Cleaning and maintaining the
safety belts
Clean the safety belts with a mild
soap solution recommended for
cleaning upholstery or carpets. Do
not bleach or dye the belts,
because these actions may weaken
the belt webbing.
Check your safety belt system
periodically to ensure that it works
properly and isn't damaged. If the
webbing shows any signs of wear,
nicks or cuts, have it inspected by
a qualified technician to determine
if replacement is necessary. Always
have your safety belt system
checked after a collision by a
qualified technician.
All safety belt assemblies,
including retractors, buckles, front
seat belt buckle support assemblies
(slide bar if equipped), child safety
seat tether bracket assemblies (if
equipped) and attaching hardware
should be inspected after any
collision. Ford recommends that all
safety belt assemblies used in
vehicles involved in a collision be
replaced. However, if the collision
was minor and a qualified
technician finds that the belts do
not show damage and continue to
operate properly, they do not need
to be replaced. Safety belt
assemblies not in use during a
collision should be inspected and
replaced if either damage or
improper operation is noted.
Maintenance and care
212

MOTORCRAFT PART NUMBERS
Component 4.6 L engine 5.4 L engine
Air filter FA-1632 FA-1632
Battery
- standard
- optionalBXT-59
BXT-65-750BXT-59
BXT-65-750
Fuel filter FG-872 FG-872
Oil filter FL-820-S FL-820-S
PCV valve EV-98 EV-233
Spark plug* - platinum AWSF-32PP AWSF-22F
* Replacement double platinum spark plug9EE9will replace9E9and
9EG9and9P9will replace9P9and9PG9suffixed plugs. Refer to the
Engine datachart for spark plug gap specifications.
CAPACITIES
Your vehicle's fuel capacity
The fuel capacity of your vehicle is:
Vehicle Fuel capacity
4x2 (standard suspension) 98 L (26 gallons)
4x2 (with air suspension) 114 L (30 gallon)
4x4 (if equipped) 114 L (30 gallons)
²Always use high quality fuel
containing detergent and other
additives. Using inferior fuel
could result in engine damage.
²To avoid overspill from the filler
neck, stop fueling at the second
automatic shut off.
²For more information, refer to
Choosing the right fuelin the
Maintenance and carechapter.
exd_motorcraft_parts_numbers
exd_fuel_capacity
exd_refill_capacities
Capacities and specifications
213

Refill capacities
Capacities - liters (quarts) 4.6 L engine 5.4 L engine
Engine crankcase 5.7 L (6.0
quarts) with filter
change5.7 L (6.0
quarts) with filter
change
Transfer case 1.9L (2.0 quarts)
Automatic transmission 4R70W-13.1L (13.9 quarts)
E4OD (4 x 2) - 15.04L (15.9
quarts)
E4OD (4 x 4) - 15.51L (16.4
quarts)
Washer fluid reservoir 4.1 L ( 4.5 quarts)
4.6 L Engine coolant-2Row
radiator
-1 Row radiator17.9 L (19.9 quarts)
17.0 L (18.0 quarts)
5.4 L Engine coolant 19.7 L (20.8 quarts)
Engine oil 5.7 L (6.0 quarts)
Power steering fluid 2.3 L (2.4 quarts)
Capacites - pints
Axle (rear)
Ford 8.89/ 9.759Ring Gear
Conventional and Traction-Lok
1
5.5 pints
Axle (front) Ford 8.89Ring Gear 3.5 pints
1Add 4 oz. of additive friction
modifier C8AZ-19B546±A, Ford
specification EST-M2C118±A, for
complete fill of 8.8 inch and 9.75
inch ring gear Traction-Lok axles.
Service refill capacities are
determined by filling the rear axle
1/4 inch to 9/16 below the bottom
of the filler hole.
exd_specifications
Capacities and specifications
214

SPECIFICATIONS
Lubricant specifications
Item Ford part nameFord part
numberFord
specification
Windshield
washer fluid
reservoirFord Ultra-Clear
Windshield
Washer Fluid
ConcentrateC9AZ-19550-AA
OR -BAESR-M17P5-A
Body hinges,
latches, door
striker plates
and rotors, seat
tracks, fuel filler
door hinge and
spring, hood
latch, auxiliary
latchMulti-Purpose
GreaseD7AZ-19584-AA
OR
D0AZ-19584-AAESR-M1C159-A
AND
ESB-M1C93-B
Lock cylinders,
swing-away
spare tire carrier
padlockPenetrating
LubricantE8AZ-19A501-B ESB-M2C75-B
Parking brake
linkage pivots
and clevisesPremium Life
Long GreaseXG-1-C ESA-M1C75-B
Brake master
cylinderHigh
Performance
DOT 3 Brake
FluidC6AZ-19542-AA ESZ-M6C25-A
Brake pedal
pivot points and
clevisesEngine Oil
SAE-10W- WSS-M2C153-F
exd_lubricant_specifications
Capacities and specifications
215

Item Ford part nameFord part
numberFord
specification
Driveshaft, slip
sline, double
Carden joint
center ballPremium Long
Life GreaseXG-1-C ESA-M13P4-A
Door
weather-stripsSilicone
LubricantsCOAZ-19553-AA
AND
D7AZ-19553-AAESR-M13P4-A
Engine coolant Ford Premium
Cooling System
FluidE2FZ-19549-AA ESE-M97B44-A
Steering linkage Premium Long
Life GreaseXG-1-C ESA-M1C75-B
Engine oil Motorcraft Motor
Oil 5W30 Super
PremiumXO-5W30-QSP WSS-M2C153-F
with API
Certification
Mark
4x4 front wheel
bearings, 4x4
spindle needle
bearings,
spindle thrust
bearings & front
drive axle
u-joint/slip slineHigh
Temperature
4x4 Front Axle
& Wheel
Bearing GreaseE8TZ-19590-A ESA-M1C198-A
Automatic
transmissionMotorcraft
MERCONT
Automatic
Transmission
Fluidxt-2-qdx MERCONT
Power steering
reservoirPremium Power
Steering FluidE6AZ-19582-AA ESW-M2C33-F
Capacities and specifications
216

Item Ford part nameFord part
numberFord
specification
Speedometer,
parking brake
cableSpeedometer
Cable LubricantE6TZ-19581-A ESF-M1C160-A
Engine oil filter Motorcraft
Long Life
Oil Filter(FL-1A)
D9AZ
-6731-AES-E1ZE
-6714-AA
Disc brake
caliper railsDisc Brake
Caliper Slide
GreaseD7AZ-19590-A ESA-M1C172-A
Accelerator
throttle lever
and
transmission
kickdown lever
ball studsPremium Long
Life GreaseXG-1-C ESA-M1C175-B
Ford
conventional
and traction lock
rear axleMotorcraft High
Performance
Synthetic Rear
Axle LubeF1TZ-19580-B WSL-M2C192-A
Ford front axle Thermally
Stable
Motorcraft Front
Axle LubricantXY-75W90-QL WSP-M2C201-A
Transfer case -
Four wheel
driveMotorcraft
MERCONT
Automatic
Transmission
FluidXT-2-QDX MERCONT
Exhaust control
valveRust penetrant
and inhibitorF219A501-A ESR-M99C56-A
Capacities and specifications
217

ENGINE DATA
Component 4.6 L engine 5.4 L engine
Required fuel grade 87 octane
Induction system tuned runner & plenum
Firing order/ijection timing 1-3-7-2-6-5-4-8
Spark plug gap .054
Ignition system E.I. DIS coil on plug
VEHICLE DIMENSIONS
4
1
exd_engine_data
exd_dimensions_vehicle
Capacities and specifications
218

Dimensions mm(inches)
1 - Overall length 5197 mm (204.6 in)
2 - Overall width 2027 mm (79.8 in)
3 - Maximum height 1963 mm (77.3 in)
4 - Wheelbase 3023 mm (119.0 in)
5 - Front track 1661 mm (65.4 in)
IDENTIFYING YOUR VEHICLE
Vehicle identification tag
The vehicle identification tag is
located on the front panel of the
engine compartment. This tag
bears technical information on
your vehicle and identifies various
components.
55
2
3
exd_plate_identification
exd_vin_number
Capacities and specifications
219

Vehicle identification number
The vehicle identification number
(VIN) is attached to a metal tag
and is located on the front driver's
side of the instrument panel. The
VIN tag may be seen by looking
through the windshield from the
outside of the vehicle.
Engine number
The engine number is stamped on
the engine block.
UF0AXXGAGAJK07767
exd_engine_number
Capacities and specifications
220

REPORTING SAFETY DEFECTS
(U.S. ONLY)
If you believe that your vehicle has
a defect that could cause a crash,
or could cause injury or death, you
should immediately inform the
National Highway Traffic Safety
Administration (NHTSA) in
addition to Ford Motor Company.
If NHTSA receives similar
complaints, it may open an
investigation, and if it finds that a
safety defect exists in a group of
vehicles, it may order a recall and
remedy campaign. However,
NHTSA cannot become involved in
individual problems between you,
your dealer or Ford Motor
Company.
To contact NHTSA, you may either
call the Auto Safety Hotline
toll-free at 1±800±424±9393
(202±366±0123 in the Washington
D.C. area) or write to:
NHTSA
U.S. Department of Transportation
400 Seventh Street
Washington D.C. 20590
You can also obtain other
information about motor vehicle
safety from the Hotline.com_reporting_defects.01
