FORD F SERIES MOTORHOME AND COMMERCIAL CHASSIS 1997 10.G Owners Manual

97
%*
[ER23100( ALL)01/96]
Towing Your Vehicle
[ER23200(B FM)01/96]
If you need to have your vehicle towed, contact
a professional towing service or, if you are a
member, your roadside assistance center.
Recommended towing options include wheel lift
towing or flat bed towing.
[ER23500( ALL)01/96]
When calling for a tow truck, tell the operator
what kind of vehicle you have. A towing
manual is available from Ford Motor Company
for all authorized tow truck operators. Have
your tow truck driver refer to this manual for
the proper hook-up and towing procedures for
your vehicle.
File:10lterm.ex
Update:Fri Dec 13 11:23:45 1996

98
Notes
File:10lterm.ex
Update:Fri Dec 13 11:23:45 1996

99
Maintenance and Care
%*
[MC00200( ALL)01/96]
Service Made Easy
*
[MC00900( ALL)01/96]
This chapter tells you about the basic parts that
you need to check and service regularly.
*
[MC01000( ALL)01/96]
If your vehicle needs professional servicing, your
dealership can provide the parts and service
required. Check yourWarranty Information Booklet
to find out which parts and services are covered.
Also see theCustomer Assistancechapter of this
Owner Guide.
*
[MC01100( ALL)01/96]
Ford Motor Company recommends that the
Owner Maintenance Checks listed in the
Maintenance Schedule and Recordbooklet be
performed for the proper operation of your
vehicle. In addition to the conditions listed in
theOwner Maintenance Checklist, be alert for any
unusual noise, vibration, or other indication that
your vehicle may need service. If you do notice
something unusual, see that your vehicle is
serviced promptly.
%
*
[MC01200( ALL)01/96]
Precautions When Servicing Your
Vehicle
*
[MC01300( ALL)01/96]
Be especially careful when inspecting or
servicing your vehicle. Here are some general
precautions for your safety:
*
[MC01400( ALL)01/96]
q
If you must work with the engine running,
avoid wearing loose clothing or jewelry that
could get caught in moving parts. Take
appropriate precautions with long hair.
*
[MC01500( ALL)01/96]
q
Do not work on a vehicle in an enclosed
space with the engine running, unless you are
sure you have enough ventilation.
File:11ltmcm.ex
Update:Fri Dec 13 11:24:54 1996

100
*
[MC01600( ALL)01/96]
q
Never get under a vehicle while it is
supported only by a jack. If you must work
under a vehicle, use safety stands.
*
[MC01700( ALL)01/96]
q
Keep all lit cigarettes and other smoking
materials away from the battery and all
fuel-related parts.
*
[MC01800( ALL)01/96]
If you disconnect the battery, the engine must
ªrelearnº its idle conditions before your vehicle
will drive properly. To find out how the engine
does this, seeBatteryin this chapter.
*
[MC01900( ALL)01/96]
Working with the engine off:
*
[MC02000( E M)01/96]
1. Set the parking brake fully and make sure
that the gearshift is securely latched in P
(Park).
*
[MC02300( ALL)01/96]
2. Remove the key from the ignition after you
turn the engine off.
*
[MC02400( ALL)01/96]
3. Block the wheels. This will prevent your
vehicle from moving unexpectedly.
*
[MC02500( ALL)01/96]
Working with the engine on:
*
[MC02700( E M)01/96]
1. Set the parking brake fully and make sure
that the gearshift is securely latched in P
(Park).
*
[MC02800( E M)01/96]
2. Block the wheels. This will prevent your
vehicle from moving unexpectedly.
*
[MC03000( ALL)01/96]
RWARNING
Do not start your engine with the air
cleaner removed and do not remove it
while the engine is running.
File:11ltmcm.ex
Update:Fri Dec 13 11:24:54 1996

101
%*
[MC05750( ALL)01/96]
Engine Oil Recommendations
*
[MC05775( ALL)01/96]
We recommend using Motorcraft oil or an
equivalent oil meeting Ford Specification
WSS-M2C153-F and displaying the American
Petroleum Institute CERTIFICATION MARK on
the front of the container.
*
[MC05800( ALL)01/96]
one third page art:0060020-D
The API Certification Mark
*
[MC05900( ALL)01/96]
Neveruse:
*
[MC06000( ALL)01/96]
q
ªNon-Detergentº oils
*
[MC06100( ALL)01/96]
q
Oils labeled API SA, SB, SC, SD, SE, SF or SG
%*
[MC06200( ALL)01/96]
q
Additional engine oil additives, oil treatments
or engine treatments
[MC06800( ALL)01/96]
Engine oils with anSAE 10W-30viscosity are
PREFERREDfor your vehicle which provide the
best engine protection for all climates down to
S5ÊF (S20ÊC). SAE5W-30 engine oils may also
be used down toS15ÊF (S25ÊC).
%*
[MC06900( ALL)01/96]
Synthetic engine oils which are CERTIFIED and
of the preferred viscosity may be used in your
engine. The engine oil and oil filter must still be
changed according to the maintenance schedule.
File:11ltmcm.ex
Update:Fri Dec 13 11:24:54 1996

102 %
*
[MC07000( ALL)01/96]
Checking and Adding Engine Oil
*
[MC07100( ALL)01/96]
Since the proper amount of engine oil is
important for safe engine operation, check the oil
using the dipstick each time you put fuel in
your vehicle. Remember the engine must be off,
the oil must be warm and the vehicle must be
parked on level ground.
%*
[MC07200( ALL)01/96]
Checking the engine oil level:
*
[MC07300( ALL)01/96]
1. Turn the engine off after it has warmed up
and allow a few minutes for the engine oil
to drain back into the oil pan.
*
[MC07500( E M)01/96]
2. Set the parking brake, making sure the
gearshift is securely latched in P (Park).
*
[MC07600( ALL)01/96]
3. Open the hood. Protect yourself from engine
heat.
*
[MC07700( ALL)01/96]
4. Locate the engine oil dipstick (highlighted in
yellow) and carefully pull it out of the
engine.
*
[MC07800( ALL)01/96]
5. Wipe the dipstick clean and put it back into
position, making sure it is fully seated.
File:11ltmcm.ex
Update:Fri Dec 13 11:24:54 1996

103
*
[MC07900( ALL)01/96]
quarter page art:0010364-D
Engine oil dipstick
*
[MC08000( ALL)01/96]
6. Carefully, pull the dipstick out again. If the
oil level is below the ªADD 1 QT.º line, add
engine oil as necessary. If the oil level is
beyond the letter ªFº in FULL, engine
damage or high oil consumption may occur
and some oil must be removed from the
engine.
*
[MC08100( ALL)01/96]
7. Put the dipstick back in and make sure it is
fully seated.
*
[MC08200( ALL)01/96]
It may be necessary to add some oil between oil
changes. Make sure you use a CERTIFIED
engine oil of the preferred viscosity. Your
vehicle's warranty coverage may not apply if
engine damage is caused by the use of improper
engine oil.
*
[MC08300( ALL)01/96]
Add engine oil through the oil filler cap
highlighted in yellow. To add oil, remove the
filler cap and use a funnel to pour oil into the
opening. Be careful not to overfill the engine.
Recheck the oil level after you finish adding oil.
File:11ltmcm.ex
Update:Fri Dec 13 11:24:54 1996

104 %
*
[MC08400( EFM)01/96]
Changing the Engine Oil and the Oil Filter
*
[MC08500( ALL)01/96]
Change the engine oil and oil filterper the
following, whichever occurs first.
[MC08700( M)01/96]
quarter page art:0021101-A
Oil change intervals
*
[MC08800( ALL)01/96]
NOTE: Idling the engine for extended periods
will accumulate more hours of use on
your vehicles than is actually indicated
by the mileage odometer.
Consequently, the odometer reading
can be often misleading when
determining the right time to change
your engine oil and filter.
*
[MC09100( ALL)01/96]
Refer to theMaintenance Schedule and Record
booklet for additional information.
%*
[MC09300( ALL)01/96]
NOTE: Always dispose of used automotive
fluids in a responsible manner. Follow
your community's standards for
disposing of these types of fluids. Call
your local recycling center to find out
about recycling automotive fluids.
*
[MC09400( ALL)01/96]
RWARNING
Continuous contact with USED motor oil
has caused cancer in laboratory mice.
*
[MC09500( ALL)01/96]
Protect your skin by washing with soap and
water.
File:11ltmcm.ex
Update:Fri Dec 13 11:24:54 1996

105
%*
[MC09600( ALL)01/96]
Brake Fluid
*
[MC09625( ALL)01/96]
Your vehicle is equipped with a brake fluid level
indicator in the master cylinder which lights the
BRAKE warning light on the instrument panel
when the brake fluid level is low.
*
[MC09650( ALL)01/96]
Under normal circumstances, your vehicle
should not use up brake fluid rapidly. However,
expect the level of the brake fluid to slowly fall
as you put more mileage on your vehicle and
the brake lining wears.
*
[MC09675( ALL)01/96]
Check the brake fluid at least once a year. You
can do this by looking at the fluid level in the
plastic brake fluid reservoir on the master
cylinder. The fluid level should be at or near the
MAX mark.
*
[MC09700( ALL)01/96]
RWARNING
Brake fluid is toxic.
*
[MC09725( ALL)01/96]
If brake fluid contacts eyes, flush eyes with
running water for 15 minutes. Get medical
attention if irritation persists. If taken internally,
drink water and induce vomiting. Get medical
attention immediately.
%*
[MC09750( ALL)01/96]
If the fluid is low, carefully clean and remove
the filler cap from the reservoir. Fill the
reservoir to the MAX line with Ford High
Performance DOT 3 Brake Fluid C6AZ-19542-AB
or DOT 3 equivalent fluid meeting Ford
specification ESA-M6C25-A.
*
[MC09775( ALL)01/96]
NOTE: If brake fluid is spilled on painted
surfaces, it must be flushed and wiped
away immediately. Brake fluid may
dissolve the paint finish on your
vehicle.
File:11ltmcm.ex
Update:Fri Dec 13 11:24:54 1996

106
*
[MC09800( ALL)01/96]
RWARNING
If you use a brake fluid that is not DOT
3, you will cause permanent damage to
your brakes.
*
[MC09825( ALL)01/96]
Do not fill the reservoir above the MAX line.
*
[MC09850( ALL)01/96]
If you find that the fluid level is excessively low
Ð below the seam or ridge on the outside of the
plastic reservoir Ð have the brake system
inspected.
*
[MC09875( ALL)01/96]
RWARNING
Do not let the reservoir for the master
cylinder run dry. This may cause the
brakes to fail.
[MC09925( M)01/96]
one third page art:0020867-B
Brake master cylinder
[MC09950( M)01/96]
Parking Brake Reservoir
[MC09975( M)01/96]
To inspect the parking brake fluid, refer to the
1997 Ford Service Manualor a qualified service
technician.
