FORD F150 2002 10.G SVT Supplement Manual

OPTIONS, COLOR AND TRIM
²Tonneau cover
Exterior:
²Black Clearcoat
²True Blue Clearcoat
²Bright Red Clearcoat
²Silver Clearcoat
Interior:
²Medium Graphite Leather/Cloth
Options, color and trim
11

MOTORCRAFT PART NUMBERS
Component 5.4L Supercharged V8 engine
Air filter element FA-1634
Fuel filter FG-986B
Battery BXT-65-650
Oil filter FL-820S
PCV valve EV-233
Spark plugs
1AGSF-12FM1
1Refer to Vehicle Emissions Control Information (VECI) decal for spark
plug gap information.
REFILL CAPACITIES
Fluid Ford Part Name Capacity
Brake fluid Motorcraft High
Performance DOT 3
Motor Vehicle Brake
FluidFill to line on reservoir
Engine oil (includes
filter change)Motorcraft SAE 5W-20
Super Premium Motor
Oil5.7L (6.0 quarts)
Engine coolant
1Motorcraft Premium
Engine Coolant
(green-colored)or
Motorcraft Premium
Gold Engine Coolant
(yellow-colored)24.1L (25.5 quarts)
Intercooler coolant
14.0L (4.2 quarts)
Power steering fluid Motorcraft MERCONt
AT FFill to line on reservoir
Rear axle lubricant
2Motorcraft SAE
80W-90 Premium Rear
Axle Lubricant3.3-3.8L (7.5-8.0
pints)
Fuel tank N/A 94.6L (25.0 gallons)
Transmission fluid
3Motorcraft MERCONt
AT F16.1L (17.0 quarts)4
Maintenance
12

Fluid Ford Part Name Capacity
Windshield washer
fluidUltra-Clear Windshield
Washer Concentrate4.0L (4.25 quarts)
1Add the coolant type originally equipped in your vehicle.
2Fill 6 mm to 14 mm (1/4 inch to 9/16 inch) below bottom of fill hole.
Add 118 ml (4 oz.) of Additive Friction Modifier C8AZ-19B546-A or
equivalent meeting Ford specification EST-M2C118±A for complete refill
of Traction-Lok axles.
Your vehicle's rear axle is filled with a synthetic rear axle lubricant and is
considered lubricated for life. These lubricants do not need to be
checked or changed unless a leak is suspected, service is required or the
axle assembly has been submerged in water. The axle lubricant should
be changed any time the rear axle has been submerged in water.
3Ensure the correct automatic transmission fluid is used. Transmission
fluid requirements are indicated on the dipstick or on the dipstick
handle. Check the container to verify the fluid being added is of the
correct type. Refer to your scheduled maintenance guide to determine
the correct service interval.
Some transmission fluids may be labeled as dual usage, such as
MERCONtand MERCONtV. These dual usage fluids are not to be used
in an automatic transmission that requires use of the MERCONttype
fluid. However, these dual usage fluids may be used in transmissions that
require the MERCONtV type fluid.
MERCONtand MERCONtV type fluids are not interchangeable.
DO NOT mix MERCONtand MERCONtV. Use of a transmission
fluid that indicates dual usage (MERCONtand MERCONtV) in
an automatic transmission application requiring MERCONtmay
cause transmission damage. Use of any fluid other than the
recommended fluid may cause transmission damage.
4Approximate dry fill capacity including transmission fluid cooling
system, actual refill capacities will vary based on vehicle application and
transmission fluid cooling system (i.e. coolers size, cooling lines. auxiliary
cooler capacities). The amount of transmission fluid and fluid level
should be set by the indication on the dipstick's normal operating range.
Maintenance
13

OCTANE RECOMMENDATIONS
Your vehicle is designed to use
ªPremiumº unleaded gasoline with
an (R+M)/2 octane rating of 91 or
higher for optimum performance.
The use of gasolines with lower
octane ratings may degrade performance. We do not recommend the use
of gasolines labeled as ªPremiumº in high altitude areas that are sold
with octane ratings of less than 91.
If your engine knocks under any driving conditions while you are using
fuel with the recommended octane rating, see your dealer or a qualified
service technician to prevent any engine damage.
WHEELS AND TIRES
Tires295/45 ZR 18 BSW tires
WheelsSVT-Signature style, 18 in x 9.5 in aluminum
5-spoke wheels
TIRE ROTATION
Because your vehicle's tires perform
different jobs, they often wear
differently. To make sure your tires
wear evenly and last longer, rotate
them as indicated in the scheduled
maintenance guide. If you notice
that the tires wear unevenly, have
them checked.
SPARE TIRE AND WHEEL
Your vehicle is equipped a 235/70R-16 spare tire on a steel wheel rim.
This is for temporary use only. Replace this spare tire with a repaired
road tire as soon as possible.
91(R+M)/2 METHOD
Maintenance
14

A WORD ABOUT WARRANTY COVERAGE
The F±150 Lightning carries the same warranty coverage as other Ford
F-150 models. This information is covered in its entirety in the Ford
Motor Company Warranty Guide.
The F±150 Lightning or any SVT can be serviced under warranty at any
Ford-Lincoln-Mercury dealer nationwide.
SVT does not recommend modifying or racing our vehicles, as they are
designed and built to be driven as delivered from the factory. The Ford
Motor Company Warranty Guide discusses the installation of aftermarket
parts and their effect on warranty coverage as follows:
Repairs are not reimbursable under warranty when:
²ªThe repairs are required because of abuse, misuse, racing, fire,
negligence, accident, modification or a natural disaster.º
²ªThe repairs are required due to installation of a non-Ford part.º
A word about warranty coverage
15
