Page 66 of 321
64
*
[CF22700(M GV)03/96]
Your vehicle may have several small storage
compartments:
[CF22900(M )04/96]
q
a glove compartment that locks (if equipped).
[CF23000(M )12/95]
q
coin holders located behind the ashtray. These
are deleted if fog lamps or convertible top are
ordered.
% [CF23300( ALL)03/96]
Using the Remote Control for the
Trunk (If equipped)
[CF23400(M )12/95]
You can use the remote control inside your
glove compartment to unlock and open the
trunk. If equipped, you can also use your remote
entry system to open the trunk.
[CF23700(M )12/95]
quarter page art:0010286-A
The remote control for the trunk
File:05rccfm.ex
Update:Thu Apr 3 07:41:31 1997
Page 97 of 321
95
*
[CF56400(MBC )03/96]
Triggering the Alarm System
*
[CF56500(MBC )01/96]
The armed system will be triggered if:
[CF56600(MBC )12/95]
q
any door is opened without disarming the
system first (see previous paragraphs)
*
[CF56700(MBC )05/96]
q
the trunk lock cylinder is removed
*
[CF56800(MBC )05/96]
NOTE: You can open the trunk with your key
without setting off the alarm.
%*
[CF57200(MBC )03/96]
Disarming a Triggered System
*
[CF57300(MBC )01/96]
The alarm can be disarmed by:
*
[CF57400(MBC )12/95]
q
unlocking a front door with the key
*
[CF57500(MBC )04/96]
q
using the UNLOCK control on the remote
entry transmitter
*
[CF57600(MBC )01/96]
NOTE: The flashing lights and honking horn
will shut off automatically within 2
minutes 45 seconds after the system is
triggered. It will trigger again if
another intrusion occurs. However, the
starter circuit remains disabled until
the system is disarmed.
*
[CF57700(M )05/96]
Coded Key Anti-Theft System
[CF57800(M )05/96]
Your vehicle is equipped with the coded key
anti-theft system, you can only use an
electronically coded key to start the vehicle.
During each vehicle start sequence, the coded
key is read by the anti-theft system. If the key's
ID code matches that in the anti-theft system,
the vehicle is enabled to start. If the key's ID
code does not match the anti-theft system, or if
no coded key is detected, then the vehicle is not
able to start. Your vehicle was equipped with
two electronically coded keys. The coded
ignition key is larger than normal due to the
electronics located in the head of the key.
Additional spare keys, maximum of 14, can be
File:05rccfm.ex
Update:Thu Apr 3 07:41:31 1997
Page 99 of 321
97
*
[CF58600(M )05/96]
If the key has been coded, the theft indicator
will illuminate for two seconds. The key can
then be used to start the vehicle.
*
[CF58700(M )05/96]
Repeat until all chosen keys have been coded
(max=16).
*
[CF58800(M )05/96]
If the key coding failed, the theft indicator will
flash and the vehicle cannot be started. One of 3
causes are possible:
*
[CF58900(M )05/96]
q
The new key was not inserted within 15
seconds or
*
[CF59000(M )05/96]
q
All 16 key codes have been stored or
*
[CF59100(M GV)03/96]
q
The key does not have an electronic code
*
[CF65000( ALL)05/96]
Remote Entry System
(If equipped)
*
[CF65100( ALL)05/96]
If your vehicle has the remote entry system, you
can lock and unlock the vehicle doors and open
the trunk without using a key. The remote also
has a personal alarm feature. The controls for
the system are located on the hand held
remote(s) that came with your vehicle.
*
[CF65200( ALL)05/96]
The system will work with up to four remotes.
Your vehicle came with two remotes. Additional
remotes can be ordered from your dealer.
*
[CF65300(MBC )01/96]
The remote entry features only operate with the
ignition in the OFF position.
File:05rccfm.ex
Update:Thu Apr 3 07:41:31 1997
Page 100 of 321
98 [CF65500(MBC )05/96]
one third page art:0001000-ARemote
%*
[CF65700( ALL)02/96]
Unlocking the doors and opening the
trunk
*
[CF65800( ALL)04/96]
To unlock the driver's door, press the UNLOCK
control.
*
[CF65900( ALL)04/96]
To unlock the other doors, press the UNLOCK
control a second time within five seconds of
unlocking the driver's door.
*
[CF66000( ALL)05/96]
To open the trunk, press the TRUNK control.
*
[CF66200( ALL)04/96]
Locking the doors
*
[CF66300( ALL)04/96]
To lock all the doors, press the LOCK control.
*
[CF66400(MBC )05/96]
If you would like a signal that the doors are
being locked, press the LOCK control again
within five seconds. The doors will lock again
and the horn will beep.
%*
[CF67200( ALL)03/96]
Activating the remote personal alarm
*
[CF67300( ALL)04/96]
If you wish to activate the remote personal
alarm, press the PANIC control. This will honk
the horn and flash the parking lamps and tail
lamps for approximately two minutes and
forty-five seconds. You can turn it OFF by
pressing the PANIC control again or by turning
the ignition key to the RUN position.
File:05rccfm.ex
Update:Thu Apr 3 07:41:31 1997
Page 101 of 321
99 [CF67400( ALL)05/96]
When you use the remote entry UNLOCK,
TRUNK or PANIC controls, the illuminated
entry system turns on the interior lights for 25
seconds. You can turn these lights off with the
LOCK control or by turning the ignition to the
RUN position. The interior lights will not turn
off if you have turned them on manually or if a
door is open.
%*
[CF67500(M )03/96]
Arming and Disarming the Alarm System
[CF67600(M )12/95]
If your vehicle is equipped with the optional
factory installed anti-theft system, the remote
entry system will automatically arm it when the
doors are locked with the remote entry LOCK
button. The remote entry UNLOCK button will
disarm or reset a triggered anti-theft alarm.
*
[CF67700(M )12/95]
The remote entry system is designed to work
with the factory installed anti-theft system. It
may not work with other anti-theft systems.
% [CF67800(M )03/96]
Using the Illuminated Entry System
[CF67900(M )05/96]
If your vehicle has this option, the interior lights
turn on when you press UNLOCK, TRUNK, or
PANIC on a programmed remote if your vehicle
is equipped with remote entry.
[CF68000(M )05/96]
These lights automatically turn off after 25
seconds or when you turn the ignition key to
ON or ACC. The inside lights will not turn off if
you have turned them on manually or if a door
is opened.
File:05rccfm.ex
Update:Thu Apr 3 07:41:31 1997
Page 102 of 321
100 % [CF68100(M )03/96]Battery Saver (With Remote Entry)
*
[CF68200(M )05/96]
When the ignition is turned off, the vehicle will
turn off battery voltage to the interior lights
after 45 minutes.
[CF68300(M )12/95]
This will prevent draining of the battery if those
lights have been left on inadvertently or if a
door is not completely closed. Battery voltage to
these lamps will be restored when the outside
front door handles are lifted, the Remote Entry
transmitter is used to unlock the doors, activate
the personal alarm or open the trunk, or the
ignition key is turned on again.
%*
[CF68400( ALL)03/96]
Replacing the Batteries
*
[CF68500(MBC )05/96]
The remote is powered by two coin type
three-volt lithium 2016 batteries (included) that
should last for several years of normal use. If
you notice a significant decrease in operating
range, the batteries should be replaced.
Replacement batteries can be purchased at most
pharmacies, watch stores or at your Ford or
Lincoln-Mercury dealer.
*
[CF68700( ALL)01/96]
NOTE: The operating range of the remote
entry system can also be affected by
weather conditions (such as very cold
temperatures) or structures around the
vehicle (buildings, other vehicles, radio
and TV towers, etc.). Typical operating
range will allow you to be up to 33
feet (10 meters) away from your
vehicle.
File:05rccfm.ex
Update:Thu Apr 3 07:41:31 1997
Page 188 of 321
190
*
[ER06900(M GV)12/95]
Since the circuit breaker for the headlamps is
mounted in the headlamp switch, you must
replace the entire switch to install a new circuit
breaker.
%
*
[ER07300( ALL)01/96]
If the Engine Cranks but Does
Not Start or Does Not Start After
a Collision
% [ER07400( ALL)12/95]
Fuel Pump Shut-off Switch
[ER07500( ALL)04/96]
If the engine cranks but does not start or does
not start after a collision, the fuel pump shut-off
switch may have been activated. The shut-off
switch is a device intended to stop the electric
fuel pump when your vehicle has been involved
in a substantial jolt.
[ER07700(M )04/96]
Once the shut-off switch is activated, you must
reset the switch by hand before you can start
your vehicle. The switch is on the left side of the
trunk near the left tail lamp.
[ER07800(M )12/95]
one third page art:0010012-D
The fuel pump shut-off switch
File:10rcerm.ex
Update:Tue Mar 4 10:01:28 1997
Page 191 of 321
193
*
[ER10600( ALL)02/96]
q
use the wheel for any other type of vehicle.
*
[ER10700(MBCG )02/96]
q
drive through an automatic car wash with
this tire. Because the temporary spare tire is
smaller than a conventional tire, it reduces
the ground clearance. Your vehicle may get
caught in the rails and it could be damaged.
%*
[ER11000( ALL)02/96]
Spare Tire Location
[ER11100( ALL)02/96]
The spare is stored in the trunk.
[ER11200(M )03/96]
half page art:0010338-D
The spare tire location
%*
[ER11500( ALL)03/96]
To remove the spare tire:
[ER11700(M )03/96]
1. Remove the spare tire cover.
[ER11800(M )03/96]
2. Unscrew the wing-nut holding down the
spare tire.
*
[ER11900(M )03/96]
3. Lift out the spare tire, jack, and lug wrench.
File:10rcerm.ex
Update:Tue Mar 4 10:01:28 1997
Page 196 of 321
198
*
[ER16000(MBC )03/96]
6. Remove the jack and fully tighten the lug
nuts in the order shown in the following
illustration. As soon as possible, have your
dealer or a qualified service technician check
the lug nuts for proper torque specifications.
% [ER16100( ALL)12/95]
quarter page art:0010350-A
The lug nuts on the wheel
*
[ER16200(MBC )03/96]
7. Place any wheel covers and ornaments in the
trunk.
*
[ER16300(MBC )03/96]
8. Put the tire, jack, and wrench away. Make
sure the jack is securely fastened so it does
not rattle when you drive.
*
[ER16400(MBC )03/96]
9. Unblock the wheels.
% [ER16600(MBC )12/95]
Aluminum Road Wheel Ornaments
(If equipped)
[ER16700(MBC )12/95]
To remove the ornament, stick the tapered end
of the jack handle between the ornament and
wheel and pry off the ornament.
[ER16800(MBC )12/95]
To replace the ornament, stick one side of the
ornament into the center of the wheel and strike
the other side with the palm of your hand.
[ER18300(M GV)12/95]
Remove the base wheelcover from the wheel
using the flanged end of the wheel nut wrench
by inserting the handle and then prying against
the inner wheelcover flange.
[ER18301(MBC )02/97]
Remove the exposed lug nut wheel cover by
using the wheel lug nut wrench to unscrew each
lug nut cover counter-clockwise.
File:10rcerm.ex
Update:Tue Mar 4 10:01:28 1997
Page 267 of 321
269
*
[CS04100( ALL)01/96]
q
Cover chrome and stainless steel parts with a
thick coat of auto wax to prevent
discoloration. Re-wax as necessary when the
vehicle is washed.
*
[CS04200( ALL)01/96]
q
Lubricate all hood, door and trunk lid hinges
and latches with a light grade oil.
*
[CS04300( ALL)01/96]
q
Cover interior soft trim to prevent fading.
*
[CS04400( ALL)01/96]
q
Keep all rubber parts free from oil and
solvents.
%*
[CS04500( ALL)01/96]
Engine
*
[CS04600( ALL)01/96]
q
Start engine every 15 days. Run at fast idle
until it reaches normal operating temperature.
*
[CS04700( ALL)01/96]
q
With your foot on the brake, shift through all
the gears while the engine is running.
%*
[CS04800( ALL)01/96]
Fuel system
%*
[CS04900( ALL)01/96]
q
Fill fuel tank with high-quality unleaded fuel
until the first automatic shutoff of the fuel
pump nozzle.
*
[CS05000( ALL)01/96]
NOTE: During extended periods of vehicle
storage (60 days or more), fuel may
deteriorate due to oxidation. This can
damage rubber and other polymers in
the fuel system and may also clog
small orifices.
File:12rccsm.ex
Update:Thu Apr 3 07:49:52 1997
