FORD SUPER DUTY 2003 1.G Diesel Supplement Manual
Manufacturer: FORD, Model Year: 2003, Model line: SUPER DUTY, Model: FORD SUPER DUTY 2003 1.GPages: 64, PDF Size: 0.31 MB
Page 41 of 64
IF THE ENGINE RUNS HOT
The following could cause the engine to overheat:
•Lack of coolant.
•Dirty cooling system.
•Plugged radiator fins, charge air cooler, A/C condenser and/or oil
cooler.
•Driving with frozen coolant.
•Sticking thermostat.
•Overloading or pulling heavy trailers during hot weather.
•Grill or radiator air blockage.
•Slipping or missing drive belt.
•Plugged or very dirty air cleaner element.
IF FUSES BURN OUT
Burned-out or blown fuses usually indicate an electrical short-circuit,
although a fuse may occasionally burn out from vibration. Insert a second
fuse. If this fuse immediately burns out and you cannot locate the cause,
return your vehicle to your dealer for a circuit check.
Replacement fuses and circuit breakers must always be the same
rating as the original equipment shown. Never replace a fuse or
circuit breaker with one of a higher rating. Higher rated fuses or circuit
breakers could allow circuit overloading in the event of a circuit
malfunction, resulting in severe vehicle damage or personal injury.
Refer to the“Owner Guide”for replacement of fuses.
Minor troubleshooting guide
41
Page 42 of 64
REFILL CAPACITIES
Component Capacity
Cooling system126.0L (27.5 quarts)
Engine oil214.2L (15.0 quarts)
Fuel tank (F-250/350/450/550) Refer to Owner Guide
Fuel tank (Excursion) 166.6L (44.0 gallons)
Radiator cap 110 kPa (16 psi)
Manual transmission
35.5L (5.8 quarts)
Automatic transmission Refer to Owner Guide
1Includes heater and 4.7L (5 quarts) in coolant recovery.
2Includes 1.0L (1 quart) in engine oil filter.
3Use Motorcraft MERCONATF, Motorcraft part number XT-2–QDX,
meeting Ford specification MERCON.
BULB SPECIFICATIONS
Lamp descriptionNumber of bulbs
requiredTrade number
Wait to Start Light 1 194
Water-in-Fuel Light 1 194
Engine Temp. Light 1 194
Capacities and specifications
42
Page 43 of 64
LUBRICANT AND MAINTENANCE MATERIALS SPECIFICATIONS
ItemFord Part
NameFord Part
NumberFord
Specification
Engine OilMotorcraft Motor
Oil 15W40 Super
Duty, 10W30
Super Duty
1
XO-15W40-QSD,
XO-10W30-QSDWSS-M2C171-D,
CI-4/SL, DHD-1
Engine Oil Filter
(Use this filter
Only)-3C3Z-6731–AA
(FL–2016)-
Air Filter
2- FA-1680 ES-E95AE-9601-AA
Battery (2
Required)- BXT-65-750 -
Engine coolant Motorcraft
Premium Gold
Engine Coolant
(yellow-colored)VC-7–A WSS-M97B51–A1
Manual
TransmissionMotorcraft
MERCONAT FXT-2–QDX MERCON
1Refer to the engine oil specification chart located underEngine oil
specificationsin theGeneral maintenance informationchapter.
2Always use the authorized Motorcraft air filter listed.Failure to use
the correct air filter may result in severe engine damage.
Capacities and specifications
43
Page 44 of 64
1. Battery (dual batteries shown)
2. Air filter assembly
3. Power steering fluid reservoir
4. Clutch fluid reservoir (if equipped)
5. Brake fluid reservoir
6. Engine coolant reservoir
7. Engine oil dipstick
8. Engine-mounted fuel filter assembly
9. Engine oil filter
10. Engine oil filler
Service points
44
Page 45 of 64
GENERAL OWNER’S INFORMATION
Vehicle Identification Number (VIN):
Owner Name:
Address:
Your satisfaction is our #1 goal. If you have questions or concerns about your vehicle, we suggest you
follow these steps:
1. Contact your Sales Representative or Service Advisor at your selling/servicing dealership.
2. If the inquiry or concern remains unresolved, contact the Sales Manager or Service Manager at the
dealership.
3. If the inquiry or concern cannot be resolved at the dealership level, please contact the Ford
Customer Assistance Center.
In the US, contact:
Ford Motor Company Customer Assistance Center
16800 Executive Plaza Drive, P.O. Box 6248
Dearborn, Michigan 48126
1-800-392-3673 (FORD)
TDD for the hearing impaired: 1-800-232-5952
In Canada, contact:
Customer Assistance Center
Ford Motor Company of Canada, Limited
P.O. Box 2000
Oakville, Ontario L6J 5E4
1-800-565-3673 (FORD)
General Owner’s Information
45
Page 46 of 64
In Puerto Rico and Virgin Islands, contact:
Ford Motor Company Caribbean Inc.
P.O. Box 11957, Caparra Heights Station
San Juan, PR 00922-1957
Telephone: (787) 782-5959
Fax: (787) 781-8975
E-mail: [email protected]
In Caribbean, Central America, Israel and
Sub-Saharan Africa, contact:
Ford Motor Company
Worldwide Direct Market Operations
Attention: Owner Relations
1555 Fairlane Drive, Fairlane Business Park #3
Allen Park, MI 48101 U.S.A.
Telephone: (313) 594-4857
Fax: (313) 390-0804
E-mail: [email protected]
In the Middle East and North Africa, contact:
Ford Middle East and North Africa
Customer Assistance Center
API World Tower 17
thFloor
Sheikh Zayed Road
Dubai, United Arab Emirates
Telephone: 971-4-326084
Fax: 971-4-327299
E-mail: [email protected]
General Owner’s Information
46
Page 47 of 64
FIND YOUR WAY
Symbol Key
Diesel
Towing a trailer or using a camper or car-top
carrier
Extensive idling and/or low-speed driving for long
distances as in heavy commercial use such as
delivery, taxi, patrol car or livery
Operating in dusty conditions such as unpaved or
dusty roads
Off-road operation
Short trip cold operating conditions
GENERAL MAINTENANCE INFORMATION
Why maintain your vehicle?
This guide describes the scheduled maintenance required for your
vehicle. Carefully following this schedule helps protect against major
repair expenses resulting from neglect or inadequate maintenance and
may also help to increase the value of your vehicle when you sell or
trade it.
It is your responsibility to see that all scheduled maintenance is
performed and that the materials used meet Ford engineering
specifications. Failure to perform scheduled maintenance specific in this
guide will invalidate warranty coverage on parts affected by the lack of
maintenance. Be sure receipts for completed maintenance are kept with
the vehicle and confirmation of the work performed is always recorded in
this guide.
Your Ford or Lincoln Mercury dealer, or Ford or Lincoln Mercury Quality
Care Center has factory trained technicians who can perform the
required maintenance using genuine Ford parts. They are committed to
meeting your service needs and to assuring your continuing satisfaction.
General Owner’s Information
47
Page 48 of 64
Protecting your investment
Maintenance is an investment that will pay dividends in the form of
improved reliability, durability and resale value. To assure the proper
performance of your vehicle and its emission control systems, it is
imperative that scheduled maintenance be completed at the designated
intervals.
Ford strongly recommends the use of genuine Ford replacement parts.
Parts other than Ford, Motorcraft or Ford authorized remanufactured
parts that are used for maintenance replacement or for the service of
components affecting emission control must be equivalent to genuine
Ford Motor Company parts in performance and durability. It is the
owner’s responsibility to determine the equivalency of such parts. Please
consult your Warranty Guide for complete warranty information.
Quality Care - one stop for all your maintenance needs
When you need maintenance for your Ford, Lincoln or Mercury vehicle,
there’s only one name to remember: Quality Care, available at your Ford
and Lincoln Mercury dealership. From scheduled maintenance to more
complicated repair work, nobody knows your car or truck better. Protect
your investment by choosing Quality Care service.
The right people
The difference is factory training and equipment, which means nobody is
more qualified to work on your Ford, Lincoln or Mercury than our
Quality Care service technicians. They’ll fix it right the first time.
The right parts
From headlights to taillights and everything in between, nothing fits like
an original. With Quality Care service, you’ll get the parts made
especially for your car or truck–genuine Ford and Motorcraftparts.
The right prices
Our commitment to quality extends to pricing as well as service. Your
Ford and Lincoln Mercury Dealership offers competitive prices on
Genuine Ford and Motorcraftparts and services, making Quality Care a
great value.
WHICH MAINTENANCE SCHEDULE SHOULD YOU FOLLOW?
Owner Checks and Services
Refer to Mileage Intervals for Additional Checks and Services
Certain basic maintenance checks and inspections should be performed by
the owner or a service technician at the intervals indicated. Service
information and supporting specifications are provided in the Owner’s Guide.
General Owner’s Information
48
Page 49 of 64
Any adverse condition should be brought to the attention of your dealer
or qualified service technician as soon as possible for the proper service
advice. The owner maintenance service checks are generally not covered
by warranties so you may be charged for labor, parts or lubricants used.
Maximum Oil Change Interval:
Normal Schedule: 7,500 miles or 6 months, whichever occurs first.
Special Operating Conditions: 5,000 miles or 6 months, see appropriate
schedule.
Check every month:
•Check function of all interior and exterior lights
•Check tires for wear and proper air pressure
•Check engine oil fluid level
•Check windshield washer solvent fluid level
•Check and drain fuel filter/water separator
Check every six months:
•Check lap/shoulder belts and seat latches for wear and function
•Check air pressure in spare tire
•Check that externally-mounted spare tire is tight (see Owner’s Guide)
•Check power steering fluid level
•Check washer spray, wiper operation and clean all wiper blades
•Check parking brake for proper operation
•Check and lubricate all hinges, latches and outside locks
•Check and lubricate door rubber weatherstrips
•Check and clean body and door drain holes
•Check safety warning lamps (brake, ABS, air bag, safety belt) for
operation
•Check cooling system fluid level and coolant strength
•Check battery connections and clean if necessary
•Check clutch fluid level, if equipped
General Owner’s Information
49
Page 50 of 64
NORMAL SCHEDULE
The following section contains the“Normal Schedule.”This schedule is
presented at specific mileage intervals with exceptions noted.
Additional information available on the Web
To learn more about the importance of routine and dealer-performed
maintenance on your vehicle, please visit the Ford Customer Service
website. You’ll also find important warranty information, customer
assistance, technical expertise, frequently asked questions and much
more. The website location is at: www.ford.com/
Then go to the service pick at the web site.
12,000 km (7,500 miles)
•Change engine oil and replace oil filter
•Inspect tires for wear and measure tread depth
•Rotate tires
•Inspect engine air filter
24,000 km (15,000 miles)
•Change engine oil and replace oil filter
•Inspect tires for wear and measure tread depth
•Rotate tires
•Inspect engine air filter
•Replace engine- and frame-mounted fuel filters
•Inspect steering linkage, suspension and, if equipped, driveshaft and
ball joints
•Inspect engine cooling system and hoses
•Inspect brake system
•Inspect exhaust system and heat shields
•Check wheels for end play and noise
•Inspect and lubricate 4x2 ball joints (except F-450/F-550)
•Inspect and lubricate steering idler arms
•Replace cabin air filter, if equipped
•Inspect half-shaft boots, if equipped
36,000 km (22,500 miles)
•Change engine oil and replace oil filter
•Inspect engine air filter
General Owner’s Information
50
