mph (45 km/h). Because the system senses
the crash severity rather than vehicle speed,
some frontal collisions at speeds above 28 mph
(45 km/h) will not inflate the air bag.
*
[SR13039(ALL)07/95]
When the sensors activate the system, the air
bags inflate rapidly, filling with non-toxic
nitrogen gas in a fraction of a second.
Immediately after inflation, the air bags deflate
by releasing the nitrogen gas through vent holes.
The whole process takes place in a matter of
seconds.
File:03ctsre.ex
Update:Tue Sep 19 15:05:35 1995

55
*
[SR13041(ALL)07/95]
RWARNING
Air bag system components get hot after
inflation. Do not touch them after
inflation.
[SR13043(ALL)09/95]
half page art:0011063-A
Inflated driver side air bag
File:03ctsre.ex
Update:Tue Sep 19 15:05:35 1995

56 [SR13045(ALL)09/95]
half page art:0011064-AInflated passenger side air bag
*
[SR13047(ALL)07/95]
RWARNING
If the air bag is inflated, THE AIR BAG
WILL NOT FUNCTION AGAIN AND
MUST BE REPLACED IMMEDIATELY. If
the air bag is not replaced, the unrepaired
area will increase the risk of injury in a
collision.
*
[SR13048(ALL)07/95]
To ensure that the air bag system will operate as
intended in a crash, the system is equipped with
a diagnostic module, which controls a readiness
lamp and a warning tone. The diagnostic
module monitors its own circuits, the air bag
electrical system, the air bag readiness light, the
air bag power, and the air bag inflators.
*
[SR13049(ALL)06/95]
The air bag system uses a readiness light on the
instrument cluster or a tone to indicate the
condition of the system. When you turn the
ignition to the ON position, this light will
File:03ctsre.ex
Update:Tue Sep 19 15:05:35 1995

57
illuminate for approximately six (6) seconds and
then turn off. This indicates that the system is
operating normally.NOTE:Maintenance of the
air bag system is not required.
%*
[SR13050(ALL)06/95]
A problem with the system is indicated by one
or more of the following:
*
[SR13055(ALL)06/95]
q
the readiness light will either flash or stay lit,
*
[SR13060(ALL)06/95]
q
or it will not light immediately after ignition
is turned on,
*
[SR13065(ALL)06/95]
q
or a group of five beeps will be heard. The
tone pattern will repeat periodically until the
problem and light are repaired.
*
[SR13090(ALL)08/95]
If any of these things happen, have the air bag
system serviced at your Ford or Lincoln-Mercury
dealer immediately. Unless serviced, the air bag
Supplemental Restraint System may not function
properly in the event of a collision.
*
[SR13120(ALL)07/95]
RWARNING
Do not attempt to service, repair, or
modify the Air Bag Supplemental
Restraint System or its fuses. See your
Ford or Lincoln-Mercury dealer.
%*
[SR13260(ALL)05/95]
Disposal of air bags or air bag equipped
vehicles
*
[SR13270(ALL)06/95]
For disposal of air bags or air bag equipped
vehicles, see your local Ford or Lincoln-Mercury
dealer. Air bagsMUSTbe disposed of by
qualified personnel.
[SR13273(ALL)08/95]
Service and information labels
[SR13275(ALL)08/95]
Service and information labels are attached to
the sun visor, on the headliner above the
driver's sun visor (Canadian vehicles), and near
the radiator support in the engine compartment.
File:03ctsre.ex
Update:Tue Sep 19 15:05:35 1995

58
%*
[SR14800(ALL)05/95]
Safety Restraints for Children
*
[SR14810(ALL)02/95]
In the U.S. and Canada, you are required by law
to use safety restraints for children. If small
children ride in your vehicle Ð this generally
includes children who are four years old or
younger and who weigh 40 pounds (18 kg) or
less Ð you must put them in safety seats that
are made specially for children. Safety belts
alone do not provide maximum protection for
these children. Check your local and state laws
for specific requirements.
*
[SR14820(ALL)08/95]
RWARNING
Never let a passenger hold a child on his
or her lap while the vehicle is moving.
The passenger cannot protect the child
from injury in a collision.
*
[SR14825(ALL)07/95]
RWARNING
To prevent the risk of injury, make sure
children sit where they can be properly
restrained.
*
[SR14830(ALL)09/95]
RWARNING
Do not allow people to ride in any area of
your vehicle that is not equipped with
seats and safety belts.
*
[SR14832(ALL)09/95]
RWARNING
Be sure everyone in your vehicle is in a
seat and using a safety belt properly.
File:03ctsre.ex
Update:Tue Sep 19 15:05:35 1995
