ENGINE
ConfigurationSupercharged longitudinally mounted,
90-degree V8, single overhead cam, cast iron
cylinder block and cast aluminum cylinder
heads
Bore x Stroke90.2 x 105.8 mm (3.55 x 4.17 in)
Displacement5409 cc (330.1 cid)
Compression ratio8.4:1
Horsepower
(SAE net)269 kW @ 4750 rpm (360 HP @ 4750 rpm)
Torque597 Nm @ 3000 rpm (440 lb.-ft. @ 3000 rpm)
Redline5250 rpm (fuel shut-off at 5500 rpm)
Specific output49.7 kW/L (66.7 HP/L)
ValvetrainSingle overhead cam, silent-design chain drive,
roller finger followers with hydraulic lash
adjustment, ovate-wire valve springs, two
valves per cylinder
Fuel systemSequential electronic fuel injection
Ignition systemCoil-on-plug electronic ignition
Mass air sensor80 mm (3.15 in) diameter, high flow capacity
Throttle bodyTwin 57 mm (2.24 in) diameter
bore-simultaneously open
SuperchargerEaton-Model 112, Generation IV,
55 kPa (8 psi) mechanical boost
Exhaust manifoldsCast-high silicon, molybdenum iron
Exhaust systemDual-stainless steel
Engine/Transmission
7

REFILL CAPACITIES
Fluid Ford Part Name Capacity
Brake fluid High Performance
DOT 3 Motor Vehicle
Brake FluidFill to line on reservoir
Engine oil (includes
filter change)Motorcraft 5W-30
Super Premium Motor
Oil5.7L (6.0 quarts)
Engine coolant
1Premium Engine
Coolant24.1L (25.5 quarts)
Intercooler coolant
1Premium Engine
Coolant4.0L (4.2 quarts)
Power steering fluid Motorcraft MERCONt
AT FFill to line on reservoir
Rear axle lubricant
2Motorcraft SAE 80W90
Premium Rear Axle
Lubricant3.3-3.8L
(7.5-8.0 pints)
Fuel tank N/A 94.6L (25.0 gallons)
Transmission fluid
3Motorcraft MERCONt
AT F15.0L (15.9 pints)
Windshield washer
fluidUltra-Clear Windshield
Washer Concentrate4.0L (4.25 quarts)
1Use Ford Premium Engine Coolant (green in color). DO NOT USE Ford
Extended Life Engine Coolant (orange in color).
2Fill 6 mm to 14 mm (1/4 inch to 9/16 inch) below bottom of fill hole.
Add 118 ml (4 oz.) of additive friction modifier C8AZ-19B546-A, Ford
specification EST-M2C118±A for complete refill of Traction-Lok axles.
Your vehicle's rear axle is filled with a synthetic rear axle lubricant and is
considered lubricated for life. These lubricants do not need to be
checked or changed unless a leak is suspected, service is required or the
axle assembly has been submerged in water. The axle lubricant should
be changed any time the rear axle has been submerged in water.
3Ensure the correct automatic transmission fluid is used. Transmission
fluid requirements are indicated on the dipstick or on the dipstick
handle. MERCONtand MERCONtV are not interchangeable. DO NOT
mix MERCONtand MERCONtV. Refer to your Scheduled Maintenance
Guide to determine the correct service interval.
Maintenance
12
