Page 109 of 288
106
*
[SS11400(ALL)05/96]
Children and Air Bags
*
[SS11450(ALL)05/96]
NOTE: For additional important safety
information on the proper use of seat
belts, child seats, and infant seats,
please read the entire Safety Restraints
chapter in this owner guide.
*
[SS11500(ALL)05/96]
RWARNING
Children should always wear their safety
belts. Failure to follow these instructions
may increase the risk of personal injury in
the event of a collision.
[SS11550(ALL)05/96]
RWARNING
Rear-facing child seats or infant carriers
should never be placed in the front seats.
%*
[SS11600(ALL)05/96]
How Does the Air Bag Supplemental
Restraint System Work?
[SS11650(ALL)05/96]
The Air Bag Supplemental Restraint System is
designed to activate when the vehicle is in a
collision similar to hitting a fixed barrier head
on at 8-14 mph. The fact that the air bags did
not inflate in a collision does not mean that
something is wrong with the system. Rather, it
means the forces were not of the type sufficient
to cause activation.
File:06prssp.ex
Update:Mon Jun 3 10:07:19 1996
Page 170 of 288
167
*
[ER03300(ALL)01/96]
RWARNING
Always replace a fuse with one that has
the specified amperage rating. Using a
fuse with a higher amperage rating can
cause severe wire damage and could start
a fire.
[ER03400(ALL)04/96]
To find a fuse's amperage rating, check the
number on the fuse or check the color.
[ER03500(ALL)01/96]
twelve pica chart:0032119-A*
[ER03600(ALL)04/96]
Even after you replace a fuse, it may continue to
blow if you do not find what caused the
overload. If the fuse continues to blow, have
your electrical system checked.
%
*
[ER03800(ALL)02/96]
Changing a Tire
*
[ER03900(ALL)02/96]
If you get a flat tire while you are driving, do
not apply the brake heavily. Instead, gradually
decrease the speed. Hold the steering wheel
firmly and slowly move to a safe place on the
side of the road. Park on a level spot, turn off
the ignition, set the parking brake, and turn on
the hazard flashers.
File:10prerp.ex
Update:Thu Jun 13 09:57:39 1996
Page 171 of 288
168 %
*
[ER04000(ALL)02/96]
The Temporary Spare Tire
%*
[ER04100(ALL)02/96]
You may have a high pressure temporary spare
tire. This spare tire is smaller than a regular tire
and is designed for emergency use only. Use it
only when you get a flat tire and replace it as
soon as you can. This spare tire is marked with
the words ªTEMPORARY USE ONLYº so that
you can easily identify it.
*
[ER04200(ALL)02/96]
RWARNING
If you use the temporary spare tire
continuously or do not follow these
precautions, the tire could fail, causing
you to lose control of the vehicle, possibly
injuring yourself or others.
*
[ER04300(ALL)02/96]
When you drive with the temporary spare tire,
DO NOT:
*
[ER04400(ALL)02/96]
q
exceed 50 mph (80 km/h) under any
circumstances.
*
[ER04500(ALL)02/96]
q
load your vehicle so that it is heavier than
the maximum vehicle load rating listed on
the tire decal.
*
[ER04700(ALL)02/96]
q
use tire chains on this tire.
File:10prerp.ex
Update:Thu Jun 13 09:57:39 1996
Page 176 of 288
173 [ER09300(ALL)01/96]
2. Remove the lug nuts by using the lug
wrench. Never loosen the hub nuts. See the
following illustration if you are not sure
where to find the lug nuts.
[ER09400(ALL)01/96]
half page art:0032086-B
Lug nut positions
*
[ER09700(ALL)01/96]
3. Replace the flat tire with the spare tire.
[ER09800(ALL)01/96]
4. Replace the lug nuts and tighten snug. The
beveled edge faces inward. Do not fully
tighten the lug nuts until you lower the
vehicle. If you do, you could force the
vehicle off the jack.
File:10prerp.ex
Update:Thu Jun 13 09:57:39 1996
Page 211 of 288
209
*
[MC25100(ALL)03/96]
q
Make sure the weight of your load is evenly
distributed.
*
[MC25200(ALL)03/96]
q
Adjust tire pressure to recommended
specifications found on the Safety Compliance
Certification Label.
*
[MC25300(ALL)03/96]
If you do not take these precautions, your tires
may fail or go flat.
*
[MC25390(ALL)03/96]
Ford Motor Company recommends obeying
posted speed limits.
*
[MC25400(ALL)03/96]
RWARNING
Driving too fast for conditions creates the
possibility of loss of vehicle control.
Driving at very high speeds for extended
periods of time may result in damage to
vehicle components.
[MC25600(ALL)01/96]
At least once a month, check the pressure in all
your vehicle's tires, including the spare. Use an
accurate tire pressure gauge. Check the tire
pressure when tires are cold, that is, after the
vehicle has been parked for at least one hour or
has been driven less than 3 miles (5 km).
[MC25700(ALL)01/96]
You can find your vehicle's proper tire inflation
pressure on the tire decal on the right door lock
pillar.
*
[MC25850(ALL)01/96]
RWARNING
Improperly inflated tires can affect vehicle
handling and can fail suddenly, possibly
resulting in loss of vehicle control.
File:11prmcp.ex
Update:Thu May 16 12:08:53 1996
Page 216 of 288
214
*
[MC28725(ALL)05/96]
RWARNING
The temperature grade for this tire is
established for a tire that is properly
inflated and not overloaded. Excessive
speed, underinflation, or excessive
loading, either separately or in
combination, can cause heat buildup and
possible tire failure.
%*
[MC28750(ALL)01/96]
Snow tires
*
[MC28770(ALL)01/96]
During the winter months in some climates, you
may need to use snow tires and occasionally
chains for your tires.
*
[MC28790(ALL)01/96]
RWARNING
Snow tires must be the same size and
grade as the tires you currently have on
your vehicle.
*
[MC28810(ALL)01/96]
Use chains on the tires only in an emergency or
if the law requires them where you live. If you
choose to use chains on your vehicle's tires, be
aware of the following:
*
[MC28820(ALL)01/96]
q
Tire chains may scratch or chip aluminum
wheels. IT IS RECOMMENDED THAT TIRE
CHAINS ARE INSTALLED ON STEEL
WHEELS ONLY. Be sure to remove wheel
covers (if equipped) from steel rims before
using tire chains to avoid scratches or
damage.
[MC28830(ALL)04/96]
q
Do not use tire chains if you have the GT
model.
*
[MC28840(ALL)01/96]
q
Local regulations may prohibit or restrict the
use of tire chains. Investigate the laws and
regulations in your area before installing
chains.
File:11prmcp.ex
Update:Thu May 16 12:08:53 1996
Page 224 of 288
222
*
[MC37000(ALL)01/96]
q
Extended use of the A/C, defroster, rear
window defroster and other accessories
*
[MC37100(ALL)01/96]
q
Underinflated tires
*
[MC37200(ALL)01/96]
q
Heavy loads
*
[MC37300(ALL)01/96]
q
Aftermarket add-ons such as bike, ski or
luggage racks, bug deflectors, etc.
[MC38000(ALL)01/96]
Air Conditioning Refrigerant
[MC38100(ALL)01/96]
Whenever service to the air conditioning system
is required, make sure the service facility uses a
refrigerant recycling system. These systems will
capture the refrigerant for reuse. Releasing
certain refrigerants into the atmosphere can
damage our environment.
%
*
[MC38200(ALL)01/96]
Emission Control System
*
[MC38300(ALL)01/96]
Your vehicle is equipped with a catalytic
converter which enables your vehicle to comply
with applicable exhaust emission requirements.
*
[MC38400(ALL)05/96]
RWARNING
Exhaust leaks may result in the entry of
harmful and potentially lethal fumes into
the passenger compartment. Under
extreme conditions excessive exhaust
temperatures could damage the fuel
system, the interior floor covering, or
other vehicle components, possibly
causing a fire.
File:11prmcp.ex
Update:Thu May 16 12:08:53 1996
Page 246 of 288
245
Customer Assistance
%*
[HS00210(ALL)05/96]
Roadside Assistance
*
[HS00215(ALL)11/95]
Ford Motor Company has set up a 24-hour,
seven-day-a-week hotline with trained operators
who put you in touch with the help you need if
you experience a problem with your vehicle.
This complimentary service is provided to you
throughout your warranty period of 3 years or
36,000 miles (60,000 km), whichever comes first.
To purchase Roadside Assistance coverages
beyond this period (available through Ford Auto
Club in the United States or Ford and
Lincoln-Mercury dealers in Canada), contact
your Ford or Lincoln-Mercury dealer. Additional
Roadside Assistance coverage is unavailable in
Puerto Rico and the Virgin Islands.
*
[HS00220(ALL)06/94]
Roadside Assistance will cover the following:
*
[HS00225(ALL)06/94]
q
Mount your spare if you have a flat tire.
*
[HS00230(ALL)06/94]
q
Jump-start your battery if it is dead.
*
[HS00235(ALL)06/94]
q
Unlock your vehicle if you are locked out.
*
[HS00240(ALL)06/94]
q
Bring you fuel if you run out.
*
[HS00245(ALL)06/94]
q
Tow your vehicle if you are stranded. Even
non-warranty related tows, like accidents or
getting stuck in mud or snow, are covered
(some exclusions apply, such as impound
towing and repossession).
File:14prhsp.ex
Update:Wed May 15 15:04:50 1996
Page 277 of 288
Index 281
F
Fan.................. 184
engine fan, avoiding injury...... 184
Federal Communications Commission.... 45
Federal Highway Administration
Regulation............... 5
Flashers, hazard............. 155
Flashing the lights............. 66
Flat tire................ 167
Foglamps................. 57
Ford Customer Assistance Center..... 247
Ford Motor Company of Canada..... 252
Ford of Canada Customer
Assistance Centre........... 252
Foreign registration........... 254
French owner guides, how to obtain.... 3
Fuel
calculating fuel economy....... 220
choosing the right fuel........ 217
filling your vehicle with fuel...... 215
filter, specifications.......... 237
fuel filler door release lever...... 215
fuel gauge............... 16
octane rating............. 217
quality................ 217
running out of fuel.......... 220
safety information relating to
automotive fuels.......... 219
storing your vehicle.......... 235
treating emergencies......... 219
Fuel cap
removing.............. 215
replacing.............215, 217
Fuel filler door
remote release............ 215
Fuel filter, specifications......... 237
Fuel gauge................ 16
File:prixp.ex
Update:Tue Jun 11 11:04:36 1996
Page 284 of 288
288 Index
Seat belts (see Safety restraints)....... 98
Seats
child safety seats........... 113
cleaning upholstery.......... 233
folding rear seats............ 96
head restraints............. 89
rear seat access............. 96
split-folding rear seat.......... 96
Serial number (VIN)........... 252
Service concerns............. 246
Servicing your vehicle
precautions when servicing...... 184
servicing when you tow........ 179
Shift positions (see Gearshift).....138, 148
Shoulder and lap belts
(see Safety restraints)....... 98,100
Shoulder belts (see Safety restraints).... 100
Side mirrors............... 78
Sliding moon roof (see Moon roof)..... 74
Snow tires and chains.......... 214
Spare tire
changing the tire.........167, 170
conventional spare.......... 169
finding the spare........... 169
removing the spare tire........ 169
storing the flat tire........169, 171
temporary spare........... 168
Spark plugs, specifications........ 237
Speed control, turning off......... 72
Speedometer............... 19
Starting your vehicle
preparing to start your vehicle..... 125
starting a cold engine......... 127
starting after a collision........ 130
starting a warm engine........ 127
starting your vehicle if the battery
is disabled............. 174
Steering, power............. 137
Steering wheel, locking........... 61
Storage compartments........... 80
File:prixp.ex
Update:Tue Jun 11 11:04:36 1996
