Improve your ventilation by keeping all air inlet
vents clear of snow, leaves, and other debris.
*
[ST13300(ALL)08/95]
If the engine is idling while you are stopped in
an open area for long periods of time, open the
windows at least one inch (2.5 cm). Also, adjust
the heating or air conditioning system to bring
in outside air.
[ST13600(ALL)03/95]
q
If you use the heater, set the fan speed on
either medium or HI with the select knob on
eitherR(floor) or VENT.
[ST13900(ALL)03/95]
q
If you use the air conditioner, set the fan
speed on either medium or HI with the select
knob on A/C. (Do not use MAX A/C.)
[ST14000(ALL)03/95]
q
If you use the automatic temperature control,
set the fan speed on medium or high and
press theS(panel and floor) orR(floor)
manual override button. (Do not use AUTO
or MAX A/C.)
File:04fcstt.ex
Update:Mon Jan 22 15:46:50 1996
ProCarManuals.com
Page 72 of 369
71
Warning Lights and
Gauges
%*
[LG00500(ALL)05/92]
In your vehicle, the warning lights and gauges
are grouped together on the instrument panel.
We call this grouping a cluster. Your vehicle has
one of the following clusters:
[LG00800(ALL)02/95]
q
Standard cluster
[LG00900(ALL)02/95]
q
Optional cluster
[LG00950( T)02/95]
q
SHO cluster
*
[LG01100(ALL)05/94]
If you are not sure which cluster your vehicle
has, check the diagrams on the following pages.
% [LG02050(ALL)05/95]The Standard Cluster
[LG02075(ALL)02/95]
The following warning lights and gauges are on
the standard cluster. All of the warning lights
and gauges alert you to possible problems with
your vehicle. Some of the lights listed are
optional. The following sections detail what each
of these indicators means.
File:05fclgt.ex
Update:Tue Jan 23 08:14:15 1996
ProCarManuals.com
Page 73 of 369
72 [LG02101(ALL)03/95]
full page art:0000663-HThe standard cluster
File:05fclgt.ex
Update:Tue Jan 23 08:14:15 1996
ProCarManuals.com
Page 74 of 369
73
*
[LG02400(ALL)01/95]
Indicator Lights and Chimes
%*
[LG02500(ALL)07/95]
Safety Belt Warning Light and Chime
*
[LG02510(ALL)09/95]
This warning light and chime remind you to
fasten your safety belt. The following conditions
will take place:
[LG02550(ALL)12/95]
q
If the driver's safety belt is not buckled when
the key is turned to the ON position, the
light will activate for 1 to 2 minutes and the
chime will sound for 4 to 8 seconds.
*
[LG02600(ALL)03/95]
q
If the driver's safety belt is buckled while the
light is on or the chime is sounding, both the
light and the chime will turn off.
[LG02650(ALL)12/95]
q
If the driver's safety belt is buckled before the
key is turned to the ON position, the light
will briefly activate, then shut off and the
chime will not activate.
[LG02700(ALL)02/95]
one inch art:0000107-B
Safety belt warning light
%*
[LG02900(ALL)06/95]
Brake System Warning Light
*
[LG03000(ALL)03/95]
The warning light for the brakes can show two
things Ð that the parking brake is not fully
released, or that the brake fluid level is low in
the master cylinder reservoir. If the fluid level is
low, the brake system should be checked by
your dealer or a qualified service technician.
File:05fclgt.ex
Update:Tue Jan 23 08:14:15 1996
ProCarManuals.com
Page 75 of 369
74 [LG03300(ALL)02/95]
one inch art:0000108-DBrake system warning light
*
[LG03500(ALL)01/95]
This light comes on when the parking brake is
set, or if it is not set, it comes on briefly when
you turn the ignition to the START position. It
normally goes off shortly after the engine starts
and you release the parking brake. If the light
stays on after you have fully released the
parking brake, have the hydraulic brake system
serviced by your dealer or a qualified service
technician.
*
[LG03700(ALL)05/95]
RWARNING
The BRAKE light indicates that the brakes
may not be working properly. Have the
brakes checked immediately.
%*
[LG03800(ALL)01/95]
Charging System Light
*
[LG03900(ALL)03/95]
This light, shown as a battery symbol on your
cluster, indicates that your battery is not being
charged and that you need to have the electrical
system checked.
[LG04000(ALL)02/95]
one inch art:0000278-B
Charging system light
File:05fclgt.ex
Update:Tue Jan 23 08:14:15 1996
ProCarManuals.com
Page 76 of 369
75
*
[LG04300(ALL)11/94]
This light comes on every time you turn your
ignition key to the ON or START position. The
light should go off when the engine starts and
the alternator begins to charge.
*
[LG04400(ALL)01/95]
If the light stays on or comes on when the
engine is running, have the electrical system
checked as soon as possible.
%*
[LG04800(ALL)02/95]
Engine Oil Pressure Warning Light
[LG04900(ALL)02/95]
This light indicates the engine's oil pressure, not
the oil level. However, if the engine's oil level is
low, it could affect the oil pressure. The light
should come on every time the ignition key is
turned to the ON or START position, and
should turn off after the engine is running.
[LG04950(ALL)02/95]
one inch art:0001025-B
Engine oil pressure warning light
[LG05100(ALL)11/94]
If the light stays on or turns on when the engine
is running, the engine has lost oil pressure and
continued operation will cause severe engine
damage.
*
[LG05105(ALL)03/95]
If you lose engine oil pressure:
*
[LG05200(ALL)03/95]
1. Pull off the road as soon as safely possible.
*
[LG05300(ALL)11/94]
2. Shut off the engine immediately. If you do
not stop the engine as soon as safely
possible, severe engine damage could result.
File:05fclgt.ex
Update:Tue Jan 23 08:14:15 1996
ProCarManuals.com
Page 77 of 369
76
*
[LG05400(ALL)10/95]
3. Check the engine's oil level, following the
instructions on checking and adding engine
oil in this Owner Guide. (SeeEngine oilin
the Index.) If you do not follow these
instructions, engine damage could result. To
ensure an accurate reading, your vehicle
should be on level ground.
*
[LG05500(ALL)11/94]
4. If the level is low, add only as much oil as
necessary to bring it to the full level before
you start the engine again. Do not overfill.
Do not operate the engine if the light is on,
regardless of the oil level. Contact your
nearest dealer for further service actions.
%*
[LG06200(ALL)01/95]
High Beam Light
*
[LG06300(ALL)03/95]
This light comes on when the headlamps are
turned to high beam or when you flash the
lights.
[LG06350(ALL)02/95]
If your vehicle is equipped with Daylight
Running Lamps (DRL), the high beam light will
not come on when you flash the lights.
[LG06400(ALL)02/95]
one inch art:0000111-B
High beam light
File:05fclgt.ex
Update:Tue Jan 23 08:14:15 1996
ProCarManuals.com
Page 78 of 369
77 %
*
[LG06500(ALL)03/95]
Door Ajar Light and Chime
[LG06800(ALL)03/95]
This light comes on and a single chime sounds if
one of the doors or the liftgate or liftgate
window (wagon) is not completely shut and the
ignition is in the ON position.
[LG06850(ALL)02/95]
one inch art:0000113-B
Door ajar light
%*
[LG07000(ALL)05/95]
Chime for Headlamps On
*
[LG07100(ALL)07/95]
This chime sounds if the driver or any passenger
door is open when the parking lamps or
headlamps are on. The chime sounds until you
close the door, turn off the lamps or turn the
ignition to the ON position.
[LG07200(ALL)03/95]
A 3-second chime sounds after a 20-second delay
if the ignition has been turned to the OFF
position, the parking lamps or headlamps are
on, and no door has been opened.
%*
[LG07400(ALL)01/95]
Air Bag Readiness Light
*
[LG07620(ALL)05/95]
A problem with the system is indicated by one
or more of the following: the readiness light will
either flash or stay lit, or it will not light, or a
group of five beeps will be heard.
*
[LG07640(ALL)05/95]
RWARNING
If any of these things happen, even
intermittently, have the air bag system
serviced at your Ford or Lincoln-Mercury
dealer immediately.
File:05fclgt.ex
Update:Tue Jan 23 08:14:15 1996
ProCarManuals.com
Page 79 of 369
78 [LG07650(ALL)11/94]
one inch art:0000653-CAir bag readiness light
%*
[LG07700(ALL)11/94]
Service Engine Soon Warning Light
*
[LG07750(ALL)03/95]
The Powertrain On-Board Diagnostic II (OBD II)
system consists of the hardware and software
necessary to monitor the operation of the
powertrain. The OBD II system is designed to
check the function of the vehicle's powertrain
control system during normal operation. If an
emission problem is detected, the Service Engine
Soon light (in the cluster) is turned on.
*
[LG07775(ALL)05/95]
Modification or additions to the vehicle may
cause incorrect operation of the OBD II system.
Additions such as burglar alarms, cellular
phones, and CB radios must be carefully
installed. Do not install these devices by tapping
into or running wires close to powertrain control
system wires or components.
[LG07800(ALL)02/95]
one inch art:0000282-B
Service engine soon light
File:05fclgt.ex
Update:Tue Jan 23 08:14:15 1996
ProCarManuals.com
Page 80 of 369
79 [LG07825(ALL)03/95]
This light comes on when you turn the ignition
key to ON, but should turn off when the engine
starts. If the light does not come on when you
turn the ignition to ON or if it comes on and
stays on when you are driving, have your
vehicle serviced as soon as possible. This
indicates a possible problem with one of the
vehicle's emission control systems. You do not
need to have your vehicle towed in.
[LG07851(ALL)10/95]
If the light turns on and off at one (1) second
intervals while you are driving the vehicle, it
means that the engine is misfiring. If this
condition persists, damage could occur to the
engine or catalytic converter. Avoid heavy
acceleration and have your vehicle serviced at
the first opportunity. You do not need to have
your vehicle towed in.
*
[LG07875(ALL)05/95]
If the light turns on and off on rare occasions
while you are driving, it means that a
malfunction occurred and the condition corrected
itself.
[LG07900(ALL)03/95]
An example of a condition which corrects itself
occurs when an engine running out of fuel
begins to misfire. In this case, the Service Engine
Soon Warning Light may turn on and will then
set a Diagnostic Trouble Code indicating that the
engine was misfiring while the last of the fuel
was being consumed. After refueling, the Service
Engine Soon Warning Light will turn off after
the vehicle has completed three consecutive
warm up cycles without a misfire condition
occurring. A warm up cycle consists of engine
start from a cold condition (engine at ambient
temperature) and running until the engine
reaches normal operating temperature.
File:05fclgt.ex
