Starting Your Mustang
*
[ST03400( ALL)03/95]
Ignition
%*
[ST03500( ALL)01/95]
Understanding the Positions of the Ignition
[ST03750( ALL)12/94]
quarter page art:0010035-B
The positions of the key in the ignition
% [ST03800(M )03/95]
ACCESSORY allows some of your vehicle's
electrical accessories such as the radio and the
windshield wipers to operate while the engine is
not running. You must push the key release
button to turn to the ACCESSORY position if
your vehicle has a manual transmission.
% [ST04001( ALL)12/94]
LOCK locks the steering wheel. It also locks the
automatic transmission gearshift lever.
*
[ST04101( ALL)01/95]
LOCK is the only position that allows you to
remove the key. The LOCK feature helps to
protect your vehicle from theft.
*
[ST04200( ALL)03/95]
OFF allows you to shut off the engine and all
accessories without locking the steering wheel or
the automatic transmission gearshift lever.
File:04rcstm.ex
Update:Wed Mar 27 09:28:42 1996

91
Steering Column Controls
*
[SC00200( ALL)01/95]
The controls on the steering column and wheel
are designed to give you easy access to the
controls while you are driving.
%
*
[SC00300( ALL)01/95]
The Turn Signal Lever
*
[SC00400( ALL)01/95]
You can use the turn signal lever on the left side
of the steering column to:
*
[SC00500( ALL)07/94]
q
operate the turn signals
*
[SC00600( ALL)01/95]
q
turn the high beams on/off
*
[SC00700( ALL)05/95]
q
flash the lamps
*
[SC00800( ALL)01/95]
q
turn the windshield wipers and washer
on/off
[SC01900( ALL)02/95]
one third page art:0011292-A
The turn signal lever
%*
[SC02100( ALL)01/95]
Turn Signals
*
[SC02201( ALL)03/95]
Move the lever up to signal a right turn. Move
it down to signal a left turn. The corresponding
indicator light in the instrument cluster will
flash.
File:07rcscm.ex
Update:Wed Mar 27 09:30:54 1996

92
*
[SC02301( ALL)03/95]
If the turn signal stays on after you turn, move
the lever back to the center (off) position.
*
[SC02401( ALL)08/95]
For lane changes, move the lever far enough to
signal but not to latch. The lever will return to
the off position when you release it.
%*
[SC02700( ALL)05/95]
High Beams
*
[SC02800( ALL)05/95]
To turn on the high beams, turn the headlamp
control knob to the headlamp ON position and
push the turn signal lever away from you until
it latches. When the high beams are ON, the
high beam indicator light on the instrument
panel comes on.
*
[SC02900( ALL)05/95]
To turn off the high beams, pull the lever
toward you until it latches. The high beam
indicator light turns off.
[SC02955(M )06/93]
NOTE: The fog lamps will turn off if you put
high beams on while fog lamps are on.
%*
[SC03200( ALL)08/95]
Flashing the Lights
*
[SC03300( ALL)06/95]
To flash the headlamps, pull the lever toward
you for a moment and then release it. The
headlamps will flash whether the headlamp
knob is in the on or off position.
%
*
[SC03500( ALL)08/95]
Windshield Wipers and Washer
*
[SC03600( ALL)03/95]
To turn on the windshield wipers, the ignition
key must be turned to the ON or ACC position.
[SC03750( ALL)01/95]
Rotate the end of the lever away from you to
activate the wipers. The first seven detents are
interval wipe positions, the eighth detent is the
LO position and the ninth detent is the HI
position.
*
[SC03800( ALL)01/95]
To turn the wipers off, turn the knob toward
you to the OFF position.
File:07rcscm.ex
Update:Wed Mar 27 09:30:54 1996

93 %
*
[SC04100( ALL)08/95]
Variable Interval Wipers
*
[SC04205( ALL)01/95]
In addition to two speed wipers, your vehicle
has wipers that you can set to operate at
varying intervals. For example, you can set the
interval so they wipe less often when it drizzles
or more often in heavier rain.
[SC04700( ALL)02/95]
one third page art:0011293-A
The variable interval wiper on the turn signal lever
*
[SC04900( ALL)03/94]
To set the interval wipers, turn the knob at the
end of the turn signal lever toward or away
from you until the wipers are going at the
desired interval.
*
[SC05300( ALL)08/95]
Windshield Washer
*
[SC05401( ALL)01/95]
To clean the windshield, push in the end of the
wiper knob. For a constant spray, keep the knob
pushed in. After you release the knob, the
wipers operate for two to three cycles before
turning off (if the wipers were OFF) or
returning to HI, LO, or the interval setting
selected.
*
[SC05500( ALL)03/95]
If the washer does not work, check the washer
fluid level and fill it if it is low. See theServicing
Your Mustangchapter. If there is enough fluid,
consult your nearest Ford or Lincoln-Mercury
dealer.
File:07rcscm.ex
Update:Wed Mar 27 09:30:54 1996

94
*
[SC05600( ALL)08/95]
Do not try to clean the windshield when the
washer fluid container is empty or activate the
washers at any time for more than 15 seconds
continuously. This could damage the washer
pump system.
*
[SC05700( ALL)08/95]
RWARNING
In freezing weather, the washer solution
may freeze on the windshield and obscure
your vision. Always warm up the
windshield with the defroster before you
use the washer fluid. If you cannot see
through the windshield clearly, it can
increase the risk of being involved in a
collision.
*
[SC05800( ALL)08/95]
For information about refilling the washer fluid
or replacing your windshield wiper blades, see
Windshield washer fluid and Wipersin the Index.
%
*
[SC05810( ALL)03/95]
Hazard Flasher
[SC05820( ALL)05/95]
To alert other drivers to hazardous situations,
push in the hazard flasher on the top of the
steering column. The same switch turns the
flashers off.
*
[SC05830( ALL)03/95]
The flashers work whether your vehicle is
running or not. The flashers work for up to two
hours when the battery is fully charged and in
good condition without draining the battery
excessively. If the flashers run for longer than
two hours or if the battery is not fully charged,
the battery can be drained.
File:07rcscm.ex
Update:Wed Mar 27 09:30:54 1996

261 [SV22198(M )09/95]
NOTE: If your vehicle is equipped with a 3.8L
engine you will need to perform
additional steps after the battery has
been disconnected, jump started or
replaced. SeeReadiness for
Inspection/Maintenance Testingin
Servicing Your Vehicle chapter.
%
*
[SV22200( ALL)03/95]
Windshield Washer Fluid and
Wipers
%*
[SV22250( ALL)03/95]
Washer Fluid
[SV22300( ALL)12/94]
Check the level of the windshield washer fluid
periodically, or when the optional lamp indicates
low fluid. The reservoir for washer fluid is
located on the driver's side of the engine
compartment. Visual inspection can determine if
the washer fluid is adequate. Do not operate the
washer when the reservoir is empty.
[SV22900(M )10/95]
half page art:0010374-D
The reservoir for the windshield washer fluid
File:15rcsvm.ex
Update:Thu Mar 28 14:48:54 1996

262
*
[SV23400( ALL)05/95]
RWARNING
Do not put windshield washer fluid in the
container for the engine coolant.
%*
[SV23500( ALL)01/95]
Use specially formulated windshield washer
fluid rather than plain water, because specially
formulated washer fluids contain additives that
dissolve road grime. For safety reasons, washer
fluids containing an appropriate antifreeze such
as methanol should be used in freezing weather
(temperatures below32ÊF [0ÊC]).State or local
regulations on Volatile Organic Compounds
(VOC's) may restrict use of the most common
antifreeze, methanol. Washer fluids containing
non-methanol antifreeze agents should be used
only if they provide cold weather protection
without damaging the vehicle's paint finish,
wiper blades, and windshield washer system.
%*
[SV23600( ALL)03/95]
Wiper Blades
*
[SV23700( ALL)03/95]
Check the windshield wiper blades at least twice
a year. Also check them whenever they seem
less effective than usual. Substances such as tree
sap and some hot wax treatments used by
commercial car washes reduce the effectiveness
of wiper blades.
*
[SV23800( ALL)09/95]
If the blades do not wipe properly, clean both
the windshield and the wiper blades. Use
undiluted windshield washer solution or a mild
detergent. Rinse thoroughly with clear water. Do
not use fuel, kerosene, paint thinner, or other
solvents to clean your wiper blades. These will
damage your blades.
*
[SV23900( ALL)03/95]
To make reaching the wiper blades easy, simply
turn the ignition to the ACC position and turn
your wipers on. Wait for them to reach a
vertical position and turn the ignition to the OFF
position. Do not move the wipers manually.
File:15rcsvm.ex
Update:Thu Mar 28 14:48:54 1996

263
Manually moving the wipers across the
windshield may damage them.
*
[SV24000( ALL)03/01]
Wiper blade replacement
*
[SV24100( ALL)09/95]
If the wiper blades still do not work properly
after you clean them, you may need to replace
the wiper blade assembly or the blade element.
When replacing the wiper blade assembly, blade
refill, or wiper arm always use a Motorcraft part
or equivalent. To replace the blades, follow the
instructions that come with them.
%
*
[SV24200( ALL)03/95]
Tires
*
[SV24300( ALL)03/95]
Look at your tires each time you fill your fuel
tank. If one tire looks lower than the others,
check the pressure in all of them. Always follow
these precautions:
*
[SV24500( ALL)03/95]
q
Keep your tires inflated to the recommended
pressures.
*
[SV24600( ALL)02/95]
q
Stay within the recommended load limits (see
Load limitsin the Index).
*
[SV24700( ALL)02/95]
q
Make sure the weight of your load is evenly
distributed.
*
[SV24800( ALL)10/89]
q
Drive at safe speeds.
*
[SV24900( ALL)01/95]
If you do not take these precautions, your tires
may fail or go flat.
*
[SV24950( ALL)07/95]
Ford Motor Company recommends obeying
posted speed limits.
*
[SV25000( ALL)05/95]
RWARNING
Driving too fast for conditions creates the
possibility of loss of vehicle control.
Driving at very high speeds for extended
periods of time may result in damage to
vehicle components.
File:15rcsvm.ex
Update:Thu Mar 28 14:48:54 1996

328 Index
Hood.................. 238
latch location............. 238
lubrication specifications........ 300
release lever............. 238
working under the hood........ 236
Horn................... 95
Hoses, checking............. 254
I
Identification Number, Vehicle (VIN) . . . 217
Idle, relearning.........204, 236, 260
Ignition
chime................. 51
positions of the ignition......... 49
removing the key............ 50
Indicator lights and chimes (see Lights) . . . 61
Infant seats (see Safety seats)...... 28,30
Instrument cluster............. 61
mechanical............... 62
standard................ 63
Instrument panel
cleaning................ 89
lighting up panel and interior...... 87
location of components......... 79
Interval wipers............92±93
J
Jack.................. 206
operation.............207, 209
positioning............207, 209
storage................ 206
Jump-starting your vehicle
attaching cables............ 201
disconnecting cables.......... 204
File:rcixm.ex
Update:Wed Mar 27 09:41:15 1996

Index 337
Tune-up specifications (VECI)...... 295
Turn signal................ 91
indicator lights........... 72,91
lever................. 91
U
Upshift speeds............. 184
Used engine oil, disposal . . 236, 251, 256, 271
V
Vanity mirror.............. 128
Variable interval wipers........92±93
VECI (Vehicle Emission Control Information)
decal................ 295
Vehicle Identification Number (VIN) . . . 217
Vehicle loading
automatic transmissions........ 192
calculating the load.......... 192
manual transmissions......... 192
understanding loading information . . . 192
Vehicle storage............. 301
Ventilating your vehicle
(see Climate control).......80±81, 83
Viscosity (see Engine oil)......248±249
Visor (see Sun visor).......... 128
Voltmeter (see Battery voltage gauge).... 68
W
Warm engine, starting........... 53
Warning chimes
key in ignition............. 51
safety belt............... 66
Warning lights (see Lights)......... 61
Warranties
basic.................. 4
Canada................ 4
radio................ 175
File:rcixm.ex
Update:Wed Mar 27 09:41:15 1996
