Page 17 of 288
13
*
[IS02700(ALL)03/96]
This light will also illuminate if the parking
brake does not release fully. If it does stay on
afterthe parking brake is fully released, it
means there may be a brake problem. Pull off
the road and stop carefully. You may notice that
the pedal is harder to push, the pedal may go
closer to the floor, or it may take longer to stop
the vehicle. Try the brakes again after you have
stopped.
*
[IS02800(ALL)03/96]
RWARNING
The BRAKE light indicates that the brakes
may not be working properly. Have the
brakes checked immediately.
%*
[IS02900(ALL)03/96]
Anti-Lock Brake System Warning Light
[IS03000(ALL)03/96]
When the ignition switch is turned to the ON
position, the anti-lock brake system warning
light will illuminate. When the engine is started,
the anti-lock brake system control unit will
determine if all components of the system are
operating correctly. The warning light could
remain on for two to four seconds.
[IS03100(ALL)01/96]
one inch art:0032359-C
The anti-lock brake system warning light
*
[IS03200(ALL)03/96]
RWARNING
If the anti-lock brake system warning
light remains on or comes on while
driving, have the braking system checked
by a qualified service technician as soon
as possible.
File:03prisp.ex
Update:Thu May 16 09:43:45 1996
Page 19 of 288
15 %
*
[IS03800(ALL)05/96]
High Beam Light
*
[IS03900(ALL)03/96]
This light illuminates when the headlamps are
turned to high beam or when you flash the
lights.
*
[IS04000(ALL)01/96]
one inch art:0030174-A
High beam light
%*
[IS04100(ALL)03/96]
Check Engine Warning Light
*
[IS04200(ALL)03/96]
This light illuminates when the electronic engine
control system is not working properly. This is
the computer that controls the operating
conditions of the engine.
*
[IS04300(ALL)01/96]
one inch art:0030175-B
Check engine warning light
[IS04400(ALL)03/96]
This light illuminates briefly when you turn the
ignition to the ON position, but should turn off
when the engine starts. If the light does not
come on when you turn the ignition to the ON
position or if it comes on and stays on when
you are driving, have your vehicle serviced as
soon as possible. This indicates a possible
problem with one of the engine's emission
control systems.You do not need to have your
vehicle towed in.
File:03prisp.ex
Update:Thu May 16 09:43:45 1996
Page 21 of 288
17
*
[IS05400(ALL)01/96]
The fuel gauge indicator may vary slightly while
the vehicle is in motion. This is the result of fuel
movement within the tank. You can get a more
accurate reading with the vehicle on smooth,
level ground.
[IS05500(ALL)01/96]
Charging System Gauge
[IS05600(ALL)01/96]
This gauge tells you your battery's voltage when
you turn your ignition key to ON. When you
start your engine, the pointer should move to
the NORMAL range if you are not operating
any electrical accessories. (If electrical accessories
are operating and the engine is not running, the
pointer may move into the red area).
[IS05700(ALL)01/96]
If the pointer moves into the red area when no
electrical accessories are operating, have the
vehicle's electrical system checked.
%*
[IS05800(ALL)04/96]
Engine Oil Pressure Gauge
[IS05900(ALL)01/96]
The gauge needle should stay in the NORMAL
range (indicating normal engine oil pressure). If
the needle drops below the NORMAL range into
the low range, there is a loss of oil pressure.
[IS06000(ALL)01/96]
If this happens:
*
[IS06100(ALL)04/96]
1. Pull off the road as soon as safely possible.
*
[IS06200(ALL)04/96]
2. Shut off the engine immediately or severe
engine damage could result.
[IS06300(ALL)01/96]
3. Check the oil level when the vehicle is on
level ground.
[IS06400(ALL)01/96]
4. Add only as much oil as the engine needs
before you drive the vehicle again. Do not
overfill the oil reservoir. For more
information, seeAdding engine oilin the
Index.
File:03prisp.ex
Update:Thu May 16 09:43:45 1996
Page 131 of 288
128 %
*
[TO06510(ALL)01/96]
If the engine does not start after two attempts:
*
[TO06520(ALL)01/96]
1. Turn the ignition key to the OFF position.
*
[TO06530(ALL)01/96]
2. Press the accelerator all the way to the floor
and hold it.
*
[TO06540(ALL)01/96]
3. Turn the ignition key to the START position.
*
[TO06550(ALL)01/96]
4. Release the ignition key when the engine
starts.
*
[TO06560(ALL)03/96]
5. Release the accelerator gradually as the
engine speeds up.
*
[TO06570(ALL)05/96]
If the engine still does not start, the fuel pump
shut-off switch may have been activated. For
directions on how to reset the switch seeFuel
Pump Shut-Off Switchin the index.
%*
[TO06580(ALL)01/96]
A computer system controls the engine's idle
speed. When you start your vehicle, the engine's
idle speed normally runs high. These faster
engine speeds will make your vehicle coast
slightly faster than its normal idle speed. It
should, however, slow down after a short time.
If it does not, have the idle speed checked.
*
[TO06585(ALL)01/96]
If the engine idle speed does not slow down
automatically, do not allow your vehicle to idle
for more than 10 minutes. Have the vehicle
checked.
*
[TO06590(ALL)01/96]
RWARNING
Extended idling at high engine speeds can
produce very high temperatures in the
engine and exhaust system, creating the
risk of fire or other damage.
File:08prtop.ex
Update:Wed May 15 15:01:01 1996
Page 138 of 288
135
engine and restart. If it remains illuminated, it
means the ABS is disabled and should be
serviced immediately to restore the benefits of
the anti-lock feature. Normal braking is not
affected unless the red BRAKE system warning
light is also illuminated.
[GF01500(ALL)04/96]
ABS has self-check capabilities. As described
above, the system turns on the ABS light each
time you start your engine. After the engine is
started and the ABS light turns off, the system
performs another test the first time the vehicle
reaches 4-9 mph (6-15 km/h). The system turns
on the ABS pump motor for approximately 1/2
second. At this time, a mechanical noise may be
heard. This is a normal part of the self-check
feature. If a malfunction is found during this
check the ABS light will come on.
[GF01510(ALL)12/96]
On vehicles equipped with an antilock braking
system (ABS), a noise from the hydraulic pump
motor and pulsation in the pedal may be
observed during ABS braking events. Pedal
pulsation coupled with noise while braking
under panic conditions or on loose gravel, wet
or snowy roads is normal and indicated proper
functioning of the vehicle's antilock brake
system. If the vehicle has continuous vibration or
shudder while braking, mainly in the steering
wheel, the vehicle most likely needs service.
[GF01600(ALL)03/96]
Ford Motor Company has not found any
detrimental effects of popular mobile radio
transmitting equipment installed on vehicles
equipped with the Anti-lock Brake System if
normal radio installation practices are rigidly
followed. However, if after installing mobile
radio transmitting equipment, the Anti-lock
Brake System light comes on at any time other
than immediately after turning the key to the
File:09prgfp.ex
Update:Fri Jan 3 09:33:04 1997
Page 140 of 288
137
*
[GF02200(ALL)01/96]
RWARNING
To prevent personal injury, do not release
the parking brake while outside the
vehicle.
*
[GF02300(ALL)01/96]
RWARNING
Always set the parking brake fully and
make sure that the gearshift is securely
latched in P (Park) (automatic transaxle) or
in 1 (First) (manual transaxle).
*
[GF02400(ALL)01/96]
Always check the Brake Warning Light each
time you start your engine. Driving with the
parking brake on will cause the brakes to wear
out quickly and will reduce the fuel economy.
*
[GF02500(ALL)02/96]
RWARNING
If the parking brake is fully released, but
the Brake System light remains on, have
the brakes checked immediately. They
may not be working properly.
*
[GF02600(ALL)03/96]
The parking brake is not designed to stop a
moving vehicle, but you can use the parking
brake to stop your vehicle in an emergency if
the normal brakes fail. However, since the
parking brake applies only the rear brakes, the
stopping distance will increase greatly and the
handling of your vehicle will be adversely
affected.
%
*
[GF02800(ALL)01/96]
Steering Your Vehicle
[GF02900(ALL)01/96]
Your vehicle is equipped with power steering.
Power steering uses energy from the engine to
help steer your vehicle.
%*
[GF03000(ALL)03/96]
If the amount of effort needed to steer your
vehicle changes at a constant vehicle speed, have
the power steering system checked. If the power
File:09prgfp.ex
Update:Fri Jan 3 09:33:04 1997
Page 185 of 288
183
Maintenance and Care
%*
[MC00300(ALL)01/96]
Service Made Easy
*
[MC00400(ALL)01/96]
Ford has two goals for servicing your vehicle.
*
[MC00500(ALL)01/96]
1. When we can, we design parts that do not
need to be serviced.
*
[MC00600(ALL)01/96]
2. We want to make servicing your vehicle as
easy as possible. To help you:
*
[MC00700(ALL)01/96]
q
We highlight do-it-yourself items in yellow in
the engine compartment so that you can find
them easily.
*
[MC00800(ALL)03/96]
q
When possible, we design parts that can be
replaced without tools.
*
[MC00900(ALL)02/96]
q
We give you a Maintenance Schedule that
makes tracking routine service for your
vehicle easy. The maintenance schedule is
located in theMaintenance Schedulebooklet.
*
[MC00925(ALL)01/96]
This chapter tells you about the basic parts that
you need to check and service regularly.
*
[MC00930(ALL)01/96]
If your vehicle needs professional servicing, your
dealership can provide the parts and service
required. Check yourWarranty Information Booklet
to find out which parts and services are covered.
Also see theCustomer Assistancechapter of this
Owner Guide.
*
[MC01000(ALL)03/96]
Ford Motor Company recommends that you
perform the Owner Maintenance Checks listed in
theMaintenance Schedulebooklet. These services
are important for the proper operation of your
vehicle. In addition to the conditions listed in
File:11prmcp.ex
Update:Thu May 16 12:08:53 1996
Page 193 of 288
191 %
*
[MC06500(ALL)01/96]
Checking and Adding Engine Oil
*
[MC06600(ALL)01/96]
Since the proper amount of engine oil is
important for safe engine operation, check the oil
using the dipstick each time you put fuel in
your vehicle. Remember the engine must be off,
the oil must be warm and the vehicle must be
parked on level ground.
%*
[MC06700(ALL)01/96]
Checking the engine oil level:
*
[MC06800(ALL)01/96]
1. Turn the engine off after it has warmed up
and allow a few minutes for the engine oil
to drain back into the oil pan.
*
[MC06900(ALL)01/96]
2. Set the parking brake fully and make sure
that the gearshift is securely latched in P
(Park) (automatic transaxle) or 1 (First)
(manual transaxle).
*
[MC07000(ALL)01/96]
3. Open the hood. Protect yourself from engine
heat.
*
[MC07100(ALL)01/96]
4. Locate the engine oil dipstick (highlighted in
yellow) and carefully pull it out of the
engine.
*
[MC07200(ALL)01/96]
5. Wipe the dipstick clean and put it back into
position, making sure it is fully seated.
[MC07300(ALL)01/96]
one inch art:0032075-A
Engine oil dipstick
File:11prmcp.ex
Update:Thu May 16 12:08:53 1996
Page 194 of 288
192 [MC07400(ALL)01/96]6. Carefully, pull the dipstick out again. If the
oil level is below the L line, add engine oil
as necessary. If the oil level is beyond the
letter F, engine damage or high oil
consumption may occur and some oil must
be removed from the engine.
*
[MC07500(ALL)01/96]
7. Put the dipstick back in and make sure it is
fully seated.
%*
[MC07600(ALL)01/96]
Adding engine oil
*
[MC07700(ALL)01/96]
It may be necessary to add some oil between oil
changes. Make sure you use a CERTIFIED
engine oil of the preferred viscosity. Your
vehicle's warranty coverage may not apply if
engine damage is caused by the use of improper
engine oil.
*
[MC07800(ALL)01/96]
Add engine oil through the oil filler cap
highlighted in yellow. To add oil, remove the
filler cap and use a funnel to pour oil into the
opening. Be careful not to overfill the engine.
Recheck the oil level after you finish adding oil.
%*
[MC07900(ALL)01/96]
Changing the Engine Oil and the Oil Filter
*
[MC08000(ALL)01/96]
Change the engine oil and oil filterper the
following, whichever occurs first.
*
[MC08100(ALL)01/96]
one third page art:0060618-C
File:11prmcp.ex
Update:Thu May 16 12:08:53 1996
Page 225 of 288
223
*
[MC38500(ALL)01/96]
To make sure that the catalytic converter and the
other emission control parts continue to work
properly:
*
[MC38600(ALL)01/96]
q
Use only unleaded fuel.
*
[MC38700(ALL)01/96]
q
Avoid running out of fuel.
*
[MC38800(ALL)01/96]
q
Do not turn off the ignition while your
vehicle is moving, especially at high speeds.
*
[MC38900(ALL)01/96]
q
Do not push start your vehicle.
*
[MC38950(ALL)03/96]
q
Have the services listed in yourMaintenance
Schedulebooklet performed according to the
specified schedule.
*
[MC39000(ALL)01/96]
RWARNING
Do not park, idle, or drive your vehicle in
dry grass or other dry ground cover. The
emission system heats up the engine
compartment and exhaust system, which
can start a fire.
*
[MC39100(ALL)01/96]
Watch for fluid leaks, strange odors, smoke, loss
of oil pressure, the charge warning light, the
check engine light, or the temperature warning
light. These sometimes indicate that the emission
system is not working properly.
*
[MC39200(ALL)01/96]
Do not make any unauthorized changes to your
vehicle or engine. Changes that cause more
unburned fuel to reach the exhaust system can
increase the temperature of the engine or
exhaust system.
%*
[MC39300(ALL)01/96]
In general, maintenance, replacement, or service
of the emission control devices or systems in
your new Ford Motor Company vehicle or
engine may be performed at your expense by
any automotive repair establishment or
individual using automotive parts equivalent to
those with which your vehicle or engine was
originally equipped.
File:11prmcp.ex
Update:Thu May 16 12:08:53 1996
