FORD F150 1996 10.G Owners Manual

189
*
[DR16310(B F )01/95]
Four-wheel drive operation (4H or 4L) on dry
pavement is not recommended. Operating the
vehicle in four-wheel drive on dry pavement
will increase tire wear, decrease fuel economy,
and make four-wheel drive disengagement
difficult for the transfer case.
*
[DR16340( F )06/93]
NOTE: All transfer cases on F-350 4x4 trucks
are equipped with an opening for a
power take-off (PTO). If this opening
is used for a transfer case mounted
PTO, additional transfer case lubricant
is required. Refer to the Refill
Capacities section for lubricant fill
requirements. Vehicles equipped with
an E4OD automatic transmission and a
7.3L diesel engine will require exhaust
modification for PTO clearance. For
vehicles equipped with an E4OD
automatic transmission: If a transfer
case mounted PTO is operated with the
transfer case shift lever in neutral, a
Vehicle Speed Sensor Self-test error
may be set in the Powertrain Control
Module (PCM) causing the
transmission to function abnormally,
and the Transmission Control Indicator
Light (TCIL) may flash on and off
repeatedly. Normal transmission
function should return when the
transfer case has been engaged and the
vehicle is driven. If the TCIL continues
to flash or the transmission continues
to operate abnormally contact your
Ford dealer as soon as possible.
File:ltdrf.ex
Update:Thu May 9 15:17:55 1996

190
*
[DR16370(B F )06/94]
4x4 system indicator lights
*
[DR16401(B F )06/94]
A 4x4 light and a LOW RANGE light are
located at the lower right of the instrument
cluster.
*
[DR16430(B F )06/94]
q
2H position Ð Neither the 4X4 or the LOW
RANGE lights are lit.
*
[DR16460(B F )06/94]
q
4H position Ð Only the 4x4 light is lit.
*
[DR16490(B F )06/94]
q
N position Ð Neither the 4x4 or LOW
RANGE lights are lit.
*
[DR16520(B F )06/94]
q
4L position Ð Both the 4x4 and the LOW
RANGE lights are lit.
*
[DR16550(B F )03/91]
Lever Operated System With Automatic
Locking Hubs
*
[DR16580(B F )06/94]
To shift from 2H to 4H:
*
[DR16610(B F )02/92]
Stop the vehicle and move the transfer case shift
lever straight back to the 4H position, the
automatic locking hubs will engage when the
vehicle is driven. When the automatic locking
hubs are engaged, shifts between 2H and 4H
may take place at any speed.
*
[DR16620(B F )02/92]
q
The automatic locking hubs may disengage in
2H if the vehicle's direction is momentarily
reversed, or the vehicle is allowed to roll
slightly in the opposite direction. If a
grinding noise occurs when shifting from 2H
to 4H while the vehicle is moving, one or
both of the automatic locking hubs have been
disengaged and the transfer case shift lever
should be switched back to the 2H position.
To shift back into 4H, stop the vehicle and
move the transfer case shift lever straight
back to the 4H position.
File:ltdrf.ex
Update:Thu May 9 15:17:55 1996

191
*
[DR16630(B F )05/91]
q
When the vehicle is stopped while in 4H and
the vehicle's direction is reversed from the
previous direction, the automatic locking hubs
momentarily disengage and then re-engage.
The automatic locking hubs may click as they
automatically engage in the new direction.
*
[DR16640(B F )06/94]
To shift from 4H to 2H:
*
[DR16670(B F )03/93]
Move the transfer case shift lever straight
forward to the 2H position. This can be done at
any speed. To disengage the automatic locking
hubs, operate the vehicle in 2H in the opposite
direction for approximately 10 feet (3 meters).
*
[DR16701(B F )06/94]
For example:
*
[DR16730(B F )03/93]
If you were driving the vehicle forward in
4H, the automatic locking hubs will
disengage the next time the vehicle is driven
in reverse in 2H for approximately 10 feet (3
meters).
*
[DR16760(B F )03/93]
If you were driving the vehicle in reverse in
4H, the automatic locking hubs will
disengage the next time the vehicle is driven
forward in 2H for approximately 10 feet (3
meters).
*
[DR16790(B F )03/91]
Ð Operating in 2H with the hubs locked
increases fuel consumption, noise, vibration, and
wear. For prolonged 2H operation on dry
pavement, disengage the automatic locking hubs.
*
[DR16820(B F )06/94]
To shift between 4H and 4L:
*
[DR16851(B F )05/91]
Stop the vehicle and place the automatic
transmission into NEUTRAL or depress the
clutch on manual transmission vehicles. Push the
transfer case shift knob down (toward the
ground) and at the same time pull or push the
lever straight forward or rearward (depending
on the desired position, 4H or 4L) in order to
shift the transfer case. This shift should be in
File:ltdrf.ex
Update:Thu May 9 15:17:55 1996

192one continuous motion without pausing in the N
(neutral) position. Pausing in the neutral position
can result in gear clash and difficult shifting. If,
while shifting between 4H and 4L, the transfer
case gets stuck in the N (neutral) position or is
difficult to shift into either 4H or 4L, it may be
necessary to let the vehicle roll slightly and/or
turn off the engine (particularly on vehicles
equipped with automatic transmissions).
*
[DR16880(B F )03/91]
To shift into and out of N (neutral)
*
[DR16910( F )05/91]
To shift into N (neutral), stop the vehicle and
engage the parking brake. Place the automatic
transmission into NEUTRAL or depress the
clutch on manual transmission vehicles. From
either the 4H or 4L position, push the transfer
case shift knob down (toward the ground) and
at the same time move the transfer case shift
lever to the N (neutral) position. The N (neutral)
position should only be used for vehicle towing
or transfer case mounted PTO use (transfer case
PTO opening available on F-350 only).
*
[DR16955(B F )12/91]
NOTE: Dash mounted four wheel drive
indicator lights are off when your
vehicle is in neutral.
*
[DR17001(B F )05/91]
To shift from N (Neutral) to either 4H or 4L,
stop the vehicle and engage the parking brake.
Place the automatic transmission into NEUTRAL
or depress the clutch on manual transmission
vehicles. Push the transfer case knob down
(toward the ground) and at the same time move
the transfer case shift lever to the desired
position. If it is difficult to shift into either 4H or
4L, it may be necessary to let the vehicle roll
slightly and/or turn off the engine (particularly
on vehicles equipped with automatic
transmissions).
File:ltdrf.ex
Update:Thu May 9 15:17:55 1996

193
*
[DR17030(B F )06/94]
Lever Operated System With Manual
Locking Hubs
*
[DR17060(B F )06/94]
To shift from 2H to 4H:
*
[DR17090(B F )06/94]
Stop the vehicle and engage the manual locking
hubs by turning both hub lock selector knobs
clockwise to the LOCK position. Move the
transfer case shift lever straight back to the 4H
position. After both hubs have been turned to
the LOCK position, shifts between 2H and 4H
(or 4H to 2H) may take place at any speed.
*
[DR17120(B F )03/91]
one third page art:0020146-C
Locking hub positions
*
[DR17150(B F )06/94]
q
Do not drive the vehicle in 4H or 4L with the
manual locking hubs in the FREE position.
*
[DR17180(B F )06/94]
q
Do not drive the vehicle with the left and
right manual locking hubs set to different
positions.
*
[DR17210(B F )06/94]
To shift from 4H to 2H:
*
[DR17240(B F )06/94]
Move the transfer case shift lever forward to the
2H position. This can be done at any speed.
However, the front driveline will remain
engaged to the front wheels until the manual
locking hubs are disengaged. To disengage the
manual locking hubs, stop the vehicle and rotate
both hub lock selector knobs counter-clockwise
to the FREE position.
File:ltdrf.ex
Update:Thu May 9 15:17:55 1996

194
*
[DR17270(B F )06/94]
Operating in 2H with the hubs in the LOCK
position increases fuel consumption, noise,
vibration, and wear. For prolonged 2H operation
on dry pavement, set the manual locking hubs
to the FREE position.
*
[DR17301(B F )06/94]
To shift between 4H and 4L:
*
[DR17330(B F )05/91]
Stop the vehicle and place the automatic
transmission into NEUTRAL or depress the
clutch on manual transmission vehicles. Push the
transfer case shift knob down (toward the
ground) and at the same time pull or push the
lever straight forward or rearward (depending
on the desired position 4H or 4L) in order to
shift the transfer case. This shift should be with
one continuous motion without pausing in the N
(neutral) position. Pausing in the neutral position
can result in gear clash and difficult shifting. If,
while shifting between 4H and 4L, the transfer
case gets stuck in the N (neutral) position or is
difficult to shift into either 4H or 4L, it may be
necessary to let the vehicle roll slightly and/or
turn off the engine (particularly on vehicles
equipped with automatic transmission).
*
[DR17390(B F )06/94]
To shift to N (neutral) from either 4H or 4L
*
[DR17420( F )05/91]
To shift into N (neutral), stop the vehicle and
engage the parking brake. Place the automatic
transmission into NEUTRAL or depress the
clutch on manual transmission vehicles. From
either the 4H or 4L position, push the transfer
case shift knob down (toward the ground) and
at the same time move the transfer case shift
lever to the N (neutral) position. The N (neutral)
position should only be used for vehicle towing
or transfer case mounted PTO use (transfer case
PTO opening available on F-350 only).
File:ltdrf.ex
Update:Thu May 9 15:17:55 1996

195
*
[DR17490(B F )12/91]
NOTE: Dash mounted four wheel drive
indicator lights are off when your
vehicle is in neutral.
*
[DR17540(B F )01/95]
To shift from N (Neutral) to either 4H or 4L,
stop the vehicle and engage the parking brake.
Place the automatic transmission into N
(Neutral) or depress the clutch on manual
transmission vehicles. Push the transfer case shift
lever to the desired position. If it is difficult to
shift into either 4H or 4L, it may be necessary to
let the vehicle roll slightly and/or turn off the
engine (particularly on vehicles equipped with
automatic transmissions).
*
[DR17570(B F )06/94]
4x4 SYSTEMS-TOUCH DRIVE
*
[DR17601(B F )06/94]
The Touch Drive 4x4 system functions in three
modes. In Two Wheel Drive mode, power is
delivered only to the rear axle at normal road
speed. The 4H position provides four-wheel
drive with power delivered to the front and rear
axles for increased traction. The 4L position
provides four-wheel drive with power delivered
to the front and rear axles when the above
average power is required at reduced speeds.
*
[DR17630(B F )06/94]
Four wheel drive operation (4x4 or 4x4 LOW
RANGE) on dry pavement is not recommended.
Operating the vehicle in four-wheel drive on dry
pavement will increase noise, vibration, tire
wear, decrease fuel economy, and make
four-wheel drive disengagement difficult for the
transfer case.
%*
[DR17660(B F )06/94]
Touch Drive system indicator lights
*
[DR17690(B F )03/91]
A 4x4 indicator light and a LOW RANGE
indicator light are located at the lower right of
the instrument cluster. In addition, two small
amber lights are located near the Touch Drive
system buttons. The amber light to the left of the
4x4 button will light up at the same time as the
File:ltdrf.ex
Update:Thu May 9 15:17:55 1996

1964x4 instrument panel light. The amber light to
the left of the LOW RANGE light will light up
at the same time as the instrument panel LOW
RANGE light.
*
[DR17750(B F )06/94]
q
Two Wheel Drive mode Ð Neither the 4x4
nor the LOW RANGE lights are lit.
*
[DR17780(B F )06/94]
q
4x4 mode Ð Only the 4x4 light is lit.
*
[DR17810(B F )06/94]
q
4x4 LOW RANGE mode Ð Both the 4x4 and
LOW RANGE lights are lit.
*
[DR17840(B F )06/94]
To shift from Two-Wheel Drive to 4x4:
*
[DR17871(B F )06/94]
To shift into 4x4, push the 4x4 button located on
the instrument panel. This shift can be done at a
stop or at speeds up to 55 miles per hour
(88 km/h). When the vehicle is driven, the
automatic locking hubs will engage. If the
vehicle is stopped while in 4x4 and the vehicle
direction is reversed from the previous direction,
the automatic locking hubs will momentarily
disengage and reengage. The automatic locking
hubs may click as they automatically engage in
the new direction.
*
[DR17900(B F )05/91]
one third page art:0020634-B
Touch drive electric shift switch
*
[DR17945(B F )06/92]
Ð At extremely low temperatures, it may be
necessary to slow down or even stop to shift
from two wheel drive to 4x4.
File:ltdrf.ex
Update:Thu May 9 15:17:55 1996

197
*
[DR17960(B F )06/94]
Ð The initial shift from two-wheel drive to 4x4
while the vehicle is moving can cause some
momentary clunk and ratcheting sounds. This is
the front drivetrain coming up to speed and the
automatic locking hubs engaging and is not a
cause for concern.
*
[DR17990(B F )12/91]
Ð Because of possible damage to powertrain
components, never shift from Two-Wheel Drive
to 4x4 with the rear wheels slipping.
*
[DR18020(B F )06/94]
To shift from 4x4 to Two-Wheel Drive:
*
[DR18050(B F )06/94]
Push the 4x4 button; the 4x4 lamp on the
instrument cluster will go out indicating the
vehicle is in Two-Wheel Drive. This can be done
at any speed. To disengage the automatic
locking hubs, operate the vehicle in Two-Wheel
Drive in the opposite direction for approximately
10 feet (3 meters) in a straight line.
*
[DR18080(B F )06/94]
For example:
*
[DR18110(B F )06/94]
If you were driving the vehicle forward in
4x4, the automatic locking hubs will
disengage the next time the vehicle is driven
in reverse in Two-Wheel Drive for
approximately 10 feet (3 meters) in a straight
line.
*
[DR18140(B F )06/94]
If you were driving the vehicle in reverse in
4x4, the automatic locking hubs will
disengage the next time the vehicle is driven
forward in Two-Wheel Drive for
approximately 10 feet (3 meters) in a straight
line.
*
[DR18170(B F )01/95]
Operating in two-wheel drive mode with the
hubs locked increases fuel consumption, noise,
vibration, and wear. For prolonged two-wheel
drive operation on dry pavement, disengagement
of the automatic locking hubs, which is not
required for two-wheel drive operation, stops all
File:ltdrf.ex
Update:Thu May 9 15:17:55 1996

198movement of front-wheel drive components
while operating in two-wheel drive.
*
[DR18230(B F )03/91]
To shift from 4x4 to 4x4 LOW RANGE:
*
[DR18290(B F )06/92]
Stop the vehicle and place the automatic
transmission in NEUTRAL or depress the clutch
on vehicles with a manual transmission. Push
the LOW RANGE button on the instrument
panel to shift the transfer case from 4x4 to 4x4
LOW RANGE. Both the 4x4 and LOW RANGE
lights are now lit.
*
[DR18300(B F )08/94]
NOTE: The vehicle must already be in 4x4
before pushing the Low Range Button.
*
[DR18320(B F )03/91]
To shift from 4x4 LOW RANGE to 4x4:
*
[DR18380(B F )06/94]
Stop the vehicle and place the automatic
transmission into NEUTRAL or depress the
clutch on vehicles with a manual transmission.
Push the LOW RANGE button on the instrument
panel to shift the transfer case from 4x4 LOW
RANGE to 4x4.
*
[DR19200(B F )01/89]
Driving Off Road with 4-Wheel
Drive
*
[DR19300(B F )11/89]
Most vehicles with four-wheel drive are
especially equipped for driving on sand, snow,
mud, or rough terrain and have operating
characteristics that are somewhat different from
conventional vehicles, both off and on the road.
The driving tips below will help you learn to
use four-wheel drive.
*
[DR19400(B F )10/94]
q
Do not use 4WD LOW on dry, hard-surfaced
roads.
*
[DR19600(B F )11/89]
q
Special maintenance procedures are necessary
after operating with drive components in
water.
File:ltdrf.ex
Update:Thu May 9 15:17:55 1996
