FORD THUNDERBIRD 1997 10.G Owners Manual

231
*
[MC33000( ALL)01/96]
If you are taking the medication ªAntabuseº or
other forms of disulfiram for the treatment of
alcoholism, vapor or skin contact with a
gasoline-methanol blend may cause the same
kind of adverse reaction as drinking an alcoholic
beverage. In sensitive individuals, serious
personal injury or sickness could result. Consult
a physician promptly if you experience an
adverse reaction.
%*
[MC33100( ALL)01/96]
Running Out of Fuel
*
[MC33200( ALL)08/95]
NOTE: Avoid running out of fuel because this
situation may have an adverse effect on
modern powertrain components.
*
[MC33300( ALL)01/96]
You may need to crank the engine several times
before the fuel system starts to pump fuel from
the tank to the engine.
[MC33400( ALL)12/95]Calculating Fuel Economy
*
[MC33500( ALL)01/96]
Fuel economy is an estimate of the efficiency of
your vehicle, and can be calculated as Miles Per
Gallon (MPG) or Liters Per 100 Kilometers
(L/100K).
*
[MC33600( ALL)01/96]
Do not calculate fuel economy during your
vehicle's break-in period. This would not be an
accurate estimate of how much fuel your vehicle
will normally use.
*
[MC33700( ALL)01/96]
To calculate fuel economy:
*
[MC33800( ALL)01/96]
1. Fill the fuel tank completely and record the
initial odometer reading.
*
[MC33900( ALL)01/96]
2. Every time you buy fuel, record the
amount (in gallons or liters) purchased.
*
[MC34000( ALL)01/96]
3. After at least 3-5 tankfuls, fill the fuel tank
and record the final odometer reading.
File:11rcmcb.ex
Update:Thu May 30 11:02:59 1996

232
*
[MC34100( ALL)01/96]
4. Use these equations to calculate your fuel
economy:
*
[MC34200( ALL)01/96]
q
English: MPG = (total miles driven)v
(gallons used)
*
[MC34300( ALL)01/96]
q
Metric: L/100k = (liters used)v
(100 kilometers)
*
[MC34400( ALL)01/96]
Comparisons With EPA Estimates
*
[MC34500( ALL)05/96]
EPA fuel economy figures are obtained from
laboratory tests under simulated road conditions
and may not reflect the actual conditions you
experience or your style of driving. The EPA
fuel economy estimate is not a guarantee that
you will achieve the fuel economy shown.
*
[MC34600( ALL)01/96]
The following decrease fuel economy:
*
[MC34700( ALL)01/96]
q
Lack of regular, scheduled maintenance
*
[MC34800( ALL)01/96]
q
Rapid acceleration and excessive speed
*
[MC34900( ALL)01/96]
q
Driving with your foot on the brake
*
[MC35000( ALL)01/96]
q
Sudden stops
*
[MC35100( ALL)01/96]
q
Extended engine idling
*
[MC35200( ALL)01/96]
q
Using speed control in hilly terrain
*
[MC35300( ALL)01/96]
q
Extended use of the A/C, defroster, rear
window defroster and other accessories
*
[MC35400( ALL)01/96]
q
Underinflated tires
*
[MC35500( ALL)01/96]
q
Heavy loads
*
[MC35600( ALL)01/96]
q
Aftermarket add-ons such as bike, ski or
luggage racks, bug deflectors, etc.
File:11rcmcb.ex
Update:Thu May 30 11:02:59 1996

233
*
[MC35700( ALL)12/95]
Self-Service Pointers
*
[MC35800( ALL)12/95]
If you choose to do your own fueling, you
should also perform a few simple maintenance
routines. This extra effort will save you
additional money and contribute to the driving
efficiency of your vehicle.
*
[MC35900( ALL)12/95]
The following procedures require only a tire
gauge, a rag, an oil can spout and windshield
washer fluid.
*
[MC36000( ALL)12/95]
q
Check the engine oil at every refueling stop
*
[MC36100( ALL)12/95]
q
Clean the windshield, outside mirrors and
headlights
*
[MC36200( ALL)12/95]
q
Check windshield washer fluid
*
[MC36300( ALL)12/95]
q
Check tires for excessive wear or worn edges
*
[MC36400( ALL)12/95]
q
Check the tire pressure at least monthly
%
*
[MC36500( ALL)01/96]
Emission Control System
*
[MC36600( ALL)01/96]
Your vehicle is equipped with a catalytic
converter which enables your vehicle to comply
with applicable exhaust emission requirements.
*
[MC36700( ALL)01/96]
RWARNING
Exhaust leaks may result in the entry of
harmful and potentially lethal fumes into
the passenger compartment. Under
extreme conditions excessive exhaust
temperatures could damage the fuel
system, the interior floor covering, or
other vehicle components, possibly
causing a fire.
File:11rcmcb.ex
Update:Thu May 30 11:02:59 1996

234
*
[MC36800( ALL)01/96]
To make sure that the catalytic converter and the
other emission control parts continue to work
properly:
*
[MC36900( ALL)01/96]
q
Use only unleaded fuel.
*
[MC37000( ALL)01/96]
q
Avoid running out of fuel.
*
[MC37100( ALL)01/96]
q
Do not turn off the ignition while your
vehicle is moving, especially at high speeds.
*
[MC37200( ALL)01/96]
q
Do not push start your vehicle.
*
[MC37300( ALL)02/96]
q
Have the services listed in theMaintenance
Schedulebooklet performed according to the
specified schedule. The scheduled
maintenance services are required because
they are considered essential to the life and
performance of your vehicle and to its
emissions system.
*
[MC37400( ALL)01/96]
In general, maintenance, replacement, or service
of the emissions control devices or systems in
your new Ford Motor Company vehicle or
engine may be performed at your expense by
any automotive repair establishment or
individual using automotive parts equivalent to
those which your vehicle or engine was
originally equipped.
*
[MC37500( ALL)01/96]
Ford strongly recommends the use of genuine
Ford replacement parts. If other than Ford or
Motorcraft parts or Ford authorized
remanufactured parts are used for maintenance
replacements or for the service of components
affecting emission control, such non-Ford parts
should be equivalent to genuine Ford Motor
Company parts in performance and durability. It
is the owner's responsibility to determine the
equivalency of such parts. Please consult your
warranty booklet for complete warranty
information.
File:11rcmcb.ex
Update:Thu May 30 11:02:59 1996

235
*
[MC37600( ALL)01/96]
RWARNING
Do not park, idle, or drive your vehicle in
dry grass or other dry ground cover. The
emission system heats up the engine
compartment and exhaust system, which
can start a fire.
*
[MC37700( ALL)01/96]
Watch for fluid leaks, strange odors, smoke, loss
of oil pressure, the charge warning light, the
check engine light, or the temperature warning
light. These sometimes indicate that the emission
system is not working properly.
*
[MC37800( ALL)01/96]
Do not make any unauthorized changes to your
vehicle or engine. Changes that cause more
unburned fuel to reach the exhaust system can
increase the temperature of the engine or
exhaust system.
*
[MC37900( ALL)01/96]
By law, anyone who manufactures, repairs,
services, sells, leases, trades vehicles, or
supervises a fleet of vehicles is not permitted to
intentionally remove an emission control device
or prevent it from working. In some of the
United States and in Canada, vehicle owners
may be liable if their emission control device is
removed or is prevented from working.
*
[MC38000( ALL)08/95]
Never use a metal exhaust collector when you
service your vehicle. If the metal collector
contacts any of your vehicle's plastic trim or
bumper parts they could melt or deform.
*
[MC38100( ALL)01/96]
Do not drive your vehicle if it does not operate
properly. See your dealer if the engine runs on
for more than five seconds after you shut it off
or if it misfires, surges, stalls, or backfires.
%*
[MC38200( ALL)01/96]
Information about your vehicle's emission
control system is on the Vehicle Emission
Control Information decal located on or near the
engine. This decal identifies engine displacement
and gives some tune-up specifications.
File:11rcmcb.ex
Update:Thu May 30 11:02:59 1996

236 %
*
[MC38300( ALL)03/96]
How to Prepare Your Vehicle for
Inspection/Maintenance (I/M) Testing
*
[MC38400( ALL)04/96]
In some localities it may become a legal
requirement to pass an
Inspection/Maintenance (I/M) test of the
On-Board Diagnostic (OBD) II system. If the
vehicle's powertrain system or its battery has
just been serviced, the OBD II system is reset to
a not ready for I/M testing condition. To
prepare for I/M testing, the law specifies that
additional city and highway driving is necessary
to complete the check of the OBD II system.
*
[MC38601( ALL)05/96]
The driving modes required to reach the ready
condition consist of a minimum of 30 minutes of
city and highway driving as described below:
*
[MC38701( ALL)05/96]
q
At least twenty minutes driving in stop and
go, city type traffic with at least four idle
periods.
*
[MC38801( ALL)05/96]
q
At least ten minutes of driving on an
expressway or highway.
[MC38901( ALL)04/96]
Before completing the above driving modes, the
engine must be warmed up and at operating
temperature. Once started, the vehicle must not
be turned off during these driving modes.
%
*
[MC41200( ALL)03/96]
Lights and Bulb Replacement
*
[MC41300( ALL)01/96]
It is a good idea to check the operation of the
following lights frequently:
*
[MC41400( ALL)01/96]
q
headlamps
*
[MC41500( ALL)01/96]
q
tail lamps
*
[MC41600( ALL)01/96]
q
brakelamps
*
[MC41700( ALL)01/96]
q
hazard flasher
*
[MC41800( ALL)01/96]
q
high-mount brakelamp
File:11rcmcb.ex
Update:Thu May 30 11:02:59 1996

237
*
[MC41900( ALL)01/96]
q
turn signals
*
[MC42100( ALL)05/96]
q
license plate lamps
%*
[MC42300( ALL)01/96]
The alignment of your headlamps should be
checked if:
*
[MC42400( ALL)01/96]
q
oncoming motorists frequently signal you to
turn off your vehicle's high beams when you
do not have the high beams on
*
[MC42500( ALL)01/96]
q
the headlamps do not seem to give you
enough light to see clearly at night
*
[MC42600( ALL)01/96]
q
the headlamp beams are pointed substantially
away from a position slightly down and to
the right
%*
[MC42700( ALL)01/96]
Headlamp Bulb
*
[MC42800( ALL)03/96]
The headlamps on your vehicle use replaceable
bulbs. When the lamp burns out, simply replace
the bulb, rather than the whole lamp.
*
[MC42900( ALL)01/96]
RWARNING
Handle a halogen headlamp bulb carefully
and keep out of children's reach. Grasp
the bulb only by its plastic base and do
not touch the glass. The oil from your
hand could cause the bulb to break the
next time the headlamps are operated.
*
[MC43000( ALL)01/96]
Do not remove the burned-out bulb unless you
can immediately replace it with a new one. If a
bulb is removed for an extended period of time,
contaminants may enter the headlamp housing
and affect its performance.
File:11rcmcb.ex
Update:Thu May 30 11:02:59 1996

238 [MC43100( BC )12/95]
half page art:0010431-AParts of a headlamp
*
[MC43400( ALL)03/96]
Removing the headlamp bulb
*
[MC43500( ALL)01/96]
1. Make sure that the headlamp switch is in
the OFF position.
*
[MC43800( BC )01/96]
2. Lift the hood and find the bulb in the
headlamp socket.
*
[MC44100( BC )12/95]
3. Remove the electrical connector from the
bulb by grasping the wire with a quick pull
rearward.
*
[MC44300( BC )12/95]
4. Remove the retaining ring by turning it 1/8
of a turn to free it from the socket. Then
slide the ring off the plastic base.Keep the
ring.You must use it again to hold the new
bulb in place.
File:11rcmcb.ex
Update:Thu May 30 11:02:59 1996

239
*
[MC44800( ALL)03/96]
Installing the headlamp bulb
*
[MC45000(MBC )01/96]
1. With the flat side of the bulb's plastic base
facing upward, insert the glass end of the
bulb into the socket. You may need to turn
the bulb left or right to line up the grooves
in the plastic base with the tabs in the
socket. When the grooves are aligned, push
the bulb into the socket until the plastic base
contacts the rear of the socket.
*
[MC45200(MBC )01/96]
2. Slip the bulb retaining ring over the plastic
base until it contacts the rear of the socket.
Lock the ring into the socket by rotating it
clockwise until you feel a ªstop.º
*
[MC45300( ALL)01/96]
3. Push the electrical connector into the rear of
the plastic base until it snaps, locking it into
position.
*
[MC45400(MBC )01/96]
4. Turn the headlamps on and make sure that
they work properly. If the headlamp was
correctly aligned before you changed the
bulb, you should not need to align it again.
%*
[MC45700( BCGV)01/96]
High-Mount Brakelamp Bulbs
[MC45800( BCGV)12/95]
Your vehicle has a brakelamp mounted in the
rear window, called a high-mount brakelamp.
You may need to remove this lamp at times to
replace the brakelamp bulb or to clean the rear
window.
File:11rcmcb.ex
Update:Thu May 30 11:02:59 1996

240 [MC45900( B )12/95]
half page art:0010434-AParts of the high-mount brakelamp
% [MC46200( BCGV)12/95]
Toremovethe high-mount brakelamp:
[MC46300( BC )12/95]
1. Slide the trim cover toward the front of the
vehicle to disengage the retaining clips.
[MC46500( BC )12/95]
2. Twist the socket counterclockwise and
remove from lamp.
[MC46800( BC )12/95]
3. Pull bulb out of socket.
[MC47000( BC )12/95]
4. Remove the retaining screw.
[MC47100( BC )12/95]
5. Lift the lamp above the carpet and slide
away from the rear window.
[MC47300( BC )12/95]
6. Replace the burned out bulbs.
File:11rcmcb.ex
Update:Thu May 30 11:02:59 1996
