FORD TAURUS 1996 Service Manual

39
*
[SR23250(ALL)08/95]
4. Grasp the shoulder portion of the belt and
pull downward until all of the belt is
extracted and a click is heard. At this time,
the retractor is in the automatic locking
mode (child seat restraint mode).
See Figure 4.
*
[SR23301(ALL)06/95]
half page art:0011241-A
Setting the retractor to automatic locking mode
*
[SR23350(ALL)07/95]
5. Allow the belt to retract. Pull up on the
shoulder webbing. A clicking sound will be
heard as the belt retracts. This indicates the
retractor is in the automatic locking mode.
Push down on the child seat while you pull
up on the belt to remove any slack in the
belt. Figures 5 and 6.
File:03fcsrt.ex
Update:Mon Jan 22 15:46:18 1996
ProCarManuals.com

40
*
[SR23401(ALL)09/95]
half page art:0011242-A
Allowing shoulder belt to retract
*
[SR23450(ALL)09/95]
half page art:0011243-A
Removing slack from belt
File:03fcsrt.ex
Update:Mon Jan 22 15:46:18 1996
ProCarManuals.com

41
*
[SR23501(ALL)07/95]
6. Before placing the child in the child seat,
forcibly tilt the seat from side to side, and
tug it forward to make sure that the seat is
securely held in place, Figure 7.
*
[SR23550(ALL)06/95]
half page art:0011244-A
Checking that the seat is secure
File:03fcsrt.ex
Update:Mon Jan 22 15:46:18 1996
ProCarManuals.com

42
*
[SR23601(ALL)11/94]
7. Double check that the retractor is in the
automatic locking mode. Try to pull more
belt out of the retractor. If you cannot, the
belt is in the automatic locking mode,
Figure 8.
*
[SR23650(ALL)06/95]
half page art:0011245-B
Checking the retractor
*
[SR23701(ALL)05/95]
8. Check to make sure that the child seat is
properly secured prior to each use. If the
retractor is not locked, repeat steps 4
through 7.
*
[SR23750(ALL)05/95]
NOTE: To remove the retractor from automatic
lock mode, allow seat belt to retract
fully to its stowed position and the
retractor will automatically switch back
to the vehicle sensitive locking mode
for normal adult usage.
File:03fcsrt.ex
Update:Mon Jan 22 15:46:18 1996
ProCarManuals.com

43
*
[SR24750(ALL)08/95]
RWARNING
Carefully follow all of the manufacturer's
instructions included with the safety seat
you put in your vehicle. If you do not
install and use the safety seat properly,
the child may be injured in a sudden stop
or collision.
%*
[SR24800(ALL)06/95]
Attaching Safety Seats With Tether Straps
*
[SR24950(ALL)06/95]
Some manufacturers make safety seats that
include a tether strap that goes over the back of
the vehicle seat and attaches to an anchoring
point. Other manufacturers offer the tether strap
as an accessory. Contact the manufacturer of
your child safety seat for information about
ordering a tether strap.
*
[SR25050(ALL)08/95]
Front Seats
*
[SR25150(ALL)08/95]
To install a tether from a child safety seat in the
front seat:
*
[SR25250(ALL)08/95]
1. Buckle the lap/shoulder belt (in the seat
directly behind the front passenger seat in
which the child safety seat will be installed).
*
[SR25350(ALL)07/95]
2. Pull all the stored belt out of the rear seat
retractor to switch the retractor to automatic
locking mode.
*
[SR25375(ALL)08/95]
3. Let the retractor wind up the slack from the
lap/shoulder belt.
*
[SR25425(ALL)08/95]
4. Install the child safety seat in the front seat.
Refer to the previous section onInstalling
Safety Seats. Hook the tether strap hook
around the webbing near the center of the
shoulder portion of the locked lap/shoulder
belt.
*
[SR25525(ALL)08/95]
5. Tighten the tether strap.
File:03fcsrt.ex
Update:Mon Jan 22 15:46:18 1996
ProCarManuals.com

44
*
[SR25550(ALL)07/95]
Rear Seats
*
[SR25600(ALL)07/95]
If you use a tethered safety seat on one of the
rear seats, you can anchor the strap to the
appropriate tether anchor directly behind that
seat position.
*
[SR25725(ALL)06/95]
Tether anchorage hardware
[SR25800(ALL)06/95]
Attachment holes (at each rear outboard seating
position) have been provided in your vehicle to
attach anchor hardware, if required. Kits can be
obtained at no charge from any Ford or
Lincoln-Mercury dealer.
*
[SR26100(ALL)06/95]
Be sure to follow the child safety seat
manufacturer's instructions.
*
[SR26500(ALL)06/95]
RWARNING
Tighten the anchor according to
specifications. Otherwise, the safety seat
may not be properly secured and the child
may be injured in a sudden stop or
collision.
[SR26600(ALL)04/95]
In a station wagon, you simply attach the tether
strap to one of the anchors that are already
installed for you.
*
[SR26615(ALL)06/95]
Tether anchorage hardware
[SR26630(ALL)04/95]
All wagons have a tether anchor installed for
each of the second row seating positions.
File:03fcsrt.ex
Update:Mon Jan 22 15:46:18 1996
ProCarManuals.com

45 [SR26700(ALL)04/95]
two third page art:0000041-C
Finding the tether anchors in the wagon
[SR26750(ALL)04/95]
1. Behind the second seat, find the plastic
snap-on covers for the floor anchors.
*
[SR26801(ALL)04/95]
2. Use a screwdriver or coin to snap the covers
off the anchor in a rearward and upward
direction. Remove the covers completely.
[SR26850(ALL)04/95]
3. Snap the tether strap hook onto the
U-shaped tether anchor.
File:03fcsrt.ex
Update:Mon Jan 22 15:46:18 1996
ProCarManuals.com

46 [SR26900(ALL)04/95]Built-In Child Seat (Wagon Ð If equipped)
[SR26950(ALL)04/95]
The second row seat may include an optional
built-in child safety seat on the passenger side.
The child restraint is to be usedonlyby children
who are at least one year old, weigh between 9
and 27 kilograms (20 and 60 pounds) and whose
shoulders (top) are below the shoulder harness
slots in the seatback.
*
[SR27000(ALL)08/95]
If your child is less than one year old or weighs
less than 9 kilograms (20 pounds),alwaysuse a
rear facing infant or convertible seat because a
child of that size is not sufficiently developed to
withstand crash forces in a front facing position.
Follow the specific manufacturer's instructions
for weight and height restrictions.
*
[SR27051(ALL)08/95]
Children must be properly buckled before riding
in the vehicle. It is the law in every state and
province. This child seat conforms to all
Federal/Canadian motor vehicle safety
standards.
*
[SR27100(ALL)08/95]
Built-in child seat belt retractors
*
[SR27150(ALL)08/95]
The belts on the built-in child seat are equipped
with a retractor that locks when both belt
tongues are latched into the crotch safety belt
buckle.
[SR27251(ALL)12/95]
The retractor will automatically snug the belts
around the child. Frequently check the child
seat's lap and shoulder harness belts for correct
placement and tightness. Use the child seat only
if the harness belts will stay snug with a child
buckled in the seat. If belts do not remain snug,
take the vehicle to the dealer for child seat
repair.
File:03fcsrt.ex
Update:Mon Jan 22 15:46:18 1996
ProCarManuals.com

47 [SR27300(ALL)12/95]
RWARNING
Always adjust the lap and shoulder
harness belts provided with this child seat
snugly around your child.
*
[SR27351(ALL)08/95]
RWARNING
Never leave a child unattended in your
vehicle.
*
[SR27400(ALL)08/95]
RWARNING
Safety belts and seats can become hot in a
vehicle that has been closed up in sunny
weather; they could burn a small child.
Check seat covers and buckles before you
place a child anywhere near them.
*
[SR27451(ALL)08/95]
RWARNING
Failure to follow all of the instructions on
the use of this child restraint system can
result in your child striking the vehicle's
interior during a sudden stop or crash.
*
[SR27500(ALL)08/95]
How to use the Built-In Child Seat
*
[SR27551(ALL)05/95]
Read the following procedures and all of the
labels on the Built-In Child Seat before using the
seat.
*
[SR27600(ALL)08/95]
RWARNING
Never use the Built-In Child Seat as a
booster cushion with the adult safety
belts. A child using the adult belts could
slide forward and out from under the
safety belts.
File:03fcsrt.ex
Update:Mon Jan 22 15:46:18 1996
ProCarManuals.com

48 [SR27605(ALL)12/95]1. Pull and release flap from top of seatback.
See Figure 1.
[SR27620(ALL)12/95]
NOTE: The child seat cannot be opened unless
the seatback is latched in the upright
position.
[SR27630(ALL)12/95]
one third page art:0001500-A
Figure 1: Releasing the flap
[SR27651(ALL)12/95]
2. Grasp the child seat at the top of the
seatback and pull the top forward to release
the latch. See Figure 2.
[SR27770(ALL)12/95]
one third page art:0001452-B
Figure 2: Releasing the latch
