8
*
[SR02700( ALL)03/95]
RWARNING
Never wear the shoulder belt under the
arm. Never swing it around the neck over
the inside shoulder. Never use a single
belt for more than one person or across
more than one seating position. Each
seating position in your vehicle has a
specific safety belt assembly which is
made up of one buckle and one tongue
that are designed to be used as a pair.
Failure to follow these precautions could
increase the risk and/or severity of injury
in a collision.
*
[SR02801( ALL)01/95]
RWARNING
Never drive or ride with a twisted or
jammed safety belt. If you cannot untwist
or unjam the safety belt, see the nearest
qualified technician immediately.
*
[SR02901( ALL)05/95]
RWARNING
To reduce the risk of serious injury in a
collision, children should always ride with
the seatback upright.
*
[SR03001( ALL)05/95]
RWARNING
Never let a passenger hold a child on his
or her lap while the vehicle is moving.
The passenger cannot protect the child
from injury in a collision.
*
[SR03200( ALL)05/95]
Lock the doors of your vehicle before driving to
lessen the risk of the door coming open in a
collision.
File:rcsrb.ex
Update:Mon Feb 19 10:53:31 1996

9
[SR03700( ALL)05/95]
Combination Lap and Shoulder
Belts
*
[SR03800( ALL)01/95]
While your vehicle is in motion, the combination
lap and shoulder belt adjusts to your movement.
However, if you brake hard, corner hard or if
your vehicle receives an impact of 5 mph
(8 km/h) or more, the lap and shoulder belt
locks and helps reduce your forward movement.
*
[SR04100( ALL)05/95]
After you get into your vehicle, close the door
and lock it. Then adjust the seat to the position
that suits you best.
[SR04400( ALL)06/93]
To fasten the belt,pull the lap/shoulder belt
from the retractor so that the shoulder portion of
the belt crosses your shoulder and chest. Be sure
the belt is not twisted. If it is, remove the twist.
Insert the belt tongue into the proper buckle
until you hear a snap and feel it latch. Make
sure the tongue is securely fastened in the
buckle.
*
[SR04550( BCGV)01/95]
quarter page art:0010018-B
Fastening the front seat combination lap and shoulder belt
File:rcsrb.ex
Update:Mon Feb 19 10:53:31 1996

10 [SR04600( BCGV)03/95]
one third page art:0010502-AFastening the rear seat combination lap and shoulder belt
*
[SR04675( ALL)05/95]
NOTE: Be sure to read and understand
Important Safety Belt Informationat
the beginning of this chapter.
% [SR04677( BC )05/95]
Safety Belts for the Front Passenger
Outboard Seating Positions
[SR04680( BC )03/95]
Your vehicle is equipped with a dual locking
mode retractor on the shoulder belt portion of
the combination lap/shoulder safety belt for
front seat passengers and a locking ªcinch
tongueº for rear outboard passengers.
*
[SR04682( ALL)05/95]
Dual locking mode retractors operate in two
ways:
*
[SR04683( ALL)03/95]
Vehicle sensitive (emergency) locking mode
[SR04684( ALL)03/95]
In this operating mode, the shoulder belt
retractor will allow the occupant freedom of
movement, locking tight only on hard braking,
hard cornering or impacts of approximately
5 mph (8 km/h) or more. The retractor can also
be made to lock by pulling/jerking on the belt.
%*
[SR04685( ALL)04/95]
Automatic locking mode
[SR04686( ALL)03/95]
In this operating mode, the shoulder belt
retractor will be automatically locked and remain
locked when the combination lap/shoulder
File:rcsrb.ex
Update:Mon Feb 19 10:53:31 1996

11
safety belt is buckled, and does not allow the
occupant freedom of movement. This mode
provides the following:
[SR04687( ALL)03/95]
q
A tight lap/shoulder belt fit on the occupant.
[SR04688( ALL)03/95]
q
Child seat or infant carrier installation
restraint.
*
[SR04689( ALL)05/95]
RWARNING
Never install a rear-facing child seat or
infant carrier in the right front passenger
seat.
*
[SR04690( ALL)03/95]
This modemust be usedwhen installing a child
safety seat on the front passenger seat and rear
outboard seats where dual locking retractors are
provided.
*
[SR04691( ALL)04/95]
To switch the retractor from the emergency
locking mode to the automatic locking mode,
perform the following steps:
*
[SR04692( ALL)03/95]
1. Buckle the lap/shoulder combination belt.
*
[SR04693( ALL)03/95]
2. Grasp the shoulder portion of the belt and
pull downward until all of the belt is
extracted, and when allowed to retract, a
clicking sound will be heard. At this time,
the belt retractor is in the automatic locking
mode (child restraint mode).
*
[SR04694( ALL)05/95]
3. A clicking sound will contnue to be heard as
the belt is allowed to retract.
[SR04695( ALL)03/95]
NOTE: When the combination lap/shoulder
belt is unbuckled and allowed to
retract completely, the retractor will
switch back to the vehicle sensitive
(emergency) locking mode. See the
detailed instructions underSafety Seats
for Childrenin this chapter.
File:rcsrb.ex
Update:Mon Feb 19 10:53:31 1996

12 % [SR05305( BC )03/95]Safety Belts with Locking Cinch Tongue
for Rear Outboard Seating Positions
[SR05307( BC )04/95]
Your vehicle is equipped with safety seat belts
containing a cinch tongue at the rear outboard
seating positions.
*
[SR05310( BC )03/95]
The locking cinch tongue will slide up and
down the belt webbing when the belt is in the
stowed position or while putting seat belts on.
When the locking cinch tongue of the
lap/shoulder combination seat belt is latched
into the buckle, the cinch tongue will allow the
lap portion to become shorter, but locks the
webbing in place to restrict it from becoming
longer.
*
[SR05320( BC )03/95]
Before you can reach and latch a combination
lap and shoulder belt having a cinch tongue into
the buckle, you may have to lengthen the lap
belt portion of it. To lengthen the lap belt, pull
some webbing out of the shoulder belt retractor.
While holding the webbing below the tongue,
grasp the tip (metal portion) of the tongue so
that it is parallel to the webbing and slide the
tongue upward. Provide enough lap belt length
so that the tongue can reach the buckle.
*
[SR05325( BC )03/95]
NOTE: If you grasp the tongue by the tongue
cover to lengthen the belt, the tongue
cover will grab the webbing, making it
difficult to slide.
File:rcsrb.ex
Update:Mon Feb 19 10:53:31 1996

13 [SR05330( BC )05/95]
half page art:0011373-A
Adjusting the cinch tongue rear combination lap and
shoulder belt
*
[SR05335( BC )05/95]
To fasten a cinch tongue, pull the combination
lap and shoulder belt from the retractor so that
the shoulder belt portion of the safety belt
crosses your shoulder and chest. Be sure the belt
is not twisted. If the belt is twisted remove the
twist. Insert the belt tongue into the proper
buckle for your seating position until you hear a
snap and feel it latch. Make sure the tongue is
securely fastened to the buckle by pulling on the
tongue.
*
[SR05400( ALL)05/95]
RWARNING
The lap belts should fit snugly and as low
as possible around the hips, not around
the waist.
File:rcsrb.ex
Update:Mon Feb 19 10:53:31 1996

14
*
[SR05500( BCGV)03/95]
RWARNING
All front and rear seat outboard
occupants (including pregnant women)
should wear lap and shoulder belts, for
optimum protection in a collision.
*
[SR05600( ALL)05/95]
RWARNING
Failure to follow these precautions could
increase the risk and/or severity of injury
in a collision. 1) Use the shoulder belt on
the outside shoulder only. Never wear the
shoulder belt under the arm. 2) Never
swing it around your neck over the inside
shoulder. 3) Never use a single belt for
more than one person.
*
[SR05630( BC )03/95]
Due to folding rear seats, sometimes the buckles
and tongues toward the center of the vehicle
may be hidden by the rear edge of the seat
cushion. Pull them out so they will be accessible.
*
[SR05635( BC )03/95]
While you are fastened in the seat belt, the
combination lap/shoulder belt with a cinch
tongue adjusts to your movement. However, if
you brake hard, turn hard, or if your vehicle
receives an impact of 5 mph (8 km/h) or more,
the safety belt will become locked and help
reduce your forward movement.
File:rcsrb.ex
Update:Mon Feb 19 10:53:31 1996

15 [SR05800( ALL)05/95]
To unfasten all the belts:
[SR05900(MBC )06/93]
1. Push the release button on the end of the
buckle. This allows the tongue to unlatch
from the buckle.
[SR06200( BC )03/95]
one third page art:0011336-A
Unfastening the front outboard lap/shoulder belts
[SR06250( BC )05/95]
one third page art:0011370-A
Unfastening the rear outboard lap/shoulder belts
*
[SR06600( ALL)03/95]
2. While the belt retracts, guide the tongue to
its stowed position. If you do not guide the
tongue, it may strike you or part of the
vehicle.
File:rcsrb.ex
Update:Mon Feb 19 10:53:31 1996

16
% [SR09300( BC )05/95]
Lap Belts Ð Rear Center Seating
Positions
*
[SR09600( BC )05/95]
The lap belt in the center of the rear seat does
not adjust automatically. You must adjust it to
fit snugly and as low as possible around your
hips. Do not wear it around your waist.
*
[SR09701( BCGV)05/95]
Pull the belt across your hips andinsert the
tongue into the correct buckleon your seat
until you hear a snap and feel it lock. Make sure
the buckle is securely fastened.
%*
[SR09801( BCGV)05/95]
If you need to lengthen the belt, unfasten it and
tip the belt tongue at a right angle to the belt.
Pull the belt tongue over your lap until it
reaches the buckle.
*
[SR09901( BCGV)05/95]
If you need to shorten the belt, pull on the loose
end of the webbing until the belt fits snugly.
*
[SR10300( BCGV)05/95]
To unfasten the belt,push the release button on
the buckle. This allows the tongue to unlatch
from the buckle.
[SR10400( BC )11/92]
Because the center lap belt does not have a
retractor, it should be shortened and fastened
when not in use.
[SR10620( BC )05/94]
one third page art:0000029-E
Unfastening center rear seat lap belt
File:rcsrb.ex
Update:Mon Feb 19 10:53:31 1996

17 %
*
[SR17500( ALL)05/95]
Safety Belt Extension Assembly
*
[SR17600( ALL)05/95]
For some people, the safety belt may be too
short even when it is fully extended. You can
add about eight inches (20 cm) to the belt length
with a safety belt extension assembly (part
number 611C22). Safety belt extensions are
available at no cost from your dealer.
*
[SR17700( ALL)05/95]
RWARNING
Failure to follow these instructions will
affect the performance of the safety belts
and increase the risk of personal injury.
*
[SR17705( ALL)05/95]
Use only extensions manufactured by the same
supplier as the safety belt. Manufacturer
identification is located at the end of the
webbing on the label. Also, use the safety belt
extension only if the safety belt is too short for
you when fully extended. Do not use extension
to change the fit of the shoulder belt across the
torso.
[SR17710( ALL)05/95]Safety Belt Maintenance
*
[SR17720(MBCG )05/95]
Check the safety belt systems periodically to
make sure that they work properly and are not
damaged.
%*
[SR17730( ALL)05/95]
All safety belt assemblies, including retractors,
buckles, front seat belt buckle support assemblies
(slide bar) (if equipped), child safety seat tether
bracket assemblies (if equipped), and attaching
hardware, should be inspected after any
collision. Ford recommends that all safety belt
assemblies used in vehicles involved in a
collision be replaced. However, if the collision
was minor and a qualified technician finds that
the belts do not show damage and continue to
operate properly, they do not need to be
replaced. Safety belt assemblies not in use
File:rcsrb.ex
Update:Mon Feb 19 10:53:31 1996
