turn signal GMC YUKON 2004 Owner's Guide

A. Low-Beam Headlamp
B. High-Beam Headlamp
2. Pull the headlamp assembly out.
3. Unplug the electrical connector.
4. Turn the old bulb counterclockwise and remove it
from the headlamp assembly.
5. Put the new bulb into the assembly and turn it
clockwise until it is tight. Use care not to touch
the bulb with your ngers or hands.
6. Plug in the electrical connector.
7. Put the headlamp assembly back into the vehicle.
Install and tighten the two pins.
Front Turn Signal, Sidemarker and
Daytime Running Lamps
A. Sidemarker Lamp
B. Retainer Clip
C. Front Turn Signal
LampD. Daytime Running
Lamp
1. Remove the headlamp assembly as mentioned
previously.
2. Press the retainer clip, located behind the turn
signal housing, towards the outside of the vehicle.
3. Pull the turn signal housing out from the vehicle.
5-56

4. Press the locking release lever, turn the bulb socket
counterclockwise and remove the socket from the
turn signal housing.
5. Remove the old bulb from the bulb socket.
6. Put the new bulb into the bulb socket. Use care not
to touch the bulb with your ngers or hands.
7. Put the bulb socket into the turn signal housing and
turn it clockwise until it locks.
8. Reinstall the turn signal housing onto the vehicle,
placing the hook and posts on the inner side into
the alignment holes, and the outer side into
the retainer bracket. Push until you hear a click.
9. Reinstall the headlamp assembly.Side Identication Marker Lamps
1. To expose the service slot, locate the lamp gasket
near the rear wheel, and pull back the edge.
2. Using a at tool, push into the slot to release the
lamp housing.
3. Pull the housing out to expose the wiring harness
and connector.
4. Unplug the lamp assembly harness from the
housing.
5. Unplug the lamp.
6. Put in a new lamp and snap it into the housing.
7. Reinstall the lamp housing.
5-57

Taillamps
A. Turn Signal Lamp
B. Back-up Lamp
C. Stoplamp1. Use a tool to remove
the two screws from
the lamp assembly.
2. Remove the lamp assembly.
3. Press the release tab and turn the bulb socket
counterclockwise to remove it from the taillamp
housing.
5-60

Fuses Usage
4WDFour-Wheel Drive System,
Auxiliary Battery
HTR A/C Climate Control System
LOCKPower Door Lock Relay
(Lock Function)
HVAC 1Inside Rearview Mirror,
Climate Control System
L DOORDriver’s Door Harness
Connection
CRUISE Cruise Control
UNLOCKPower Door Lock Relay
(Unlock Function)
RR FOG LP Rear Fog Lamp (Export Only)
BRAKE Anti-Lock Brake System
DRIVER UNLOCKPower Door Lock Relay
(Driver’s Door Unlock
Function)
IGN 0 PCM, TCM
TBC IGN 0 Truck Body Controller
VEH CHMSLVehicle and Trailer High
Mounted Stoplamp
LT TRLR ST/TRN Left Turn Signal/Stop TrailerFuses Usage
LT TRNLeft Turn Signals and
Sidemarkers
VEH STOPVehicle Stoplamps, Brake
Module, Electronic Throttle
Control Module
RT TRLR ST/TRN Right Turn Signal/Stop Trailer
RT TRNRight Turn Signals and
Sidemarkers
BODY Harness Connector
DDM Driver Door Module
AUX PWR 2Rear Cargo Area Power
Outlets
LOCKS Power Door Lock System
ECCRear Electronic Climate
Control, Liftgate
TBC 2C Truck Body Controller
FLASH Flasher Module
CB LT DOORSLeft Power Window Circuit
Breaker
TBC 2B Truck Body Controller
TBC 2A Truck Body Controller
5-115

Fuses Usage
4WSVent Solenoid
Canister/Quadrasteer Module
Power
RR HVAC Rear Climate Control
AUX PWRAuxiliary Power
Outlet — Console
IGN 1 Ignition Relay
PCM 1 Powertrain Control Module
ETC/ECMElectronic Throttle Control,
Electronic Brake Controller
IGN EInstrument Panel Cluster, Air
Conditioning Relay, Turn
Signal/Hazard Switch, Starter
Relay
RTD Ride Control
TRL B/U Backup Lamps Trailer Wiring
PCM BPowertrain Control Module,
Fuel Pump
F/PMP Fuel Pump (Relay)
B/U LPBack-up Lamps, Automatic
Transmission Shift Lock
Control SystemFuses Usage
RR DEFOG Rear Window Defogger
HDLP-HI Headlamp High Beam Relay
PRIME Not Used
SIRSupplemental Inatable
Restraint System
FRT PARKFront Parking Lamps,
Sidemarker Lamps
DRLDaytime Running Lamps
(Relay)
SEO IGN Rear Defog Relay
TBC IGN1 Truck Body Controller Ignition
HI HDLP-LT High Beam Headlamp-Left
LH HID Not Used
DRL Daytime Running Lamps
IPC/DICInstrument Panel
Cluster/Driver Information
Center
HVAC/ECAS Climate Control Controller
CIG LTR Cigarette Lighter
HI HDLP-RT High Beam Headlamp-Right
5-120

Audio System(s) (cont.)
Radio with CD............................................3-81
Radio with Six-Disc CD..............................3-108
Rear Seat Audio (RSA)...............................3-134
Setting the Time for Radios with Radio Data
Systems (RDS)........................................3-78
Setting the Time for Radios without Radio
Data Systems (RDS)................................3-77
Theft-Deterrent Feature...............................3-135
Understanding Radio Reception...................3-137
XM™ Satellite Radio Antenna System...........3-139
Automatic Dimming Mirror Operation..........2-45, 2-47
Automatic Headlamp System............................3-16
Automatic Level Control...................................4-61
Automatic Transfer Case..................................2-29
Automatic Transmission
Fluid..........................................................5-23
Operation...................................................2-24
Autoride™.....................................................4-62
Auxiliary Roof Mounted Lamp Switch.................3-18
B
Backing Up....................................................4-72
Battery..........................................................5-44
BATTERY NOT CHARGING.............................3-70
Battery Replacement......................................... 2-6Battery Run-Down Protection............................3-20
Battery Warning Light......................................3-45
Before Leaving on a Long Trip.........................4-43
Before You Drive...........................................3-122
Before You Go Off-Roading..............................4-24
Bench Seat....................................................1-16
Bench Seat Split (50/50)..................................1-11
Bench Seat, Split (60/40)................................... 1-8
Brake
Parking......................................................2-37
System Warning Light..................................3-46
Brake Adjustment............................................5-44
Brake Fluid....................................................5-41
Brake Pedal, Throttle.......................................2-23
Brake Pedal Travel.........................................5-44
Brake Wear...................................................5-43
Brakes..........................................................5-41
Braking........................................................... 4-6
Braking in Emergencies..................................... 4-8
Break-In, New Vehicle.....................................2-20
Bucket Seats, Rear.........................................1-21
BUCKLE PASSENGER....................................3-70
BUCKLE SEATBELT.......................................3-70
Bulb Replacement...........................................5-55
Front Turn Signal, Sidemarker and Daytime
Running Lamps........................................5-56
Halogen Bulbs............................................5-55
Headlamps.................................................5-55
2

Headlamps....................................................5-55
Bulb Replacement.......................................5-55
Front Turn Signal, Sidemarker and Daytime
Running Lamps........................................5-56
Halogen Bulbs............................................5-55
Roof Marker Lamps.....................................5-58
Side Identication Marker Lamps...................5-57
Headphones.................................................3-129
Heated Seats................................................... 1-5
Heating.........................................................3-32
Highway Hypnosis...........................................4-44
Hill and Mountain Roads..................................4-44
Hitches..........................................................4-69
HomeLink
®Transmitter....................................2-55
HomeLink®Transmitter, Programming................2-56
Hood
Checking Things Under................................5-10
Release.....................................................5-11
Horn............................................................... 3-7
How to Add Coolant to the Coolant
Surge Tank.................................................5-34
How to Add Fluid............................................5-25
How to Check........................................5-23, 5-72
How to Check Lubricant...................................5-52
How to Check Power Steering Fluid..................5-39
How to Inspect...............................................5-21
How to Use This Manual...................................... ii
How to Wear Safety Belts Properly...................1-28
Hydroplaning..................................................4-40
I
If No Steam Is Coming From Your Engine..........5-31
If Steam Is Coming From Your Engine...............5-30
If the Light is Flashing.....................................3-53
If the Light Is On Steady.................................3-53
If You Are Caught in a Blizzard.........................4-48
If You Are Stuck in Sand, Mud, Ice or Snow.......4-50
If You Do Decide To Pull A Trailer.....................4-63
Ignition Positions.............................................2-21
Infants and Young Children, Restraints...............1-48
Ination - Tire Pressure...................................5-72
Instrument Panel
Cluster.......................................................3-41
Overview..................................................... 3-4
Instrument Panel Brightness.............................3-19
Instrument Panel Fuse Block..........................5-114
Interior Lamps................................................3-19
J
Jump Starting.................................................5-45
K
KEYFOB X BATTERY LOW.............................3-72
Keyless Entry System....................................... 2-4
Keys............................................................... 2-3
8

Tire Size.......................................................5-67
Tire Terminology and Denitions........................5-69
Tires.............................................................5-63
Buying New Tires........................................5-78
Chains.......................................................5-82
Changing a Flat Tire....................................5-84
If a Tire Goes Flat.......................................5-83
Ination - Tire Pressure................................5-72
Inspection and Rotation................................5-76
Pressure Monitor System..............................5-73
Spare Tire................................................5-102
Uniform Tire Quality Grading.........................5-79
Wheel Alignment and Tire Balance.................5-80
Wheel Replacement.....................................5-81
When It Is Time for New Tires......................5-77
Entering or Exiting the Third Row Seats.............. 1-8
To Use the Engine Coolant Heater....................2-24
Top Strap......................................................1-55
Top Strap Anchor Location...............................1-57
Torque Lock...................................................2-40
Total Weight on Your Vehicle’s Tires..................4-69
Tow/Haul Mode...............................................2-28
Tow/Haul Mode Light.......................................3-56
Towing
Recreational Vehicle.....................................4-53
Towing a Trailer..........................................4-63
Your Vehicle...............................................4-53Traction
Assist System (TAS)...................................... 4-9
Off Light.....................................................3-48
Stabilitrak
®System......................................4-11
TRACTION ACTIVE........................................3-76
Traction Control Operation................................4-12
TRACTION SYS LIMITED................................3-77
Trailer
Recommendations.......................................4-62
Trailer Brakes.................................................4-70
Trailer Wiring Harness.....................................4-75
Transfer Case........................................5-51, 5-53
Transmission
Fluid, Automatic...........................................5-23
Temperature Gage.......................................3-49
TRANSMISSION HOT.....................................3-76
Transmission Operation, Automatic....................2-24
Transmission, Transaxle, Transfer Case Unit
Repair Manual............................................7-12
Transportation Options...................................... 7-8
Traveling to Remote Areas...............................4-26
Trip Information Button....................................3-59
Trip Odometer................................................3-42
Turn and Lane Change Signals.......................... 3-8
TURN SIGNAL ON.........................................3-77
Turn Signal/Multifunction Lever........................... 3-8
Turn Signals When Towing a Trailer..................4-72
16
