3. Remove the two screws and
carefully disengage parking
lamp/turn signal assembly from the
vehicle.
4. Rotate bulb socket
counterclockwise about
1¤4turn and
remove from lamp assembly.
5. Carefully pull bulb straight out of
the socket and push in the new
bulb.
6. Install the bulb socket in lamp
assembly by turning clockwise.
7. Align the lamp assembly on the
vehicle.
8. Install two screws on parking
lamp/turn signal assembly.
Maintenance and care
196

Replacing tail lamp/turn/backup lamp bulbs
The tail lamp/turn/backup lamp
bulbs are located in the same
portion of the tail lamp assembly,
one just below the other. Follow the
same steps to replace either bulb:
1. Remove the four screws and the
lamp assembly from vehicle.
2. Rotate bulb socket
counterclockwise about
1¤4turn and
remove from lamp assembly.
3. Carefully pull the bulb straight
out of the socket and push in the
new bulb.
4. Install the bulb socket in lamp
assembly by turning clockwise.
5. Install the lamp assembly and
secure with four screws.
Replacing high-mount brakelamp bulbs
To remove the brakelamp assembly:
1. Remove the two screws and lamp
assembly from vehicle.
2. Remove the bulb socket from
lamp assembly by rotating it 45
degrees.
3. Carefully pull bulb straight out of
socket and push in the new bulb.
Maintenance and care
197

To install the brakelamp assembly:
1. Install the bulb socket into the lamp assembly and rotate 45 degrees.
2. Install the lamp assembly on the vehicle and secure with two screws.
Replacing license plate lamp bulbs
The license plate bulbs are located
behind the rear bumper. To change
the license plate lamp bulbs:
1. Reach behind the rear bumper to
locate the bulb socket.
2. Twist the socket counterclockwise
and remove.
3. Pull out the old bulb from socket
and push in the new bulb.
4. Install the bulb socket in lamp
assembly by turning it clockwise.
Interior bulbs
Check the operation of the following interior bulbs frequently:
²dome lamps
²map lamps
²second row reading lamps
²third row reading lamp
For bulb replacement, see a qualified service technician or your dealer.
USING THE RIGHT BULBS
Replacement bulbs are specified in the chart below. Headlamp bulbs
must be marked with an authorized ªD.O.T.º for North America and an
ªEº for Europe to assure lamp performance, light brightness and pattern
and safe visibility. The correct bulbs will not damage the lamp assembly
or void the lamp assembly warranty and will provide quality bulb burn
time.
Maintenance and care
198

exterior ....................................201
exterior lamps .........................202
instrument cluster lens ..........202
instrument panel ....................202
interior .....................................203
plastic parts ............................201
safety belts ..............................203
washing ....................................200
waxing .....................................200
wheels ......................................201
wiper blades ............................202
Climate control (see Air
conditioning or Heating) ............22
Clock ............................................36
Compass, electronic ....................60
calibration .................................62
set zone adjustment .................61
Console ........................................64
overhead ..............................55±57
Controls
power seat .................................75
Coolant
checking and adding ..............165
refill capacities ................169, 204
specifications ..................207, 209
Cruise control
(see Speed control) ....................45
Customer Assistance ................136
Ford accessories for your
vehicle .....................................219
Ford Extended Service Plan...212
Getting assistance outside the
U.S. and Canada .....................218
Getting roadside assistance ...136
Getting the service you need..212
Ordering additional owner's
literature .................................223
The Dispute Settlement
Board .......................................215Utilizing the Mediation/
Arbitration Program ...............218
D
Daytime running lamps
(see Lamps) ................................18
Defrost
rear window ..............................26
Dipstick
automatic transmission fluid...172
engine oil .................................160
Doors
door ajar warning .....................13
lubricant specifications ..........207
Driving under special
conditions ..........................123±124
sand .........................................124
snow and ice ...........................125
through water .................124, 128
E
Emergencies, roadside
jump-starting ..........................151
Emission control system ..........192
Engine ........................................209
check engine/service engine
soon light ................................8±9
cleaning ...................................201
coolant .....................................165
diesel ...........................................3
fail-safe coolant ......................170
idle speed control ...................175
lubrication
specifications ..................207, 209
refill capacities ........................204
service points ..........................160
starting after a collision .........137
Index
226
