Features
149 remember. This is the number that you enter on the keypad to
unlock the door. The personal code can be changed as often as
you like.
[FV05400(ALL)02/95]
The permanent code is a number that is assigned to your
vehicle and can be used to program your personal code into the
system.
[FV05500(ALL)02/95]
For your convenience, one additional piece of tape with the
permanent code has been included in the glove box. Place this
additional piece of tape in a safe location where you can refer
to it when necessary. Do not put it in any location that is
accessible to unauthorized persons, since this would allow them
entrance to your vehicle.
%*
[FV06200(ALL)02/95]
Programming your Personal Code
[FV06250(ALL)02/95]
A personal code does not replace the permanent code that the
dealership gave you. The original dealer code will always work
in addition to your personal code.
*
[FV06300(ALL)02/95]
To program your own code:
*
[FV06350(ALL)02/95]1.
Select five digits for your personal code.
[FV06400(ALL)10/93]2.
Enter the permanent code.
[FV06500(ALL)11/93]3.
Within five seconds, press the 1/2 button.
[FV06600(ALL)11/93]4.
Within five seconds of pressing the 1/2 button, enter your
personal code. Press each digit within five seconds of the
previous digit.
[FV06700(ALL)11/93]5.
The keyless system registers this second code. To open your
vehicle, you can now use either code. The module
remembers only one personal code at a time. Entering a
second personal code will erase the first and replace it with
the new code.
[FV06800(ALL)10/93]6.
After you have entered your personal code, the driver's door
will unlock.
File:wnfvs.ex
Update:Tue Mar 19 08:21:54 1996

150
*
[FV06901(ALL)02/95]
To erase your personal code:
*
[FV07001(ALL)02/95]1.
Enter the original permanent code.
[FV07101(ALL)04/95]2.
Press the 1/2 button within five seconds of step #1.
*
[FV07201(ALL)02/95]3.
Wait six seconds.
[FV07250(ALL)11/93]4.
The keyless entry system automatically erases your personal
code. The system will now only respond to the permanent
code.
[FV07270(ALL)10/93]
Do not set a code that presents the numbers in sequential order,
such as 1/2, 3/4, 5/6, 7/8, 9/0. Studies show that people who
idly press the buttons usually press a sequential pattern. Also,
do not select a code that uses the same button five times.
Thieves can easily figure out these types of codes.
%*
[FV07300(ALL)01/93]
Unlocking the Doors with the Keyless Entry System
[FV07401(ALL)05/95]
You must unlock the driver's door before you unlock any of the
other doors. If you let more than five seconds pass between
pressing numbers, the system shuts down and you have to
enter the code again. The system has shut down if the keypad
light is out. If the keyless entry system does not work properly,
use the key or Remote Entry transmitter(s) to lock and unlock
the doors or liftgate until the system can be serviced.
[FV07501(ALL)02/95]1.
To unlock the driver's door, enter the code. All codes have 5
numbers. After you press the fifth number, the driver's door
unlocks.
[FV07601(ALL)06/94]2.
To unlock the passenger's door, sliding door and liftgate,
press 3/4 within five seconds of step #1, or re-enter the code
to open the driver's door then press 3/4.
*
[FV07701(ALL)02/95]
Locking the doors with the keyless entry system
*
[FV07801(ALL)03/94]
Along with unlocking your doors, you can use the keyless entry
system to lock the doors.
File:wnfvs.ex
Update:Tue Mar 19 08:21:54 1996

Features
151
[FV07901(ALL)06/94]
To lock all of the doors at the same time, press the 7/8 and 9/0
buttons at the same time. It is not necessary to first enter the
keypad code. This will also arm your Ford anti-theft system.
%*
[FV09301(ALL)08/94]
Battery Saver
[FV09302(ALL)06/94]
When the ignition switch is turned to OFF, the vehicle will turn
off battery voltage to the interior lamps after 45 minutes. (The
exterior lamps are not affected.) The purpose is to minimize
extended battery drain if the lights have inadvertently been left
on or if a door or the glove box is not completely closed.
However, the timer will be immediately reset to another 45
minutes if any of the following occurs:
[FV09304(ALL)11/93]
n
any door is open or closed
[FV09305(ALL)11/93]
n
the front door handle is lifted (for Illuminated Entry only)
[FV09306(ALL)11/93]
n
taking the key IN or OUT of the ignition switch
[FV09307(ALL)11/93]
n
the Keyless Entry keypad is used
[FV09308(ALL)11/93]
n
the Remote Entry transmitter is activated
%*
[FV09313(ALL)02/95]
Remote Entry System (If equipped)
[FV09316(ALL)06/94]
If your vehicle has the remote entry system, you can lock and
unlock the vehicle doors without using a key. The remote entry
system also has a personal alarm feature. The buttons that
control the system are located on the hand held transmitter that
come with your vehicle.
*
[FV09318(ALL)02/95]
The system will work with up to four transmitters. Your vehicle
came with two transmitters. Additional transmitters can be
ordered from your dealer.
*
[FV09319(ALL)02/95]
The remote entry features only operate with the ignition in the
OFF position.
File:wnfvs.ex
Update:Tue Mar 19 08:21:54 1996

152
[FV09323(ALL)11/93]
10-1/2 pica
art:0050158-B
The remote entry transmitter
% [FV09325(ALL)03/94]
Unlocking the doors
*
[FV09327(ALL)02/95]
To unlock the driver's door, press the UNLOCK button.
*
[FV09329(ALL)02/95]
To unlock the other doors, press the UNLOCK button a second
time within five seconds of unlocking the driver's door.
*
[FV09331(ALL)02/95]
Locking the doors
*
[FV09333(ALL)02/95]
To lock all the doors, press the LOCK button.
[FV09336(ALL)06/94]
If you would like a signal that the doors have been locked,
press the LOCK button again within five seconds. The doors
will lock again and the horn will beep.
%*
[FV09351(ALL)02/95]
Activating the remote personal alarm
[FV09361(ALL)05/95]
If you wish to activate the remote personal alarm, press the
PANIC button. This will honk the horn and flash the tail lamps
for approximately two minutes and forty-five seconds. You can
turn it OFF by pressing the PANIC button again on the same
transmitter or by turning the ignition key to the RUN position.
If the alarm does not turn off, move the transmitter closer to the
vehicle and press the button again.
File:wnfvs.ex
Update:Tue Mar 19 08:21:54 1996

Features
153
[FV09371(ALL)04/95]
When you use the remote entry UNLOCK, or PANIC buttons,
the illuminated entry system turns on the interior lights for 25
seconds. You can turn these lights off with the LOCK button or
by turning the ignition to the RUN position.
%*
[FV09381(ALL)02/95]
Replacing the batteries
*
[FV09392(ALL)02/95]
The remote entry transmitter is powered by two coin type
three-volt lithium 2016 batteries (included) that should last for
several years of normal use. If you notice a significant decrease
in operating range, the batteries should be replaced.
Replacement batteries can be purchased at most pharmacies,
watch stores or at your Ford or Lincoln-Mercury dealer.
*
[FV09401(ALL)11/93]
NOTE: The operating range of the remote entry system can
also be affected by weather conditions (such as very
cold temperatures) or structures around the vehicle
(buildings, other vehicles, radio towers, etc.). Typical
operating range will allow you to be up to 33 feet (10
meters) away from your vehicle.
[FV09411(ALL)11/93]
7-1/2 pica art:0050159-A
Replacing the batteries
*
[FV09421(ALL)02/95]
The transmitter can be snapped apart to replace the batteries by
twisting a thin coin between the two halves of the transmitter.
DO NOT TAKE THE FRONT PART OF THE TRANSMITTER
APART. When installing the new batteries, be sure to place the
positive (+) side down as marked. Snap the two halves back
together.
File:wnfvs.ex
Update:Tue Mar 19 08:21:54 1996

154
%*
[FV09431(ALL)02/95]
Replacement/additional transmitters
*
[FV09441(ALL)02/95]
In the event a transmitter is lost, return the remaining
transmitters to your dealer for reprogramming of your remote
entry system. This is necessary to prevent further unauthorized
use of the lost transmitter.
*
[FV09451(ALL)02/95]
Additional transmitters may be purchased from your dealer
(remote entry system will work with up to four transmitters).
Return your existing transmitters to your dealer so the remote
entry system can be reprogrammed with your new and existing
transmitters.
*
[FV09461(ALL)02/95]
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC
RULES. OPERATION IS SUBJECT TO THE FOLLOWING
TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE
HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST
ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING
INTERFERENCE THAT MAY CAUSE UNDESIRED
OPERATION.
%*
[FV09501(ALL)04/95]
Illuminated Entry System (If equipped)
*
[FV09511(ALL)04/95]
This system will provide illumination of the vehicle's interior
courtesy lamps when either outside front door handle is pulled
or when the remote entry system is used to unlock the door or
sound the personal alarm. The system will automatically turn
off after approximately 25 seconds or when the ignition is
turned to the RUN or ACC position.
[FV09521(ALL)06/94]
NOTE: The illuminated entry timer will not turn off the
courtesy lamps if they have been turned on by the
door and or dimmer switch.
% [FV09525(ALL)05/95]
Autolock
[FV09530(ALL)05/95]
The Autolock feature is part of your remote entry system and is
enabled at the factory. With the Autolock feature enabled, all of
the doors will automatically lock when:
[FV09535(ALL)05/95]
n
the vehicle doors and liftgate are closed
File:wnfvs.ex
Update:Tue Mar 19 08:21:54 1996

Features
155
[FV09540(ALL)05/95]
n
the ignition key is turned to the ON position
[FV09545(ALL)05/95]
n
the brake pedal is pressed
[FV09550(ALL)05/95]
n
you shift through R (Reverse)
[FV09555(ALL)05/95]
n
the brake pedal is released
[FV09560(ALL)05/95]
The Autolock feature will repeat when:
[FV09565(ALL)05/95]
n
a door is opened and then all doors and the liftgate are
closed
[FV09570(ALL)05/95]
n
the brake pedal is released
[FV09575(ALL)05/95]
On vehicles with Keyless Entry, you can deactivate the system
by using the buttons for the keyless entry system if you do not
want to use the Autolock feature.
[FV09580(ALL)05/95]
The doors may not lock automatically at the correct time if the
driver:
[FV09585(ALL)05/95]
n
shifts through gears without pressing the brake
[FV09590(ALL)05/95]
n
shifts through gears quickly after starting the vehicle
[FV09595(ALL)05/95]
n
releases their foot from the brake while someone has stepped
out of the vehicle for a moment
[FV09600(ALL)05/95]
To deactivate the Autolock system:
[FV09605(ALL)05/95]1.
Enter your permanent five-digit entry code (not the user
code you may have set).
[FV09610(ALL)05/95]2.
Within five seconds, press and hold 7/8.
[FV09615(ALL)05/95]3.
Within five more seconds, press and release 3/4.
[FV09620(ALL)05/95]4.
Release 7/8.
[FV09625(ALL)05/95]
To reactivate the Autolock system, simply repeat the instructions
for deactivating the system. By re-entering the code that
deactivates the Autolock, the keyless entry system reinstates the
Autolock feature.
File:wnfvs.ex
Update:Tue Mar 19 08:21:54 1996

156
% [FV09630(ALL)05/95]
Anti-Theft System (if equipped)
*
[FV09635(ALL)05/95]
When armed, this system helps protect your vehicle against
break-ins or theft.
%*
[FV09640(ALL)05/95]
When an unauthorized entry occurs, the system triggers and
will:
*
[FV09645(ALL)05/95]
n
flash the headlamps, parking lamps, and alarm indicator
lamp
*
[FV09650(ALL)05/95]
n
honk the horn
*
[FV09655(ALL)05/95]
n
disable the starting circuit to prevent the vehicle from being
started
%*
[FV09660(ALL)05/95]
Arming the system
*
[FV09665(ALL)05/95]1.
Remove the key from the ignition. The hood must be closed
to arm the system.
*
[FV09670(ALL)05/95]2.
Open any door. The alarm indicator light will start flashing
to remind you to arm the system.
*
[FV09675(ALL)05/95]3.
Lock the doors by using the power door lock switch. The
alarm indicator light will now glow steadily.
[FV09680(ALL)05/95]4.
Close all doors. The alarm indicator light will then remain
on steadily for 30 seconds and then go out. When the light
goes out, the system is armed.
*
[FV09685(ALL)05/95]
NOTE: Be sure to close all doors completely. If not, the alarm
indicator light will remain on. Remember, your
anti-theft system is armed only after the alarm
indicator light remains on steadily for approximately
30 seconds after the last door is closed, and then goes
out.
*
[FV09690(ALL)05/95]
You can also arm the anti-theft system with the factory installed
remote entry system or the keyless entry system by following
this sequence:
File:wnfvs.ex
Update:Tue Mar 19 08:21:54 1996

Features
157
*
[FV09695(ALL)05/95]1.
Remove the key from the ignition. The hood must be closed
to arm the system
*
[FV09700(ALL)05/95]2.
Close all of the doors.
[FV09705(ALL)05/95]3.
Press the remote entry transmitter LOCK button or use the
keyless entry system by pressing 7/8 and 9/0 at the same
time. The alarm indicator will come on for 30 seconds to
show the alarm is arming and then turn off to show that it
has armed.
[FV09710(ALL)05/95]
The anti-theft system is designed to work with the factory
installed remote keyless entry system. It may not work with
other remote entry systems.
%*
[FV09715(ALL)05/95]
Disarming an untriggered anti-theft system
[FV09720(ALL)05/95]
You can disarm the system by unlocking either front door or
the liftgate with your door key. Turn the key all the way to the
end of travel or the system will not disarm.
[FV09725(ALL)05/95]
You can also disarm the system by unlocking the driver's door
by using the UNLOCK button of the remote entry transmitter or
by using the five-digit unlock code on the keyless entry system
keypad.
*
[FV09731(ALL)04/95]
If the system is armed and you remain in your vehicle, simply
insert the key into the ignition and turn it to ON. This disarms
the system and allows you to open the door and exit without
triggering the system.
%*
[FV09791(ALL)05/95]
Disarming a triggered system
*
[FV09801(ALL)05/95]
The alarm can be disarmed by:
*
[FV09811(ALL)04/95]
n
unlocking any door with the key, or
*
[FV09821(ALL)05/95]
n
using the UNLOCK button of the remote entry transmitter
[FV09825(ALL)11/93]
n
using the five-digit unlock code on the keyless entry keypad
File:wnfvs.ex
Update:Tue Mar 19 08:21:54 1996

158
[FV09831(ALL)03/94]
NOTE: The flashing lights and honking horn will shut off
automatically approximately two minutes and 45
seconds after the system is triggered. It will trigger
again if another intrusion occurs. However, the starter
circuit remains disabled until the system is disarmed.
%*
[FV09901(ALL)01/93]
Liftgate
*
[FV09905(ALL)01/89]
Liftgate opening procedure
[FV09910(ALL)11/93]1.
To open the liftgate, insert the door key into the lock and
turn it clockwise. You can also unlock the latch (but not
release it) with the power door lock system.
*
[FV09915(ALL)01/89]2.
Reach under the license plate light shield and release the
liftgate latch by squeezing the paddle handle rearward.
[FV09920(ALL)06/94]3.
To make the gate swing up to the fully opened position, pull
back and upward on the latch paddle handle under or
behind the license plate shield.
[FV09930(ALL)12/93]
13-1/2 pica
art:0050108-B
Opening the liftgate
File:wnfvs.ex
Update:Tue Mar 19 08:21:54 1996
