AdvanceTracmodes
The AdvanceTracsystem, when used with off-road mode, provides the
SVT Raptor with alternative AdvanceTraccalibrations which improve
off-road performance.
With off-road mode on, the following changes to AdvanceTracwill
occur:
•Pressing the stability control off button once–This places the
vehicle in the off-road sport mode with the ESC, TCS and ABS active.
TCS and ESC are altered to allow for more tire spin and vehicle slip. It
also puts the ABS in a unique off-road mode calibration. RSC is
disabled in this mode.
Note:Operating the vehicle in this mode does not guarantee that the
vehicle will not become stuck in sand, snow or mud, etc. It is the
driver’s responsibility to assess off-road situations and determine if the
terrain is passable.
•Pressing and holding the stability control off button–This places
the vehicle in the off-road sport mode with the ESC, RSC, and TCS
disabled. A unique off-road ABS calibration is also engaged. Note that
when the transfer case is in the 2H position and the electronic locking
differential is engaged, an alternative TCS calibration is enabled
between 0 and 13 mph (0 and 20 km/h).
Driving
10
2011 F-150(f12)
Supplement, 1st Printing
USA(fus)

AdvanceTrac with RSC features when using Off Road mode
Off
Road
modeButton functions“Sliding
car” iconMessage center display
RSC ESC TCS ABS
AdvanceTracOff Road
mode
– Default at start-up Off Enabled Off On On On Street
Off Button pressed momentarily On Sport Off On Sport Sport Street
Off Button pressed and held for more
than 5 seconds while traveling
under 35 mph (56 km/h)Flashes, then
stays onDisabled Off Off Off Off* Street
Off Vehicle speed exceeds 35 mph
(56 km/h) while/after button is
pressed and held for more than
5 secondsOn Disabled Off On Sport On Street
On Button pressed momentarily
On Sport On Off Sport SportOff
Road
On Button pressed and held for more
than 5 secondsFlashes, then
stays onDisabled On Off Off Off*Off
Road
*When the transfer case is in 2H and the electronic locking differential is engaged, an alternative TCS calibration is used
between 0–13 mph (0–20 km/h)
Note:When off-road mode is on, pressing the stability control off button will change the ABS to an
off-road specific calibration. The ABS off-road mode desensitizes the ABS. The ABS calibration in
off-road mode is optimized for performance on off-road surfaces. This helps on very rough
terrain/adverse driving conditions where the standard ABS calibration may become too active and
hinder the type of driving required in off-road conditions.
For more information on the AdvanceTracand its operation, refer toAdvanceTracwith Roll
Stability Control™ (RSC) stability enhancement systemin theDrivingchapter of your
Owner’s Guide.
