FORD F SERIES MOTORHOME AND COMMERCIAL CHASSIS 1997 10.G Owners Manual

147
Capacities and
Specifications
*
[CS00200( ALL)01/96]
Refill Capacities, Motorcraft Parts,
and Lubricant Specifications
%*
[CS00300( ALL)01/96]
Motorcraft Parts
[CS00500( M)01/96]
fourteen pica chart:0020735-KFile:12ltcsm.ex
Update:Fri Dec 13 11:25:18 1996

148 %
*
[CS01800( ALL)01/96]
Refill Capacities
[CS02160( M)01/96]
sixteen pica chart:0020734-EFile:12ltcsm.ex
Update:Fri Dec 13 11:25:18 1996

149 %
*
[CS02300( ALL)01/96]
Lubricant Specifications
[CS02600( M)01/96]
thirty-six pica chart:0020736-IFile:12ltcsm.ex
Update:Fri Dec 13 11:25:18 1996

150 [CS02620( M)01/96]
thirty-six pica chart:0020737-F
File:12ltcsm.ex
Update:Fri Dec 13 11:25:18 1996

151 [CS02640( M)01/96]
thirty-six pica chart:0020868-E
File:12ltcsm.ex
Update:Fri Dec 13 11:25:18 1996

152
%*
[CS02660( ALL)01/96]
Vehicle Storage
*
[CS02670( ALL)01/96]
Maintenance Tips
*
[CS02680( ALL)01/96]
If you plan on storing your vehicle for an
extended period of time (60 days or more), refer
to the following maintenance recommendations
to ensure your vehicle stays in good operating
condition.
*
[CS02690( ALL)01/96]
General
*
[CS02700( ALL)01/96]
q
Store all vehicles in a dry, ventilated place.
*
[CS02710( ALL)01/96]
q
Protect from sunlight, if possible.
*
[CS02720( ALL)01/96]
q
If vehicles are stored outside, they require
regular maintenance to protect against rust
and damage.
*
[CS02730( ALL)01/96]
Body
*
[CS02740( ALL)01/96]
q
Wash vehicle thoroughly to remove dirt,
grease, oil, tar or mud from exterior surfaces,
rear wheel housing and underside of front
fenders.
*
[CS02750( ALL)01/96]
q
Periodically wash vehicles stored in exposed
locations.
*
[CS02760( ALL)01/96]
q
Touch-up raw or primed metal to prevent
rust.
*
[CS02770( ALL)01/96]
q
Cover chrome and stainless steel parts with a
thick coat of auto wax to prevent
discoloration. Re-wax as necessary when the
vehicle is washed.
*
[CS02780( ALL)01/96]
q
Lubricate all hood, door and trunk lid hinges
and latches with a light grade oil.
*
[CS02790( ALL)01/96]
q
Cover interior soft trim to prevent fading.
*
[CS02800( ALL)01/96]
q
Keep all rubber parts free from oil and
solvents.
File:12ltcsm.ex
Update:Fri Dec 13 11:25:18 1996

153 %
*
[CS02810( ALL)01/96]
Engine
*
[CS02820( ALL)01/96]
q
Start engine every 15 days. Run at fast idle
until it reaches normal operating temperature.
*
[CS02830( ALL)01/96]
q
With your foot on the brake, shift through all
the gears while the engine is running.
%*
[CS02840( ALL)01/96]
Fuel system
%*
[CS02850( ALL)01/96]
q
Fill fuel tank with high-quality unleaded fuel
until the first automatic shutoff of the fuel
pump nozzle.
*
[CS02860( ALL)01/96]
NOTE: During extended periods of vehicle
storage (60 days or more), fuel may
deteriorate due to oxidation. This can
damage rubber and other polymers in
the fuel system and may also clog
small orifices.
*
[CS02870( ALL)01/96]
Ford Gas Stabilizer should be added whenever
actual or expected storage periods exceed 60
days. Follow the instructions on the label. The
vehicle should then be operated at idle speed to
circulate the additive throughout the fuel system.
*
[CS02890( ALL)01/96]
A volatile corrosion inhibitor added to the fuel
system will protect the fuel system's inner
surfaces from corrosion. Follow the instructions
packaged with the product.
%*
[CS02900( ALL)01/96]
Cooling system
*
[CS02910( ALL)01/96]
q
Protect against freezing temperatures.
File:12ltcsm.ex
Update:Fri Dec 13 11:25:18 1996

154 %
*
[CS02920( ALL)01/96]
Battery
*
[CS02930( ALL)01/96]
q
Check and recharge as necessary.
*
[CS02940( ALL)01/96]
q
Keep connections clean and covered with a
light coat of grease.
%*
[CS02950( ALL)01/96]
Brakes
*
[CS02960( ALL)01/96]
q
Make sure brakes and parking brake are fully
released.
%*
[CS02970( ALL)01/96]
Tires
*
[CS02980(B FM)01/96]
q
Maintain recommended air pressures.
*
[CS02990( ALL)01/96]
Miscellaneous
*
[CS03000( ALL)01/96]
q
Make sure all linkages, cables, levers and
clevis pins under vehicle are covered with
grease to prevent rust.
*
[CS03010( ALL)01/96]
q
Move vehicles at least 25 feet (10 m) every 15
days to lubricate working parts to prevent
corrosion.
File:12ltcsm.ex
Update:Fri Dec 13 11:25:18 1996

155
Customer Assistance
[HS00105( M)06/95]
Motorhome Assistance
[HS00110( M)05/95]
If you have a service concern, please follow the
directions below. If you require roadside
assistance (flat tire, jump start, fuel, locked out),
please refer toRoadside Assistancein this section.
[HS00115( M)05/95]
Call our Motorhome Customer Assistance Center
(1-800-444-3311) which is available 24 hrs/day.
[HS00120( M)05/95]
If inspections or repairs are required let the
assistance center make an appointment for you
at the most appropriate repair location in your
area.
[HS00125( M)05/95]
Please have the following information ready
before you call:
*
[HS00130( M)01/95]
q
Vehicle Identification Number
[HS00135( M)05/95]
q
Current Mileage
[HS00140( M)05/95]
q
A Summary of Your Concern
[HS00145( M)05/95]
When you arrive at the repair location explain
your concern fully to the service writer. If your
problem is resolved please contact
(1-800-444-3311) and advise them accordingly.
[HS00150( M)05/95]
If your service problem is not resolved, ask to
see the Service Manager and review your
concern with him.
[HS00155( M)05/95]
If you are still not satisfied, contact
(1-800-444-3311) and our Motorhome Customer
Assistance Center will assist you and/or the
repair location as needed.
File:14lthsm.ex
Update:Fri Dec 13 11:25:38 1996

156
%*
[HS00205( ALL)06/94]
Roadside Assistance
*
[HS00210( ALL)11/95]
Ford Motor Company has set up a 24-hour,
seven-day-a-week hotline with trained operators
who put you in touch with the help you need if
you experience a problem with your vehicle.
This complimentary service is provided to you
throughout your warranty period of 3 years or
36,000 miles (60,000 km), whichever comes first.
To purchase Roadside Assistance coverages
beyond this period (available through Ford Auto
Club in the United States or Ford and
Lincoln-Mercury dealers in Canada), contact
your Ford or Lincoln-Mercury dealer. Additional
Roadside Assistance coverage is unavailable in
Puerto Rico and the Virgin Islands.
*
[HS00215( ALL)06/94]
Roadside Assistance will cover the following:
*
[HS00220( ALL)06/94]
q
Mount your spare if you have a flat tire.
*
[HS00225( ALL)06/94]
q
Jump-start your battery if it is dead.
*
[HS00230( ALL)06/94]
q
Unlock your vehicle if you are locked out.
*
[HS00235( ALL)06/94]
q
Bring you fuel if you run out.
*
[HS00240( ALL)06/94]
q
Tow your vehicle if you are stranded. Even
non-warranty related tows, like accidents or
getting stuck in mud or snow, are covered
(some exclusions apply, such as impound
towing and repossession).
*
[HS00245( ALL)06/94]
How to use Roadside Assistance
*
[HS00250( ALL)06/94]
Your Roadside Assistance identification card can
be found in the Owner Guide portfolio in your
glove compartment. Complete the card and place
it in your wallet for quick reference.
*
[HS00255( ALL)04/95]
To receive roadside assistance in the United
States call 1-800-241-FORD (in Canada call
1-800-665-2006).
