immobilizer GMC TERRAIN 2019 Owner's Manual

GMC Terrain/Terrain Denali Owner Manual (GMNA-Localizing-U.S./Canada/
Mexico-12146071) - 2019 - crc - 7/27/18
Keys, Doors, and Windows 29
Keys, Doors, and
Windows
Keys and Locks
Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Remote Keyless Entry (RKE)System . . . . . . . . . . . . . . . . . . . . . . . 30
Remote Keyless Entry (RKE) System Operation . . . . . . . . . . . . 30
Remote Vehicle Start . . . . . . . . . . 36
Door Locks . . . . . . . . . . . . . . . . . . . . 38
Power Door Locks . . . . . . . . . . . . . 40
Delayed Locking . . . . . . . . . . . . . . . 40
Automatic Door Locks . . . . . . . . . 41
Lockout Protection . . . . . . . . . . . . . 41
Safety Locks . . . . . . . . . . . . . . . . . . . 41
Doors
Liftgate . . . . . . . . . . . . . . . . . . . . . . . . 42
Vehicle Security
Vehicle Security . . . . . . . . . . . . . . . . 48
Vehicle Alarm System . . . . . . . . . 48
Immobilizer . . . . . . . . . . . . . . . . . . . . 49
Immobilizer Operation . . . . . . . . . 50
Exterior Mirrors
Convex Mirrors . . . . . . . . . . . . . . . . 51
Power Mirrors . . . . . . . . . . . . . . . . . . 51
Folding Mirrors . . . . . . . . . . . . . . . . . 51
Heated Mirrors . . . . . . . . . . . . . . . . . 51
Automatic Dimming Mirror . . . . . 52
Reverse Tilt Mirrors . . . . . . . . . . . . 52
Interior Mirrors
Interior Rearview Mirrors . . . . . . . 52
Manual Rearview Mirror . . . . . . . . 52
Automatic Dimming Rearview Mirror . . . . . . . . . . . . . . . . . . . . . . . . . 52
Windows
Windows . . . . . . . . . . . . . . . . . . . . . . . 52
Power Windows . . . . . . . . . . . . . . . 53
Sun Visors . . . . . . . . . . . . . . . . . . . . . 54
Roof
Sunroof . . . . . . . . . . . . . . . . . . . . . . . . 55
Keys and Locks
Keys
{Warning
Leaving children in a vehicle with
a Remote Keyless Entry (RKE)
transmitter is dangerous and
children or others could be
seriously injured or killed. They
could operate the power windows
or other controls or make the
vehicle move. The windows will
function with the RKE transmitter
in the vehicle, and children or
others could be caught in the path
of a closing window. Do not leave
children in a vehicle with an RKE
transmitter.

GMC Terrain/Terrain Denali Owner Manual (GMNA-Localizing-U.S./Canada/
Mexico-12146071) - 2019 - crc - 7/27/18
Keys, Doors, and Windows 49
On Solid :Vehicle is secured
during the delay to arm the system.
Fast Flash : Vehicle is unsecured.
A door, the hood, or the liftgate
is open.
Slow Flash : Alarm system is
armed.
Arming the Alarm System
1. Turn off the vehicle.
2. Lock the vehicle in one of two ways:
.Use the RKE transmitter.
. With a door open, press the
interior
Q.
3. After 30 seconds the alarm system will arm, and the
indicator light will begin to
slowly flash indicating the
alarm system is operating.
Pressing
Qon the RKE
transmitter a second time will
bypass the 30-second delay
and immediately arm the alarm
system. The vehicle alarm system will not
arm if the doors are locked with
the key.
If the driver door is opened without
first unlocking with the RKE
transmitter, the horn will chirp and
the lights will flash to indicate
pre-alarm. If the vehicle is not
started, or the door is not unlocked
by pressing
Kon the RKE
transmitter during the 10-second
pre-alarm, the alarm will be
activated.
If a door, the hood, or the liftgate is
opened without first disarming the
system, the turn signals will flash
and the horn will sound for about
30 seconds. The alarm system will
then re-arm to monitor for the next
unauthorized event.
Disarming the Alarm System
To disarm the alarm system or turn
off the alarm if it has been activated:
. Press
Kon the RKE transmitter.
. Start the vehicle. To avoid setting off the alarm by
accident:
.
Lock the vehicle after all
occupants have left the vehicle
and all doors are closed.
. Always unlock a door with the
RKE transmitter.
Unlocking the driver door with the
key will not disarm the system or
turn off the alarm.
How to Detect a Tamper
Condition
IfKis pressed on the RKE
transmitter and the horn chirps and
the lights flash three times, an alarm
occurred previously while the alarm
system was armed.
If the alarm has been activated, a
message will appear on the Driver
Information Center (DIC).
Immobilizer
See Radio Frequency Statement
0 405.

GMC Terrain/Terrain Denali Owner Manual (GMNA-Localizing-U.S./Canada/
Mexico-12146071) - 2019 - crc - 7/27/18
50 Keys, Doors, and Windows
Immobilizer Operation
This vehicle has a passive
theft-deterrent system.
The system does not have to be
manually armed or disarmed.
The vehicle is automatically
immobilized when the transmitter
leaves the vehicle.
The immobilization system is
disarmed when the ignition is turned
on or in ACC/ACCESSORY and a
valid Remote Keyless Entry (RKE)
transmitter is in the vehicle.
The security light, in the instrument
cluster, comes on if there is a
problem with arming or disarming
the theft-deterrent system.The system has one or more RKE
transmitters matched to an
immobilizer control unit in your
vehicle. Only a correctly matched
RKE transmitter will start the
vehicle. If the transmitter is ever
damaged, you may not be able to
start your vehicle.
When trying to start the vehicle, the
security light may come on briefly
when the ignition is turned on.
If the engine does not start and the
security light stays on, there is a
problem with the system. Turn the
ignition off and try again.
If the ignition will not change from
off to on or ACC/ACCESSORY, and
the RKE transmitter appears to be
undamaged, try another transmitter.
Or, you may try placing the
transmitter in the cupholder in the
center console.
If the ignition mode will not change
with the other transmitter or with the
transmitter in the cupholder, your
vehicle needs service. If the ignition
does change modes, the first
transmitter may be faulty. See your
dealer who can service the
theft-deterrent system and have a
new RKE transmitter programmed to
the vehicle.
It is possible for the immobilizer
system to learn new or replacement
RKE transmitters. Up to eight
transmitters can be programmed to
the vehicle. To program additional
transmitters, see
“Programming
Transmitters to the Vehicle” under
Remote Keyless Entry (RKE)
System Operation 030.
Do not leave the transmitter or
device that disarms or deactivates
the theft-deterrent system in the
vehicle.

GMC Terrain/Terrain Denali Owner Manual (GMNA-Localizing-U.S./Canada/
Mexico-12146071) - 2019 - crc - 7/27/18
Instruments and Controls 141
Security Light
The security light should come on
briefly as the engine is started. If it
does not come on, have the vehicle
serviced by your dealer. If the
system is working normally, the
indicator light turns off.
If the light stays on and the engine
does not start, there could be a
problem with the theft-deterrent
system. SeeImmobilizer Operation
0 50.
High-Beam On Light
This light comes on when the
high-beam headlamps are in use.
See Headlamp High/Low-Beam
Changer 0163.
IntelliBeam Light
This light comes on when the
IntelliBeam system, if equipped, is
enabled. See Exterior Lamp
Controls 0161.
Front Fog Lamp Light
If equipped, the fog lamp light
comes on when the fog lamps are
in use. The light goes out when the fog
lamps are turned off. See
Fog
Lamps 0165 for more information.
Lamps On Reminder
For vehicles with the lamps on
reminder light, it comes on when the
lights are in use.
Cruise Control Light
The cruise control light is white
when the cruise control is on and
ready, and turns green when the
cruise control is set and active.

GMC Terrain/Terrain Denali Owner Manual (GMNA-Localizing-U.S./Canada/-
Mexico-12146071) - 2019 - crc - 7/27/18
426 Index
Headlamps (cont'd)Automatic . . . . . . . . . . . . . . . . . . . . . 164
Bulb Replacement . . . . . . . . . . . . 314
Daytime Running
Lamps (DRL) . . . . . . . . . . . . . . . . 163
Flash-to-Pass . . . . . . . . . . . . . . . . . 163
High Intensity Discharge (HID) Lighting . . . . . . . . . . . . . . . 315
High-Beam On Light . . . . . . . . . . 141
High/Low Beam Changer . . . . . 163
Lamps On Reminder . . . . . . . . . 141
Heated Rear Seats . . . . . . . . . . . . . . . . . . . . . 70
Steering Wheel . . . . . . . . . . . . . . . .114
Heated and Ventilated Front Seats . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Heated Mirrors . . . . . . . . . . . . . . . . . . . 51
Heater Engine . . . . . . . . . . . . . . . . . . . . . . . . 200
Heating . . . . . . . . . . . . . . . . . . . . 170, 172
High-Beam On Light . . . . . . . . . . . . 141
Hill and Mountain Roads . . . . . . . . 188
Hill Descent Control (HDC) . . . . . 225
Hill Descent Control Light . . . . . . . 137
Hill Start Assist (HSA) . . . . . . . . . . 221
Hood . . . . . . . . . . . . . . . . . . . . . . . . . . . 287
Horn . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114 How to Wear Seat Belts
Properly . . . . . . . . . . . . . . . . . . . . . . . . 72
HVAC . . . . . . . . . . . . . . . . . . . . . . 170, 172
I
Ignition Positions . . . . . . . . . . . . . . . 195
Immobilizer . . . . . . . . . . . . . . . . . . . . . . 49
Indicator Pedestrian Ahead . . . . . . . . . . . . 137
Vehicle Ahead . . . . . . . . . . . . . . . . 137
Infants and Young Children, Restraints . . . . . . . . . . . . . . . . . . . . . . 93
Information Publication Ordering . . . . . . . . . . 404
Infotainment . . . . . . . . . . . . . . . . . . . . 169
Infotainment System . . . . . . . . . . . . 408
Instrument Cluster . . . . . . . . . 122, 125
Interior Rearview Mirrors . . . . . . . . . 52
Introduction . . . . . . . . . . . . . . . . . . . . . . . 2
J
Jump Starting - North America . . . . . . . . . . . . . . . . . . . . . . . 360
K
Keyless EntryRemote (RKE) System . . . . . . . . . 30
Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
L
Labeling, Tire Sidewall . . . . . . . . . . 327
Lamps
Courtesy . . . . . . . . . . . . . . . . . . . . . . 166
Daytime Running (DRL) . . . . . . 163
Dome . . . . . . . . . . . . . . . . . . . . . . . . . 166
Exterior Controls . . . . . . . . . . . . . . 161
Exterior Lighting BatterySaver . . . . . . . . . . . . . . . . . . . . . . . 168
Front Turn Signal . . . . . . . . . . . . . 315
License Plate . . . . . . . . . . . . . . . . . 316
Malfunction Indicator
(Check Engine) . . . . . . . . . . . . . 133
On Reminder . . . . . . . . . . . . . . . . . 141
Reading . . . . . . . . . . . . . . . . . . . . . . 167
Taillamps . . . . . . . . . . . . . . . . . . . . . 316
Lane Change Alert (LCA) . . . . . . . 256
Lane Departure Warning (LDW) . . . . . . . . . . . . . . . . 258
Lane Keep Assist (LKA) . . . . . . . . 258
Lane Keep Assist Light . . . . . . . . . 137
Lap-Shoulder Belt . . . . . . . . . . . . . . . 74
LATCH System Replacing Parts after a
Crash . . . . . . . . . . . . . . . . . . . . . . . 103
LATCH, Lower Anchors and Tethers for Children . . . . . . . . . . . . 98
LED Lighting . . . . . . . . . . . . . . . . . . . . 315

GMC Terrain/Terrain Denali Owner Manual (GMNA-Localizing-U.S./Canada/-
Mexico-12146071) - 2019 - crc - 7/27/18
430 Index
Service (cont'd)Maintenance Records . . . . . . . . 390
Maintenance, General
Information . . . . . . . . . . . . . . . . . . 376
Parts Identification Label . . . . . 391
Scheduling Appointments . . . . . 401
Service Electric Parking Brake Light . . . . . . . . . . . . . . . . . . . . 136
Services
Special Application . . . . . . . . . . . 383
Servicing the Airbag . . . . . . . . . . . . . 89
Shifting Into Park . . . . . . . . . . . . . . . . . . . . . . 202
Out of Park . . . . . . . . . . . . . . . . . . . 203
Side Blind Zone Alert (SBZA) . . . 255
Signals, Turn and Lane-Change . . . . . . . . . . . . . . . . . 165
Spare Tire
Compact . . . . . . . . . . . . . . . . . . . . . . 359
Special Application Services . . . . 383
Specifications and Capacities . . . . . . . . . . . . . . . . . . . . . 392
Speedometer . . . . . . . . . . . . . . . . . . . 128
StabiliTrak
OFF Light . . . . . . . . . . . . . . . . . . . . . 138
Start Assist, Hill . . . . . . . . . . . . . . . . . 221
Start Vehicle, Remote . . . . . . . . . . . 36
Starter Switch Check . . . . . . . . . . . 310 Starting the Engine . . . . . . . . . . . . . 197
Steering . . . . . . . . . . . . . . . . . . . . . . . . 182
Heated Wheel . . . . . . . . . . . . . . . . .114
Wheel Adjustment . . . . . . . . . . . . .114
Wheel Controls . . . . . . . . . . . . . . . .114
Stop/Start System . . . . . . . . . . . . . . 199
Storage Areas Cargo Cover . . . . . . . . . . . . . . . . . . .110
Center Console . . . . . . . . . . . . . . . 109
Convenience Net . . . . . . . . . . . . . . 111
Glove Box . . . . . . . . . . . . . . . . . . . . 109
Roof Rack System . . . . . . . . . . . . . 111
Storage Compartments . . . . . . . . . 109
Storing the Tire Sealant and Compressor Kit . . . . . . . . . . . . . . . 353
Struts
Gas . . . . . . . . . . . . . . . . . . . . . . . . . . . 313
Stuck Vehicle . . . . . . . . . . . . . . . . . . . 190
Summer Tires . . . . . . . . . . . . . . . . . . 327
Sun Visors . . . . . . . . . . . . . . . . . . . . . . . 54
Sunroof . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . 3
System Forward CollisionAlert (FCA) . . . . . . . . . . . . . . . . . . 250
Infotainment . . . . . . . . . . . . . 169, 408
Roof Rack . . . . . . . . . . . . . . . . . . . . . 111 Systems
Driver Assistance . . . . . . . . . . . . . 242
T
Tachometer . . . . . . . . . . . . . . . . . . . . . 128
Taillamps . . . . . . . . . . . . . . . . . . . . . . . 316
Text Telephone (TTY) Users . . . . 398
Theft-Deterrent Systems . . . . . . . . . 50
Immobilizer . . . . . . . . . . . . . . . . . . . . . 49
Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117
Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . 325 All-Season . . . . . . . . . . . . . . . . . . . . 326
Buying New Tires . . . . . . . . . . . . . 341
Chains . . . . . . . . . . . . . . . . . . . . . . . . 345
Changing . . . . . . . . . . . . . . . . . . . . . 354
Compact Spare . . . . . . . . . . . . . . . 359
Designations . . . . . . . . . . . . . . . . . 329
Different Size . . . . . . . . . . . . . . . . . 342
If a Tire Goes Flat . . . . . . . . . . . . 345
Inspection . . . . . . . . . . . . . . . . . . . . 339
Pressure . . . . . . . . . . . . . . . . . . . . . . 332
Pressure Light . . . . . . . . . . . . . . . . 139
Pressure Monitor Operation . . 335
Pressure Monitor System . . . . . 334
Rotation . . . . . . . . . . . . . . . . . . . . . . 339
Sealant and
Compressor Kit . . . . . . . . . . . . . 347
