high beam FORD ESCORT 1999 6.G Owners Manual

Downloaded from www.Manualslib.com manuals search engine Shift indicator light (if equipped)
To maximize fuel economy, the shift
indicator light illuminates when the
manual transmission should be
shifted to the next highest gear.
Anti-lock brake system (ABS) (If equipped)
Momentarily illuminates when the
ignition is turned on and the engine
is off. If the light does not illuminate
momentarily at start up, remains on
or continues to flash, the ABS needs
to be serviced. With the ABS light on, the anti-lock brake system is
disabled and normal braking is still effective unless the brake warning
light also remains illuminated with parking brake released.
Turn signal
Illuminates when the left or right
turn signal or the hazard lights are
turned on. If one or both of the
indicators stay on continuously or
flash faster, check for a burned-out
turn signal bulb. Refer toExterior bulbsin theMaintenance and care
chapter.
High beams
Illuminates when the high beam
headlamps are turned on.
Anti-theft system (if equipped)
Refer toSecuriLockypassive
anti-theft systemin theControls
and featureschapter.
ABS
THEFT
Instrumentation
9

Downloaded from www.Manualslib.com manuals search engine Daytime running lamps (DRL) (if equipped)
Turns the headlamps on with a reduced output. To activate:
²the ignition must be in the ON position and
²the headlamp control is in the OFF or Parking lamps position.
Always remember to turn on your headlamps at dusk or during
inclement weather. The Daytime Running Light (DRL) System
does not activate your tail lamps and generally may not provide
adequate lighting during these conditions. Failure to activate your
headlamps under these conditions may result in a collision.
High beams
Push forward to activate.
Flash to pass
Pull toward you to activate and
release to deactivate.
TURN SIGNAL CONTROL
²Push down to activate the left
turn signal.
²Push up to activate the right turn
signal.
OFF
OFF
OFF
Controls and features
43

Downloaded from www.Manualslib.com manuals search engine INTERIOR BULBS
Dome lamp
1. Remove the lamp lens by applying
pressure to both tabs at the top of
the lamp and pulling lens
downward.
2. Pull out the burned-out bulb and
install a new one.
3. Install the lamp lens by applying
pressure to both sides of the lamp
lens and popping the lamp lens up
on the assembly.
Map lamps
For bulb replacement, see a qualified service technician or your dealer.
Using the right bulbs
Function Trade Number
Front park/turn lamps 3457 NAK
Foglamps (if equipped) 881
Headlamps-aero high and low beam 9007
Rear license plate lamps 168
High-mount brake lamp 921
Backup lamps 3156K
Brake lamps 3157K
Interior overhead lamp 12V/10W
To replace all instrument panel lights - see your dealer
OFF DOOR ON
Maintenance and care
167

Downloaded from www.Manualslib.com manuals search engine Headlamps ...................................42
aiming ...............................168,169
bulb specifications ..................167
daytime running lights .............43
flash to pass ..............................43
high beam ..............................9,43
replacing bulbs .......................162
turning on and off ....................42
warning chime ..........................10
Heating ........................................37
heater only system ...................37
heating and air
conditioning system .................39
Hood ..........................................127
Ignition ................................176,177
positions of the ignition ...........42
Infant seats
(see Safety seats) .......................77
Inspection/
maintenance (I/M) testing .......160
Instrument panel ..........................6
cleaning ...................................172
lighting up panel
and interior ...............................14
location of components ..............6
Jump-starting your vehicle ......117
Keys
key in ignition chime ...............10
positions of the ignition ...........42
Lamps
cargo lamps ...............................14
daytime running light ...............43
fog lamps ...................................44
headlamps ..........................42,162
headlamps, flash to pass ..........43
instrument panel, dimming .....14
interior lamps ....................51,167
replacing bulbs ..161,164,165,166
Lane change indicator
(see Turn signal) ........................43
Lights, warning and indicator ......6
air bag ..........................................8anti-lock brakes (ABS) .........9,89
anti-theft .....................................9
brake ............................................8
charging system ........................10
high beam ...................................9
liftgate ajar ................................10
low fuel ........................................7
oil pressure ...............................10
safety belt ...................................8
service engine soon ....................7
turn signal indicator ...................9
Load limits .................................100
GAWR ......................................100
GVWR ......................................100
trailer towing ..........................100
Locks
childproof ..................................52
Lubricant specifications ....175,176
Manual transaxle .........................92
fluid capacities ........................174
lubricant specifications ..........176
reverse .......................................95
Mirrors
side view mirrors (power) .......14
Moon roof ....................................50
Motorcraft parts .................156,174
Octane rating ............................155
Odometer .....................................13
Panic alarm feature, remote
entry system ................................57
Parking brake ..............................90
Parts (see Motorcraft parts) ....174
Power distribution box
(see Fuses) ...............................110
Power door locks ........................52
Power steering ............................91
fluid, checking and adding ....140
fluid, refill capacity ................174
fluid, specifications ..........175,176
Radio ............................................15
Relays .................................107,113
Remote entry system ............55,57
Index
196
