FORD F SERIES MOTORHOME AND COMMERCIAL CHASSIS 1996 10.G Owners Manual

167 [SV54980( M)03/94]
thirty-six pica chart:0020868-D
File:ltsvm.ex
Update:Tue Jun 20 16:44:35 1995

168
*
[SV56000( ALL)01/95]
Vehicle Storage
*
[SV56100( ALL)01/95]
Maintenance Tips
*
[SV56150( ALL)01/95]
If you plan on storing your vehicle for an
extended period of time (60 days or more), refer
to the following maintenance recommendations
to ensure your vehicle stays in good operating
condition.
*
[SV56200( ALL)01/95]
General
*
[SV56300( ALL)01/95]
q
Store all vehicles in a dry, ventilated place.
*
[SV56400( ALL)01/95]
q
Protect from sunlight, if possible.
*
[SV56500( ALL)01/95]
q
If vehicles are stored outside, they require
regular maintenance to protect against rust
and damage.
*
[SV56600( ALL)01/95]
Body
*
[SV56700( ALL)01/95]
q
Wash vehicle thoroughly to remove dirt,
grease, oil, tar or mud from exterior surfaces,
rear wheel housing and underside of front
fenders.
*
[SV56800( ALL)01/95]
q
Periodically wash vehicles stored in exposed
locations.
*
[SV56900( ALL)01/95]
q
Touch-up raw or primed metal to prevent
rust.
*
[SV57000( ALL)01/95]
q
Cover chrome and stainless steel parts with a
thick coat of auto wax to prevent
discoloration. Re-wax as necessary when the
vehicle is washed.
*
[SV57100( ALL)04/95]
q
Lubricate all hood, door and trunk lid hinges
and latches with a light grade oil.
*
[SV57200( ALL)01/95]
q
Cover interior soft trim to prevent fading.
*
[SV57300( ALL)01/95]
q
Keep all rubber parts free from oil and
solvents.
File:ltsvm.ex
Update:Tue Jun 20 16:44:35 1995

169 %
*
[SV57350( ALL)01/95]
Engine
*
[SV57400( ALL)01/95]
q
Start engine every 15 days. Run at fast idle
until it reaches normal operating temperature.
*
[SV57500( ALL)01/95]
q
With your foot on the brake, shift through all
the gears while the engine is running.
%*
[SV57600( ALL)01/95]
Fuel system
%*
[SV57700( ALL)07/94]
q
Fill fuel tank with high-quality unleaded fuel
until the first automatic shutoff of the fuel
pump nozzle.
*
[SV57900( ALL)03/95]
NOTE: During extended periods of vehicle
storage (60 days or more), fuel may
deteriorate due to oxidation. This can
damage rubber and other polymers in
the fuel system and may also clog
small orifices.
*
[SV58000( ALL)01/95]
Ford Gas Stabilizer should be added whenever
actual or expected storage periods exceed 60
days. Follow the instructions on the label. The
vehicle should then be operated at idle speed to
circulate the additive throughout the fuel system.
*
[SV58100( ALL)01/95]
A volatile corrosion inhibitor added to the fuel
system will protect the fuel system's inner
surfaces from corrosion. Follow the instructions
packaged with the product.
%*
[SV58200( ALL)01/95]
Cooling system
*
[SV58300( ALL)01/95]
q
Protect against freezing temperatures.
%*
[SV58400( ALL)01/95]
Battery
*
[SV58500( ALL)01/95]
q
Check and recharge as necessary.
*
[SV58600( ALL)01/95]
q
Keep connections clean and covered with a
light coat of grease.
File:ltsvm.ex
Update:Tue Jun 20 16:44:35 1995

170 %
*
[SV58700( ALL)01/95]
Brakes
*
[SV58800( ALL)01/95]
q
Make sure brakes and parking brake are fully
released.
%*
[SV58900( ALL)01/95]
Tires
*
[SV59000(B FM)05/95]
q
Maintain recommended air pressures.
*
[SV59100( ALL)01/95]
Miscellaneous
*
[SV59200( ALL)01/95]
q
Make sure all linkages, cables, levers and
clevis pins under vehicle are covered with
grease to prevent rust.
*
[SV59300( ALL)05/95]
q
Move vehicles at least 25 feet (10 m) every 15
days to lubricate working parts to prevent
corrosion.
File:ltsvm.ex
Update:Tue Jun 20 16:44:35 1995

171
*
[SV99900( ALL)05/95]
thirty-six pica chart:FORDADPLN
File:ltsvm.ex
Update:Tue Jun 20 16:44:35 1995

172
Notes
File:ltsvm.ex
Update:Tue Jun 20 16:44:35 1995

173
General Information
*
[BK00050( ALL)05/95]
thirty-two pica chart:0060629-D
File:ltbkm.ex
Update:Tue Jun 20 16:42:47 1995

174Table of ContentsMaintenance Schedule and Record.......... 175
General Maintenance Information........... 175
Severe Duty Schedule................................. 178
Owner Maintenance Checks...................... 205
*
[BK00110( ALL)05/95]
twenty-two pica chart:0060691-A
File:ltbkm.ex
Update:Tue Jun 20 16:42:47 1995

175
Maintenance Schedule and
Record
[BK00140( M)05/93]
quarter page art:0020742-C*
[BK00200( ALL)01/95]
General Maintenance Information
*
[BK00300( ALL)01/95]
The required Scheduled Maintenance Services
listed in this booklet are considered essential to
the proper operation, safety and performance of
your Ford Motor Company vehicle. We
recommend that you also perform the Owner
Maintenance Checks listed. These services are
matters of day-to-day care that are also
important to the proper operation of your
vehicle. The recommended lubricants, fluids and
service parts conforming to Ford Specifications
are available from your dealer.
*
[BK00350( ALL)01/95]
This booklet gives you a place to record the
services that are performed on your vehicle so
that you can keep a record of when parts should
be checked or replaced. Give yourMaintenance
Schedule and Recordbooklet to the dealer service
manager.
*
[BK00400( ALL)01/95]
Maintenance: An investment
*
[BK00500( ALL)01/95]
An investment which will pay dividends in the
form of improved reliability, durability, and
resale value.
File:ltbkm.ex
Update:Tue Jun 20 16:42:47 1995

176
*
[BK01300( ALL)01/95]
To assure the durability of your vehicle and its
emission control systems, it is necessary that
scheduled maintenance be performed at the
designated intervals.
*
[BK01400( ALL)05/95]
Ford strongly recommends the use of genuine
Ford replacement parts. If other than Ford or
Motorcraft parts or Ford authorized
remanufactured parts are used for maintenance
replacements or for the service of components
affecting emission control, such non-Ford parts
should be equivalent to genuine Ford Motor
Company parts in performance and durability. It
is the owner's responsibility to determine the
equivalency of such parts. Please consult your
warranty booklet for complete warranty
information.
*
[BK01410( ALL)05/95]
No Cost PCV Valve Replacement
[BK01425( M)02/93]
THE PCV VALVE ON LIGHT TRUCKS IS A
CRITICAL EMISSION COMPONENT. YOUR
DEALER WILL REPLACE THE VALVE AT NO
COST AT 60,000 MILES/96,000 KILOMETERS
(EXCEPT CANADA VEHICLES).
*
[BK01435( ALL)06/94]
Wheel Lug Nuts
*
[BK01455( ALL)06/94]
Wheel lug nuts must be retightened to proper
torque specifications at 500 miles/800 km of
new vehicle operation (100 miles/160 km for
vehicles equipped for snowplowing). Proper
torque specifications are provided in your
Owner Guide. Also retighten to proper torque
specification at 500 miles/800 km after (1) any
wheel change or (2) any other time the wheel
lug nuts have been loosened.
