Manual locking hubs must be in LOCK
position before shifting into four-wheel drive.
*
[DR19800(B F )11/89]
When using four-wheel drive, maintain steering
wheel control at all times, especially in rough
terrain. Since sudden changes in terrain can
result in abrupt steering wheel motion, make
sure you grip the steering wheel rim from the
outside. Do not grip the spokes.
*
[DR19900(B F )05/90]
Drive cautiously to avoid vehicle damage from
concealed objects such as rocks and stumps.
Know the terrain or examine maps of the area in
question before driving. Map out your route
beforehand. To maintain steering and braking
control of your vehicle, you must have all four
tires on the ground, and they must be rolling,
not sliding or spinning.
*
[DR19925(B F )11/89]
Transmission upshift in 4x4 with transfer case in
4L may be quite firm due to large total gear
reduction. This condition is normal.
*
[DR20000(B F )11/89]
Sand
*
[DR20100(B F )11/89]
When driving over sand, try to keep all four
wheels of the vehicle on the most solid area of
the trail. Do not reduce the tire pressures but
shift to a lower gear and drive steadily through
the terrain. Apply accelerator slowly and avoid
spinning the wheels.
*
[DR20200(B F )11/89]
Mud and Water
*
[DR20300(B F )12/89]
When driving through water, determine the
depth; avoid water higher than the bottom of
the hubs (if possible) and proceed slowly. If the
ignition system gets wet, the vehicle may stall.
*
[DR20400(B F )11/89]
Once through water, always try the brakes. Wet
brakes do not stop the vehicle as effectively as
dry brakes. Drying can be improved by moving
your vehicle slowly, while applying light
pressure on the brake pedal.
File:ltdrf.ex
Update:Thu May 9 15:17:55 1996

200
*
[DR20500(B F )11/89]
After driving through mud, clean off residue
stuck to rotating driveshafts and tires. Excess
mud stuck on tires and rotating driveshafts
causes an imbalance which could damage drive
components.
*
[DR20525(B F )07/94]
NOTE: If the transmission and transfer case is
submerged in water, their fluids should
be checked and changed, if necessary.
*
[DR20550( F )05/90]
NOTE: Refer to the Diesel Engine Owner's
Guide Supplement for driving through
deep water information.
*
[DR20600( F )05/89]
Additional Special Driving
Instructions for 4-Wheel Drive
Vehicle Operators
*
[DR20701(B F )11/89]
Driving on Hill or Slope Terrain
*
[DR20800(B F )08/94]
When driving on a hill, it may be necessary to
travel diagonally up or down. Avoid driving
crosswise or turning on steep slopes, you could
lose traction and slip sideways. Drive straight
up, straight down or avoid the hill completely.
Know the conditions on the other side of a hill
before driving over the crest.
*
[DR20900(B F )11/89]
When climbing a steep hill, start in a lower gear,
rather than finding it necessary to downshift
from a higher gear after the ascent has started.
This reduces strain on the engine and the
possibility of stalling.
*
[DR21000(B F )11/89]
When descending a steep hill avoid sudden
braking. Rapid pumping of the brake pedal will
help slow the vehicle and still maintain steering
control.
File:ltdrf.ex
Update:Thu May 9 15:17:55 1996

201
*
[DR21101(B F )11/89]
Driving on Snow or Ice
*
[DR21200(B F )10/90]
A four-wheel drive vehicle has advantages over
two-wheel drive vehicles in snow and ice but
can skid like any other vehicle. If so equipped,
keep the vehicle in four-wheel drive if icy or
slippery conditions exist.
*
[DR21300(B F )11/89]
Avoid sudden applications of power and quick
changes of direction on snow or ice. Apply the
accelerator slowly and steadily when starting
from a full stop.
[DR21312(B F )05/95]
All utility-type and Four-Wheel Drive vehicles
have special design and equipment features to
make them capable of performing in a wide
variety of off-road applications. Specific design
characteristics give them higher centers of
gravity than ordinary passenger cars.
*
[DR21325(B F )05/95]
RWARNING
All utility and four-wheel drive vehicles
are not designed for cornering at speeds
as high as passenger cars any more than
low-slung sports cars are designed to
perform satisfactorily under off-road
conditions. Avoid sharp turns or abrupt
maneuvers in these vehicles.
%
*
[DR21400( ALL)03/95]
Brakes
*
[DR21500( ALL)01/93]
Front Disc Brakes
*
[DR21525( F )05/94]
F-150/250/350
*
[DR21600( ALL)03/94]
The front disc brakes are self-adjusting. They do
not require service other than periodic inspection
for pad wear.
File:ltdrf.ex
Update:Thu May 9 15:17:55 1996

202
*
[DR21900(BEF )10/94]
Rear Drum Brakes
*
[DR22000(BEF )03/95]
The rear drum brakes are self-adjusting.
Automatic adjustment occurs when the brakes
are applied while ªbacking up.º If normal
operation does not include much backing, adjust
the brakes when they seem ªlow,º using the
procedure underIf Brakes Do Not Grip Well or
Pedal is Lowin this chapter.
*
[DR22025( F )03/91]
Rear Disc Brakes (F-Super Duty and
F-Series Stripped Chassis Only)
*
[DR22050( EFM)04/95]
The rear disc brakes are self-adjusting. They do
not require service other than periodic
lubrication of the caliper slide rails and
inspection for pad wear.
*
[DR22100( ALL)11/89]
Hydraulic Power Brakes
*
[DR22200(BEF )08/94]
The hydraulic brake system is made up of two
independent hydraulic circuits. One hydraulic
circuit supplies fluid to the front disc brakes and
the other hydraulic circuit supplies fluid to the
rear drum brakes. These two circuits are
supplied by a common hydraulic brake fluid
reservoir, with a fluid level sensor.
*
[DR22300( ALL)11/89]
The brake light in the instrument cluster will
light for low brake fluid in the common brake
fluid reservoir.
*
[DR22400( ALL)05/95]
RWARNING
An increase in pedal travel will result in
reduced braking capability. The brake
system should be checked immediately.
File:ltdrf.ex
Update:Thu May 9 15:17:55 1996

203
*
[DR22500( F )10/94]
Rear Anti-lock Brakes
*
[DR22600( F )02/92]
Except for F-Super Duty and F-Series
Commercial and Motorhome Stripped Chassis,
F-Series Light Trucks are equipped with a Rear
Antilock Brake System. This system prevents at
least one and often both rear wheels from
locking up when the brakes are applied in a
panic stop, for example.
*
[DR22800( EF )07/94]
Even with the Anti-lock Brake System, you
should be careful when braking. Front brake
lock up on any surface, even on smooth
pavement causes loss of steering control. Heavy
braking on roads with loose surfaces such as
snow or gravel, or severe pavement irregularities
could also cause you to lose steering control of
your vehicle.
*
[DR22900( EF )05/95]
RWARNING
If the anti-lock brake system warning
light remains on or comes on while
driving, have the braking system checked
by a qualified service technician as soon
as possible.
*
[DR22902( EF )05/95]
NOTE: If a fault occurs in the anti-lock
system, and the brake warning light is
not lit, the anti-lock system is disabled
but normal brake function remains
operational.
*
[DR23100( F )11/89]
If Brakes Do Not Grip Well or Pedal is
ªLowº (F-150/350 Only)
*
[DR23200(BEF )11/89]
If brakes do not grip well, it may indicate the
rear drum brakes need adjustment. To do this,
drive the vehicle in reverse at 5 mph (8 km/h)
on level, dry pavement. Stop the vehicle by
firmly applying the brakes. Repeat this
procedure four or five times.
File:ltdrf.ex
Update:Thu May 9 15:17:55 1996

204
*
[DR23250( ALL)11/89]
If during normal operation the brake pedal
seems ªlowº, it may indicate the need for a
brake system inspection and/or service. You
should have your brakes checked as soon as
possible.
*
[DR23300( ALL)02/95]
Occasional brake squeal during light to moderate
stops does not affect the function of the brake
system and is normal. However, if the squeal
becomes annoyingly loud or increases
significantly in frequency of occurrence, return
the vehicle to your dealer for inspection.
*
[DR23400(BEF )11/89]
RWARNING
Modifications to the suspension spring
rates and/or vehicle ride height may
adversely affect vehicle stopping ability.
*
[DR23500(BEF )07/92]
If Brakes Pull
*
[DR23600(BEF )07/92]
q
Check tire pressure
*
[DR23700(BEF )07/92]
q
Perform the self-adjustment procedure
described underIf Brakes Do Not Grip Well or
Pedal is ªLow.º
*
[DR23800(BEF )05/95]
If pull occurs during the first 500 miles
(800 km), make 10 moderately fast stops from
40 mph (65 km/h) and then perform the
self-adjustment procedure above. It may be
necessary to repeat this operation to properly
seat new brake linings and pads.
*
[DR24000( ALL)01/93]
Stopping Distances
*
[DR24100( ALL)11/89]
Stopping distances vary with different loads and
driving conditions. Use caution when
encountering new conditions and acquaint
yourself with vehicle performance. Take full
advantage of engine braking power when
slowing down.
File:ltdrf.ex
Update:Thu May 9 15:17:55 1996

205 %
*
[DR24200( ALL)01/95]
Applying the Brakes
*
[DR24300( ALL)05/95]
Apply the brake pedal gradually. Use the
ªsqueezeº technique Ð push on the brake pedal
with a steadily increasing force. This allows the
wheels to continue to roll while you are slowing
down, which lets you steer properly.
*
[DR24400( ALL)05/95]
RWARNING
Do not drive with your foot resting on the
brake pedal. This will increase your
vehicle's stopping distance and may also
cause brake damage.
*
[DR24500( ALL)05/95]
RWARNING
If you are driving down a long or steep
hill, shift to a lower gear. Do not apply
your brakes continuously, as they may
overheat and become less effective.
*
[DR24600( ALL)03/95]
Using the Parking Brake
*
[DR24650(BEF )01/95]
The parking brake should be used whenever you
park your vehicle.
*
[DR24800(B F )12/91]
The parking brake pedal is suspended just below
the bottom of the instrument panel to the left of
service brake and/or clutch pedals. To set the
parking brake while parking your vehicle, press
the brake pedal with your right foot and hold it
while you push the parking brake pedal down
firmly and fully with your left foot.
File:ltdrf.ex
Update:Thu May 9 15:17:55 1996

206
*
[DR24920(B FM)07/91]
one third page art:0020893-A
Parking Brake
*
[DR24950(B F )03/95]
RWARNING
When parking, do not use the gearshift in
place of the parking brake. Turn the key
to LOCK whenever you leave your
vehicle. Always set the parking brake
fully and make sure that the gearshift is
securely latched in P (Park) (automatic
transmission) or in 1 (First) (manual
transmission). Never leave your vehicle
unattended while it is running. If you do
not take these precautions, your vehicle
may move unexpectedly and injure
someone.
[DR24970(B F )05/95]
When the transfer case is in the N (Neutral)
position, the engine and transmission are
disconnected from the rest of the driveline.
Therefore, the vehicle is free to roll even if the
automatic transmission is in P (Park) or the
manual transmission is in gear.
File:ltdrf.ex
Update:Thu May 9 15:17:55 1996

207
*
[DR24975(B F )05/95]
RWARNING
Do not leave the vehicle unattended with
the transfer case in the N (Neutral)
position. Always set the parking brake
fully and turn off the ignition when
leaving the vehicle.
*
[DR25000(B FM)03/93]
To release the parking brake, press the service
brake pedal with your right foot and pull the
parking brake release lever.
*
[DR25050( ALL)01/93]
RWARNING
If the parking brake is fully released, but
the Brake System light remains on, have
the brakes checked immediately. They
may not be working properly.
*
[DR25100( ALL)01/95]
The parking brake is not designed to stop a
moving vehicle, but you can use the parking
brake to stop your vehicle in an emergency if
the normal brakes fail. However, since the
parking brake applies only the rear brakes, the
stopping distance will increase greatly and the
handling of your vehicle will be adversely
affected.
*
[DR25200( ALL)01/95]
Driving Under Special Conditions
*
[DR25250( ALL)01/95]
Tips for Safe Driving
*
[DR25301( ALL)05/95]
As with any new vehicle, yours may drive and
handle differently from your previous vehicle.
Use care until you become accustomed to its
various features and driving characteristics.
*
[DR25350( ALL)03/95]
Operate your vehicle within reasonable limits.
Sudden acceleration, deceleration, turning, or
combinations of these maneuvers can cause a
vehicle to behave differently than anticipated.
File:ltdrf.ex
Update:Thu May 9 15:17:55 1996

208
*
[DR25501( ALL)02/95]
Wheel Spin
*
[DR25550( ALL)11/92]
q
Extreme acceleration can cause the rear
wheels to spin, perhaps resulting in reduced
steering control.
*
[DR25601( ALL)05/90]
If the wheels spin during vehicle start-up, shift
to a different gear:
*
[DR25750(B F )03/93]
q
Automatic Overdrive 4R7OW: use 2 (Second)
*
[DR25800( ALL)03/93]
q
Electronic 4-Speed Automatic Transmission
E4OD: use 2 (Second)
*
[DR25950(B F )05/90]
q
Mazda R2 5-Speed Overdrive Manual: use 2
(Second)
*
[DR26001( F )01/93]
q
4-Speed Manual: use 3 (Third)
*
[DR26050( EF )05/90]
q
3-Speed Automatic (C6): use 2 (Second)
*
[DR26201( F )01/89]
q
Heavy Duty ZF S5-42 5-Speed Manual with
Overdrive (Unloaded): use 3 (Third)
*
[DR26250( F )01/89]
q
Heavy Duty ZF S5-42 5-Speed Manual with
Overdrive (loaded): use 2 (Second)
*
[DR26301( ALL)01/89]
Move forward slowly and evenly. If this does
not work, try rocking the vehicle.
*
[DR26401(B F )05/91]
For 4x4 vehicles, engage 4WD, and try to drive
away.
*
[DR26550( ALL)05/90]
High Speed Driving
*
[DR26575( ALL)05/95]
Ford Motor Company recommends obeying
posted speed limits.
*
[DR26601( ALL)05/95]
RWARNING
Driving too fast for conditions creates the
possibility of loss of vehicle control.
Driving at very high speeds for extended
periods of time may result in damage to
vehicle components.
File:ltdrf.ex
Update:Thu May 9 15:17:55 1996
