FORD FOCUS 2008 2.G Quick Reference Guide

*8S4J_19G217_AA*8S4J 19G217 AA
This Quick Reference Guide is not intended to replace your
vehicle Owner’s Guide which contains more detailed
information concerning the features of your vehicle, as well as important safety
warnings designed to help
reduce the risk of injury to you and your occupants. Please
read your entire Owner’s Guide carefully as you begin learning about your new vehicle and refer to the appropriate
chapters when questions arise.
Ford Motor Company
Customer Relationship Center
P.O. Box 6248
Dearborn, MI 48121
1-800-392-3673 (FORD)
(TDD for the hearing impaired:
1-800-232-5952)
July 2007
First Printing
Quick Reference Guide Focus
Litho in U.S.A.
USB Port (if equipped) Your vehicle may be
equipped with a USB port inside your
center console. This feature allows you to plug in media playing devices, memory
sticks, and to charge devices. For further
information on this feature, refer to your SYNC supplement.
AUxiliAry inPUt JAck The auxiliary input jack provides a way to connect your portable
music player to the in-vehicle audio system and allows the audio from a portable music player to be played through the vehicle
speakers with high fidelity. Press AUX on
the vehicle radio repeatedly until LINE IN appears in the display.
AUxiliAry Power Point (12VDc) The
auxiliary power points are located on the instrument panel. Do not use the power
points for operating the cigarette lighter
element (if equipped). To prevent the fuse from being blown, do not use the power point(s) over the vehicle capacity of
12 VDC/180W.
Moon roof (if equipped) The moon roof has an automatic, one-touch, express opening and closing feature. To open or close the moon roof, press and release the rear or front
portion of the moon roof control. To stop motion at any time during the
one-touch operation, press the control a second time.
tilt Steering To adjust the steering wheel,
pull the lever down to unlock the steering column, then move the steering wheel up
or down until you find the desired position. While holding the steering wheel in place,pull the lever up to its original position to lock the steering column. SecUrilocktM PASSiVe Anti-tHeft SySteM
SecuriLockTM passive anti-theft system
is an engine immobilization system. This
system is designed to help prevent the
engine from being started unless a coded
key programmed to your vehicle is used.
The use of the wrong type of coded key
may lead to a “no-start” condition.
reAr SeA tS One or both rear seatbacks can
be folded down to provide additional cargo
space. To lower the seatback(s) from inside
the vehicle, pull the strap located on the
outboard side of the seatback to release it,
and then fold seatback down. When raising
the seatback(s), make sure you hear the
seat latch into place.
HeA teD SeA tS (if equipped) The heated seats
switch is located on the instrument panel.
To operate the heated seats, push the
control to activate. Push again to
deactivate. The heated seats will activate
when the ignition is in the RUN position
and the engine is running. The system
automatically shuts off after 10 minutes.
HeADlAMP/fog lAMP control Turn the
headlamp control clockwise to the first
position to turn on the parking lamps,
instrument panel lamps, license plate
lamps and the tail lamps. Continue to
turn the headlamp control to the second
position to turn on the headlamps. The
fog lamps (if equipped) can be turned on
when the headlamp control is in the
or position and the high beams are not
turned on. Pull the headlamp control
towards you to turn the fog lamps on. The
fog lamp indicator
light on the
headlamp control will illuminate.
Power MirrorS (if equipped) Rotate the
control clockwise to adjust the right mirror or counterclockwise to adjust the left

mirror. Move the control in the direction you wish to tilt the mirror. Return to the
center position to lock the mirrors in place. If your vehicle has both rear defroster and heated mirrors, the mirrors are heated
automatically to remove ice, mist and fog
when the rear window defrost is activated.
AMBient ligHting (if equipped) The
ambient lighting control switch
is
located on the instrument panel. Pressing this switch will illuminate 4 footwells and 3 cupholders with a choice of 7 colors.
To activate, press and release the control
switch to cycle through the 7 color choices and off. The lights come on to the last color choice whenever the headlamps/ parklamps are turned on through the
headlamp switch.
reMote keyleSS entry (if equipped) This
feature allows you to lock or unlock the
vehicle’s doors without a key. It also allows you to activate a personal alarm, arm or
disarm an anti-theft system (if equipped) or open the luggage compartment.
cAr finDer Press
twice within three
seconds. The horn will chirp and the turn lamps will flash. It is recommended that
this method be used to locate your vehicle, rather than using the panic alarm.
SMArt lockS This feature helps to prevent
you from locking yourself out of the vehicle if your key is still in the ignition.
When you open one of the front doors and you lock the vehicle with the power door
lock control, all the doors will lock, then all doors will automatically unlock reminding you that your key is still in the ignition.
All information contained in
this Quick Reference Guide
was accurate at the time of
duplication. We reserve the
right to change features,
operation and/or functionality
of any vehicle specification at
any time. Your Ford dealer is
the best source for the most
current information.
For detailed operating
and safety information, please
consult your Owner’s Guide.
1 loAD Press LOAD and a memory preset
to load a specific slot. Press and hold to
autoload up to six CDs. Not operational on
single CD system.
2 on/off/Vol (Volume) Press to turn on or
off. Turn to increase/decrease volume. If
the volume is set above a certain level and
the ignition is turned off, the volume will
come back on at a “nominal” listening
level when the ignition switch is turned
back on.
3 Direct Press to access a desired radio
station, track, MP3 folder or SIRIUS
satellite channel (if equipped).
4 (Phone) If your vehicle is equipped
with SYNC, press to access SYNC PHONE
features. For further information, please
refer to the SYNC supplement. If your
vehicle is not equipped with SYNC, the
display will read NO PHONE.
5 ScAn In radio mode, press for a brief
sampling of all strong radio stations. In CD/
MP3 mode, press for a brief sampling of
all tracks on the current disc or folder.
In satellite radio mode (if equipped), press
SCAN for a brief sampling of all available
SIRIUS satellite channels.
6 cA t (category)/folD (folder) In Radio
mode, press to select from various
music categories. In MP3 mode, press
FOLD and then press
to access the
previous/next folder. In satellite radio mode
(if equipped), press to toggle between
turning the most recently selected satellite
radio category on or off.
7 AM/fM Press repeatedly to select an AM/
FM1/FM2 frequency band.
8 MeMory PreSetS To set a station, select a
frequency band AM/FM1/FM2; tune to a station, then press and hold a preset
button until sound returns. You can store up to 30 stations, ten in AM, ten in FM1
and ten in FM2. In CD/MP3 mode, press to select tracks or desired folders. In satellite radio mode (if equipped), there are 30
available presets, 10 each for SAT1, SAT2 and SAT3. To save satellite channels in your memory presets, tune to
the desired channel then press and hold a preset control until sound returns.
9 Seek/trAck Press to access the previous
or next strong station, CD track, previous/ next channel (if equipped with satellite radio), previous/additional display text
or category.
10 cD Press to enter CD/MP3 mode. If a
disc is already loaded into the system, a
CD/MP3 will begin where it ended last. If no CD is loaded, NO DISC will appear in the display.
11 AUx Press repeatedly to cycle through
LINE IN (auxiliary audio mode), SYNC (if
equipped) or SAT1, SAT2 and SAT3 modes
(satellite radio, if equipped). Satellite radio is available only with a valid SIRIUS radio subscription. Check with your authorized dealer for availability.
12 SiriUS (Satellite radio, if equipped) Press
repeatedly to access satellite radio mode. Press repeatedly to cycle through SAT1,
SAT2 and SAT3 modes. SIRIUS Satellite Radio is a subscription based satellite radio service that broadcasts music,
sports, news and entertainment
programming. For more information on
extended subscription terms, contact SIRIUS at 1-888-539-7474.
13 text Press this button repeatedly to view
Album (AL), Folder (FL), Song (SO) and
Artist (AR) in the MP3 mode, if available.
Press and release to display the artist and
song title in satellite mode (if equipped).
When the < / > indicator is active while in
TEXT mode, there is additional text to be
displayed. Press TEXT, then
to view
the additional text.
14 MenU Press repeatedly to access the
following features: SATELLITE RADIO
MENU (if equipped) Press MENU when
satellite radio mode is active to access.
Press OK to enter into the satellite radio
menu. Press to cycle through the following
options: CATEGORY, SAVE SONG, DELETE
SONG, DELETE ALL SONGS, ENABLE
ALERTS/DISABLE ALERTS.
15 SoUnD Press repeatedly to cycle through
the following features: BASS, TREBLE,
BALANCE, FADE, SPEED COMPENSATED
VOLUME, ALL SEATS (Occupancy mode,
if equipped).
16 clock To set the time, press CLOCK.
The display will read SET TIME. Use the
memory preset numbers to enter in the
desired time, hours and minutes.
17 tUne/ok Turn the knob to go up or down
the frequency band. In CD/DVD mode (if
equipped), press this control to play or
pause the current CD/DVD.
ok Your vehicle may be equipped with
special phone and media features which
will require you to confirm commands by
pressing OK. For further information, refer
to the SYNC supplement.
18 eJect Press this button and a memory
preset to eject a CD from a specific slot.
Press and hold to auto eject all CDs
present in the system.
QUICK REFERENCE GUIDE
2008 FOCUS
AUDIO SYSTEMAM/fM/in-DASH cD6/MP3 SA tellite coMPAtiBle (if equipped)
2
13456798101112131415161718

is fun, quick and dependable. It’s going to be like hanging out with your new
best friend, from spur of the moment errands to 2,000 mile-road trips.
Focus comes equipped with lots of cool features – most are no-brainers, but
some may be new to you. So take a few minutes to use this Quick Reference
Guide to familiarize yourself with your
Focus and enjoy the time you’ll spend with your newfound friend.
For more detailed information,
including important safety information, please consult your Owner’s Guide.
1 SPeeD control (if
equipped)
To set a speed,
press the ON button,
accelerate to the desired
speed and press the SET+
button, then take your
foot off the accelerator pedal. You can
increase your speed by pressing and
releasing the SET+ until you reach the
desired speed. You can decrease speed
the same way using the SET- button. To
disengage the speed control, press the OFF
button or depress the brake pedal.
2 MUlti-fUnction leVer
The multi-function lever
controls the windshield
wiper modes, speeds and
the windshield washer.
Rotate the end of the
control away or toward you to increase/
decrease the speed of the wipers. For
windshield washer control, push the end
of the stalk briefly to cause a single swipe
of the wipers without washer fluid. With
a quick push and hold, the wipers will
swipe three times with washer fluid. With
a long push and hold, the wipers and
washer fluid will be activated for up to
ten seconds. Push up or down to activate
the right turn or left turn signal. Push the
lever toward the instrument panel to
activate high beams. Pull the lever toward
you to deactivate.
3 SerVice engine Soon ligHt
The service engine soon
indicator light illuminates when the ignition is first
turned to the ON position to check the bulb. If the light turns solid or blinks, the On-Board
Diagnostics System has detected a
malfunction. Drive in a moderate fashion
(avoid heavy acceleration or deceleration)
and have your vehicle serviced immediately.
4 Anti-lock BrAkeS (if equipped)
This system
helps you maintain
steering control during emergency stops by
keeping the brakes from
locking. The light will illuminate when you start your engine. If the light does not
illuminate during start up, remains on or
flashes, there may be a malfunction, see your dealer’s service department immediately.

5 Steering wHeel AUDio controlS (if equipped)

Press MEDIA to select AM,
FM1, FM2, or CD, SAT1, SAT2 or SAT3 (satellite
radio mode, if equipped) or LINE IN (Auxiliary input jack) (if equipped)
.
Press VOL + or VOL - to
adjust the volume. Press
to access the next/previous
strong preset station or track on a CD.

Sync HAnDS free control feA tUre
(if equipped) Press and hold the control
briefly until the voice appears on the
display. Press and hold
to send a call
or text message. Press OK to confirm your
selection. For further information
on the SYNC system, refer to the
SYNC supplement.
6 AUDio SySteM Refer to the Audio System
section for instructions on this feature.
7 trAction control™
(if equipped)
This system
helps you maintain the
stability and steerability
of your vehicle, especially
on slippery road surfaces
such as snow or ice-covered roads and
gravel roads. The Traction Control™ switch,
located on the center console by the
gearshift lever, can deactivate the traction
control system, but will automatically turn
the system back on every time the ignition
is turned off and on. For more information,
please refer to your owner’s guide.
8 clock Refer to the Audio System section
for instructions on this feature.
locA tion of SPAre tire AnD toolS (if
equipped) Your vehicle may be equipped
with a conventional spare tire that is
located in the luggage compartment under the floor cover. Remove the spare tire and jack by turning their tie-down bolts
counterclockwise. The lug wrench is
located in a bag next to, or on top of the spare tire. Refer to the Roadside
Emergencies chapter in the Owner’s Guide for further information
fUel recoMMenDAtionS For optimum
performance, use “Regular” unleaded gasoline with a pump (R+M)/2 octane
rating of 87. We do not recommend the
use of gasolines labeled as “Regular” that
are sold with octane ratings of 86 or lower in high altitude areas. Use only
UNLEADED or UNLEADED fuel blended with a mixture of 10% ethanol. Your
vehicle was not designed to run on E85
fuels that are blended with a maximum of 85% ethanol.
fUel PUMP SHUt-off SwitcH The fuel
pump shut-off switch stops the electric
fuel pump from sending fuel to the engine when your vehicle has had a substantial jolt. This switch is located in the front
passenger’s footwell, behind the kick panel access cover. For more information
regarding the fuel pump shut-off switch,
refer to the Roadside Emergencies chapter of your Owner’s Guide.
fUSeS If the vehicle’s electrical
components are not working properly, a
fuse may have blown. For more informa-
tion regarding changing fuses, refer to the Roadside Emergencies chapter of your Owner’s Guide.
tire PreSSUre Safe operation of your
Focus requires that your tires be
properly inflated. The recommended
inflation pressure is found on the Tire Label or the Safety Compliance
Certification Label located near the front
door latch on the edge of the driver’s door At least once a month and before long trips, inspect each tire and check the
tire pressure. Don’t forget the spare (if
equipped). Air pressure should be checked
when the tires are cool. Inflate all tires to
the inflation pressure recommended by
Ford Motor Company. As an added safety
feature, your vehicle has been equipped
with a tire pressure monitoring system
(TPMS) that illuminates a low tire pressure
warning light
when one or more of your
tires is significantly under-inflated. Refer to
the Tires, Wheels and Loading chapter in
the Owner’s Guide for further information.
teMPorAry MoBility kit (if equipped) Your
vehicle may be equipped with a temporary
mobility kit located in the spare tire well in
the trunk. The temporary mobility kit
consists of an air compressor to reinflate
the tire and a sealing compound in a
canister that will seal most punctures
caused by nails or similar objects. This kit
will provide a temporary seal allowing you
to drive your vehicle up to 120 miles (200
km) at a maximum speed of 50 mph (80
km/h). Do not attempt to repair punctures
larger than 1/4 inch (6.4 mm) or damage
to the tire’s sidewall. The tire may not
completely seal. If you use the Tire
Mobility Kit (TMK), the sealant compound
in the canister is to be used for one tire
only. See your Ford authorized dealer for
additional replacement sealant canisters.
reAr winDow BUffeting When one or both
of the rear windows are open, the vehicle
may demonstrate a wind throb or buffeting
noise; this noise is common among a wide
range of vehicles and can be eliminated
by simply lowering a front window
approximately two to three inches.
roADSiDe ASSiSt Ance During your vehicle’s
warranty period, the assurance and support
of a 24-hour emergency roadside
assistance program is included. Roadside
assistance includes such services as fuel
delivery, tire changes, jump starts, help
when you are locked out of your vehicle,
and towing. To receive roadside assistance
in the United States, call (800) 241-3673.
In Canada, call (800) 665-2006.
Use extreme caution when using any

device or feature that may take your attention off the road. Your primary
responsibility is the safe operation of
the vehicle. Only use the non-essential features and devices when it is safe
to do so.
2008 FOCUS
213456 87
ESSENTIAL INFORMATION
