Page 521 of 574

GMC SIERRA 2005  Owners Manual *1— Gasoline Engine and Diesel Engine.
*2— Gasoline Engine; ECMRPV — Diesel Engine.
*3— Gasoline Engine; FUEL HT — Diesel Engine.
*4— Gasoline Engine; ECM I — Diesel Engine.
*5— IGN/ED

Page 522 of 574

GMC SIERRA 2005  Owners Manual Fuses Usage
AUX PWRAuxiliary Power
Outlet — Console
IGN 1 Ignition Relay
PCM 1 Powertrain Control Module
ETC/ECMElectronic Throttle Control,
Electronic Brake Controller
IGN EInstrument Panel Cluster

Page 523 of 574

GMC SIERRA 2005  Owners Manual Fuses Usage
BTSIBrake Transmission Shift
Interlock System
CRNK Starting System
LO HDLP-RT Headlamp Low Beam-Right
FOG LP Fog Lamp Relay
FOG LP Fog Lamps
HORN Horn Relay
W/S WASHWindshield Washer Pump

Page 524 of 574

GMC SIERRA 2005  Owners Manual Capacities and Speci�cations
The following approximate capacities are given in English and metric conversions. SeeRecommended Fluids and
Lubricants on page 6-14for more information.
ApplicationCapacit

Page 525 of 574

GMC SIERRA 2005  Owners Manual ApplicationCapacities
English Metric
Cooling System
VORTEC™ 4800 V8 Manual with Front A/C**
VORTEC™ 5300 V8 Automatic with Front A/C*
VORTEC™ 5300 V8 Automatic with Front A/C**
VORTEC™ 6000 V8

Page 526 of 574

GMC SIERRA 2005  Owners Manual ApplicationCapacities
English Metric
Engine Oil with Filter
4300 V6
4800 V8; 5300 V8; 6000 V8
8100 V84.5 qt
6.0 qt
6.5 qt4.3 L
5.7 L
6.1 L
Fuel Tank
Short Bed and 2500 LD
Long Bed and Chassis Cab (Pic

Page 527 of 574

GMC SIERRA 2005  Owners Manual Engine Speci�cations
Engine VIN Code Transmission Spark Plug Gap
VORTEC™ 4300 V6 WAutomatic
Manual0.060 inches (1.52 mm)
VORTEC™ 4800 V8 VAutomatic
Manual0.040 inches (1.01 mm)
VORTEC™ 5300 V8 Z

Page 528 of 574

GMC SIERRA 2005  Owners Manual ✍NOTES
5-134

Page 529 of 574

GMC SIERRA 2005  Owners Manual Maintenance Schedule......................................6-2
Introduction...................................................6-2
Maintenance Requirements..............................6-2
Your Vehicle

Page 530 of 574

GMC SIERRA 2005  Owners Manual Maintenance Schedule
Introduction
Important: Keep engine oil at the proper level and
change as recommended.
Have you purchased the GM Protection Plan? The Plan
supplements your new vehicle warranties.
