Passenger compartment fuse panel
Fuse/Relay
LocationFuse Amp
RatingFuse Description
1 20A Horn
2 15A Turn/Hazard lamps
3 20A Cigar lighter
4 10A Diagnostic connectors
5 15A Back-up lamps, DRL relays, Blend door
actuator, Heated seat module, Trailer ABS
relay
6—Not used
7—Not used
8 5A Radio, GEM
9 5A Switch illumination (Headlamp, Power
windows, Power door locks), Power window
relay
10 15A Heated/Lighted mirrors
11 30A Wiper motor, Washer pump relay
12 10A Stoplamp switch (Hydraulic brake vehicles
only)
2005 F650/750(f67)
Supplement
USA English(fus)
Roadside emergencies
141

Fuse/Relay
LocationFuse Amp
RatingFuse Description
13 20A Radio, Cluster
14 10A Interior lamps
15 10A GEM, Interior lamp relay, Map lamps
16 15A High beams
17—Not used
18 5A Headlamp switch, GEM
19 15A Engine ECM (Caterpillar and Cummins
engines)
Engine ECM, Accel, Crank (6.0L Power
Stroke engine only)
20 15A Starter relay, GEM
21 10A Daytime Running Lamps (DRL)
22 15A Air solenoid 4–pack (Air horn, Air suspension
dump, Differential lock axle and Two-speed
axle)
23 10A Electronic flasher
24 15A Vacuum pump, Air dryer, ABS, Fuel
heater/Fuel transfer pump relay, Heated
drain valve, 6.0L Power Stroke Water In Fuel
(WIF) module
25 10A Blower motor relay
26 10A RH low beam headlamp
27—Not used
28 10A LH low beam headlamp
29 10A Cluster (Power, Warning lamps), Hydraulic
ABS relay, Air traction control
30 30A Not used
31 15A Allison transmissions
Relay 1—Interior lamps
Relay 2—Not used
Relay 3—Horn
Relay 4—One-touch down window
Relay 5—Not used
2005 F650/750(f67)
Supplement
USA English(fus)
Roadside emergencies
142

Fuse/Relay
LocationFuse Amp
RatingFuse Description
15 7.5A* Body builder prep/trailer socket stop (6.0L
Power Stroke engine only)
16 5A* WABCO hydraulic ABS Run feed
17—Not used
18 10A* Fuel transfer pump (duel fuel tanks only)
19—Not used
20 10A* Engine ECM power relay (6.0L Power Stroke
engine only)
21 10A* GEM (Hydraulic brake vehicles only)
22 10A* Engine IDM2 logic power (6.0L Power Stroke
engine only)
23—Not used
24—Not used
101 30A** Bendix Air ABS relay (Air brake vehicles
only)
WABCO ABS modulator relay (Hydraulic
brake vehicles only)
102 20A** Body builder prep Run feed
103 50A** Ignition switch (Junction box fuses 8, 9, 10,
11, 19, 20, 22, 23, 24, 25, 29, 30, 31)
104 20A** Power point
105 20A** Power door locks
106 30A** Headlamps
107 50A** Junction box battery feed (1, 2, 3, 4, 12, 13,
14, 15)
108 40A** Fuel heater (Cummins engine only)
109 40A** Power windows
110—Not used
111 30A** Body builder prep
112 40A** Blower motor
113 30A** Heated seat (passenger side)
114 25A** WABCO ABS battery feed (Hydraulic brake
vehicles only)
2005 F650/750(f67)
Supplement
USA English(fus)
Roadside emergencies
144

In addition to the items to be performed daily or at each oil change, the
following need to be completed as specified:
Maintenance Operation Frequency — ObservationClean body/door drain holes.
Clean windshield wiper blades.
Replace windshield wiper blades.
Lubricate body lock cylinders, door and hood hinges.
Check headlamp alignment.
Check windshield washer fluid level. Add fluid if required.At least twice annually.
As required.
If wiping the blades with a clean cloth and mild detergent
and washing the windshield with a cleaner does not restore
a clean wipe.
Difficult to operate or noisy.
Lamp beams in wrong position when vehicle operating
loaded.
If washers do not spray fluid when operated. GENERAL MAINTENANCE SERVICES
Listed below are vehicle checks that should be made periodically either by the owner or a qualified technician. It is recommended
that deficiencies be brought to the attention of your dealer or another qualified service outlet as soon as possible in order that
advice regarding the need for service or replacement can be obtained.
2005 F650/750(f67)
Supplement
USA English(fus)
General maintenance information
236

speedometer .............................26
tachometer ................................26
trip odometer ............................26
H
Hazard flashers .........................140
Headlamps ...................................47
aiming ........................................48
daytime running lights .............47
flash to pass ..............................47
high beam .................................47
warning chime ..........................21
Heating ..................................44–45
heater only system ...................44
manual heating and air
conditioning system .................45
Hood ..........................................169
I
Ignition
chime .........................................21
Infant seats
(see Safety seats) .......................83
Instrument panel
cleaning ...................................160
lighting up panel and
interior .......................................48
J
Jump-starting your vehicle ......147
K
Keys
key in ignition chime ...............21L
Lamps
bulb replacement
specifications chart ..................49
cargo lamps ...............................48
daytime running light ...............47
headlamps .................................47
headlamps, flash to pass ..........47
high beams ................................47
instrument panel, dimming .....48
interior lamps ...........................49
replacing bulbs ...................49–51
Lane change indicator
(see Turn signal) ........................48
Lights, warning and indicator ....21
air suspension ...........................21
anti-lock brakes (ABS) ....21, 114
brake ..........................................21
charging system ........................21
safety belt .................................21
service engine soon ..................21
traction control off ...................21
turn signal indicator .................21
Lubricant specifications ...........213
M
Maintenance and Care ..............231
Manual transmission .................123
lubricant specifications ..........213
Mirrors .........................................56
fold away ...................................58
heated ........................................57
side view mirrors (power) .......57
O
Odometer .....................................26
P
Paint chips, repairing ...............159
2005 F650/750(f67)
Supplement
USA English(fus)
Index
265
