GMC YUKON 2010 User Guide

Remote Vehicle Start
With this feature the engine can be started from outside
of the vehicle.
Starting the Vehicle
1. Aim the RKE transmitter at the vehicle.
2. Press
Q.
3. Immediately after completing Step 2, press and hold
/until the turn signal lamps flash.
When the vehicle starts, the parking lamps will turn
on and remain on as long as the engine is running.
The doors will be locked and the climate control system
may come on.
The engine will continue to run for 10 minutes. Repeat
the steps for a 10-minute time extension. Remote start
can be extended only once.
Canceling a Remote Start
To cancel a remote start:
.Aim the RKE transmitter at the vehicle and press
and hold
/until the parking lamps turn off.
.Turn on the hazard warning flashers.
.Turn the ignition on and then back off.
See Remote Vehicle Start on page 3‑8.
Door Locks
There are several ways to lock and unlock the vehicle.
From outside, use the Remote Keyless Entry (RKE)
transmitter or the key in the driver door. From inside,
use the power door locks or the manual door locks.
To lock or unlock the door with the manual locks, push
down or pull up on the manual lock knob.
Power Door Locks
If available, these switches are located on the front
doors.
K:Press to unlock the doors.
Q:Remove the key from the ignition and press to lock
the doors.
For more information, see:
.Programmable Automatic Door Lockson
page 3‑11.
.Rear Door Security Locks on page 3‑12.
1-5

Liftgate
Power Liftgate
Use the Remote Keyless Entry (RKE) transmitter or the
power door lock switches to unlock the liftgate.There are several ways to open and close the power
liftgate:
.Press and hold&on the RKE transmitter until
the liftgate starts moving.
.Press&on the overhead console inside the
vehicle.
.Press the touchpad switch (B) on the outside
liftgate handle to open.
.Press thelbutton next to the liftgate latch to
close.
To disable the power liftgate function, press OFF on the
overhead console.
Liftglass
There are two ways to unlatch the liftglass:
.Press the button on the underside of the underside
of the license plate applique (A).
.Pressmon the RKE transmitter.
1-6

Windows
The power window
switches are located
on the driver door.
In addition, each
passenger door has a
switch for its own window.
Press the switch to lower the window. Pull the switch up
to raise it.
For more information, see:
.Windows on page 3‑19.
.Power Windows on page 3‑20.
Seat Adjustment
Front Seats
Manual Seats
If the vehicle has a manual seat, it can be moved
forward or rearward.
1. Lift the bar to unlock the seat.
2. Slide the seat to the desired position and
release the bar.
Try to move the seat with your body to be sure the seat
is locked in place.
See Manual Seats on page 2‑4.
1-7

Power Seats
If equipped, the power seat controls are located on the
outboard side of the front seats.
Move the seat forward or rearward by sliding the control
forward or rearward.
Raise or lower the front or rear part of the cushion by
moving the front or rear part of the control up or down.
Raise or lower the entire seat by moving the entire
control up or down.
SeePower Seats on page 2‑5.
Manual Lumbar
If equipped, this control is
located on the outboard
side of the seat.
Increase or decrease lumbar support by turning the
knob forward or rearward.
1-8

Power Lumbar
If equipped, this control is located on the outboard side
of the seat.On vehicles with two-way lumbar, press and hold
the top of the control to increase lumbar support.
To decrease, press and hold the bottom of the control.
On vehicles with four-way lumbar, press and hold
the front of the control to increase lumbar support.
To decrease, press and hold the rear of the control.
To raise the height of the support, press and hold the
top of the control. To lower, press and hold the bottom
of the control.
See
Power Lumbar on page 2‑7.
1-9

Manual Reclining Seatbacks
If equipped, this control is located on the outboard side
of the seat.
To recline the seatback:1. Lift the recline lever.
2. Move the seatback to the desired position, then release the lever to lock the seatback in place.
3. Push and pull on the seatback to make sure it is locked.
See Reclining Seatbacks on page 2‑12.
Power Reclining Seatbacks
If available, this control is located on the outboard side
of the seat.
To recline the seatback, tilt the top of the control
rearward.
To bring the seatback forward, tilt the top of the control
forward.
SeeReclining Seatbacks on page 2‑12.
1-10

Memory Features
This vehicle may have the memory package.
The controls for this
feature are located on
the driver door, and are
used to program and
recall memory settings
for the driver seat,
outside mirrors, and the
adjustable throttle and
brake pedal feature.
For more information, see Memory Seat, Mirrors, and
Pedals on page 2‑10.
Second Row Seats
If the vehicle has a 60/40 split bench or buckets seats,
the seat(s) can be folded for additional cargo space or
folded and tumbled for easy entry and exit to the third
row seats, if the vehicle has them. If the vehicle has
bucket seats, the seatbacks can be also be reclined.
These seats will have either the manual fold and tumble
feature or the automatic seat release fold and tumble
feature.
For more information, see 60/40 Split Bench Seat
on
page 2‑15or Bucket Seats on page 2‑21.
Third Row Seats
If the vehicle has a third row seat, the seatback(s) can
be folded and the entire seat can be tumbled,
or removed from the vehicle.
For detailed instructions, see Third Row Seat
on
page 2‑27.
1-11

Heated Seats
Front Seats
On vehicles with heated front seats, or heated and
cooled front seats, the controls are located on the driver
and passenger doors.
{(If Equipped):Press to cool the entire seat.
+:Press to heat the seatback only.
z:Press to heat the seat and seatback.
Continue to press the desired button to cycle through
the temperature settings: high (three indicator lights),
medium (two indicator lights), low (one indicator light),
and off (no lights).
See Heated Seats
on page 2‑8andHeated and
Cooled Seats on page 2‑9.
Rear Seats
The heated rear seat controls are located on the Rear
Sear Audio (RSA) panel.
M: Press to heat the seat cushion and to cycle through
the three temperature settings.
See Heated Seats on page 2‑15.
Head Restraint Adjustment
Do not drive until the head restraints for all occupants
are installed and adjusted properly.
For more information see Head Restraints
on
page 2‑3.
1-12

Safety Belt
Refer to the following sections for important information
on how to use safety belts properly.
.Safety Belts: They Are for Everyone on page 2‑32.
.How to Wear Safety Belts Properly on page 2‑37.
.Lap-Shoulder Belt on page 2‑46.
.Lower Anchors and Tethers for Children (LATCH)on page 2‑67.
Sensing System for Passenger
Airbag
The passenger sensing system, if equipped, will turn off
the right front passenger frontal airbag under certain
conditions. The driver airbags, seat‐mounted side
impact airbags, if equipped, and roof‐rail airbags are
not affected by this.
If the vehicle has one of the indicators pictured in the
following illustrations, then the vehicle has a passenger
sensing system for the right front passenger position.
The passenger airbag status indicator, if equipped, will
be visible on the overhead console when the vehicle is
started.
United StatesCanada
See Passenger Sensing System
on page 2‑94for
important information.
1-13

Mirror Adjustment
Exterior Mirrors
Vehicles with manual outside mirrors can be adjusted
so that the side of the vehicle and the area behind
are seen.
If the vehicle has towing mirrors, they can be adjusted
for a clearer view of the objects behind you. Manually
pull out the mirror head to extend it for better visibility
when towing a trailer. SeeOutside Towing Mirrors
on
page 3‑55.
Vehicles with outside
power mirrors and
foldaway mirrors have
controls located on the
driver door.
1. Press (A) or (B) to select the driver or passenger side mirror.
2. Press one of the four arrows located on the control pad to adjust the mirror.
3. Press either (A) or (B) again to deselect the mirror.
Power Foldaway Mirrors
To fold the mirrors: 1. Press (C) to fold the mirrors out to the driving position.
2. Press (D) to fold the mirrors in to the folded position.
1-14
