Page 364 of 524

GMC ENVOY 2006 Manual Online Filling the Tank
{CAUTION:
Fuel vapor burns violently and a fuel �re can
cause bad injuries. To help avoid injuries to
you and others, read and follow all the
instructions on the pump island. Turn off

Page 366 of 524

GMC ENVOY 2006 Manual Online Filling a Portable Fuel Container
{CAUTION:
Never �ll a portable fuel container while it is in
your vehicle. Static electricity discharge from
the container can ignite the gasoline vapor.
You can be b

Page 368 of 524

GMC ENVOY 2006 Manual Online Engine Compartment Overview
When you open the hood on the 4.2L L6 engine, here is what you will see:
5-12

Page 369 of 524

GMC ENVOY 2006 Manual Online A. Engine Air Cleaner/Filter. SeeEngine Air
Cleaner/Filter on page 5-21.
B. Engine Coolant Recovery Tank. SeeCooling System
on page 5-30.
C. Windshield Washer Fluid Reservoir. See “Adding
Washer Flu

Page 370 of 524

GMC ENVOY 2006 Manual Online When you open the hood on the 5.3L V8 engine, here is what you will see:
5-14

Page 371 of 524

GMC ENVOY 2006 Manual Online A. Engine Coolant Recovery Tank. SeeCooling System
on page 5-30.
B. Engine Air Cleaner/Filter. SeeEngine Air
Cleaner/Filter on page 5-21.
C. Windshield Washer Fluid Reservoir. See “Adding
Washer Flu

Page 372 of 524

GMC ENVOY 2006 Manual Online Engine Oil
Checking Engine Oil
It is a good idea to check your engine oil every time you
get fuel. In order to get an accurate reading, the oil
must be warm and the vehicle must be on level ground.
Th

Page 373 of 524

GMC ENVOY 2006 Manual Online If the oil is below the L mark for the L6 engine or the
cross-hatched area at the tip of the dipstick for the
V8 engine, you will need to add at least one quart/liter
of oil. But you must use the righ

Page 374 of 524

GMC ENVOY 2006 Manual Online What Kind of Engine Oil to UseLook for two things:
GM6094M
Your vehicle’s engine requires oil meeting GM
Standard GM6094M. You should look for and use
only an oil that meets GM Standard GM6094M.
S

Page 375 of 524

GMC ENVOY 2006 Manual Online Oils meeting these
requirements should also
have the starburst
symbol on the container.
This symbol indicates
that the oil has been
certi�ed by the American
Petroleum Institute (API).
You should look
