Page 1 of 76
To Operate
How to Play a Video Cassette Tape
Your system audio defaults to wireless
headphones. To play the system audio over
your vehicle's speakers:
1. Slide the frequency switch from the OFF
position to position 1 (88.7 MHz) or
position 2 (89.1 MHz).
2. Turn the audio system ON and tune the
radio to 88.7 or 89.1 depending on where
you set the frequency switch in step 1.
3. Press the POWER control on the video
display unit.
4. Insert a VHS videocassette into the VCP,
and the video should start playing.
Do not force the tape into the VCP while the ignition is OFF.
To Play a Video Game
How to Use Auxiliary Inputs
Your system is capable of accepting other
auxiliary inputs such as video games or
camcorders. These may require a
12-volt DC to 120-volt AC power inverter.
²Remove the black plastic cover at the
back of the overhead video display unit.
²Connect the video line from your video
game device to the YELLOW jack on the
overhead video display unit.
²Connect the left and right audio cables
to the WHITE and RED jacks
respectively on the overhead video
display unit.
²Press the select switch on the video
display unit. The AV2 indicator will
illuminate.
²Turn on the game.
After Using your Rear Seat Entertainment system:
²To resume normal AM/FM radio operation, slide the frequency switch to the
off position. Rotate the flip-down screen up into the housing for storage when
not in use.
How To Get Going
REMOTE
SENSOR
CST INDEW
POWER
BRIGHTNESS VOLUMESENSORSELECT
FREQUENCY
OFF 1 2AV 1 AV 2
Page 6 of 76
CARE OF THE VIDEOCASSETTE PLAYER (VCP)
Environmental extremes
Videocassette players subjected to harsh environmental conditions may
be damaged or perform at less than maximum capability. To avoid these
outcomes, avoid leaving your video cassette player:
²in extremely hot or cold temperatures.
²in direct sunlight.
²in high humidity.
²in a dusty environment.
²in locations where strong magnetic fields are generated.
²on a surface that is instable or subject to vibrations.
Temperature extremes
When the vehicle is parked under direct sunlight or in an extremely cold
place for a long period of time, wait until the cabin temperature of the
vehicle is at normal temperature before operating the system.
Humidity and moisture condensation
Moisture in the air will condense in the VCP under extremely humid
conditions or when moving from a cold place to a warm one. Moisture
condensation on the tape playback head drum may damage the
videocassette and/or drum. If moisture condensation occurs, the dew
sensor LED on the VCP will blink. Do not insert a videocassette into the
player. If a videocassette is already in the player, remove it. Turn the
VCP power ON to dry the moisture before inserting a videocassette. This
could take an hour or more.
Introduction
4
Page 9 of 76
VCP PROTECTION CIRCUITS
Dew sensor circuit
²Under high moisture (dewed) conditions, the VCP will not operate.
²When the vehicle's cabin temperature is very low and then is heated
quickly, or the humidity is very high within the vehicle, the inside of
the windows most likely will be fogged. Under these conditions, the
inside of the VCP most likely is dewed.
²When a dewed condition exists, the dew sensor circuit stops machine
operation and the DEW indicator lamp on the VCP flashes. The lamp
will remain flashing until the system is dry enough to operate safely.
Description
7
Page 10 of 76
VIDEO CASSETTE PLAYER (VCP) CONTROLS
1.POWERbutton
Press to turn the VCP ON or OFF.
2.REMOTE CONTROL(Remote Sensor)
To operate the VCP with the remote control unit, aim the remote control
toward the pod control panel or the VCP.
3.INDICATOR LAMPS
Each lamp is ON when its related function is operating.
CST INThe cassette is in the player.
DEW(Red) Flashes when dew is present in the VCP
AUTO REPEATThe LED is on when the auto repeat function is
engaged.
4.PLAYbutton (Auto repeat)
Press to playback a videocassette tape.
If the auto repeat feature is included, press and hold for two seconds to
engage the auto repeat function. When the tape reaches the end, it will
rewind and play again. Other buttons will not operate in Auto Repeat
mode. To release the Auto Repeat mode, press the play button for two
seconds again.
REMOTE
SENSOR
CST INDEW
AUTO
REPEATPOWER
REW
FFPLAY STOP/
EJECT
23156473
Description
8
Page 12 of 76
VIDEO DISPLAY UNIT
The roof-mounted Video Display Unit is the most visible component of
your RSES. In essence, it is the ªnerve centerº of your system. In
addition to containing the flip-down LCD video screen, it contains many
of the system's main control buttons, important indicator lights, and
facilities to support both the wireless and optional wired headphones.
1.POWERbutton
Press this button to turn the RSES system On and Off alternately.
2.REMOTE CONTROL SENSOR
To operate the VCP with the remote control, aim it toward this location.
3.VOLUMEbuttons
Press (+) or (þ) button to decrease or increase audio volume through
thewiredheadphones.
Wired headphones are not supplied. Any headphones for portable
cassette and compact disc units can be used.
4.SELECTbutton
Press to select between AV1 and AV2.
POWER
BRIGHTNESS VOLUMESENSORSELECT
FREQUENCY
OFF 1 2AV 1 AV 2
54321
876
Description
10
Page 19 of 76
Inserting/removing cassette
Inserting cassette
Driver should never operate
any function of the VCP
mounted in the Floor Console
when the vehicle is moving. Give
full attention to driving and the
road. Pull off the road and park in
a safe place to insert or remove
video tapes from the VCP. A
remote control is included in the
system to allow rear seat
occupants to operate the VCP
functions without distracting the
driver.
²Open the RSES floor console cover, and slide a videocassette into the
cassette compartment.
Inserting a videocassette into the VCP automatically turns the power ON
(the RED power indicator lamp will illuminate) and the tape will begin
playback.
If the vehicle is traveling over rough terrain, it may be difficult to insert
the cassette because the machine attempts to hold the cassette firmly to
prevent vibration. If this condition is encountered, the passenger should
either press firmly or remove the cassette and insert it again. If a
cassette is inserted in the wrong position, the protection circuit will
automatically eject the cassette. If this occurs, the passenger should wait
a few seconds and insert the cassette again in the correct position.
²Once the cassette is completely inserted, close the console cover.
REMOTE
SENSOR
CST INDEWPOWER
REW
FFPLAY STOP/
EJECT
Operating Instructions
17
Page 20 of 76
Removing cassette
1. Open the console cover, and
press the STOP/EJECT button once.
2. Press the STOP/EJECT button
again. The tape will eject.
Playback operation
1. Press the power button on the pod.
2. Insert videocassette into the VCP.
3. Video should automatically begin playback.
²If video is not shown on the screen, press the SELECT button on the
RSES control panel to switch from AV2 to AV1 mode.
4. Tracking is automatically adjusted.
²If excessive video ªnoiseº (picture fluctuates up and down) occurs,
press the PLAY button on the remote control or on the VCP.
5. Press the STOP/EJECT button to discontinue playback. Press
STOP/EJECT again to remove the cassette.
REMOTE
SENSOR
CST INDEWPOWER
REW
FFPLAY STOP/
EJECT
Operating Instructions
18
Page 27 of 76
Fonctionnement
Lecture d'une vide ocassette
La fonction audio de votre systeÁ me est
re gle e par de faut pour diriger le son vers les
casques d'e coute sans fil. Pour diriger le son
vers les haut-parleurs du ve hicule :
1. Faites glisser le se lecteur de fre quence de
la position d'arrØt aÁ la position 1 (88,7
MHz) ou aÁ la position 2 (89,1 MHz).
2.
Allumez la chaÜne audio et syntonisez la radio
aÁ 88,7 MHz ou aÁ 89,1 MHz, selon la position du
se lecteur de fre quence choisie aÁ l'e tape 1.
3. Appuyez sur la touche marche/arrØt du
lecteur de vide ocassettes.
4.
Inse rez la vide ocassette (VHS) dans le lecteur et ce dernier se mettra en fonction.
Ne forcez pas la vide ocassette dans le lecteur lorsque le contact est coupeÂ.
Jeux videÂos
Branchement d'appareils vide o auxiliaires
Il est possible de brancher des appareils
auxiliaires sur votre systeÁ me tels que des
appareils de jeux vide o ou des camescopes.
Ceux-ci peuvent exiger l'utilisation d'un
ondulateur pour convertir le courant
continu de 12 volts du ve hicule en courant
alternatif de 120 volts.
²Retirez le couvercle de plastique noir au
dos du panneau de commande videÂo au
pavillon.
²Branchez le cÑble vide o de l'appareil de
jeuc videÂos aÁ la prise JAUNE du panneau
de commande vide o au pavillon.
²Branchez les cÑbles audio gauche et
droit aux prises BLANCHE et ROUGE
respectivement du panneau de
commande vide o au pavillon.
²Appuyez sur la touche SELECT du
panneau de commande videÂo.Lete moin
AV2 s'allume.
²Commencez le jeu.
ApreÁ s avoir utilise votre systeÁ me audiovisuel pour passagers arrieÁre :
²Pour repasser en mode radio AM/FM, faites glisser le se lecteur de fre quence aÁ
la position d'arrØt. Relevez l'e cran abaissable dans son boÜtier pour le remettre
en position de rangement lorsqu'il n'est pas utiliseÂ.
Mode d'emploi
REMOTE
SENSOR
CST INDEW
POWER
BRIGHTNESS VOLUMESENSORSELECT
FREQUENCY
OFF 1 2AV 1 AV 2
Page 36 of 76
COMMANDES DU LECTEUR DE VIDˆOCASSETTES
1.Touche marche/arrØt (POWER)
Appuyez sur cette touche pour allumer ou ×teindre l'appareil.
2.TˆLˆCOMMANDE(capteur de signal de t×l×commande)
Pour faire fonctionner l'appareil ° partir de la t×l×commande, dirigez
celle-ci vers le panneau de commande du systÖme ou le lecteur de
vid×ocassettes.
3.TˆMOINS
Chaque t×moin s'allume lorsque la fonction correspondante est utilis×e.
CST INIndique que la vid×ocassette est dans le lecteur.
DEW(rouge) Clignote en cas de condensation dans le lecteur de
vid×ocassettes.
AUTO REPEATCe t×moin s'allume lorsque la fonction de lecture
r×p×t×e automatique est activ×e.
4.Touche de lecture (PLAY) (lecture r×p×t×e automatique)
Appuyez sur cette touche pour visionner une vid×ocassette.
REMOTE
SENSOR
CST INDEW
AUTO
REPEATPOWER
REW
FFPLAY STOP/
EJECT
23156473
Description
8
Page 38 of 76
ˆCRAN DE VISUALISATION
L'×cran de visualisation au pavillon est l'×l×ment le plus visible du
systÖme audiovisuel pour passagers arriÖre. Il est en fait le « cúur » du
systÖme audiovisuel. En plus de l'×cran abaissable ° cristaux liquides, il
comprend la plupart des touches de commande du systÖme, des t×moins
importants et des dispositifs d'utilisation des casques d'×coute sans fil ou
des casques d'×coute branchables en option.
1.Touche marche/arrØt (POWER)
Appuyez sur cette touche pour allumer ou ×teindre le systÖme
audiovisuel pour passagers arriÖre.
2.CAPTEUR DE SIGNAL DE TˆLˆCOMMANDE
Pour utiliser le lecteur de vid×ocassettes ° partir de la t×l×commande,
dirigez celle-ci vers ce capteur.
3.Touches de volume
Appuyez sur les touches (+) ou (þ) pour augmenter ou diminuer le
volume sonore aux casques d'×coutebranchables.
POWER
BRIGHTNESS VOLUMESENSORSELECT
FREQUENCY
OFF 1 2AV 1 AV 2
54321
876
Description
10
