Page 7 of 160

TheCheck Engineindicator light illuminates when the ignition is first
turned to the ON position to check the bulb. If it comes on after the
engine is started, one of the engine's emission control systems may be
malfunctioning. The light may illuminate without a driveability concern
being noted. The vehicle will usually be drivable and will not require
towing.
What you should do if the check engine light illuminates
Light turns on solid:
This means that the OBD II system has detected a malfunction.
Temporary malfunctions may cause yourCheck Enginelight to
illuminate. Examples are:
1. The vehicle has run out of fuel.
(The engine may misfire or run poorly.)
2. Poor fuel quality or water in the fuel.
3. The fuel cap may not have been properly installed and securely
tightened.
These temporary malfunctions can be corrected by filling the fuel tank
with good quality fuel and/or properly installing and securely tightening
the gas cap. After three driving cycles without these or any other
temporary malfunctions present, theCheck Enginelight should turn off.
(A driving cycle consists of a cold engine startup followed by mixed
city/highway driving.) No additional vehicle service is required.
If theCheck Enginelight remains on, have your vehicle serviced at the
first available opportunity.
Light is blinking:
Engine misfire is occurring which could damage your catalytic converter.
You should drive in a moderate fashion (avoid heavy acceleration and
deceleration) and have your vehicle serviced at the first available
opportunity.
Under engine misfire conditions, excessive exhaust temperatures
could damage the catalytic converter, the fuel system, interior
floor coverings or other vehicle components, possibly causing a fire.
Instrumentation
7
Page 9 of 160

Turn signal
Illuminates when the left or right
turn signal or the hazard lights are
turned on. If one or both of the
indicators stay on continuously,
check for a burned-out turn signal
bulb. Refer toExterior bulbsin theMaintenance and carechapter.
High beams
Illuminates when the high beam
headlamps are turned on.
Alarm system (if equipped)
Illuminates when the alarm system
is pre-arming and flashes when the
alarm system is active. Refer to
Perimeter alarm systemin the
Controls and featureschapter.
Charging system
Illuminates when the ignition is
turned to the ON position and the
engine is off. The light also
illuminates when the battery is not
charging properly, requiring
electrical system service.
O/D off (if equipped)
Illuminates when the transmission
control switch has been pushed.
When the light is on, the
transmission does not shift into
overdrive. If the light does not come
on when the transmission control switch is depressed or if the light
flashes when you are driving, have your vehicle serviced.
THEFT
O/D
OFF
Instrumentation
9
Page 75 of 160

Utility and four-wheel drive vehicles arenotdesigned for
cornering at speeds as high as passenger cars any more than
low-slung sports cars are designed to perform satisfactorily under
off-road conditions. Avoid sharp turns or abrupt maneuvers in these
vehicles.
4WD operation is not recommended on dry pavement. Doing so could
result in difficult disengagement of the transfer case, increased tire wear
and decreased fuel economy.
4WD system indicator lights
The 4WD system indicator lights illuminate only under the following
conditions. If these lights illuminate during normal driving, have your
vehicle serviced.
²4WD HIGH± illuminates when
the ignition is turned on or when
4H (4WD High) is selected.
²4WD LOW± illuminates when
the ignition is turned on and 4L
(4WD Low) is selected.
Using the electronic shift 4WD system (if equipped)
Positions of the electronic shift system
2WD (2WD High)± Power to rear axle only.
4X4 HIGH (4WD High)± Power delivered to front and rear axles for
increased traction.
4X4 LOW (4WD Low)± Power to front and rear axles at low speeds.
4WD
HIGH
4WD
LOW
Driving
75
Page 116 of 160

²3.0L V6/4.0L V6 engine
6. Wipe the indicator clean. Insert the indicator fully, then remove it
again.
²If the oil level isbetween the MIN and MAX marks (2.5L engine)
orbetween the ADD and FULL marks (3.0L and 4.0L engine)
the oil level is acceptable.DO NOT ADD OIL.
²If the oil level is below the MIN
mark (2.5L engine) or ADD mark
(3.0L and 4.0L engine), add
enough oil to raise the level
within the MIN-MAX range
(2.5L engine) or the ADD-FULL
range (3.0L and 4.0L engine).
²Oil levels above the MAX mark (2.5L engine) or the letter F in FULL
(3.0L and 4.0L engine) may cause engine damage. Some oil must be
removed from the engine by a service technician.
7. Put the indicator back in and ensure it is fully seated.
ADD 1 QTFULL
Maintenance and care
116
Page 156 of 160

Aiming headlamps ....................142
Air bag supplemental restraint
system ..........................................47
and child safety seats ..............48
description ................................47
disposal ......................................50
indicator light ...........................50
passenger air bag ...........48,51,52
Air conditioning
manual heating and air
conditioning system .......19,20,21
Ambulance packages ....................3
Anti-lock brake system (ABS)
description ................................66
Anti-theft system ........................35
Battery .......................................128
voltage gauge ............................15
Brake fluid
checking and adding ..............118
Brakes ..........................................64
anti-lock ................................64,65
anti-lock brake system (ABS)
warning light .............................66
fluid, checking and adding ....118
Brake-shift interlock ...................67
Break-in period .............................2
Bulbs, replacing ........................139
headlamps ...............................140
specifications ..........................141
Changing a tire .........................101
Child safety seats ........................54
Chime
headlamps on ............................11
Cleaning your vehicle ...............142
engine compartment ..............143
fabric ........................................146
instrument panel ....................146
plastic parts ............................145
safety belts ..............................146
tail lamps .................................145
washing ....................................142
waxing .....................................143wheels ......................................143
windows ..................................146
Clutch
fluid ..........................................119
Controls ..................................23,31
Driving under special
conditions ....................................77
high water .................................78
slippery roads ......................78,79
Emission control system ..........138
Engine ........................................151
service points ............112,113,114
Engine block heater ...................62
Engine coolant
checking and adding ..............121
disposal ....................................122
refill capacities ........................123
Engine oil ...........................115,117
changing oil and oil filter .......118
checking and adding .......115,117
Exhaust fumes ............................63
Foglamps .....................................16
Four-Wheel Drive vehicles .........74
control trac ..........................22,75
indicator light ...........................75
Fuel
calculating fuel economy .......137
improving fuel economy ..........92
octane rating ...........................136
quality ......................................136
running out of fuel .................137
safety information relating
to automotive fuels ................135
Fuel gauge ...................................12
Fuel pump shut-off switch .........93
Fuse panels
instrument panel ......................95
power distribution box .............98
Fuses .......................................94,95
Gauges, Mechanical
engine coolant temperature
gauge .........................................13
Index
156
