Page 4 of 439
Introduction
About This Manual...........................................7
Symbols Glossary
.............................................7
Data Recording
..................................................9
California Proposition 65..............................11
Perchlorate.........................................................11
Ford Credit
..........................................................11
Replacement Parts Recommendation
........................................11
Special Notices................................................12
Mobile Communications Equipment.....................................................12
Export Unique Options..................................13
Environment
Protecting the Environment........................14
Child Safety
General Information
.......................................15
Installing Child Restraints
............................16
Booster Seats
..................................................23
Child Restraint Positioning.........................25
Child Safety Locks..........................................27
Seatbelts
Principle of Operation
..................................28
Fastening the Seatbelts..............................29
Seatbelt Height Adjustment
.......................31
Seatbelt Warning Lamp and Indicator Chime
..............................................................32
Seatbelt Reminder.........................................32
Child Restraint and Seatbelt Maintenance................................................34
Personal Safety System ™
Personal Safety System ™
..........................35
Supplementary Restraints System
Principle of Operation..................................36 Driver and Passenger Airbags....................37
Front Passenger Sensing System
............38
Side Airbags
......................................................41
Safety Canopy ™
.............................................42
Crash Sensors and Airbag Indicator........43
Airbag Disposal...............................................44
Keys and Remote Controls
General Information on Radio Frequencies..................................................45
Remote Control..............................................45
Replacing a Lost Key or Remote Control............................................................47
MyKey ™
Principle of Operation..................................48
Creating a MyKey...........................................49
Clearing All MyKeys.......................................50
Checking MyKey System Status................51
Using MyKey With Remote Start Systems
.........................................................52
MyKey Troubleshooting
...............................52
Locks
Locking and Unlocking
.................................53
Manual Liftgate
..............................................56
Security
Passive Anti-Theft System
........................58
Steering Wheel
Adjusting the Steering Wheel
...................60
Audio Control
..................................................60
Voice Control
....................................................61
Cruise Control...................................................61
Information Display Control
.......................62
Wipers and Washers
Windshield Wipers.........................................63
Autowipers
.......................................................63
1
Tourneo Connect/Transit Connect (CHC) Canada/United States of America, enUSA, First Printing Table of Contents
Page 33 of 439
Pregnant women should always wear their
safety belt. The lap belt portion of a
combination lap and shoulder belt should
be positioned low across the hips below
the belly and worn as tight as comfort will
allow. The shoulder belt should be
positioned to cross the middle of the
shoulder and the center of the chest.
Safety Belt Locking Modes
WARNINGS
After any vehicle crash, the safety
belt system at all passenger seating
positions must be checked by an
authorized dealer to verify that the
automatic locking retractor feature for
child seats is still functioning properly. In
addition, all safety belts should be checked
for proper function. Safety belt and retractor assemblies
must be replaced if the safety belt
assembly automatic locking retractor
feature, or any other safety belt function
is not operating correctly when checked
by an authorized dealer. Failure to replace
the safety belt and retractor assembly
could increase the risk of injury in a crash. All safety belts in your vehicle are
combination lap and shoulder belts. The
driver safety belt has the first type of
locking mode, and the front outboard
passenger and rear seat safety belts have
both types of locking modes described as
follows: Vehicle Sensitive Mode
This is the normal retractor mode, which
allows free shoulder belt length
adjustment to your movements and
locking in response to vehicle movement.
For example, if the driver brakes suddenly
or turns a corner sharply, or the vehicle
receives an impact of approximately 5 mph
(8 km/h) or more, the combination safety
belts will lock to help reduce forward
movement of the driver and passengers.
In addition, the retractor is designed to lock
if the webbing is pulled out too quickly. If
this occurs, let the safety belt retract
slightly and pull webbing out again in a
slow and controlled manner.
Automatic Locking Mode
In this mode, the shoulder belt is
automatically pre-locked. The safety belt
will still retract to remove any slack in the
shoulder belt. The automatic locking mode
is not available on the driver safety belt.
When to Use the Automatic Locking
Mode
This mode should be used any time a child
safety seat, except a booster, is installed
in passenger front or rear seating positions.
Children 12 years old and under should be
correctly restrained in a rear seating
position whenever possible. See Child
Safety (page 15).
30
Tourneo Connect/Transit Connect (CHC) Canada/United States of America, enUSA, First Printing Seatbelts
Page 34 of 439
How to Use the Automatic Locking
Mode
1. Buckle the combination lap and
shoulder belt.
2. Grasp the shoulder portion and pull downward until the entire safety belt
is pulled out.
Allow the safety belt to retract. As the
safety belt retracts, you will hear a clicking
sound. This indicates the safety belt is now
in the automatic locking mode.
How to Disengage the Automatic
Locking Mode
Unbuckle the combination lap and
shoulder belt and allow it to retract
completely to disengage the automatic
locking mode and return the safety belt to
the vehicle sensitive (emergency) locking
mode.
Safety Belt Extension Assembly WARNING
Do not use extensions to change the
fit of the shoulder belt across the
torso.
If the safety belt is too short when fully
extended, a safety belt extension assembly
can be obtained from an authorized dealer. Only use extensions manufactured by the
same supplier as the safety belt.
Manufacturer identification is located at
the end of the webbing on the label or the
retractor behind the trim. Only use an
extension if the safety belt is too short for
you when fully extended.
SEATBELT HEIGHT
ADJUSTMENT
WARNING
Position the safety belt height
adjuster so that the safety belt rests
across the middle of your shoulder.
Failure to adjust the safety belt correctly
could reduce its effectiveness and increase
the risk of injury in a crash. 1. Press the button.
2. Slide the height adjuster up or down.
3. Release the button and pull down on
the height adjuster to make sure it is
locked in place.
31
Tourneo Connect/Transit Connect (CHC) Canada/United States of America, enUSA, First Printing SeatbeltsE142591 E165022
1
2
2
3
Page 40 of 439
DRIVER AND PASSENGER
AIRBAGS
WARNINGS
Never place your arm or any objects
over an airbag module. Placing your
arm over a deploying airbag can
result in serious arm fractures or other
injuries. Objects placed on or over the
airbag inflation area may cause those
objects to be propelled by the airbag into
your face and torso causing serious injury. Airbags can kill or injure a child in a
child seat. Never place a rear-facing
child seat in front of an active airbag.
If you must use a forward-facing child seat
in the front seat, move the seat upon which
the child seat is installed all the way back. The driver and front passenger airbags will
deploy during significant frontal and near
frontal crashes.
The driver and passenger front airbag
system consists of:
•
Driver and passenger airbag modules.
• Front passenger sensing system. · Crash sensors and monitoring
system with readiness indicator.
See Crash Sensors and Airbag
Indicator (page 43). Proper Driver and Front Passenger
Seating Adjustment WARNING
National Highway Traffic Safety
Administration (NHTSA)
recommends a minimum distance
of at least 10 inches (25 centimeters)
between an occupant’ s chest and the
driver airbag module. To properly position yourself away from
the airbag:
•
Move your seat to the rear as far as you
can while still reaching the pedals
comfortably.
• Recline the seat slightly (one or two
degrees) from the upright position.
After all occupants have adjusted their
seats and put on safety belts, it is very
important that they continue to sit
properly. A properly seated occupant sits
upright, leaning against the seat back, and
centered on the seat cushion, with their
feet comfortably extended on the floor.
Sitting improperly can increase the chance
of injury in a crash event. For example, if
an occupant slouches, lies down, turns
sideways, sits forward, leans forward or
sideways, or puts one or both feet up, the
chance of injury during a crash is greatly
increased.
Children and Airbags WARNING
Airbags can kill or injure a child in a
child seat. Never place a rear-facing
child seat in front of an active airbag.
If you must use a forward-facing child seat
in the front seat, move the seat upon which
the child seat is installed all the way back. 37
Tourneo Connect/Transit Connect (CHC) Canada/United States of America, enUSA, First Printing Supplementary Restraints SystemE151127
Page 109 of 439
Adjusting the Height of the Driver
Seat (If Equipped)
Recline Adjustment
(If Equipped)
Folding the Seatback
WARNINGS
When folding the seatback down,
take care not to get your fingers
caught between the seatback and
seat frame. Failure to follow this warning
could result in serious personal injury. WARNINGS
Do not sit behind a seat that you fold
forward. This can increase the risk of
serious personal injury in a crash.
1. Lift the lever.
2. Fold the seatback forward.
POWER SEATS
WARNINGS
Do not adjust the driver's seat or
seatback when your vehicle is
moving.
Do not place cargo or any objects
behind the seatback before returning
it to the original position.
106
Tourneo Connect/Transit Connect (CHC) Canada/United States of America, enUSA, First Printing SeatsE70730 E189283 E167549
Page 430 of 439
A
A/C
See: Climate Control........................................... 95
About This Manual...........................................7
ABS See: Brakes............................................................ 129
ABS driving hints See: Hints on Driving With Anti-Lock
Brakes................................................................. 129
Accessories....................................................382 Exterior Style....................................................... 382
Interior Style........................................................ 382
Lifestyle................................................................. 382
Peace of Mind..................................................... 382
Accessories See: Replacement Parts
Recommendation............................................. 11
Adjusting the Headlamps........................205 Horizontal Aim Adjustment.......................... 206
Vertical Aim Adjustment................................ 205
Adjusting the Steering Wheel...................60
Airbag Disposal...............................................44
Air Conditioning See: Climate Control........................................... 95
Air Filter See: Changing the Engine Air Filter..............212
Air Vents............................................................95 Center Air Vents.................................................... 95
Side Air Vents........................................................ 96
Appendices...................................................404
Audible Warnings and Indicators.............84 Automatic Transmission Warning
Chime.................................................................. 84
Headlamps On Warning Chime..................... 84
Key in Ignition Warning Chime........................ 84
Parking Brake On Warning Chime.................84
Audio Control..................................................60
Audio Input Jack...........................................272
Audio System................................................258 General Information......................................... 258
Audio Troubleshooting...............................273
Audio Unit - Vehicles With: AM/FM/CD/ SYNC/Satellite Radio
.............................265
Audio Unit - Vehicles With: AM/FM/CD/ SYNC.............................................................263 Audio Unit - Vehicles With: AM/
FM...................................................................259
AUX Button.......................................................... 262
Clock Button......................................................... 261
Frequency Band Buttons................................. 261
Menu Button........................................................ 262
Sound Button....................................................... 261
Station Preset Buttons..................................... 261
Station Tuning Buttons.................................... 261
Audio Unit - Vehicles With: Premium AM/FM/CD..................................................262
Autolamps
........................................................68
Windshield Wiper Activated
Headlamps........................................................ 68
Automatic Climate Control........................97 Mono Mode............................................................ 99
Switching Mono Mode Back On..................... 99
Switching Mono Mode Off............................... 99
Temperature Control.......................................... 99
Automatic Transmission
............................126
Brake-Shift Interlock.......................................... 127
If Your Vehicle Gets Stuck In Mud or Snow................................................................... 128
SelectShift Automatic® Transmission................................................... 126
Understanding the Positions of Your Automatic Transmission............................. 126
Automatic Transmission Fluid Check
............................................................200
Autowipers.......................................................63
Auxiliary Power Points.................................113 12 Volt DC Power Point...................................... 113
Locations................................................................. 113
B
Battery See: Changing the 12V Battery...................... 201
Blind Spot Information System................141 Switching the System Off and On...............143
System Errors....................................................... 143
Using the System................................................. 141
Bonnet Lock See: Opening and Closing the Hood...........193
Booster Seats
..................................................23
Types of Booster Seats...................................... 24
Brake Fluid Check.......................................200
427
Tourneo Connect/Transit Connect (CHC) Canada/United States of America, enUSA, First Printing Index
Page 432 of 439
Cruise control
See: Using Cruise Control................................ 140
Cup Holders.....................................................114
Customer Assistance..................................175
D
Data Recording
..................................................9
Event Data Recording........................................... 9
Service Data Recording........................................ 9
Daytime Running Lamps............................69 Type 1 - Conventional
(Non-Configurable)....................................... 69
Type 2 - Configurable......................................... 69
Digital Radio
...................................................267
HD Radio Reception and Station
Troubleshooting............................................ 268
Direction Indicators
.........................................71
Driver and Passenger Airbags....................37 Children and Airbags........................................... 37
Proper Driver and Front Passenger Seating Adjustment........................................................ 37
Driving Aids......................................................141
Driving Hints....................................................167
Driving Through Water...............................168
DRL See: Daytime Running Lamps......................... 69
E
Economical Driving
......................................167
Emission Control System...........................123 On-Board Diagnostics (OBD-II).................... 124
Readiness for Inspection/Maintenance (I/M) Testing.................................................... 125
End User License Agreement.................404 SYNC End User License Agreement
(EULA)............................................................. 404
Engine Block Heater
......................................117
Using the Engine Block Heater........................ 117
Engine Coolant Check
................................198
Adding Engine Coolant.................................... 199
Checking the Engine Coolant........................ 198
Recycled Engine Coolant................................ 199
Severe Climates................................................. 200
Engine Immobilizer See: Passive Anti-Theft System..................... 58Engine Oil Check
...........................................197
Adding Engine Oil................................................ 197
Engine Oil Dipstick - 1.6L EcoBoost™..................................................197
Engine Oil Dipstick - 2.5L...........................197
Engine Specifications - 1.6L EcoBoost™
.................................................249
Drivebelt Routing............................................... 249
Engine Specifications - 2.5L....................249 Drivebelt Routing............................................... 250
Entertainment..............................................339 AM/FM Radio...................................................... 340
Bluetooth Audio................................................. 355
CD........................................................................\
.... 350
SD Card Slot and USB Port............................. 351
SIRIUS® Satellite Radio (If Activated)........................................................ 345
Supported Media Players, Formats and Metadata Information................................ 355
Environment......................................................14
Essential Towing Checks...........................162 Before Towing a Trailer..................................... 163
Hitches.................................................................... 162
Launching or Retrieving a Boat or Personal Watercraft........................................................ 164
Safety Chains....................................................... 162
Trailer Brakes........................................................ 163
Trailer Lamps........................................................ 163
Trailer Towing Connector................................. 162
When Towing a Trailer...................................... 163
Event Data Recording See: Data Recording.............................................. 9
Export Unique Options..................................13
Extended Service Plan (ESP)
.................384
SERVICE PLANS (CANADA ONLY)............385
SERVICE PLANS (U.S. Only)......................... 384
Exterior Mirrors
.................................................77
Fold Away Exterior Mirrors................................ 78
Power Exterior Mirrors......................................... 77
F
Fastening the Seatbelts
..............................29
Safety Belt Extension Assembly...................... 31
Safety Belt Locking Modes............................... 30
Using Safety Belts During Pregnancy...........29
Floor Mats
.......................................................168
429
Tourneo Connect/Transit Connect (CHC) Canada/United States of America, enUSA, First Printing Index
Page 435 of 439
Manual Seats.................................................105
Adjusting the Height of the Driver
Seat.................................................................... 106
Adjusting the Lumbar Support .................... 105
Folding the Seatback....................................... 106
Moving the Seat Backward and Forward............................................................. 105
Recline Adjustment........................................... 106
Media Hub
.......................................................272
Message Center See: Information Displays................................. 85
Mirrors See: Heated Windows and Mirrors...............101
See: Windows and Mirrors................................ 74
Mobile Communications Equipment
.......12
Motorcraft Parts - 1.6L EcoBoost™.................................................250
Motorcraft Parts - 2.5L
...............................251
MyFord Touch ™............................................319
General Information.......................................... 319
MyKey Troubleshooting
...............................52
MyKey ™............................................................48
Principle of Operation........................................ 48
N
Navigation.......................................................372 cityseekr................................................................. 374
Destination Mode............................................... 372
Map Mode............................................................. 378
Navigation Map Updates................................. 381
Navigation Voice Commands........................ 381
Point of Interest (POI) Categories...............374
Quick-touch Buttons....................................... 380
Setting Your Navigation Preferences..........375
Normal Scheduled Maintenance
..........389
Intelligent Oil-Life Monitor™........................ 389
Maintenance Intervals..................................... 390
O
Oil Change Indicator Reset.......................198 Resetting the Oil Life Monitoring
System.............................................................. 198
Oil Check See: Engine Oil Check....................................... 197Opening and Closing the Hood...............193
Closing the Hood................................................ 194
Opening the Hood.............................................. 193
Ordering Additional Owner's Literature.......................................................179
Obtaining a French Owner ’s Manual...........179
Overhead Console
.........................................114
Rear Door Storage Compartment.................114
P
Parking Aids....................................................135 Principle of Operation....................................... 135
Parking Brake
.................................................130
Passive Anti-Theft System........................58
SecuriLock®........................................................... 58
PATS See: Passive Anti-Theft System..................... 58
Perchlorate.........................................................11
Personalized Settings..................................88 Measure Units....................................................... 88
Switching Chimes Off........................................ 88
Personal Safety System ™
..........................35
How Does the Personal Safety System
Work?.................................................................. 35
Phone...............................................................355 Making Calls........................................................ 358
Pairing Subsequent Cell Phones.................. 357
Pairing Your Cell Phone for the First Time................................................................... 356
Phone Menu Options....................................... 358
Phone Settings.................................................... 361
Phone Voice Commands................................ 362
Receiving Calls................................................... 358
Text Messaging................................................... 359
Post-Crash Alert System............................174
Power Door Locks See: Locking and Unlocking............................. 53
Power Seats
...................................................106
Power Steering Fluid Check....................200
Power Windows - Vehicles With: One-Touch Down Driver Window..........74
Accessory Delay.................................................... 74
One-Touch Down................................................. 74
432
Tourneo Connect/Transit Connect (CHC) Canada/United States of America, enUSA, First Printing Index
Page 436 of 439
Power Windows - Vehicles With: Rear
Power Windows ..........................................74
Accessory Delay.................................................... 76
Bounce-Back.......................................................... 75
One-Touch Down................................................. 75
One-Touch Up....................................................... 75
Window Lock.......................................................... 75
Protecting the Environment........................14
R
Rear Parking Aid............................................135
Rear Passenger Climate Controls...........101
Rear Seat Armrest.........................................112
Rear Seats.......................................................107 Type 1....................................................................... 107
Type 2..................................................................... 109
Rear Under Floor Storage..........................148 Adjustable Load Floor...................................... 148
Passenger Compartment Floor.................... 148
Rear View Camera........................................137 Switching the Rear View Camera Off.........139
Switching the Rear View Camera On..........137
Using the Display................................................. 137
Vehicles With Parking Aid ................................139
Rear View Camera See: Rear View Camera.................................... 137
Rear Window Wiper and Washers...........65 Rear Window Washer......................................... 66
Rear Window Wiper............................................ 65
Recommended Towing Weights............160 Calculating the Maximum Loaded Trailer
Weight................................................................. 161
Reduced Engine Performance.................167
Refueling...........................................................121 Easy Fuel ™ Capless Fuel System.................121
Remote Control..............................................45 Car Finder................................................................ 47
Integrated Keyhead Transmitter.................... 45
Programming a New Remote Control.........46
Replacing the Battery......................................... 46
Reprogramming the Unlocking Function .............................................................. 46
Repairing Minor Paint Damage...............218 Replacement Parts
Recommendation.........................................11
Collision Repairs..................................................... 11
Scheduled Maintenance and Mechanical Repairs................................................................... 11
Warranty on Replacement Parts..................... 12
Replacing a Lost Key or Remote Control.............................................................47
Reporting Safety Defects (Canada Only)..............................................................180
Reporting Safety Defects (U.S. Only)...............................................................179
Roadside Assistance...................................170 Vehicles Sold in Canada: Getting Roadside
Assistance........................................................ 170
Vehicles Sold in Canada: Using Roadside Assistance........................................................ 170
Vehicles Sold in the United States: Getting Roadside Assistance.................................... 170
Vehicles Sold in the United States: Using Roadside Assistance.................................... 170
Roadside Emergencies
...............................170
Roof Racks and Load Carriers.................150 Maximum Load Weights................................... 151
Running-In See: Breaking-In.................................................. 167
Running Out of Fuel....................................120 Refilling With a Portable Fuel
Container.......................................................... 120
S
Safety Canopy ™
.............................................42
Safety Precautions.......................................118
Satellite Radio..............................................269 Satellite Radio Electronic Serial Number
(ESN)................................................................. 270
Satellite Radio Reception Factors...............270
SIRIUS® Satellite Radio Service.................. 270
Troubleshooting................................................... 271
Scheduled Maintenance Record...........394
Scheduled Maintenance..........................386
Seatbelt Height Adjustment
.......................31
Seatbelt Reminder.........................................32 Belt-Minder™........................................................ 32
Seatbelts...........................................................28 Principle of Operation........................................ 28
433
Tourneo Connect/Transit Connect (CHC) Canada/United States of America, enUSA, First Printing Index
