light FORD F-150 2022 Owners Manual

Autowipers
......................................................141
Checking the Wiper Blades ......................
142
Replacing the Front Wiper Blades ........
142
Washers ..........................................................
143
Wipers and Washers – Troubleshooting ........................................................................\
.
143
Exterior Lighting
Exterior Lighting Control ...........................
145
Exterior Lighting Control - Police Responder ..................................................
145
Headlamps ....................................................
145
Headlamps – Troubleshooting ..............
146
Autolamps .....................................................
146
Exterior Lamps ..............................................
147
Exterior Zone Lighting ................................
149
Automatic High Beam Control ...............
150
Automatic High Beam Control – Troubleshooting .......................................
152
Glare Free Lighting ......................................
153
Glare Free Lighting – Troubleshooting ........................................................................\
.
155
Adaptive Front Lighting .............................
155
Interior Lighting
Switching All of the Interior Lamps On and Off .........................................................
157
Switching the Front Interior Lamps On and Off .........................................................
157
Switching the Front Interior Lamps On and Off - Police Responder .................
157
Switching the Rear Interior Lamps On and Off ........................................................
158
Interior Lamp Function ..............................
158
Adjusting the Instrument Panel Lighting Brightness ..................................................
158
Ambient Lighting .........................................
158
Interior Lighting – Troubleshooting ......
158
Windows
Opening and Closing the Windows ......
159Window Bounce-Back
..............................
159
Locking the Rear Window Controls ......
160
Opening and Closing the Sliding Windows ....................................................
160
Interior Mirror
Interior Mirror Precautions ........................
161
Manually Dimming the Interior Mirror ........................................................................\
..
161
Auto-Dimming Interior Mirror ..................
161
Exterior Mirrors
Adjusting the Exterior Mirrors ..................
162
Folding the Exterior Mirrors - Vehicles With: Manual Folding Mirrors ..............
162
Folding the Exterior Mirrors - Vehicles With: Power Folding Mirrors ................
162
Extending the Exterior Mirrors ................
163
Auto-Dimming Exterior Mirror ................
163
Moonroof
Opening and Closing the Sun Shade ........................................................................\
.
164
Opening and Closing the Moonroof ......
164
Venting the Moonroof ...............................
164
Moonroof Bounce-Back ...........................
165
Instrument Cluster
Instrument Cluster Overview - Vehicles With: 4.2 Inch Screen .............................
166
Instrument Cluster Overview - Vehicles With: 8 Inch Screen .................................
167
Instrument Cluster Overview - Vehicles With: 12.3 Inch Screen ...........................
168
Tachometer ...................................................
168
Speedometer ................................................
168
Fuel Gauge .....................................................
168
Engine Coolant Temperature Gauge ........................................................................\
169
Engine Oil Pressure Gauge ......................
169
Transmission Fluid Temperature Gauge ........................................................................\
169
4
2022 F-150 (TFD) Canada/United States of America, enUSA, Edition date: 202109, First-Printing Table of Contents

Blind Spot Information System
Indicators ....................................................371
Blind Spot Information System – Troubleshooting .......................................
371
Cross Traffic Alert
What Is Cross Traffic Alert .......................
372
How Does Cross Traffic Alert Work ......
372
Cross Traffic Alert Precautions ..............
372
Cross Traffic Alert Limitations ................
372
Switching Cross Traffic Alert On and Off ........................................................................\
373
Locating the Cross Traffic Alert Sensors ........................................................................\
373
Cross Traffic Alert Indicators ...................
373
Cross Traffic Alert – Troubleshooting ........................................................................\
374
Pre-Collision Assist
What Is Pre-Collision Assist ....................
375
How Does Pre-Collision Assist Work ........................................................................\
375
Pre-Collision Assist Precautions ...........
375
Pre-Collision Assist Limitations ............
376
Switching Pre-Collision Assist On and Off - Police Responder ..........................
377
Switching Pre-Collision Assist On and Off .................................................................
377
Locating the Pre-Collision Assist Sensors - Police Responder .................................
378
Locating the Pre-Collision Assist Sensors ........................................................................\
378
Distance Indication ....................................
379
Distance Alert ..............................................
380
Automatic Emergency Braking ..............
381
Evasive Steering Assist ..............................
381
Pre-Collision Assist – Troubleshooting ........................................................................\
382
Driver Alert
What Is Driver Alert ....................................
386
How Does Driver Alert Work ...................
386Driver Alert Precautions
...........................
386
Driver Alert Limitations ............................
386
Switching Driver Alert On and Off .......
386
Driver Alert – Troubleshooting ...............
387
Load Carrying
Load Carrying Precautions .....................
388
Using a Slide-In Camper .........................
389
Locating the Safety Compliance Certification Labels ...............................
389
What Is the Gross Axle Weight Rating .......................................................................
389
What Is the Gross Vehicle Weight Rating .......................................................................
389
What Is the Gross Combined Weight Rating .........................................................
390
Calculating Payload ....................................
391
Calculating the Load Limit .......................
391
Pickup Bed
Pickup Bed Precautions ...........................
394
Pickup Bed Anchor Points ......................
394
Tailgate Anchor Points .............................
395
Pickup Bed Ramps ....................................
396
Connecting a Trailer
Connecting a Trailer Precautions .........
399
Hitches ...........................................................
399
Connecting a Trailer ..................................
399
Trailer Lighting Check ................................
401
Connecting a Trailer – Troubleshooting ........................................................................\
402
Towing a Trailer
Towing a Trailer Precautions ..................
403
Trailer Brake Precautions ........................
403
Towing a Trailer Limitations ...................
404
Loading Your Trailer ..................................
404
Trailer Towing Hints ...................................
404
Launching or Retrieving a Boat or Personal Watercraft ..............................
405
12
2022 F-150 (TFD) Canada/United States of America, enUSA, Edition date: 202109, First-Printing Table of Contents

SVT
The Ford Special Vehicle Team (SVT) was
established in 1991 to polish the Ford Oval
by creating low-volume, factory-produced
vehicles designed for those select few
whose idea of driving is a high-powered,
passionate experience – not just a means
of getting from point A to point B.
In a move to support this spirited
enthusiasm, Ford Motor Company carefully
integrated the wide array of talent in the
company into a small, cross-functional
group of engineers and product planners,
housed together under one roof with a
common mission: to create vehicles
specifically designed to meet the unique
needs and desires of the knowledgeable
driving enthusiast.
More than 400,000 SVT and Ford
Performance vehicles were produced since
the 1993 model year. These include the
SVT Mustang Cobra and the Cobra R, the
SVT F-150 Lightning, the SVT Contour, the
SVT Focus, Ford GT, Shelby GT350, Shelby
GT500, GT500KR and the F-150 SVT
Raptor.
TEAM RS
Team RS traces its roots back nearly 60
years from the Lotus Ford Cortina and Twin
Cam Escorts of the mid 1960’
s, through
the first RS branded Escorts of the 1970’ s
to the founding of Special Vehicle
Engineering (SVE) in 1980. Through the
1980s and 90s, SVE delivered a breadth
of vehicles from exciting XR and RS
branded road going performance cars
through homologation specials such as
the iconic Sierra Cosworth RS500. The first
ST (Sport Technology) vehicle appeared
in 1996 as the ST24 Mondeo. The first
collaboration between Ford ’s European
and North American performance teams
appeared in 2002 as the ST170 in Europe and SVT Focus in North America. In 2003,
Team RS replaced SVE in Europe as
performance car and motorsport personnel
were brought together as one team. Team
RS subsequently created the 2004 Fiesta
ST, 2005 Focus ST and 2009 Focus RS.
FORD PERFORMANCE
Welcome to the Ford Performance family!
SVT and Team RS officially began working
together as one team in 2009. In 2015,
these two teams, along with Ford Racing,
were formally combined establishing Ford
Performance as a single team responsible
for all performance and racing oriented
products and activities worldwide at Ford
Motor Company. Your Ford Performance
vehicle represents the best of what Ford
Performance has to offer from around the
globe. Your vehicle has been designed and
developed with the four hallmarks of Ford
Performance in mind: Performance,
Substance, Exclusivity and Value. We are
proud and passionate about what we do,
and we are glad you have made us your
choice.
Included in the purchase price of your Ford
Performance vehicle is a one day class at
the Ford Performance racing school. For
additional information, refer to
www.fordperformanceracingschool.com.
19
2022 F-150 (TFD) Canada/United States of America, enUSA, Edition date: 202109, First-Printing About Us - RaptorE354711

ABOUT THIS PUBLICATION
WARNING: Driving while distracted
can result in loss of vehicle control, crash
and injury. We strongly recommend that
you use extreme caution when using any
device that may take your focus off the
road. Your primary responsibility is the
safe operation of your vehicle. We
recommend against the use of any
hand-held device while driving and
encourage the use of voice-operated
systems when possible. Make sure you
are aware of all applicable local laws
that may affect the use of electronic
devices while driving. WARNING: You risk death, fire, or
serious injury to yourself and others if you
do not follow the instruction highlighted
by the warning symbol.
Thank you for choosing Ford. We
recommend that you take some time to
get to know your vehicle in order to benefit
from greater safety and pleasure from
driving it. Use this publication to familiarize
yourself with the basics and then read the
digital version, that is available in your
vehicle. You can also view the
comprehensive manual through the
FordPass app and through the local Ford
website.
Note: To download the FordPass app, visit
your device's app store.
Note: To find the local Ford website, visit
ht tp s:/ / c orpor a t e .f or d . c om/ oper a tions/
l oc a tions/ gl ob al-link s.html .
Note: Use and operate your vehicle in line
with all applicable laws and regulations.
Note: Pass on all printed owner ’s
information when selling this vehicle. Our digital resources include a
comprehensive digital Owner
’s Manual
dynamically created according to the
features on your vehicle by using the
vehicle identification number. See
Locating the Vehicle Identification
Number
(page 596). The digital Owner ’s
Manual includes visual and full text search
functions so that you can quickly locate
the information you are looking for. It also
includes links to a number of how-to
videos created to help you understand
some of the advanced technologies on
your vehicle.
Features and Options
This publication describes product features
and options available throughout the range
of available models, sometimes even
before they are generally available. It could
describe options that are not available on
the vehicle you have purchased.
Illustrations
Some of the illustrations in this publication
could show features as used in different
models, so they could appear different to
you on your vehicle.
Location of Components
This manual may qualify the location of a
component as left-hand side or right-hand
side. The side is determined when facing
forward in the seat.
22
2022 F-150 (TFD) Canada/United States of America, enUSA, Edition date: 202109, First-Printing Introduction

Fuse compartment
Hazard flashers
Heated rear window
Windshield defrosting system
Interior luggage compartment
release
Jack
Keep out of reach of children
Lighting control
Low tire pressure warning
Maintain correct fluid level
Note operating instructions
Horn control
Panic alarm
Parking aid
Passenger airbag activated Passenger airbag deactivated
Power steering fluid
Power windows front/rear
Power window lockout
Requires registered technician
Safety alert
See Owner's Manual
See Service Manual
Malfunction Indicator Lamp
(MIL)
Side airbag
Shield the eyes
Stability control
Hill descent control
Trail control
Windshield wiping system
25
2022 F-150 (TFD) Canada/United States of America, enUSA, Edition date: 202109, First-Printing Symbols Glossary E161353 E270945 E139213 E270849 E270850 E231159 E65963 E231158 E167012 E138639 E163171 E332910 E270969

UNIQUE FEATURES
Powertrain
•
3.5L EcoBoost engine.
• 10R80 10-speed automatic
transmission with paddle shifters and
water to air transmission cooler.
• Torque On Demand™ 2-speed transfer
case with 4 Hi-Loc.
• Rear differential capable of locking in
4A, 4H and 4L.
• 35 spline rear axle shafts for increased
capability.
• 4.10 front and rear axle ratios and
optional Torsen front differential.
• Equal length dual exhaust with X-pipe
and active exhaust valves, 4.5 in
(114.3 mm) exhaust tips.
• Charge air cooler fan assembly for
greater cooling at low speeds.
Chassis
• Cast aluminum lower control arms.
• Forged steel upper control arms.
• Fox Factory 3.1 Live Valve Internal
Bypass front shocks.
• Fox Factory 3.1 Live Valve Internal
Bypass Remote Reservoir rear shocks.
• 24 inch triple rate rear springs.
• Unique underbody shields.
• Heavy duty fully boxed frame.
• Unique 5 link rear suspension.
• Unique cast aluminum knuckle.
• Ride height sensors at each corner.
• Off-road tuned stabilizer bar and
jounce bumpers. Exterior
•
Optional off-road driving lights.
• Modified rear bumper with integrated
rear tow hooks.
• Underbody shields plus front tow
hooks.
• Hood with functional air extractors.
• Front fenders with functional air
extractors.
• Front and rear LED marker lamps.
• 17 x 8.5 aluminum wheels.
• Optional 17 x 8.5 forged beadlock
compatible wheels.
• LT 315/70R17 BF Goodrich All Terrain
TA KO2 tires.
• Optional 37x12.5R17 LT BF Goodrich All
Terrain TA KO2 tires.
Interior
• Unique terrain-mode and trail control
functionality plus six auxiliary switches.
• Optional premium leather and suede
seats.
31
2022 F-150 (TFD) Canada/United States of America, enUSA, Edition date: 202109, First-Printing At a Glance - Raptor

FRONT EXTERIOR
See Locating the 360 Degree Cameras (page 321).
A
See
What Is the Lane Keeping System (page 361).
B
See
Folding the Exterior Mirrors (page 162).
C
See
Deploying and Stowing the Power Running Boards (page 137).
D
See
Exterior Lighting Control (page 145).
E
See
Accessing the Front Towing Point (page 467).
F
41
2022 F-150 (TFD) Canada/United States of America, enUSA, Edition date: 202109, First-Printing Visual SearchABC
DEFE320690

FRONT EXTERIOR - POLICE RESPONDER
See Locating the 360 Degree Cameras (page 321).
A
See
What Is the Lane Keeping System (page 361).
B
See
Folding the Exterior Mirrors (page 162).
C
See
Exterior Lighting Control (page 145).
D
See
Accessing the Front Towing Point (page 467).
E
43
2022 F-150 (TFD) Canada/United States of America, enUSA, Edition date: 202109, First-Printing Visual SearchABC
DEE343533

7.
Pull the seatbelt out of the retractor to
make sure the retractor is in the
automatic locking mode. You should
not be able to pull more belt out. If the
retractor is not locked, unbuckle the
belt and repeat Steps 5 and 6. 8.
Remove remaining slack from the belt.
Force the seat down with extra weight,
for example, by pressing down or
kneeling on the child restraint while
pulling up on the shoulder belt in order
to force slack from the belt. This is
necessary to remove the remaining
slack that exists once you add the extra
weight of the child to the child restraint.
It also helps to achieve the proper
snugness of the child restraint to your
vehicle. Sometimes, a slight lean
toward the buckle helps to remove
remaining slack from the belt.
9. If the child restraint has a tether strap, attach it. 10. Before placing the child in the seat,
forcibly move the seat forward and
back to make sure the seat is securely
held in place.
To check this, grab the seat at the belt path
and attempt to move it side to side and
forward and back. There should be no
more than 1 in (2.5 cm) of movement.
We recommend checking with a NHTSA
Certified Child Passenger Safety
Technician to make certain the child
restraint is properly installed. In Canada,
check with Transport Canada for referral
to a Child Car Seat Clinic.
Using Seatbelts WARNING:
Always use both the
lap and shoulder portion of the seatbelt
in the center seating position.
Note: The following applies to the front
center position of Super Cab and Crew Cab
vehicles.
The seatbelt webbing below the tongue is
the lap portion of the seatbelt. The
webbing above the tongue is the shoulder
belt portion of the seatbelt.
1. Position the child restraint in the front center seat.
53
2022 F-150 (TFD) Canada/United States of America, enUSA, Edition date: 202109, First-Printing Child SafetyE142533 E142534

A seatbelt warning light and
chime.
Crash sensors and monitoring
system with readiness indicator.
The seatbelt pretensioners are designed
to tighten the seatbelts when activated. In
frontal and near-frontal crashes, the
seatbelt pretensioners may be activated
alone or, if the crash is of sufficient severity,
together with the front airbags. In side
crashes and rollovers, the pretensioners
will be activated when the Safety Canopy
is activated.
FASTENING AND
UNFASTENING THE
SEATBELTS
This applies to all seating positions, except
for the front center position of Super Cab
and Crew Cab. 1. Insert the seatbelt tongue into the
buckle until you hear a snap and feel it
latch. 2. Press the button to release the
seatbelt.
Using the Seatbelt With Cinch
Tongue
This applies to the front center seating
position of Super Cab and Crew Cab.
The cinch tongue slides up and down the
seatbelt webbing when you stow the
seatbelt or when you put the seatbelts on.
When you buckle the seatbelt, the cinch
tongue allows you to shorten the lap
portion, but pinches the webbing to keep
the lap portion from getting longer. The
cinch tongue is designed to slip during a
crash, so wear the shoulder belt properly
and do not allow any slack in either the lap
or shoulder portions.
Fastening the Cinch Tongue WARNING: Always drive and ride
with your seatback upright and the lap
belt snug and low across the hips.
1. Pull the seatbelt from the retractor so that the shoulder belt portion of the
seatbelt crosses your shoulder and
chest.
2. Make sure the belt is not twisted. If the
belt is twisted, remove the twist.
62
2022 F-150 (TFD) Canada/United States of America, enUSA, Edition date: 202109, First-Printing SeatbeltsE71880 E67017 E142587 E142588
