One touch down
²Press AUTO completely down and
release quickly. The driver's
window will open fully. Depress
again to stop window operation.
One touch down can be deactivated
during operation by pushing down
on the top part of the driver power
window control.
Accessory delay (if equipped)
With accessory delay, the window switches may be used for up to ten
minutes after the ignition switch is turned to the OFF position or until
any door is opened.
MIRRORS
Automatic dimming rear view mirrors (if equipped)
Your vehicle is equipped with an inside rear view mirror with an
auto-dimming function. The electronic day/night mirror will change from
the normal state to the non-glare state when bright lights (glare) reach
the inside rear view mirror. When the inside rear view mirror detects
bright light from behind the vehicle, the inside rear view mirror will
automatically adjust (darken) to minimize glare.
Do not block the sensor on the backside of the inside rear view mirror
since this may impair proper system performance.
Press the control to turn the mirror
OFF or AUTO.
The mirror will automatically return
to the normal state whenever the
vehicle is placed in R
(Reverse)(when the mirror is on) to ensure a bright clear view when
backing up.
AUTO
OFF AUTO
Driver Controls
86

Passenger compartment fuse panel
The fuse panel is located below and to the left of the steering wheel by
the brake pedal. Remove the panel cover to access the fuses.
To remove a fuse use the fuse puller tool provided on the fuse panel
cover.
The fuses are coded as follows.
Fuse/Relay
LocationFuse Amp
RatingPassenger Compartment Fuse
Panel Description
1 15A Audio
2 5A Powertrain Control Module
(PCM), Cluster
3 20A Cigar Lighter, Data Link
Connector
4 5A Exterior Rear View Mirror Switch,
Mirror turn Signal Relays
FUSE1 12 22
21323
617 27
718 28
819 29
930
20
31 21 11 10
RELAY
5 RELAY
4 RELAY
3 RELAY
2 RELAY
1
31424
41525
51626
Roadside Emergencies
214

daytime running light ...............66
fog lamps ...................................65
headlamps .................................65
headlamps, flash to pass ..........66
instrument panel, dimming .....67
interior lamps .....................68±69
replacing bulbs .............69, 71±75
Lane change indicator
(see Turn signal) ........................67
Lights, warning and indicator ....10
air bag ........................................13
anti-lock brakes (ABS) ....12, 171
anti-theft ...................................15
brake ..........................................12
charging system ........................13
check coolant ............................13
cruise indicator .........................14
door ajar ....................................14
engine oil pressure ...................13
fuel cap light .............................12
high beam .................................14
low fuel ......................................13
low washer fluid .......................14
safety belt .................................13
service engine soon ..................11
speed control ............................92
turn signal indicator .................14
Load limits .................................197
GAWR ......................................197
GVWR ......................................197
trailer towing ..........................197
Loading instructions .................199
Locks
autolock ...................................113
childproof ................................107
Lubricant
specifications .....................299, 301
Lumbar support, seats .............123M
Manual transmission .................178
fluid capacities ........................295
lubricant specifications ..........301
reverse .....................................183
Mirrors .........................................78
automatic dimming rearview
mirror ........................................86
fold away ...................................88
side view mirrors (power) .......87
Moon roof ....................................92
Motorcraft parts ................276, 294
O
Octane rating ....................274±275
Odometer .....................................19
Oil (see Engine oil) ..................258
Overdrive .....................................84
P
Panic alarm feature, remote
entry system ..............................110
Parking brake ............................172
Parts (see Motorcraft parts) ....294
Pedals (see Power adjustable
foot pedals) .................................88
Power distribution box
(see Fuses) ...............................217
Power door locks ..............106, 113
Power steering ..........................173
fluid, checking and adding ....282
fluid, refill capacity ................295
fluid, specifications .........299, 301
