FORD F SERIES MOTORHOME AND COMMERCIAL CHASSIS 1997 10.G Owners Manual

167
General Information
*
[BK00050( ALL)08/95]
thirty-two pica chart:0060629-D
File:18ltbkm.ex
Update:Thu Dec 12 13:32:30 1996

168Table of ContentsMaintenance Schedule and Record
........
169
General Maintenance Information........ 169
Severe Duty Schedule
..................................
172
Owner Maintenance Checks
.....................
199
*
[BK00110( ALL)01/96]
ten pica chart:0060691-B
File:18ltbkm.ex
Update:Thu Dec 12 13:32:30 1996

169
Maintenance Schedule and
Record
[BK00140( M)05/93]
quarter page art:0020742-C*
[BK00200( ALL)01/95]
General Maintenance Information
*
[BK00300( ALL)01/95]
The required Scheduled Maintenance Services
listed in this booklet are considered essential to
the proper operation, safety and performance of
your Ford Motor Company vehicle. We
recommend that you also perform the Owner
Maintenance Checks listed. These services are
matters of day-to-day care that are also
important to the proper operation of your
vehicle. The recommended lubricants, fluids and
service parts conforming to Ford Specifications
are available from your dealer.
*
[BK00400( ALL)01/95]
Maintenance: An investment
*
[BK00500( ALL)01/95]
An investment which will pay dividends in the
form of improved reliability, durability, and
resale value.
File:18ltbkm.ex
Update:Thu Dec 12 13:32:30 1996

170
*
[BK01300( ALL)01/95]
To assure the durability of your vehicle and its
emission control systems, it is necessary that
scheduled maintenance be performed at the
designated intervals.
*
[BK01400( ALL)01/96]
Ford strongly recommends the use of genuine
Ford replacement parts. If other than Ford or
Motorcraft parts or Ford authorized
remanufactured parts are used for maintenance
replacements or for the service of components
affecting emission control, such non-Ford parts
should be equivalent to genuine Ford Motor
Company parts in performance and durability. It
is the owner's responsibility to determine the
equivalency of such parts. Please consult your
warranty booklet for complete warranty
information.
*
[BK01410( ALL)05/95]
No Cost PCV Valve Replacement
[BK01425( M)02/93]
THE PCV VALVE ON LIGHT TRUCKS IS A
CRITICAL EMISSION COMPONENT. YOUR
DEALER WILL REPLACE THE VALVE AT NO
COST AT 60,000 MILES/96,000 KILOMETERS
(EXCEPT CANADA VEHICLES).
*
[BK01435( ALL)06/94]
Wheel Lug Nuts
[BK01455( ALL)06/96]
Wheel lug nuts must be retightened to proper
torque specifications at 500 miles/800 km of
new vehicle operation (100 miles/160 km for
vehicles equipped for snowplowing). Proper
torque specifications are provided in your
Owner Guide. Also retighten to proper torque
specification at 500 miles/800 km after (1) any
wheel change or (2) any other time the wheel
lug nuts have been loosened.
File:18ltbkm.ex
Update:Thu Dec 12 13:32:30 1996

171
*
[BK01462( ALL)01/95]
PRE-DELIVERY CHECK
*
[BK01464( ALL)01/95]
q
Pre-Delivery Service Inspection Completed
*
[BK01466( ALL)08/93]
four pica chart:0060627-A
File:18ltbkm.ex
Update:Thu Dec 12 13:32:30 1996

172 Severe Duty ScheduleSevere Duty Schedule
*
[BK49700( ALL)09/95]
NOTE: Items for Emission Control Service are shown
in this type and style.
*
[BK49800( ALL)01/95]
For items marked with a number in parentheses
such as (1), see footnote at the end of this
section.
*
[BK49900( ALL)05/93]
NOTE: The Severe Duty Schedule provides
maintenance intervals for replacing
your air cleaner filter if you drive in
severe dust conditions. However, the
conditions you drive in may require
even more frequent air cleaner
replacement intervals than those
shown. Check with your dealer.
*
[BK50050( ALL)01/95]
Maintenance
Intervals
for Severe
Duty Schedule
[BK50075( M)09/95]
NOTE: Rear axle lube quantities must be
replaced every 99,000 miles
(165,000 km) or if the axle has been
submerged in water. Otherwise, the
lube should not be checked or changed
unless a leak is suspected or repair
required.
File:18ltbkm.ex
Update:Thu Dec 12 13:32:30 1996

Severe Duty Schedule 173
*
[BK50100( ALL)01/95]
3,000 MILES (5,000 Kilometers)
*
[BK50200( ALL)11/95]
q
Change engine oil and replace oil filter.
*
[BK50450( ALL)04/93]
four pica chart:0060627-A
*
[BK50501( ALL)01/95]
6,000 MILES (10,000 Kilometers)
*
[BK50601( ALL)11/95]
q
Change engine oil and replace oil filter.
*
[BK50650( ALL)08/95]
q
Rotate tires and adjust air pressure. (3)(5)(6)
*
[BK50801( ALL)09/95]
q
Inspect and lubricate automatic transmission
shift linkage.
*
[BK50901( ALL)06/95]
q
Inspect exhaust system for leaks, damage or
loose parts. Remove any foreign material
trapped by exhaust system shielding.
*
[BK50910( ALL)09/95]
NOTE: It is normal for a certain amount of
moisture and staining to be present
around the muffler seams. The
presence of soot, light surface rust or
moisture does not indicate a faulty
muffler.
*
[BK51001( ALL)08/95]
q
Lubricate steering linkage suspension,
driveshaft U-joint if equipped with grease
fittings and lubricate slip yoke (if equipped).
(2)
*
[BK51150( ALL)04/93]
four pica chart:0060627-A
File:18ltbkm.ex
Update:Thu Dec 12 13:32:30 1996

174 Severe Duty Schedule
*
[BK51201( ALL)01/95]
9,000 MILES (15,000 Kilometers)
*
[BK51301( ALL)11/95]
q
Change engine oil and replace oil filter.
*
[BK51350( ALL)04/93]
four pica chart:0060627-A
*
[BK51401( ALL)01/95]
12,000 MILES (20,000 Kilometers)
*
[BK51501( ALL)11/95]
q
Change engine oil and replace oil filter.
*
[BK52001( ALL)09/95]
q
Inspect and lubricate automatic transmission
shift linkage.
*
[BK52101( ALL)06/95]
q
Inspect exhaust system for leaks, damage or
loose parts. Remove any foreign material
trapped by exhaust system shielding.
*
[BK52110( ALL)09/95]
NOTE: It is normal for a certain amount of
moisture and staining to be present
around the muffler seams. The
presence of soot, light surface rust or
moisture does not indicate a faulty
muffler.
*
[BK52201( EFM)08/95]
q
Lubricate steering linkage suspension,
driveshaft U-joint if equipped with grease
fittings and lubricate slip yoke (if equipped).
(2)
*
[BK52350( ALL)04/93]
four pica chart:0060627-A
File:18ltbkm.ex
Update:Thu Dec 12 13:32:30 1996

Severe Duty Schedule 175
*
[BK52401( ALL)01/95]
15,000 MILES (25,000 Kilometers)
*
[BK52501( ALL)11/95]
q
Change engine oil and replace oil filter.
*
[BK52550( ALL)06/95]
q
Inspect engine cooling system, hoses, and clamps;
and check coolant strength every 15,000 miles
(25,000 km) or 12 months.
*
[BK52601( ALL)08/95]
q
Rotate tires and adjust air pressure. (3)(5)(6)
*
[BK52801( ALL)05/93]
q
Inspect disc brake system and lubricate
caliper slide rails. (2)
*
[BK53001( ALL)08/95]
q
Change fuel filter (Recommended but not
required for California Certified Vehicles).
*
[BK53030( FM)02/95]
q
Check spring U-bolt torque (F-Super Duty).
*
[BK53035( FM)02/95]
q
Inspect parking brake fluid (F-Super Duty).
*
[BK53050( ALL)04/93]
four pica chart:0060627-A
*
[BK53101( ALL)01/95]
18,000 MILES (30,000 Kilometers)
*
[BK53201( ALL)11/95]
q
Change engine oil and replace oil filter.
*
[BK53501( ALL)09/95]
q
Inspect and lubricate automatic transmission
shift linkage.
*
[BK53601( ALL)06/95]
q
Inspect exhaust system for leaks, damage or
loose parts. Remove any foreign material
trapped by exhaust system shielding.
*
[BK53610( ALL)09/95]
NOTE: It is normal for a certain amount of
moisture and staining to be present
around the muffler seams. The
presence of soot, light surface rust or
moisture does not indicate a faulty
muffler.
File:18ltbkm.ex
Update:Thu Dec 12 13:32:30 1996

176 Severe Duty Schedule
*
[BK53801( ALL)08/95]
q
Lubricate steering linkage suspension,
driveshaft U-joint if equipped with grease
fittings and lubricate slip yoke (if equipped).
(2)
*
[BK54050( ALL)04/93]
four pica chart:0060627-A
*
[BK54101( ALL)01/95]
21,000 MILES (35,000 Kilometers)
*
[BK54201( ALL)11/95]
q
Change engine oil and replace oil filter.
*
[BK54225( ALL)10/95]
q
Change automatic transmission fluid.
*
[BK54250( ALL)04/93]
four pica chart:0060627-A
*
[BK54301( ALL)01/95]
24,000 MILES (40,000 Kilometers)
*
[BK54401( ALL)11/95]
q
Change engine oil and replace oil filter.
*
[BK54501( ALL)08/95]
q
Rotate tires and adjust air pressure. (3)(5)(6)
*
[BK54801( ALL)09/95]
q
Inspect and lubricate automatic transmission
shift linkage.
*
[BK54901( ALL)06/95]
q
Inspect exhaust system for leaks, damage or
loose parts. Remove any foreign material
trapped by exhaust system shielding.
*
[BK54910( ALL)09/95]
NOTE: It is normal for a certain amount of
moisture and staining to be present
around the muffler seams. The
presence of soot, light surface rust or
moisture does not indicate a faulty
muffler.
