torque FORD F150 1999 10.G SVT Supplement Manual

ENGINE
ConfigurationSupercharged longitudinally mounted,
90-degree V8, single overhead cam, cast iron
cylinder block and cast aluminum cylinder
heads
Bore x Stroke90.2 x 105.8 mm (3.55 x 4.17 in)
Displacement5409 cc (330.1 cid)
Compression ratio8.4:1
Horsepower
(SAE net)269 kW @ 4750 rpm (360 HP @ 4750 rpm)
Torque597 Nm @ 3000 rpm (440 lb.-ft. @ 3000 rpm)
Redline5250 rpm (fuel shut-off at 5500 rpm)
Specific output49.7 kW/L (66.7 HP/L)
ValvetrainSingle overhead cam, silent-design chain drive,
roller finger followers with hydraulic lash
adjustment, ovate-wire valve springs, two
valves per cylinder
Fuel systemSequential electronic fuel injection
Ignition systemCoil-on-plug electronic ignition
Mass air sensor80 mm (3.15 in) diameter, high flow capacity
Throttle bodyTwin 57 mm (2.24 in) diameter
bore-simultaneously open
SuperchargerEaton-Model 112, Generation IV,
55 kPa (8 psi) mechanical boost
Exhaust manifoldsCast-high silicon, molybdenum iron
Exhaust systemDual-stainless steel
Engine/Transmission
7
