GMC JIMMY 2001 Owner's Guide

1-14
Tilting the 50/50 Split Bench Seat
CAUTION:
If the seatback isn't locked, it could move forward
in a sudden stop or crash. That could cause injury
to the person sitting there. Always press rearward
on the seatback to be sure it is locked.
CAUTION:
If the support rod isn't properly engaged, the
folded third row seat could come loose in a
sudden stop or crash. That could cause injury to
people and damage to your vehicle. Always be
sure the support rod is properly engaged when
the third row seat is folded forward.
Once the third seatback has been folded down, the
entire seat can be tilted forward to create a flat load
floor. To do this, do the following:
1. Enter the rear cargo area of the vehicle.
2. Make sure the head restraints have been
lowered completely.
3. With the seat folded, unlatch the seat from the floor
by pulling up on the lever located under the carrying
handle at the rear of the seat labeled 2.
4. Lift the rear of the seat up, off the floor. You will not
be able to unlatch the seat from the floor unless the
seatback is folded down.
5. Tilt the seat fully forward and secure it in place using
the support rod located on the underside of the seat
on the passenger's side. Make sure the rod pin is
fully engaged in the lock.
6. Push and pull on the seat. Make sure the support rod is
holding it firmly in place. Use the seat in this position
only when necessary for additional cargo space.

1-15
To return the seat to the seating position do the
following:
1. Push forward on the seat and release the support
lock rod.
2. Secure the support rod in its stored position on the
underside of the seat.
3. Lower the seat to the floor and let the seat drop
into place.
4. Lift up on the carrying handle to make sure the seat
is locked in place.
5. Return the seatback to the upright position by pulling
up on the release lever labeled 1 before the back can
be folded upright.
6. Pull the seatback forward to make sure it is locked
in place.
Removing the 50/50 Split Bench Seat
To remove the 50/50 split bench seat, do the following:
1. Open the rear doors and enter the rear of the vehicle.2. Fold the seatback
forward onto the seat
cushion by using the
lever labeled 1. The seat
cannot be removed
unless the seatback
is folded.
3. To unlatch the seat from
the floor, pull up on the
release lever labeled 2,
located at the rear of the
seat, and lift the rear of
the seat up off the floor.

1-16
4. Squeeze the release lever, located in the lower
middle to unlatch the seat from the floor, while
pulling the seat out.
5. While holding the rear of the seat up, roll the seat out
of the vehicle.
Replacing the 50/50 Split Bench Seat
CAUTION:
If the seatback isn't locked, it could move forward
in a sudden stop or crash. That could cause injury
to the person sitting there. Always press rearward
on the seatback to be sure it is locked.
CAUTION:
A seat that isn't locked into place properly can
move around in a collision or sudden stop. People
in the vehicle could be injured. Be sure to lock
the seat into place properly when installing it.
CAUTION:
A safety belt that is improperly routed, not
properly attached, or twisted won't provide the
protection needed in a crash. The person wearing
the belt could be seriously injured. After
installing the seat, always check to be sure that
the safety belts are properly routed and attached,
and are not twisted.
To reinstall the 50/50 split bench, do the following:
1. While holding the rear of the seat up, slide the front
wheels into the slots on the floor. The front latches
should lock into place. If the latches do not lock, try
tilting the rear of the seats upwards.
2. Once the latches are engaged, let the seat drop into
place. Release the lever labeled 1 to return the seat to
its upright position.
3. Push and pull on the seat to make sure it is
locked into place. The seatback cannot be raised
to the upright position unless the seat is secured
to the floor.

1-17 Full Bench Seat (Third Row)
If your vehicle has a full bench seat, the seatback can
be folded and the seat can be tilted or removed from
the vehicle.
Folding the Seatback
CAUTION:
If the seatback isn't locked, it could move forward
in a sudden stop or crash. That could cause injury
to the person sitting there. Always press rearward
on the seatback to be sure it is locked.
To fold the seatback on the bench seat, do the following:
1. Pull up on the release
lever, labeled 1, located
on the rear of the
seatback and push the
seatback forward.
2. To return the seat to an upright position, pull up
on the release lever labeled 1 and then pull up on
the seatback until the seatback locks into the
upright position.
Push and pull on the seatback to check that it is locked
into place.

1-18
Tilting the Full Bench Seat
CAUTION:
If the seatback isn't locked, it could move forward
in a sudden stop or crash. That could cause injury
to the person sitting there. Always press rearward
on the seatback to be sure it is locked.
CAUTION:
If the support rod isn't properly engaged, the
folded third row seat could come loose in a
sudden stop or crash. That could cause injury to
people and damage to your vehicle. Always be
sure the support rod is properly engaged when
the third row seat is folded forward.
Once the third seatback has been folded down, the entire
seat can be tilted forward to create a flat load floor. To
do this, do the following:
1. Enter the rear cargo area of the vehicle.
2. Make sure the head restraints have been
lowered completely.
3. With the seat folded,
unlatch the seat from the
floor by pulling up on
the lever located under
the carrying handle at
the rear of the seat
labeled 2.
4. Lift the rear of the seat up, off the floor. You will not
be able to unlatch the seat from the floor unless the
seatback is folded down.

1-19
5. Tilt the seat fully forward and secure it in place using
the support rod located on the underside of the seat
on the passenger's side. Make sure the rod pin is
fully engaged in the lock.
6. Push and pull on the seat. Make sure the support
rod is holding it firmly in place. Use the seat in
this position only when necessary for additional
cargo space.
To return the seat to the seating position do
the following:
1. Push forward on the seat and release the support
lock rod.
2. Secure the support rod in its stored position on the
underside of the seat.
3. Lower the seat to the floor and let the seat drop
into place.
4. Lift up on the carrying handle to make sure the seat
is locked in place.
5. Return the seatback to the upright position by pulling
up on the release lever labeled 1 before the back can
be folded upright.
6. Pull the seatback forward to make sure it is locked
in place.Removing the Full Bench Seat
To remove the full bench seat, do the following:
1. Open the rear doors and enter the rear of the vehicle.
2. Fold the seatback
forward onto the seat
cushion by using the
lever labeled 1. The seat
cannot be removed
unless the seatback
is folded.

1-20
3. To unlatch the seat from
the floor, pull up on the
release lever labeled 2,
located at the rear of the
seat, and lift the rear of
the seat up off the floor.
4. Squeeze the release lever, located in the lower
middle to unlatch the seat from the floor while
pulling the seat out.
5. While holding the rear of the seat up, roll the seat
out of the vehicle.Replacing the Full Bench Seat
CAUTION:
If the seatback isn't locked, it could move forward
in a sudden stop or crash. That could cause injury
to the person sitting there. Always press rearward
on the seatback to be sure it is locked.
CAUTION:
A seat that isn't locked into place properly can
move around in a collision or sudden stop. People
in the vehicle could be injured. Be sure to lock
the seat into place properly when installing it.

1-21
CAUTION:
A safety belt that is improperly routed, not
properly attached, or twisted won't provide
the protection needed in a crash. The person
wearing the belt could be seriously injured. After
installing the seat, always check to be sure that
the safety belts are properly routed and attached,
and are not twisted.
To reinstall the full bench seat, do the following:
1. While holding the rear of the seat up, slide the front
wheels into the slots on the floor. The front latches
should lock into place. If the latches do not lock, try
tilting the rear of the seats upwards.
2. Once the latches are engaged, let the seat drop into
place. Release the lever labeled 1 to return the seat to
its upright position.
3. Push and pull on the seat to make sure it is
locked into place. The seatback cannot be raised
to the upright position unless the seat is secured
to the floor.
Entering or Exiting the Third Row Seats
CAUTION:
If the seatback isn't locked, it could move forward
in a sudden stop or crash. That could cause injury
to the person sitting there. Always press rearward
on the seatback to be sure it is locked.
CAUTION:
If any easy entry seat isn't locked, it can move. In a
sudden stop or crash, the person sitting there could
be injured. And, even if there is no crash or sudden
stop, a driver sitting in an unlocked easy entry seat
could be startled by the sudden movement and hit
the wrong control or pedal, causing an accident.
After you've used it, be sure to push rearward on
any easy entry seat to be sure it is locked.

1-22
Suburban/Yukon XL: The passenger's side of the
second row 60/40 or rear bucket seats has an easy entry
feature. This makes it easy to get in and out of the third
seat, if your vehicle has one.
To operate the easy entry seat turn the release lever,
located near the back of the seat rearward.
Tilt the seatback toward the front of the vehicle
by pulling the top of the seat forward. When you
do the seat bottom will release. Pull the seat forward
until it stops.
Be sure to return the seat to the passenger position when
finished. Push and pull on the seat to make sure it is
locked in place.Safety Belts: They're for Everyone
This part of the manual tells you how to use safety belts
properly. It also tells you some things you should not do
with safety belts.
And it explains the air bag system.
CAUTION:
Don't let anyone ride where he or she can't wear
a safety belt properly. If you are in a crash and
you're not wearing a safety belt, your injuries
can be much worse. You can hit things inside the
vehicle or be ejected from it. You can be seriously
injured or killed. In the same crash, you might
not be if you are buckled up. Always fasten your
safety belt, and check that your passengers' belts
are fastened properly too.

1-23
CAUTION:
It is extremely dangerous to ride in a cargo
area, inside or outside of a vehicle. In a collision,
people riding in these areas are more likely to be
seriously injured or killed. Do not allow people
to ride in any area of your vehicle that is not
equipped with seats and safety belts. Be sure
everyone in your vehicle is in a seat and using
a safety belt properly.
Your vehicle has a light
that comes on as a reminder
to buckle up. See ªSafety
Belt Reminder Lightº in
the Index.In most states and Canadian provinces, the law says to
wear safety belts. Here's why: They work.
You never know if you'll be in a crash. If you do have a
crash, you don't know if it will be a bad one.
A few crashes are mild, and some crashes can be so
serious that even buckled up a person wouldn't survive.
But most crashes are in between. In many of them,
people who buckle up can survive and sometimes walk
away. Without belts they could have been badly hurt
or killed.
After more than 30 years of safety belts in vehicles,
the facts are clear. In most crashes buckling up does
matter ... a lot!
