FORD THUNDERBIRD 1997 10.G Owners Manual

221
not use fuel, kerosene, paint thinner, or other
solvents to clean your wiper blades. These will
damage your blades.
*
[MC24600( ALL)01/96]
To make reaching the wiper blades easy, simply
turn the ignition to the ACC position and turn
your wipers on. Wait for them to reach a
vertical position and turn the ignition to the OFF
position. Do not move the wipers manually.
Manually moving the wipers across the
windshield may damage them.
*
[MC24700( ALL)02/96]
Wiper blade replacement
*
[MC24800( ALL)01/96]
If the wiper blades still do not work properly
after you clean them, you may need to replace
the wiper blade assembly or the blade element.
When replacing the wiper blade assembly, blade
refill, or wiper arm always use a Motorcraft part
or equivalent. To replace the blades, follow the
instructions that come with them.
%
*
[MC24900( ALL)01/96]
Tires
%*
[MC25001( ALL)03/96]
Checking Tire Pressure
*
[MC25100( ALL)02/96]
q
Use an accurate tire pressure gauge.
*
[MC25200( ALL)02/96]
q
Check the tire pressure when tires are cold,
after the vehicle has been parked for at least
one hour or has been driven less than 3 miles
(5 km).
*
[MC25400( ALL)03/96]
q
Adjust tire pressure to recommended
specifications found on the Safety Compliance
Certification Label.
*
[MC25900( ALL)01/96]
RWARNING
Improperly inflated tires can affect vehicle
handling and can fail suddenly, possibly
resulting in loss of vehicle control.
File:11rcmcb.ex
Update:Thu May 30 11:02:59 1996

222 %
*
[MC26000( ALL)01/96]
Tire Rotation
*
[MC26100( ALL)01/96]
Because your vehicle's front and rear tires
perform different jobs, they often wear
differently. To make sure your tires wear evenly
and last longer, rotate them as indicated in the
following diagram.
*
[MC26200( ALL)12/95]
For tire rotation intervals, see theMaintenance
Schedulebooklet. If you notice that the tires wear
unevenly, have them checked.
[MC26400( B )12/95]
half page art:0010731-E
Rotating the tires
File:11rcmcb.ex
Update:Thu May 30 11:02:59 1996

223 %
*
[MC26800( ALL)01/96]
Replacing the Tires
*
[MC26900( ALL)01/96]
Replace any tires that show wear bands. When
your tire shows a wear band, it has only 1/16
inch (2 mm) of tread left.
% [MC27000( ALL)12/95]
one inch art:0001318-A
A worn-out tire
*
[MC27100( ALL)02/96]
Because your vehicle's tires may wear unevenly,
you may need to replace them before a wear
band appears across the entire tread.
*
[MC27200( ALL)01/96]
RWARNING
When replacing full size tires, never mix
radial, bias-belted, or bias-type tires. Use
only the tire sizes that are listed on the
tire pressure decal. Make sure that all tires
are the same size, speed rating, and
load-carrying capacity. Use only the tire
combinations recommended on the decal.
If you do not follow these precautions,
your vehicle may not drive properly and
safely.
*
[MC27300( ALL)01/96]
Tires that are larger or smaller than your
vehicle's original tires may also affect the
accuracy of your speedometer.
File:11rcmcb.ex
Update:Thu May 30 11:02:59 1996

224 %
*
[MC27400( ALL)01/96]
Information About Tire Quality Grades
*
[MC27500( ALL)01/96]
New vehicles are fitted with tires that have their
Tire Quality Grade (described below) molded
into the tire's sidewall. These Tire Quality
Grades are determined by standards that the
United States Department of Transportation has
set.
*
[MC27600( ALL)01/96]
Tire Quality Grades apply to new pneumatic
tires for use on passenger cars. They do not
apply to deep tread, winter-type snow tires,
space-saver or temporary use spare tires, tires
with nominal rim diameters of 10 to 12 inches or
limited production tires as defined in Title 49
Code of Federal Regulations Part 575.104(c)(2).
*
[MC27700( ALL)01/96]
U.S. Department of Transportation Ð Tire
quality grades:The U.S. Department of
Transportation requires Ford to give you the
following information about tire grades exactly
as the government has written it.
%*
[MC27800( ALL)01/96]
Treadwear
*
[MC27900( ALL)01/96]
The treadwear grade is a comparative rating
based on the wear rate of the tire when tested
under controlled conditions on a specified
government test course. For example, a tire
graded 150 would wear one and one-half (1 1/2)
times as well on the government course as a tire
graded 100. The relative performance of tires
depends upon the actual conditions of their use,
however, and may depart significantly from the
norm due to variations in driving habits, service
practices and differences in road characteristics
and climate.
File:11rcmcb.ex
Update:Thu May 30 11:02:59 1996

225
*
[MC28000( ALL)01/96]
Traction A B C
*
[MC28100( ALL)05/96]
The traction grades, from highest to lowest, are
A, B, and C, and they represent the tire's ability
to stop on wet pavement as measured under
controlled conditions on specified government
test surfaces of asphalt and concrete. A tire
marked C may have poor traction performance.
[MC28150( ALL)04/96]
RWARNING
The traction grade assigned to this tire is
based on braking (straight ahead) traction
tests and does not include cornering
(turning) traction.
*
[MC28200( ALL)01/96]
Temperature A B C
*
[MC28300( ALL)05/96]
The temperature grades are A (the highest), B,
and C, representing the tire's resistance to the
generation of heat and its ability to dissipate
heat when tested under controlled conditions on
a specified indoor laboratory test wheel.
Sustained high temperature can cause the
material of the tire to degenerate and reduce tire
life, and excessive temperature can lead to
sudden tire failure. The grade C corresponds to
a level of performance which all passenger car
tires must meet under the Federal Motor Vehicle
Safety Standard No. 109. Grades B and A
represent higher levels of performance on the
laboratory test wheel than the minimum
required by law.
File:11rcmcb.ex
Update:Thu May 30 11:02:59 1996

226 [MC28325( ALL)04/96]
RWARNING
The temperature grade for this tire is
established for a tire that is properly
inflated and not overloaded. Excessive
speed, underinflation, or excessive
loading, either separately or in
combination, can cause heat buildup and
possible tire failure.
*
[MC28350( ALL)03/96]
RWARNING
Driving too fast for conditions creates the
possibility of loss of vehicle control.
Driving at very high speeds for extended
periods of time may result in damage to
vehicle components.
%*
[MC28400( ALL)01/96]
Snow Tires and Chains
*
[MC28500( BCGV)03/96]
The tires on your vehicle have all-weather treads
that provide traction in rain or snow. However,
during the winter months in some climates, you
may need to use snow tires and occasionally
chains for your tires.
*
[MC28700( ALL)01/96]
RWARNING
Snow tires must be the same size and
grade as the tires you currently have on
your vehicle.
*
[MC28900( ALL)01/96]
Use chains on the tires only in an emergency or
if the law requires them where you live. If you
choose to use chains on your vehicle's tires, be
aware of the following:
*
[MC29000( ALL)01/96]
q
Make sure the chains are the right size for
your tires. Use only SAE Class ªSº chains.
Other types may damage your vehicle.
File:11rcmcb.ex
Update:Thu May 30 11:02:59 1996

227
*
[MC29200( ALL)01/96]
q
Put the chains on tightly with the ends held
down securely. Verify that no chain touches
any wiring, brake lines, or fuel lines. Follow
the chain manufacturer's instructions.
*
[MC29300( ALL)01/96]
q
Drive slowly. If you can hear the chains rub
or bang against your vehicle, stop the vehicle
and tighten the chains. If you continue to
hear the chains rub or bang against your
vehicle, remove the chains to prevent damage
to your vehicle.
*
[MC29400( ALL)01/96]
q
Avoid fully loading your vehicle if possible.
*
[MC29500( ALL)01/96]
q
Remove tire chains at the first opportunity
after using them on snow and ice. Do not use
the chains on dry roads.
%
*
[MC29600( ALL)01/96]
Filling the Fuel Tank
*
[MC29800(MBC )12/95]
The fuel door is outside the car on the passenger
side near the back. To fill the fuel tank:
*
[MC29900( ALL)01/96]
1. After opening the fuel filler door, remove
the cap carefully and slowly by turning it
counterclockwise 1/2 to 3/4 turn.
*
[MC30000( ALL)01/96]
RWARNING
The fuel system may be under pressure. If
the fuel cap is venting vapor or if you
hear a hissing sound, wait until it stops
before completely removing the cap.
*
[MC30100( ALL)01/96]
2. Put the nozzle all the way inside the fuel
filler pipe before pumping the fuel.
*
[MC30200( ALL)01/96]
NOTE: If you spill any fuel on the body of
your vehicle, clean it off immediately.
The fuel may dull or soften the paint
if you do not wash it off.
File:11rcmcb.ex
Update:Thu May 30 11:02:59 1996

228 %
*
[MC30300( ALL)03/96]
3. Replace the fuel cap completely when you
are finished. Turn it clockwise 1/4 turn until
it is tight. It will click when it is fully
tightened.
*
[MC30400( ALL)01/96]
4. Push the fuel door closed.
%*
[MC30500( ALL)01/96]
RWARNING
If you do not use the proper fuel cap, the
pressure in the fuel tank can damage the
fuel system or cause it to work improperly
in a collision.
*
[MC30600( ALL)01/96]
NOTE: If you replace your fuel cap with an
aftermarket fuel filler cap, the customer
warranty may be void for any damage
to the fuel tank and/or fuel system.
%*
[MC30700( ALL)01/96]
Choosing the Right Fuel
*
[MC30801( ALL)03/96]
Use only UNLEADED FUEL. The use of leaded
fuel is prohibited by law and could damage
your vehicle. The damage may not be covered
by your warranty.
*
[MC30901( ALL)04/96]
Your vehicle was not designed to use fuel
containing manganese-based additives such as
MMT. Additionally, vehicles certified to
California emission standards (indicated on the
underhood Vehicle Emissions Control
Information label) are designed to operate on
California reformulated gasolines. If California
reformulated gasoline is not available when you
refuel, your vehicle can be operated on
non-California fuels. However, even though your
engine will perform adequately on other
gasolines, the performance of the emission
control devices and systems may be adversely
affected. Repair of damage caused by using a
fuel that your vehicle was not designed for may
not be covered by your warranty.
File:11rcmcb.ex
Update:Thu May 30 11:02:59 1996

229 [MC31000( ALL)05/96]
Octane recommendation
*
[MC31101( ALL)04/96]
Your vehicle is designed to use regular gasoline
with an (R+M)/2 octane rating of 87.We do not
recommend gasolines labeled as ªregularº in
high altitude areas that are sold with octane
ratings of 86 or even less.
[MC31200( ALL)12/95]
one inch art:0060001-C*
[MC31401( ALL)04/96]
Do not be concerned if your vehicle sometimes
knocks lightly. However, if it knocks heavily
under most driving conditions on the
recommended octane fuel, see your dealer or a
qualified service technician to prevent any
engine damage.
%*
[MC31450( ALL)04/96]
Fuel quality
*
[MC31501( ALL)04/96]
If you are experiencing starting, rough idle or
hesitation problems try a different brand of fuel.
If the condition persists, see your dealer or a
qualified service technician.
*
[MC31530( ALL)04/96]
The American Automobile Manufacturers
Association (AAMA) issued a gasoline
specification to provide information on high
quality fuels that optimize the performance of
your vehicle. We recommend the use of
gasolines that meet the AAMA specification if
they are available.
*
[MC31560( ALL)04/96]
It should not be necessary to add any
aftermarket products to your fuel tank if you
continue to use a high-quality fuel.
File:11rcmcb.ex
Update:Thu May 30 11:02:59 1996

230
*
[MC31600( ALL)04/96]
Clean air
*
[MC31701( ALL)04/96]
Ford approves the use of gasolines to improve
air quality, including reformulated gasolines that
contain oxygenates such as a maximum of 10%
ethanol or 15% MTBE. There should be no more
than 5% methanol with cosolvents and additives
to protect the fuel system.
%*
[MC32000( ALL)01/96]
Safety Information Relating to Automotive
Fuels
*
[MC32100( ALL)01/96]
RWARNING
Automotive fuels can cause serious injury
or death if misused or mishandled.
*
[MC32200( ALL)05/96]
q
Turn vehicle off when refueling.
*
[MC32300( ALL)08/95]
q
Do not smoke when refueling. Fuels are
extremely flammable.
*
[MC32400( ALL)08/95]
q
Do not siphon any fuel by mouth.
*
[MC32500( ALL)02/96]
RWARNING
Gasoline or gasoline blended with
methanol can cause blindness and
possible death when swallowed. If any
fuel is swallowed, call a physician or
poison control center immediately.
*
[MC32600( ALL)08/95]
q
Avoid breathing vapors while refueling.
*
[MC32700( ALL)08/95]
q
If fuel is splashed on the skin, wash with
soap and water.
*
[MC32800( ALL)08/95]
q
If fuel is splashed in the eyes, remove contact
lenses (if worn), flush with water for 15
minutes, and seek medical attention.
*
[MC32900( ALL)01/96]
Gasoline and gasoline blends may contain small
amounts of carcinogens, such as benzene.
Long-term exposure to unleaded gasoline vapors
has caused cancer in laboratory animals.
File:11rcmcb.ex
Update:Thu May 30 11:02:59 1996
