•Longer, cast aluminum lower control arms
•Longer, forged steel upper control arms
•Front coil springs and rear leaf springs
•Fox Racing 47mm piston internal bypass front shocks
•Fox Racing 47mm pistons, internal bypass, remote reservoir rear
shocks
•Micro-cellular urethane jounce bumpers (front and rear)
•Raptor navigation welcome screen
•17” cast aluminum wheels and 315/70-17 BFGoodrichall-terrain tires
•Full size all-terrain spare tire
•Off-road specific calibrations for engine, transmission and
AdvanceTractraction control system
•Instrument panel cluster graphics
•Steering wheel - unique wrap with on-center marker, thumb pads, and
improved grip contour
•Door trim inserts and center stack trim
•Off-road style floor mats with SVT logo
F-150 SVT Raptor specific features
5
2010 F-150(f12)
Supplement, 1st Printing
USA(fus)

WHEELS AND TIRES
TiresLT315/70R17 BSW tires
WheelsSVT-Signature style, 17 in x 8.5 in
aluminum 6-spoke wheels
TIRE ROTATION
Because your vehicle’s tires perform
different jobs, they often wear
differently. To make sure your tires
wear evenly and last longer, have
them rotated.Note:The F-150
Raptor requires tire rotations every
5,000 miles (8,000 km). If you
notice that the tires wear unevenly,
have them checked.
SPARE TIRE AND WHEEL
Your vehicle is equipped with an LT315/70R17 spare tire. The spare
tire/wheel assembly has the same capability as the road tire/wheel
assembly, but is not equipped with a tire pressure monitoring sensor. If
TPMS functionality is desired, a TPMS sensor must be installed in the
spare tire/wheel assembly. Note that the spare wheel is painted black to
differentiate it from the road wheels.
Maintenance
25
2010 F-150(f12)
Supplement, 1st Printing
USA(fus)

VALUE SHOPPING FOR YOUR VEHICLE’S MAINTENANCE NEEDS
Your dealership recognizes the competitive landscape of maintenance and
light repair automotive services. With factory-trained technicians and
one-stop service for everything from routine maintenance like oil changes
and tire rotations to your most complex needs, Ford and Lincoln
Mercury Dealerships offer outstanding value.
It is recommended that the following basic maintenance checks and
inspections be performed at the designated time intervals. See your
“Owner’s Guide” for more information.
Check every month for all vehicles
❑Check function of all interior and exterior lights.❑Check tires for wear and proper air pressure, including spare.
❑Check engine oil fluid level.
❑Check windshield washer fluid level.
Check every six months for all vehicles
❑Check lap/shoulder belts and seat latches for wear and proper operation.❑Check that externally mounted spare tire is properly stowed (tight) (see yourOwner’s Guide).
❑Check power steering fluid level, if equipped.
❑Check washer spray, wiper operation, and clean all wiper blades (replace blades as necessary).
❑Check parking brake for proper operation.
❑Check and lubricate all hinges, latches, door check straps (see dealer) and outside locks.
❑Check and lubricate upper and lower sliding door tracks, if equipped.
❑Check and clean sliding door contact switches, if equipped.
❑Check and lubricate door rubber weatherstrips.
❑Check and clean body and door drain holes.
❑Check safety warning lamps (brake, ABS, air bag, safety belt) for operation.
❑Check engine cooling system level and strength.
❑Check battery connections and clean if necessary.
❑Check clutch fluid level, if equipped.
Retightening lug nuts
❑On vehicles equipped with dual rear wheels, retighten the wheel lug nuts to the specified torque at 100 miles (160 km),
and again at 500 miles (800 km) of new vehicle operation and after any wheel disturbance (tire rotation, changing a flat
tire, wheel removal, etc.).
❑Refer toWheel Lug Nut Torque Specificationin yourOwner’s Guidefor the proper lug nut torque specification.
Scheduled Maintenance Guide
35
2010 F-150(f12)
Supplement, 1st Printing
USA(fus)

If your Ford or Lincoln Mercury dealership sells the name-brand tire,
they can also honor the tire manufacturer’s warranty.
Tires degrade over time depending on many factors such as weather,
storage conditions, and conditions of use (load, speed, inflation, etc.) the
tires experience throughout their lives. In general, tires should be
replaced after 6 years, regardless of tread wear. However, heat caused by
hot climates or frequent high loading conditions can accelerate the aging
process and may require the tires to be replaced more frequently. You
should replace your spare tire when you replace your road tires or after
6 years due to aging even if the tire has not been used.
BATTERIES
The technicians at your Ford or
Lincoln Mercury dealership can
determine the health of your
vehicle’s battery during any service
visit. The Motorcraft Tested Tough
Max Series with its “long-life” design
outlasted other long-life batteries by
up to 200%. That’s one reason why
we stand behind this battery with a
national, 3-year, free replacement
warranty and prorated-cost replacement thereafter for up to 100 months
and unlimited mileage. Should your battery need to be replaced, please
consider a Motorcraft brand battery that meets your vehicle’s Ford Motor
Company specifications.
Scheduled Maintenance Guide
37
2010 F-150(f12)
Supplement, 1st Printing
USA(fus)

Parts
Genuine Ford Collision Parts are designed, engineered, and warranted by
Ford Motor Company. See your dealer for limited warranty details. They
are manufactured to the same specifications as those on your vehicle
when it was built. The right replacement parts will help maintain the
value of your vehicle.
Ford recommended scheduled maintenance – In order to keep your
vehicle running right, it is important to have the systems on your vehicle
checked regularly. This can help identify potential issues and prevent
major problems. Ford Motor Company recommends the following
multi-point inspection be performed at every scheduled maintenance
interval to help ensure your vehicle keeps running great.
MULTI-POINT INSPECTION - Recommended at every visit
❑Check and top up fluid levels: brake, coolant recovery reservoir, power steering and window washer❑Inspect tires for wear and check air pressure, including spare.
❑Check exhaust system for leaks, damage, loose parts and foreign material.
❑Check battery performance.
❑Check operation of horn, exterior lamps, turn signals and hazard warning lights.
❑Check radiator, coolers, heater and air conditioning hoses.
❑Inspect windshield washer spray and wiper operation.
❑Check windshield for cracks, chips and pitting.
❑Inspect for oil and fluid leaks.
❑Inspect engine air filter.
❑Inspect half shaft dust boots.
❑Check shocks and struts and other suspension components for leaks and damage.
❑Inspect steering and linkage.
❑Inspect accessory drive belt(s).
Scheduled Maintenance Guide
40
2010 F-150(f12)
Supplement, 1st Printing
USA(fus)
