GMC Savana Owner Manual (GMNA-Localizing-U.S./Canada-14583543) -
2021 - crc - 7/10/20
194 Vehicle Care
3. Fill the radiator with the proper mixture,up to the base of the filler neck. See
Recommended Fluids and Lubricants
0255 for more information about the
proper coolant mixture.
4. Remove the coolant recovery tank cap
and fill to the COLD FILL mark.
5. Reinstall the cap back on the coolant recovery tank, but leave the radiator
pressure cap off.
6. Start the engine and let it run until the upper radiator hose can be felt getting
hot. Watch out for the engine
cooling fan. 7. By this time, the coolant level inside the
radiator filler neck may be lower. If the
level is lower, add more of the proper
mixture through the filler neck until the
level reaches the base of the filler neck.
8. Replace the pressure cap. At any time during this procedure if coolant begins to
flow out of the filler neck, reinstall the
pressure cap.
Caution
If the pressure cap is not tightly installed,
coolant loss and engine damage may
occur. Be sure the cap is properly and
tightly secured.
Engine Overheating
If the vehicle has a diesel engine, see the
Duramax diesel supplement.
Caution
Do not run the engine if there is a leak
in the engine cooling system. This can
cause a loss of all coolant and can
damage the system and vehicle. Have
any leaks fixed right away. The vehicle has an indicator to warn of
engine overheating.
There is an engine coolant temperature
gauge on the vehicle's instrument cluster.
See
Engine Coolant Temperature Gauge 073.
If the decision is made not to lift the hood
when this warning appears, but instead get
service help right away, see Roadside
Assistance Program 0265.
If the decision is made to lift the hood,
make sure the vehicle is parked on a level
surface.
Then check to see if the engine cooling fans
are running. If the engine is overheating, the
fan should be running. If it is not, do not
continue to run the engine and have the
vehicle serviced.
See if the engine cooling fan speed increases
when idle speed is doubled by pushing the
accelerator pedal down. If it does not, the
vehicle needs service. Turn off the engine.

GMC Savana Owner Manual (GMNA-Localizing-U.S./Canada-14583543) -
2021 - crc - 7/10/20
Vehicle Care 197
Caution (Continued)
.Do not use engine coolant (antifreeze)
in the windshield washer. It can
damage the windshield washer system
and paint.
.Do not mix water with ready-to-use
washer fluid. Water can cause the
solution to freeze and damage the
washer fluid tank and other parts of
the washer system.
.When using concentrated washer fluid,
follow the manufacturer instructions
for adding water.
.Fill the washer fluid tank only
three-quarters full when it is very cold.
This allows for fluid expansion if
freezing occurs, which could damage
the tank if it is completely full.
Brakes
Disc brake linings have built-in wear
indicators that make a high-pitched warning
sound when the brake linings are worn and
new linings are needed. The sound can come
and go or can be heard all the time when
the vehicle is moving, except when applying
the brake pedal firmly.
{Warning
The brake wear warning sound means
that soon the brakes will not work well.
That could lead to a crash. When the
brake wear warning sound is heard, have
the vehicle serviced.
Caution
Continuing to drive with worn-out brake
linings could result in costly brake
repairs.
Some driving conditions or climates can
cause a brake squeal when the brakes are
first applied, clearing up following several
applications. This does not mean something
is wrong with the brakes.
Properly torqued wheel nuts are necessary
to help prevent brake pulsation. When tires
are rotated, inspect brake linings for wear
and evenly tighten wheel nuts in the proper
sequence to torque specifications. See
Capacities and Specifications 0258.
Brake pads should be replaced as complete
axle sets.
Brake Pedal Travel
See your dealer if the brake pedal does not
return to normal height, or if there is a
rapid increase in pedal travel. This could be
a sign that brake service may be required.
Replacing Brake System Parts
Always replace brake system parts with
new, approved replacement parts. If this is
not done, the brakes may not work
properly. The braking performance can
change in many ways if the wrong brake
parts are installed or if parts are improperly
installed.
Brake Fluid
The brake master cylinder reservoir is filled
with DOT 3 brake fluid. See Engine
Compartment Overview 0180 for the
location of the reservoir.
There are only two reasons why the brake
fluid level in the reservoir may go down:

GMC Savana Owner Manual (GMNA-Localizing-U.S./Canada-14583543) -
2021 - crc - 7/10/20
220 Vehicle Care
active. The TIRE LEARNING ACTIVE
message on the DIC display screen
goes off.
9. Turn the vehicle off.
10. Set all four tires to the recommended air pressure level as indicated on the Tire
and Loading Information label.
Tire Inspection
We recommend that the tires, including
the spare tire, if the vehicle has one, be
inspected for signs of wear or damage
at least once a month.
Replace the tire if:
.The indicators at three or more
places around the tire can be seen.
.There is cord or fabric showing
through the tire's rubber.
.The tread or sidewall is cracked, cut,
or snagged deep enough to show
cord or fabric.
.The tire has a bump, bulge, or split.
.The tire has a puncture, cut, or other
damage that cannot be repaired well
because of the size or location of the
damage.
Tire Rotation
Tires should be rotated every 12 000 km
(7,500 mi). See Maintenance Schedule
0 249.
Tires are rotated to achieve a more
uniform wear for all tires. The first
rotation is the most important.
Anytime unusual wear is noticed, rotate
the tires as soon as possible, check for
proper tire inflation pressure, and check
for damaged tires or wheels. If the
unusual wear continues after the
rotation, check the wheel alignment.
See When It Is Time for New Tires 0222
and
Wheel Replacement 0225.
Use this rotation pattern when rotating
the tires if the vehicle has single rear
wheels.
Dual Tire Rotation
When the vehicle is new, or whenever a
wheel, wheel bolt, or wheel nut is
replaced or serviced, check the wheel
nut torque after 160, 1 600, and
10 000 km (100, 1,000, and 6,000 mi) of
driving. For proper torque and wheel
nut tightening information, see
“Removing the Flat Tire and Installing
the Spare Tire” underTire Changing
0 228 and “Wheel Nut Torque” under
Capacities and Specifications 0258 and

GMC Savana Owner Manual (GMNA-Localizing-U.S./Canada-14583543) -
2021 - crc - 7/10/20
254 Service and Maintenance
.Signs that the headlamps need attention
include dimming, failure to light, cracking,
or damage. The brake lamps need to be
checked periodically to ensure that they
light when braking.
.With a multi-point inspection, your dealer
can check the lamps and note any
concerns.
Shocks and Struts
Shocks and struts help aid in control for a
smoother ride.
.Signs of wear may include steering wheel
vibration, bounce/sway while braking,
longer stopping distance, or uneven
tire wear.
.As part of the multi-point inspection,
trained dealer technicians can visually
inspect the shocks and struts for signs of
leaking, blown seals, or damage, and can
advise when service is needed.
Tires
Tires need to be properly inflated, rotated,
and balanced. Maintaining the tires can save
money and fuel, and can reduce the risk of
tire failure.
.Signs that the tires need to be replaced
include three or more visible treadwear
indicators; cord or fabric showing through
the rubber; cracks or cuts in the tread or
sidewall; or a bulge or split in the tire.
.Trained dealer technicians can inspect and
recommend the right tires. Your dealer
can also provide tire/wheel balancing
services to ensure smooth vehicle
operation at all speeds. Your dealer sells
and services name brand tires.
Vehicle Care
To help keep the vehicle looking like new,
vehicle care products are available from your
dealer. For information on how to clean and
protect the vehicle’s interior and exterior,
see Interior Care 0245 and
Exterior Care 0241.
Wheel Alignment
Wheel alignment is critical for ensuring that
the tires deliver optimal wear and
performance.
.Signs that the alignment may need to be
adjusted include pulling, improper vehicle
handling, or unusual tire wear.
.Your dealer has the required equipment
to ensure proper wheel alignment. Windshield
For safety, appearance, and the best
viewing, keep the windshield clean and
clear.
.Signs of damage include scratches, cracks,
and chips.
.Trained dealer technicians can inspect the
windshield and recommend proper
replacement if needed.
Wiper Blades
Wiper blades need to be cleaned and kept in
good condition to provide a clear view.
.Signs of wear include streaking, skipping
across the windshield, and worn or split
rubber.
.Trained dealer technicians can check the
wiper blades and replace them when
needed.

GMC Savana Owner Manual (GMNA-Localizing-U.S./Canada-14583543) -
2021 - crc - 7/10/20
Index 283
CompartmentsStorage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Compass . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Connected Services Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . 279
Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . 280
Navigation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 278
Connections Connected Services . . . . . . . . . . . . . . . . . . . . 279
Control Traction and Electronic Stability . . . . . . . 147
Control of a Vehicle . . . . . . . . . . . . . . . . . . . . . . 127
Convex Mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Coolant Engine Temperature Gauge . . . . . . . . . . . . . 73
Cooling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119, 122
Cooling System . . . . . . . . . . . . . . . . . . . . . . . . . . . 191
Courtesy Transportation Program . . . . . . . . 267
Cruise Control . . . . . . . . . . . . . . . . . . . . . . . . . . . 149
Light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
Customer Assistance . . . . . . . . . . . . . . . . . . . . . 264
Offices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 264
Text Telephone (TTY) Users . . . . . . . . . . . . 264
Customer Information Publications Ordering Information . . . . . 269
Customer Satisfaction Procedure . . . . . . . . . 262
Cybersecurity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 271D
Damage Repair, Collision . . . . . . . . . . . . . . . . . 268
Danger, Warning, and Caution . . . . . . . . . . . . . .2
Data Collection Infotainment System . . . . . . . . . . . . . . . . . . 272
OnStar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 272
Data Recorders, Event . . . . . . . . . . . . . . . . . . . 272
Daytime Running Lamps (DRL) . . . . . . . . . . . . .91
Defensive Driving . . . . . . . . . . . . . . . . . . . . . . . . 126
Delayed Locking . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Devices Auxiliary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108
Diagnostics Connected Services . . . . . . . . . . . . . . . . . . . . 280
Distracted Driving . . . . . . . . . . . . . . . . . . . . . . . . 126
Dome Lamps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
Door Cargo Door Relocking . . . . . . . . . . . . . . . . . . . . 11
Delayed Locking . . . . . . . . . . . . . . . . . . . . . . . . . 12
Locks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Power Locks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Rear Doors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Side . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Sliding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Drive Belt Routing, Engine . . . . . . . . . . . . . . . 261
Driver Assistance Systems . . . . . . . . . . . . . . . 150
Driver Information Center (DIC) . . . . . . . . . . . .81 Driving
Better Fuel Economy . . . . . . . . . . . . . . . . . . . 126
Characteristics and Towing Tips . . . . . . . . 160
Defensive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126
Hill and Mountain Roads . . . . . . . . . . . . . . 129
If the Vehicle is Stuck . . . . . . . . . . . . . . . . . . 131
Impaired . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127
Loss of Control . . . . . . . . . . . . . . . . . . . . . . . . 128
Off-Road Recovery . . . . . . . . . . . . . . . . . . . . . 128
Vehicle Load Limits . . . . . . . . . . . . . . . . . . . . . 131
Wet Roads . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129
Winter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130
E
Electrical Equipment, Add-On . . . . . . . . . . . . 176
Electrical SystemEngine Compartment Fuse Block . . . . . . . 206
Floor Console Fuse Block . . . . . . . . . . . . . . . 209
Fuses and Circuit Breakers . . . . . . . . . . . . . 205
Overload . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 205
Emergency
OnStar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 274
Engine Air Cleaner/Filter . . . . . . . . . . . . . . . . . . . . . . 189
Check Light (Malfunction Indicator) . . . . . 76
Compartment Overview . . . . . . . . . . . . . . . . 180
Coolant Heater . . . . . . . . . . . . . . . . . . . . . . . . 138
Coolant Temperature Gauge . . . . . . . . . . . . 73

GMC Savana Owner Manual (GMNA-Localizing-U.S./Canada-14583543) -
2021 - crc - 7/10/20
284 Index
Engine (cont'd)Cooling System . . . . . . . . . . . . . . . . . . . . . . . . . 191
Drive Belt Routing . . . . . . . . . . . . . . . . . . . . . 261
Exhaust . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 141
Fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 195
Oil Life System . . . . . . . . . . . . . . . . . . . . . . . . 186
Oil Pressure Gauge . . . . . . . . . . . . . . . . . . . . . 72
Oil Pressure Light . . . . . . . . . . . . . . . . . . . . . . . 80
Overheating . . . . . . . . . . . . . . . . . . . . . . . . . . . 194
Power Messages . . . . . . . . . . . . . . . . . . . . . . . . 85
Running While Parked . . . . . . . . . . . . . . . . . . 141
Starting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136
Enhanced Technology Glass . . . . . . . . . . . . . . . . 21
Entry Lighting . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
Equipment, Towing . . . . . . . . . . . . . . . . . . . . . . . 172
Event Data Recorders . . . . . . . . . . . . . . . . . . . . 272
Exit Lighting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
Extender, Seat Belt . . . . . . . . . . . . . . . . . . . . . . . .35
Exterior Lamp Controls . . . . . . . . . . . . . . . . . . . . 90
Exterior Lamps Off Reminder . . . . . . . . . . . . . 90
Exterior Lighting Battery Saver . . . . . . . . . . . 95
F
Fan Engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 195
Fast Idle System . . . . . . . . . . . . . . . . . . . . . . . . . .138 Filter,
Engine Air Cleaner . . . . . . . . . . . . . . . . . . . . . 189
Fixed Mast Antenna . . . . . . . . . . . . . . . . . . . . . 103
Flash-to-Pass . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .91
Flashers, Hazard Warning . . . . . . . . . . . . . . . . . 92
Flat Tire . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 226 Changing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 228
Floor Mats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 247
Fluid Automatic Transmission . . . . . . . . . . 186, 189
Brakes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 197
Power Steering . . . . . . . . . . . . . . . . . . . . . . . . 196
Washer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 196
Folding Mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Forward Collision Alert (FCA) System . . . . .154
Frequency Statement Radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 270
Front Seats Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Front Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Front Turn Signal Bulb Replacement . . . . . . . . . . . . . . . . . . . . . . 202
Fuel Additives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 158
Economy, Driving for Better . . . . . . . . . . . 126
Filling a Portable Fuel Container . . . . . . . 160
Filling the Tank . . . . . . . . . . . . . . . . . . . . . . . . 158
Foreign Countries . . . . . . . . . . . . . . . . . . . . . . 158 Fuel (cont'd)
Gauge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Low Fuel Warning Light . . . . . . . . . . . . . . . . 80
Prohibited Fuels . . . . . . . . . . . . . . . . . . . . . . . 158
Recommended . . . . . . . . . . . . . . . . . . . . . . . . . 158
Top Tier . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 157
Full-Size Spare Tire . . . . . . . . . . . . . . . . . . . . . . . 235
Fuses
Engine Compartment Fuse Block . . . . . . . 206
Floor Console Fuse Block . . . . . . . . . . . . . . . 209
Fuses and Circuit Breakers . . . . . . . . . . . . . 205
G
GaugesEngine Coolant Temperature . . . . . . . . . . . . 73
Engine Oil Pressure . . . . . . . . . . . . . . . . . . . . . 72
Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Odometer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Speedometer . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Trip Odometer . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Voltmeter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Warning Lights and Indicators . . . . . . . . . . 70
General Information Service and Maintenance . . . . . . . . . . . . . . 248
Towing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 160

GMC Savana Owner Manual (GMNA-Localizing-U.S./Canada-14583543) -
2021 - crc - 7/10/20
286 Index
Lights (cont'd)Antilock Brake System (ABS)
Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
Brake System Warning . . . . . . . . . . . . . . . . . 77
Charging System . . . . . . . . . . . . . . . . . . . . . . . 76
Check Engine (Malfunction Indicator) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
Cruise Control . . . . . . . . . . . . . . . . . . . . . . . . . . 81
Engine Oil Pressure . . . . . . . . . . . . . . . . . . . . . 80
Flash-to-Pass . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
High-Beam On . . . . . . . . . . . . . . . . . . . . . . . . . . 81
High/Low Beam Changer . . . . . . . . . . . . . . . 91
Lane Departure Warning . . . . . . . . . . . . . . . . 79
Low Fuel Warning . . . . . . . . . . . . . . . . . . . . . . 80
Seat Belt Reminders . . . . . . . . . . . . . . . . . . . . 74
Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
StabiliTrak OFF . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Tire Pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
Tow/Haul Mode . . . . . . . . . . . . . . . . . . . . . . . . 78
Traction Control System (TCS)/StabiliTrak . . . . . . . . . . . . . . . . . . . . . . 79
Locking Rear Axle . . . . . . . . . . . . . . . . . . . . . . . . 148
Locks Automatic Door . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Cargo Door Relocking . . . . . . . . . . . . . . . . . . . . 11
Delayed Locking . . . . . . . . . . . . . . . . . . . . . . . . . 12
Door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Lockout Protection . . . . . . . . . . . . . . . . . . . . . . . 12 Locks (cont'd)
Power Door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Loss of Control . . . . . . . . . . . . . . . . . . . . . . . . . . .128
Low Fuel Warning Light . . . . . . . . . . . . . . . . . . 80
Lower Anchors and Tethers for Children (LATCH System) . . . . . . . . . . . . . . . . .52
M
Maintenance
Records . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 257
Maintenance and Care
Additional . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 253
Maintenance Schedule . . . . . . . . . . . . . . . . . . . 249 Recommended Fluids andLubricants . . . . . . . . . . . . . . . . . . . . . . . . . . . . 255
Malfunction Indicator Lamp . . . . . . . . . . . . . . . 76
Manual Mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Manual Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . 144
Manual Windows . . . . . . . . . . . . . . . . . . . . . . . . . .19
Media Avoiding Untrusted Devices . . . . . . . . . . . . 104
Messages Engine Power . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
Vehicle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
Vehicle Speed . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
Mirrors Convex . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 Mirrors (cont'd)
Folding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Heated . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Manual Rearview . . . . . . . . . . . . . . . . . . . . . . . 19
Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Trailer Tow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Mirrors, Interior Rearview . . . . . . . . . . . . . . . . . .19
Monitor System, Tire Pressure . . . . . . . . . . . . 217
Multi-band Antenna . . . . . . . . . . . . . . . . . . . . . 104
N
Navigation Connected Services . . . . . . . . . . . . . . . . . . . . 278
New Vehicle Break-In . . . . . . . . . . . . . . . . . . . . .134
Noise Control System . . . . . . . . . . . . . . . . . . . . 199
O
Odometer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71 Trip . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Off-Road Recovery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128
Oil Engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 184
Engine Oil Life System . . . . . . . . . . . . . . . . . 186
Engine Oil Pressure Gauge . . . . . . . . . . . . . . 72
Pressure Light . . . . . . . . . . . . . . . . . . . . . . . . . . 80
Older Children, Restraints . . . . . . . . . . . . . . . . . 46
Online Owner Center . . . . . . . . . . . . . . . . . . . . 264
