FORD ESCORT 1998 7.G Owners Manual

FluidFord Part
NameApplication Capacity
Engine oil
(includes filter
change)Motorcraft 5W30
Super Premium
Motor OilZX2 4.25L
(4.5 quarts)
Sedan/wagon 3.8L
(4.0 quarts)
Fuel tank
capacityN/A All 48.5L
(12.8 gallons)
Power steering
fluidMotorcraft
MERCONtAT FAll Fill to line in
reservoir
Transmission
fluid
Motorcraft
MERCONtAT FAutomatic
transaxles3.9L
(4.1 quarts)
Manual
transaxles3.35L
(3.55 quarts)
Windshield
washer fluidUltra-Clear
Windshield
Washer
ConcentrateAll 2.2L
(2.32 quarts)
LUBRICANT SPECIFICATIONS
FluidFord Part
Name or
EquivalentFord Part
NumberFord
Specification
Brake master
cylinderHigh
Performance
DOT 3 Motor
Vehicle Brake
FluidC6AZ-19542-AB ESA-M6C25-A
Door latch, hood
latch, auxiliary
hood latch,
trunk latchMulti-Purpose
GreaseDOAZ-19584-AA ESR-M1C159-A
and
ESA-M1C93-A
Capacities and specifications
181

FluidFord Part
Name or
EquivalentFord Part
NumberFord
Specification
Lock cylinder Penetrating
lubricantE8AZ-19A501-B N/A
Automatic
transmissionMotorcraft
MERCONtAT FXT-2-QDX MERCONt
Manual
transmissionMotorcraft
MERCONtAT FXT-2-QDX MERCONt
Engine oil Motorcraft 5W30
Super Premium
Motor OilXO-5W30-QSP WSS-M2C153-G
and API
Certification
Mark
Constant
velocity jointsCV Joint Grease
(High Temp.)E43Z-19590-A ESP-M1C207-A
Engine coolant Ford Premium
Cooling System
FluidE2FZ-19549-AA ESE-M97B44-A
Power steering
reservoirMotorcraft
MERCONtAT FXT-2-QDX MERCONt
ENGINE DATA
Engine 2.0L-2V engine 2.0L-4V Zetec engine
Cubic inches 121 121
Horsepower 110 @ 5000 rpm 130 @ 5750 rpm
Torque 125 lb. ft. @
3750 rpm127 lb-ft. @ 4250 rpm
Required fuel grade 87 octane 87 octane
Firing order 1-3-4-2 1-3-4-2
Spark plug gap 1.3-1.4 mm
(0.052-.056 inch)1.22-1.32 mm
(0.048-.052 inch)
Ignition system DIS DIS
Capacities and specifications
182

Engine 2.0L-2V engine 2.0L-4V Zetec engine
Compression ratio 9.2:1 9.6:1
VEHICLE DIMENSIONS
Vehicle
dimensionsCoupe mm (in) Sedan mm (in) Wagon mm
(in)
(1) Overall
length4 451.0 (175.2) 4 432.3 (174.5) 4 392.0 (172.9)
(2) Overall
width1 712.0 (67.4) 1 681.0 (66.2) 1 701.0 (67.0)
(3) Overall
height1 328.4 (52.3) 1 351.0 (53.2) 1 369.1 (53.9)
(4) Wheelbase 2 499.0 (98.4) 2 499.0 (98.4) 2 499.0 (98.4)
(5) Track -
Front1 435.1 (56.5) 1 435.1 (56.5) 1 435.1 (56.5)
(5) Track - Rear 1 435.1 (56.5) 1 435.1 (56.5) 1 435.1 (56.5)
²Coupe and Sedan models
2
55
Capacities and specifications
183

²Coupe model
²Sedan model
4
3
1
1
4
Capacities and specifications
184

²Wagon model
²Wagon model
5
2
1
4
Capacities and specifications
185

IDENTIFYING YOUR VEHICLE
Safety compliance label
The National Highway Traffic
Safety Administration Regulations
require that a Safety Compliance
Certification Label be affixed to a
vehicle and prescribe where the
Safety Compliance Certification
Label may be located. The Safety
Compliance Certification Label is
located on the front door latch
pillar on the driver's side.
Vehicle identification number
The vehicle identification number
is attached to a metal tag and is
located on the driver side
instrument panel.
Engine number
The engine number (the last eight
numbers of the vehicle
identification number) is stamped
on the engine block, transmission,
frame and transfer case (if so
equipped).
MFD. BY FORD MOTOR CO. IN U.S.A.
EXT PNT: XXXXXX XXXXXX RC: XX DSO: XXXX F0000
BAR INT TR TP/PS R AXLE TR SPR T0000
X XX XXX X XX X XXXX
UTC
ÑFOHT-15294A10-GA
MAXIMUM LOAD=OCCUPANTS + LUGGAGE=XXXKG/XXXXLB
OCCUPANTS: X TOTAL X FR X 2ND X RR OCCUPANTS LUGGAGE
XX XXXKG/XXXXLB
TIRE: XXXX/XXXXX XXX X XXXKG/XXXXLB
PRESSURE (FR) XXX kPa/33 PSI COLD
PRESSURE (RR) XXX kPa/33 PSI COLD
TRAILER TOWING - SEE OWNER GUIDE
DATE: XXXXX GVWR:XXXXX LB/ XXXXX KG
VIN: XXXXXXXXXXXXXXXXX TYPE: XXXXXXXXXXXXXXX FGAWR: XXXXXX/XXXXXXX RGAWR: XXXXXXX/XXXXXXX
THIS VEHICLE CONFORMS TO ALL APPLICABLE FEDERAL
MOTOR VEHICLE SAFETY STANDARDS IN EFFECT ON THE
DATE OF MANUFACTURE SHOWN ABOVE.
XXXXXXXXXXXXXXXXX
AIR BAG
Capacities and specifications
186

REPORTING SAFETY DEFECTS
(U.S. ONLY)
If you believe that your vehicle has
a defect that could cause a crash,
or could cause injury or death, you
should immediately inform the
National Highway Traffic Safety
Administration (NHTSA) in
addition to notifying Ford Motor
Company.
If NHTSA receives similar
complaints, it may open an
investigation, and if it finds that a
safety defect exists in a group of
vehicles, it may order a recall and
remedy campaign. However,
NHTSA cannot become involved in
individual problems between you,
your dealer or Ford Motor
Company.
To contact NHTSA, you may either
call the Auto Safety Hotline
toll-free at 1±800±424±9393
(202±366±0123 in the Washington
D.C. area) or write to:
NHTSA
U.S. Department of Transportation
400 Seventh Street
Washington D.C. 20590
You can also obtain other
information about motor vehicle
safety from the Hotline.
Reporting safety defects
187
