display FORD PROBE 1997 2.G User Guide

36
*
[AS21400(ALL)03/96]
Using the Controls on Your New Radio
*
[AS21500(ALL)08/95]
How to turn the radio on and adjust the
volume
*
[AS21701(ALL)10/95]
Press the ªPOWERº button to turn the radio on.
Press it again to turn it off.
*
[AS21950(ALL)02/96]
Press the right (+) side of the ªVOLUMEº
button to increase the volume. Press the left (S)
side of the button to decrease the volume.
Illuminated bars in the display show the relative
volume level.
*
[AS21975(ALL)02/96]
NOTE: If the volume level is set above a
certain listening level when the
ignition switch is turned off, when the
ignition switch is turned back on, the
volume will come back to a ªnominalº
listening level. However, if the radio
power is turned off, the volume will
remain in the position it was set at
when radio power was switched off.
*
[AS22100(ALL)03/96]
Selecting the AM or FM frequency band
*
[AS22225(ALL)02/96]
Push the ªAM/FMº button to select the desired
frequency band. Pushing the button more than
once will alternate between AM, FM1 and FM2.
These functions are used with the station
memory buttons described underHow to tune
radio stations.
*
[AS22300(ALL)02/96]
How to tune radio stations (Stereo Radio)
*
[AS22400(ALL)02/96]
There are three ways for you to tune in to a
particular station. You can manually locate the
station by using the ªTUNEº button, ªSEEKº the
station or select the station by using the memory
preset buttons, which you can set to any desired
frequency.
File:04prasp.ex
Update:Mon Jun 3 10:03:33 1996

37 %
*
[AS22410(ALL)02/96]
How to tune radio stations (Stereo Cassette
Radio)
[AS22420(ALL)03/96]
There are four ways for you to tune in to a
particular station. You can manually locate the
station by using Automatic Music Search
ªAMSº, ªSEEKº the station, ªSCANº to the
station or select the station by using the memory
buttons, which you can set to any desired
frequency.
*
[AS22430(ALL)09/95]
q
Using the ªTUNEº function (Stereo Radio)
*
[AS22440(ALL)08/95]
You can change the frequency up or down
one increment at a time by pressing and
releasing either the right (+) or left (S) side
of the ªTUNEº button. To change frequencies
quickly, press and hold down either the right
or left side of the ªTUNEº button.
*
[AS22450(ALL)03/96]
Manual tuning adjusts your radio to any
allowable broadcast frequency, whether or
not a station is present on that frequency.
(SeeAll About Radio Frequenciesin this
section.)
*
[AS22730(ALL)02/96]
q
Using the ªAMSº function to manually tune
your radio (Stereo Cassette Radio)
*
[AS22740(ALL)02/96]
You can change the frequency up or down
one increment at a time by first pressing the
ªAMSº button (display shows ªTUNEº) then
within approximately five seconds pressing
and releasing either the right
aor left
b
side of the ªSEEKº button. To change
frequencies quickly, press andhold down
either the right or left side of the ªSEEKº
button.
File:04prasp.ex
Update:Mon Jun 3 10:03:33 1996

39
*
[AS23900(ALL)03/96]
NOTE: If the vehicle's battery is disconnected,
the clock and station memory preset
buttons will need to be reset.
*
[AS24000(ALL)10/95]
Adjusting the tone balance and speaker
output of your radio
*
[AS24100(ALL)02/96]
q
Increasing or decreasing bass response
*
[AS24225(ALL)02/96]
Push the ªAUDIOº button repeatedly until
the display reads ªBASS.º Push the right (+)
side of the ªVOLUMEº button to increase
bass (more ªlowsº), and push the left (S)
side to decrease bass (less ªlowsº).
*
[AS24300(ALL)02/96]
q
Increasing or decreasing treble response
*
[AS24425(ALL)02/96]
Push the ªAUDIOº button repeatedly until
the display reads ªTREB.º Push the right (+)
side of the ªVOLUMEº button to increase the
treble (more ªhighsº), and push the left (S)
side to decrease treble (less ªhighsº).
*
[AS24500(ALL)02/96]
Speaker features and operation
*
[AS24600(ALL)02/96]
q
Adjusting speaker balance
*
[AS24725(ALL)02/96]
Balance control allows you to adjust the
sound distribution between the right and left
speakers. Push the ªAUDIOº button
repeatedly until the display reads ªBAL.º
Push the right (+) side of the ªVOLUMEº
button to shift the sound to the right
speakers, and push the left (S) side to shift
the sound to the left speakers.
File:04prasp.ex
Update:Mon Jun 3 10:03:33 1996

40
*
[AS24800(ALL)04/96]
q
Adjusting speaker fader
*
[AS24925(ALL)02/96]
Fade control allows you to adjust the sound
distribution between the front and rear
speakers. Push the ªAUDIOº button
repeatedly until the display reads ªFADE.º
Push the right (+) side of the ªVOLUMEº
button to shift the sound to the front
speakers, and push the left (S) side to shift
the sound to the rear speakers.
*
[AS24950(ALL)09/95]
NOTE: Illuminated bars in the display show
relative levels of bass and treble and
positions of speaker balance and fader
functions after adjustments are made,
then revert to volume level set.
*
[AS25000(ALL)04/96]
Using the Controls of Your Cassette Tape
Player (If equipped)
*
[AS25500(ALL)08/95]
How to insert a tape
*
[AS25600(ALL)08/95]
Insert a cassette (with the open edge to the
right) firmly into the tape door opening, making
sure the cassette is completely in and ªseated.º
[AS25650(ALL)07/93]
NOTE: A cassette tape can be loaded with the
ignition on whether or not the radio
power is on. Inserting a cassette tape
with the radio power off will turn the
audio system on. After the cassette is
ejected, radio play will return.
*
[AS25700(ALL)12/95]
How to locate a desired track on the tape
*
[AS25800(ALL)06/95]
NOTE: The tape track or side number
indicated in the display does not
necessarily correspond to the tape track
or side number on the cassette label. It
is used only to indicate when the tape
mechanism reverses tracks.
File:04prasp.ex
Update:Mon Jun 3 10:03:33 1996

41
*
[AS25896(ALL)02/96]
q
Using the Automatic Music Search (ªAMSº)
function with cassette tape player
*
[AS25897(ALL)03/96]
Press and hold the ªAMSº button (ªAMSº will
appear in the display). Then, push the left
h
button to rewind to the beginning of the current
selection or press the right
gbutton to fast
forward to the beginning of the next selection.
*
[AS25900(ALL)09/95]
q
Fast forwarding the tape
*
[AS26000(ALL)04/96]
Push the right
gbutton to fast forward
the tape.
*
[AS26100(ALL)08/95]
q
Rewinding the tape
*
[AS26200(ALL)04/96]
Push the left
hbutton to rewind the tape.
*
[AS26900(ALL)08/95]
q
How to change the side of the tape being
played
*
[AS27000(ALL)09/95]
The alternate track (other side) of the tape
can be selected at any time by pushing both
fast-wind buttons (
hand
g) at the
same time. The number in the display will
alternate between 1 and 2.
*
[AS27100(ALL)08/95]
How to eject the tape
*
[AS27250(ALL)04/96]
To stop the tape and eject the cassette, press the
eject (i) button. The radio will resume playing.
*
[AS27300(ALL)02/96]
Using the DolbyHB noise reduction feature
*
[AS27400(ALL)09/95]
NOTE: Noise reduction system manufactured
under license from Dolby Labs
Licensing Corporation. ªDolbyº and
double-D symbol are trademarks of
Dolby Laboratories Licensing
Corporation.
*
[AS27550(ALL)05/95]
Push station memory button 3 to activate DolbyH
B Noise Reduction.
File:04prasp.ex
Update:Mon Jun 3 10:03:33 1996

43 %
*
[AS28400(ALL)01/96]
Clock Operation
*
[AS28500(ALL)08/95]
How to view the clock mode
*
[AS28650(ALL)08/95]
Press the ªCLOCKº button to alternate the
frequency and time in the display. In the clock
mode, pressing any radio function will
automatically display the radio frequency for
approximately ten seconds before changing back
to the clock mode.
*
[AS28800(ALL)08/95]
How to set the clock
*
[AS28900(ALL)08/95]
1. Turn the radio on.
*
[AS29025(ALL)04/96]
2. Press and hold in the ªCLOCKº button.
Press the ªSEEKº button left (
b) to advance
the hours and right (
a) to advance the
minutes.
*
[AS29200(ALL)09/95]
NOTE: The clock displays 12-hour time with
no AM/PM indications.
%*
[AS29250(ALL)03/96]
Radio Antenna
[AS29300(ALL)03/96]
The radio antenna is mounted on the rear
passenger side quarter panel of the vehicle. It is
a fixed mast antenna and cannot be retracted.
%*
[AS35200(ALL)04/96]
Common Radio Reception Conditions
*
[AS35300(ALL)08/95]
Several conditions prevent FM reception from
being completely clear and noise-free, such as
the following:
*
[AS35400(ALL)08/95]
1. Distance/Strength
*
[AS35500(ALL)08/95]
The strength of the FM signal is directly related
to the distance the signal must travel. The
listenable range of an average FM signal is
approximately 25 miles (40 kilometers). Beyond
this distance, the radio is operating in a fringe
area and the signal becomes weaker.
File:04prasp.ex
Update:Mon Jun 3 10:03:33 1996

45
displayed frequency does not change. While
passing the tower, the station may switch back
and forth a few times before returning to the
original station.
*
[AS36400(ALL)03/96]
When several broadcast towers are present
(common in metropolitan areas), several stations
may overload the receiver, resulting in
considerable station changing, mixing and
distortion.
*
[AS36500(ALL)08/95]
Automatic gain control circuitry for both AM
and FM bands has been incorporated into this
system to reduce strong signal capture and
overload.
%
*
[AS36600(ALL)08/95]
All About Radio Frequencies
*
[AS36700(ALL)08/95]
The Federal Communications Commission (FCC)
and the Canadian Radio Telecommunications
Commission (CRTC) establish the frequencies
that AM and FM radio stations may use for
their broadcasts. The allowable frequencies are,
AM: 530, 540...1600, 1610 kHz in 10 kHz steps;
FM: 87.9, 88.1...107.7, 107.9 MHz in 0.2 MHz
steps.
*
[AS36800(ALL)08/95]
Not all frequencies will be assigned to a given
area. This radio will tune to each of these
frequencies using manual tune and no fine
tuning is necessary as radio stations may not use
other frequencies.
*
[AS36900(ALL)08/95]
Some FM radio stations advertise a
ªrounded-offº frequency which is not the
frequency they actually broadcast on. For
example, a radio station that is assigned a
frequency of 98.7 MHz may call itself ªRadio 99º
even though 99.0 MHz is not an allowable FM
broadcast frequency.
File:04prasp.ex
Update:Mon Jun 3 10:03:33 1996

190
%*
[MC05600(ALL)01/96]
Engine Oil Recommendations
*
[MC05700(ALL)01/96]
We recommend using Motorcraft oil or an
equivalent oil meeting Ford Specification
WSS-M2C153-F and displaying the American
Petroleum Institute CERTIFICATION MARK on
the front of the container.
*
[MC05800(ALL)01/96]
one third page art:0060021-E
The API Certification Mark
*
[MC05900(ALL)01/96]
Neveruse:
*
[MC06000(ALL)01/96]
q
ªNon-Detergentº oils
*
[MC06100(ALL)02/96]
q
Oils labeled API SA, SB, SC, SD, SE, SF or SG
%*
[MC06200(ALL)01/96]
q
Additional engine oil additives, oil treatments
or engine treatments
%*
[MC06300(ALL)03/96]
Engine oils with anSAE 5W-30viscosity are
PREFERREDfor your vehicle. They provide the
best engine performance, fuel economy and
engine protection for all climates down to-15ÊF
(-25ÊC).
%*
[MC06400(ALL)03/96]
Synthetic engine oils which are CERTIFIED and
of the preferred viscosity may be used in your
engine. The engine oil and oil filter must still be
changed according to the maintenance schedule.
File:11prmcp.ex
Update:Thu May 16 12:08:53 1996
