GAWR (Gross Axle Weight Rating)
*
[DR30310( ALL)06/92]
q
GCWR (Gross Combined Weight Rating)
*
[DR30320( ALL)06/92]
q
Maximum Trailer Weight Rating
*
[DR30330( ALL)06/92]
q
Maximum Trailer Weight
*
[DR30340( ALL)06/92]
q
Trailer Weight Range
*
[DR30351( ALL)03/91]
Base Curb Weight
*
[DR30401( ALL)03/94]
The Base Curb Weight is the weight of the
vehicle including fuel, coolants, lubricants,
emergency tools, spare wheel and tire. It also
includes any equipment that isstandardon that
model. It does not include passengers, cargo or
optional equipment installed by factory, dealer,
aftermarket supplier or customer.
*
[DR30451( ALL)03/91]
Payload
*
[DR30501( ALL)03/91]
Payload is the combined, maximum allowable
weight of cargo, occupants and optional
equipment that the truck is designed to carry. It
is Gross Vehicle Weight Rating minus the base
curb weight.
*
[DR30550( ALL)03/91]
Gross Vehicle Weight (GVW)
*
[DR30601( ALL)03/91]
If you add base curb weight and the weight of a
load (including passengers, cargo and optional
equipment) being carried at a particular time,
you get the Gross Vehicle Weight (GVW).
*
[DR30650( ALL)10/94]
It is important to remember that GVWis not a
limit or a specification.If an owner loads up a
vehicle and weighs it, that's the GVW at that
moment. If the owner piles on more of a load
and weighs it again, that becomes the
GVW...until such time as the vehicle is unloaded.
File:ltdrf.ex
Update:Thu May 9 15:17:55 1996
ProCarManuals.com

258
%*
[RE03600( ALL)03/95]
Changing a Tire
*
[RE03700( ALL)01/95]
If you get a flat tire while you are driving, do
not apply the brake heavily. Instead, gradually
decrease the speed. Hold the steering wheel
firmly and slowly move to a safe place on the
side of the road. Park on a level spot, turn off
the ignition, set the parking brake, and turn on
the hazard flashers.
*
[RE03800( ALL)03/95]
The Conventional Spare Tire
*
[RE03900(BEF )01/95]
If you have the conventional spare tire, you can
use it as a spare or as a regular tire. This spare
tire is identical to the other tires that come with
your vehicle, although the wheel may not match.
*
[RE04275(BEF )05/95]
RWARNING
To avoid injury, never run the engine
with one wheel off the ground, such as
when changing a tire.
*
[RE04280(BEF )10/94]
Extended use of other than matching size spare
tires on a Traction-Lok axle could result in a
permanent reduction in effectiveness. This loss of
effectiveness does not affect normal driving and
should not be noticeable to the driver.
File:ltref.ex
Update:Thu May 9 15:24:41 1996
ProCarManuals.com

260
*
[RE12200( F )01/89]
4. Lower spare tire, swing the channel to the
rear and remove the lug wrench from the
channel tube.
*
[RE12300( F )04/89]
5. Remove the wheel retainer from the center
bolt. If necessary, use the tapered end of the
wrench inserted in the retainer for more
leverage.
*
[RE12400( F )01/89]
6. Remove the spare tire from the channel
assembly.
*
[RE12500( F )05/95]
RWARNING
Never allow any part of your body to
extend under the channel with mounted
spare tire during removal or installation.
*
[RE12600( F )01/89]
To stow the spare tire:
*
[RE12700( F )01/89]
1. Position the spare tire so it is balanced on
the channel assembly.
*
[RE12800( F )01/89]
2. Screw the retainer on the center bolt and
tighten until the wheel is secured to the
channel.
*
[RE12900( F )01/89]
3. Put the tapered end of the lug nut wrench
into the channel assembly tube and lift and
line up the channel and eyebolt, so the
shoulder of the eyebolt is pushed all the way
into the slot.
*
[RE13000( F )01/89]
4. Tighten the eyebolt with the tapered end of
the wrench until the spare tire cannot be
moved by hand pressure. Adjustment of the
driver side channel ball end bolt is not
required when stowing an original
equipment size wheel and tire.
File:ltref.ex
Update:Thu May 9 15:24:41 1996
ProCarManuals.com

262
*
[RE13500( F )01/89]
When the truck is ordered with a spare wheel
only (no tire), it is stowed with a wood spacer
in the usual spare tire location. Remove the
wood spacer before installing the spare tire and
wheel.
*
[RE13600( F )01/89]
After the spare tire and wheel are stowed, adjust
the driver side channel ball end bolt and the
eyebolt as necessary until the tire cannot be
moved by hand pressure.
*
[RE15100(BEF )05/95]
RWARNING
Make sure the spare tire and jacking
equipment are stowed and secured in the
proper storage location.
%*
[RE15200( ALL)03/95]
Preparing to Change the Tire
*
[RE15250( ALL)12/91]
NOTE: To lift your vehicle by other than the
front or rear jacking points, be sure to
use only hoist adapters with a wide
contact surface.
*
[RE15300(B F )03/91]
1. Make sure that your vehicle will not move
or roll. If you have an automatic
transmission, put the gearshift in Park. If
you have a manual transmission, put the
gearshift in Reverse. Set the parking brake
and block the wheel that is diagonally
opposite the tire that you are changing.
*
[RE15335(B F )12/91]
NOTE: Make sure the ignition is in the OFF
position.
File:ltref.ex
Update:Thu May 9 15:24:41 1996
ProCarManuals.com

264 [RE15445( FM)05/95]On F-Super Duty vehicles, the parking brake is
on the transmission. Therefore, the vehicle will
not be prevented from moving when a rear
wheel is lifted, even if the vehicle is in Park and
the parking brake is applied. Be sure to block
both directions of the wheel that is diagonally
opposite to the wheel that is being lifted.
*
[RE15450( FM)05/95]
RWARNING
If the vehicle slips off the jack, you or
someone else could be seriously injured.
*
[RE15550(BEF )05/95]
2. Get out the spare tire and jack.
*
[RE15800(B F )10/92]
The jack and lug wrench are stowed under the
hood on the right front fender inner panel, and
the jack handle is on the radiator support.
*
[RE15900(B F )06/93]
half page art:0020286-E
Jack and assembly location
File:ltref.ex
Update:Thu May 9 15:24:41 1996
ProCarManuals.com

271
*
[RE21151(BEF )10/92]
one third page art:0020939-B
*
[RE21200( F )08/91]
b. Turn the jack handle clockwise until the
wheel is completely off the ground.
*
[RE21400(BEF )01/95]
3. Remove the lug nuts with the lug nut
wrench.
*
[RE21500(BEF )01/95]
4. Replace the flat tire with the spare tire.
*
[RE21600( EFM)01/89]
If your vehicle has dual rear wheels, there are
locating pins on the hubs and wheels with
corresponding holes. When you put the wheel
back on, make sure the pins are lined up with
the proper holes.
[RE21800( EF )02/95]
If your vehicle has single rear wheels, thread the
lug nuts on the wheel studs with the beveled
face toward the wheel. Use the lug nut wrench
to screw the lug nut snugly against the wheel
but do not tighten.
File:ltref.ex
Update:Thu May 9 15:24:41 1996
ProCarManuals.com

274 [RE23615(BEF )02/95]8. Put the tire, jack, and wrench away. (Make
sure jack is securely fastened so it doesn't
rattle when you drive.) The carrier is
designed to hold the temporary spare which
comes with your vehicle. The stowage of a
full size tire in the spare tire carrier may
damage the tire or the vehicle. The flat full
size tire should be stowed securely in the
vehicle until it can be repaired.
*
[RE23700(BEF )01/95]
9. Unblock the wheels.
*
[RE24100( EFM)06/93]
On vehicles equipped with dual rear wheels
retighten the wheel lug nuts to the specified
torque at 100 miles (160 km), and again at 500
miles (800 km) of new vehicle operation and at
the intervals specified in theMaintenance Schedule
and Recordbooklet.
*
[RE24200( ALL)10/89]
Also retighten to the specified torque at 500
miles (800 km) of operation after any wheel
change or any time the lug nuts are loosened.
*
[RE24301( ALL)05/95]
RWARNING
Failure to retighten wheel lug nuts at
mileages specified could allow wheels to
come off while the vehicle is in motion.
File:ltref.ex
Update:Thu May 9 15:24:41 1996
ProCarManuals.com

335
*
[SV26450(BEF )03/95]
Traction-Lok Rear Axle (If equipped)
*
[SV26460(BEF )03/95]
This axle provides added drive away traction on
slippery surfaces, particularly when one or more
wheels are on a surface with poor traction.
*
[SV26470(BEF )05/95]
RWARNING
To avoid injury, never run the engine
with one wheel off the ground, such as
when changing a tire.
%*
[SV26500( ALL)02/95]
Tire Rotation
*
[SV26600( ALL)03/95]
Because your vehicle's front and rear tires
perform different jobs, they often wear
differently. To make sure your tires wear evenly
and last longer, rotate them at the mileage
shown in theMaintenance Schedule and Record
booklet which came with your vehicle.
*
[SV26625( F )03/93]
For F-250 (over 8500 GVWR [3,855 kg]), F-350
and Super Duty vehicles, rotate the tires at 5,000
miles (8,000 km), then at 15,000 miles
(24,000 km), and then every 15,000 miles
(24,000 km) thereafter.
*
[SV26660( EF )03/94]
If your light truck has dual rear wheels, you can
rotate the front tires side to side without
disturbing the rear tires.
*
[SV26700(BEF )07/92]
Rotate the tires according to the following
diagram. If you notice that the tires wear
unevenly, have them checked. If your light truck
has a temporary spare tire, do not include it in
the tire rotation pattern.
*
[SV26750(BEF )03/90]
In situations where the tires differ from front to
rear (snow/traction), simply rotate using a side
to side pattern.
File:ltsvf.ex
Update:Thu May 9 15:30:19 1996
ProCarManuals.com

336
*
[SV26800(BEF )06/93]
half page art:0020364-A
Tire rotation pattern
*
[SV26900(BEF )10/89]
After each rotation, adjust individual tire
pressure as specified on the Safety Compliance
Certification Label. Tighten wheel lug nuts to the
required torque specification and retighten again
after 500 miles (800 km).
*
[SV27000(BEF )10/94]
If your vehicle has aluminum wheels, you may
demount the full size, non-temporary spare
tire (if so equipped) and remount on an
aluminum wheel to rotate the spare tire into
your vehicle's rotation pattern.
File:ltsvf.ex
Update:Thu May 9 15:30:19 1996
