Using the Power Lumbar Support and Side
Bolsters
*
[FV47400(BEF )12/91]
If your vehicle is equipped with this option, you
can inflate a lumbar support pad in the seat
back. To inflate the lumbar pad, push the (+)
side of the rocker switch. To deflate push the (-)
side of the switch.
*
[FV47500(BEF )06/92]
quarter page art:0020860-B
Power lumbar switch
*
[FV47550( F )06/93]
quarter page art:0021085-A
Power lumbar switch - 40/20/40 seat
*
[FV47600(BEF )04/95]
Cleaning the Seats
*
[FV47620(BEF )05/95]
Leather and vinyl
*
[FV47625(BEF )05/95]
For routine cleaning, wipe the surface with a
soft, damp cloth. For more thorough cleaning,
wipe the surface with a leather and vinyl cleaner
or a mild soap.
*
[FV47630(BEF )04/95]
Wipe the surface with a damp, soft cloth, then
dry and buff with a dry, soft cloth.
File:ltfvf.ex
Update:Thu May 9 15:20:08 1996

130
*
[FV47640(BEF )04/95]
Fabric
*
[FV47650(BEF )04/95]
Remove dust and loose dirt with a whisk broom
or a vacuum cleaner. Remove fresh spots
immediately. Follow the directions that come
with the cleaner.
*
[FV47660(BEF )04/95]
NOTE: Before using any cleaner, test it on a
small, hidden area of fabric. If the
fabric's color or texture is adversely
affected by a particular cleaner, do not
use it.
*
[FV50000(BEF )01/95]
Mirrors
*
[FV50200(BEF )03/91]
With the door closed and the seat adjusted for
comfort and proper vehicle control, move the
mirrors for best view by tilting up or down, left
or right. Do not adjust the mirrors while the
vehicle is in motion.
*
[FV50325(BEF )05/95]
RWARNING
Make sure you can see clearly through the
rearview mirror at all times. Do not allow
anything to block your vision. If you can't
see through the mirror, you could be
involved in an accident and injure
yourself or others.
File:ltfvf.ex
Update:Thu May 9 15:20:08 1996

131 %
*
[FV50700(B F )01/95]
Automatic Dimming Inside Rearview
Mirror (If equipped)
*
[FV50850(B F )03/93]
half page art:0021008-A
Automatic dimming inside rearview mirror
*
[FV50900(B F )03/93]
This mirror is equipped with an electrochromic
glare control feature that automatically darkens
the mirror, reducing glare from the headlamps
of vehicles behind you. A forward facing light
sensor measures the ambient light just as your
eyes do. When the rear facing light sensor in the
glass senses glare, such as from following
headlights, it energizes a chemical layer in the
glass causing it to darken and absorb light. As
the glare subsides, the mirror glass returns to its
normal clear state.
File:ltfvf.ex
Update:Thu May 9 15:20:08 1996

132
*
[FV51050(B F )03/94]
To turn the mirror on, push the On/Off switch,
located on the bottom of the mirror, to latch it
in the ON position. The button will be latched in
the up position and at night a low intensity
green light will be visible from the button when
the mirror is turned on. To turn the mirror off,
push the On/Off switch again and the button
will unlatch shutting off the light and the mirror
will be off.
*
[FV51100(B F )03/93]
DemonstrationÐ The mirror's operation may
be demonstrated by simulating glare as follows:
*
[FV51200(B F )03/94]
1. Cover the forward facing sensor, located on
the right side of the mirror back, with a
dark (preferably black) cloth. Hold the dark
cloth over the sensor until you notice the
mirror glass start to darken to the non-glare
state. If the surrounding lighting conditions
are too dark it may be necessary to shine
additional lighting, such as from a flashlight,
on the rearward sensor located on the glass
face.
*
[FV51400(B F )03/93]
2. Remove the cloth (and shut off the flashlight
if applicable) and the glass will return to the
clear reflective stage.
*
[FV51500(B F )01/95]
One important safety feature is that the mirror
automatically returns to the normal position
whenever the vehicle is placed in R (Reverse)
(when the mirror is in the ON position). This
feature ensures a bright clear view in the mirror
when backing up.
File:ltfvf.ex
Update:Thu May 9 15:20:08 1996

133
*
[FV52400( EF )05/93]
Illuminated Vanity Mirror (If equipped)
*
[FV52500( EF )05/93]
Your vehicle may feature illuminated vanity
mirrors on the sun visors. You can turn on the
lighted mirror by lifting the mirror door cover.
*
[FV52600( EF )05/93]
quarter page art:0020251-A
Visor vanity mirror
*
[FV52700( F )05/93]
Visors that are equipped with the lighted vanity
mirror also have an auxiliary visor. The auxiliary
visor slides right and left to cover the
windshield when the primary visor is pivoted to
the door window.
*
[FV52800( F )05/93]
one third page art:0020665-A
Auxiliary sun visor
File:ltfvf.ex
Update:Thu May 9 15:20:08 1996

134
*
[FV52900(BEF )12/89]
Outside Mirrors (Manual Control)
*
[FV53000(BEF )10/89]
Adjust outside mirrors with the door closed and
the seat adjusted for comfort and proper vehicle
control. Move the mirrors for best view by
tilting up or down, left or right.
*
[FV53100(BEF )03/95]
On vehicles equipped with fold-away mirrors,
the mirrors should be folded rearward into the
body position before entering automatic car
wash systems.
*
[FV53300(B F )12/91]
quarter page art:0020900-B
Standard fold-away mirror
*
[FV53500( F )05/91]
one third page art:0020254-C
Low-mount swingaway mirror and swing-out recreational
mirror
*
[FV53900( EF )05/90]
On vehicles equipped with ªnonº folding
(swing-out recreational) mirrors, automatic car
wash systems are not recommended. Use special
truck wash facilities for vehicles with this type
of mirror.
File:ltfvf.ex
Update:Thu May 9 15:20:08 1996

135
*
[FV54300( F )01/93]
For vehicles equipped with the swing-out
recreational mirrors, the right-hand side mirror is a
flat glass mirror. All other right-hand side view
mirrors used are convex. Convex mirrors have a
curved surface and will show a wider view of the
lane next to and behind your vehicle.
*
[FV54400(BEF )05/95]
RWARNING
The side view mirror on the right makes
objects appear smaller and farther away
than they actually are.
*
[FV54500(BEF )08/91]
Dual Electric Remote Control Mirrors
(If equipped)
*
[FV54600(BEF )08/91]
To adjust the remote controlled side mirrors:
*
[FV54800(BEF )06/94]
1. Find the control switch in the driver's door
panel.
*
[FV55000(BEF )06/94]
2. Select the right or left mirror by moving the
selector switch to R or L.
*
[FV55200(BEF )06/94]
3. Move the control knob in the direction you
want to move the mirror.
*
[FV55400(BEF )06/94]
4. Return the selector switch to the middle
position to keep the mirror in place.
*
[FV55700(B F )12/91]
quarter page art:0020886-A
Power mirror control
*
[FV55900(BEF )12/91]
Do not clean the plastic housing of any electric
mirror with gasoline or other petroleum-based
cleaning products.
File:ltfvf.ex
Update:Thu May 9 15:20:08 1996

136
*
[FV59400(BEF )01/95]
Console
*
[FV59500(BEF )12/91]
Your vehicle may have a full console. The full
console has the features shown in the illustration
below.
*
[FV60100(B F )12/91]
half page art:0020683-C
The features on the console
File:ltfvf.ex
Update:Thu May 9 15:20:08 1996

137
*
[FV60200(B F )12/91]
three fourths page art:0020909-A
Seat mounted console
File:ltfvf.ex
Update:Thu May 9 15:20:08 1996

138
*
[FV69900(BEF )03/95]
Power Point Electrical Outlet
*
[FV70000(B F )05/94]
The power point outlet is located on the
instrument panel to the right of the shift lever.
This outlet should be used in place of the
cigarette lighter for optional electrical accessories.
*
[FV70200(BEF )06/92]
NOTE: Do not use the cigarette lighter in
place of the power point.
*
[FV70300(B F )06/92]
quarter page art:0020929-A
Power point electrical outlet
*
[FV70500(B F )07/92]
To access the outlet, lift up the hinged cover.
