Slot number Fuse
amperage
ratingCircuits protected
13 30 amp Auxiliary blower
14 60 amp Four wheel anti-lock brake system
(4WABS)
15 50 amp Air suspension compressor
16 40 amp Trailer tow battery charge, engine
minifuse box fuse #2, engine minifuse
box fuse #4
17 30 amp Four-wheel drive (4WD) transfer case
motor and clutch
18 30 amp Driver power seat
19 20 amp Fuel pump
20 50 amp Junction box ignition switched feed
21 50 amp Junction box ignition switched feed
22 50 amp Junction box battery feed
23 40 amp Front blower
24 30 amp Powertrain control module power
25 30 C.B. Windows
26 - not used
27 40 amp Heated backlite and mirrors
28 30 amp Trailer tow electric brake
29 30 amp Hybrid fan, moon roof, flip windows
Slot number Description
1 - not used
2 - PCM diode
Slot number Description
1 - Windshield wipers high/low speed
2 - Windshield wipers run/park
3 - Front washer pump relay
4 - Fuel pump relay
Roadside emergencies
138
Junction box
Slot number Amperage Description
1 15 amp Stop/turn lamps
2 5 amp Instrument cluster, trip
computer
3 25 amp Cigar lighter
4 5 amp Autolamp module, head
lamp relay, remote entry
anti-theft with personality
module (RAP), power
mirrors
5 15 amp Air condition (A/C) clutch,
hybrid fan relay, backup
lamps, speed control,
DRL, instrument panel
blend door actuator,
electronic variable orifice
(EVO) steering module
1
1
2
3
4
512 22
21323
31424
4
16 15
25
526
61727
71828
81929
11 21 31930
10 20
exd_junction_box
Roadside emergencies
141
